SC&T IP01 User manual

Smart Cabling & Transmission Corp.
V1.0
IP/ PoE Extender
User Manual
Model : IP01
Passive IP over Coaxial Extender

1
User Manual
IP01
Introduction
IP01 is an Ethernet extender that can use coaxial cable to send IP signal without replacing existing cable,
which can smoothly upgrade your CCTV system at lowest cost..
Features
Bandwidth up to 100Mbps.
Signal extension up to 300M over RG6U coaxial cable.
No power required for TX & RX unit.
Installation view
Transmission Speed and Distance
Transmission distance, speed, depend on the quality of the coax cable used
Please refer to the following guidelines
Coax Cable
Link Speed
Distance ( Max)
RG59
Auto 100Mbps
100M
RG59
10Mbps
200M
RG6U
Auto 100Mbps
150M
RG6U
10Mbps
300M
Cable
Link cable use high quality 75ΩRG59, RG6U coaxial cable.
Caution
1.RG59 coax over 100M and RG6U over 150M, the network switch link speed need to manually setting at
10Mbps.
2. For 10Mbps switch that you could use below model no: IP01H

2
User Manual
IP01
IP01H：Ethernet Switch with 4Port 10M + 1Port 10/100M
4 Port Ethernet Switch with 4 ports BNC and 1 port RJ45.
RJ45 terminal support 10/100Mbps auto detect function
BNC terminal support 10Mbps, must work with IP01.
LED indication: Link/Active, Power.
Complies with standard IEEE802.3 and IEEE802.3u.
Auto MDI/MDI-X auto cross at RJ45 terminal.
Specification
ITEM NO.
IP01
Support
Transmission Distance
300M
Network Bandwidth
10/ 100Mbps
Ports & Interfaces
Input
1 x RJ45
Output
1 x BNC
Ambient Temperature
Operation
0 to 55℃
Storage
-20 to 85℃
Humidity
Up to 95%
Physical Characteristics
Dimensions
64 x 25 x 22mm
Weight
25g
