Scarab M6 User manual

E&OE
SCARAB M6 - Abbreviated Operating Instructions
TOENTERSWEEPMODE
VEHICLEENGINERUNNING.AIRTANKSFULL.
1. PresstheStartSwitchonthemainpaneltostarttheauxiliaryengineandentersweepmode.
2. Preselecttherequiredsweepingcombination.Aseachitemisselectedthecorresponding
symbolontheLCDmonitorwillchangeasillustratedbelow.Startthesuctionfan.
3. Engageasuitablegearratioandreleasetheclutchtocommencesweeping.
WHENREVERSING
1. Whenreversegearisselected,allsweepinggearwillautomaticallystopandretract.
2. Whenreverseisdeselected,allactivesweepingequipmentwillredeploy.
LEAVINGSWEEPMODE
1. Movethemulti‐functionswitchforwardtotheOFFpositiontostopandretractallactive
sweepingequipment.
2. Switchoffthesuctionfan.
REARDOOR&HOPPERCONTROLS
Thehoppersafetypropmustalwaysbedeployedwhenworkingbeneatharaisedhopper.
Reardoorsafetypropmustbedeployedandwhenworkingbeneathopenreardoor.
DISCHARGINGTHEPAYLOAD(TIPPING)
1. Simultaneouslypressthesafetyinterlockanddooropenswitch,untilthedoorisfullyopen.
2. Simultaneouslypressthesafetyinterlockandhopperraiseswitch,untilthehopperisfully
raised.
Beforeloweringthehopper,ensurethattheareabelowitisclear.Stowthehopperprop.
3. Simultaneouslypressthesafetyinterlockandhopperdownswitch,untilthehopperisfully
down.
Beforeclosingthereardoor,ensureallpersonnelareclearoftheimmediateareaandthat
thedoorsealandseal‐matingfaceareclean.Stowthereardoorprop.
4. Simultaneouslypressthesafetyinterlockanddoorcloseswitch,untilthedoorisfullyclosed.
Beforestoppingtheauxiliaryengine,allowittoidleforatleast2minutestoallowtheturbo‐
chargertocooldown.
Thisdocumentisdesignedasaquickreferenceguide,toallowtheoperatortodrivethe
vehicleinSweepModeandoperatethebasiccontrols.Itdoesnotconstitutethefulloperating
instructions.
!
EQUIPMENTNOTSELECTED
EQUIPMENTPRE‐SELECTED
EQUIPMENTOPERATING
WATERPRE‐SELECTED
EQUIPMENT+WATERPRE‐SELECTED
MAINEQUIPMENTCOLOURCODES
WIDESWEEPWATERACTIVE
NOZZLETILTINDICTOR
WORKLIGHTON
BRUSHACTIVE
WATERACTIVE
PRESSTODISABLE
HOPPERRAISE/LOWERANDREAR
DOOROPEN/CLOSEWARNINGBUZZER
MAINPANEL
HIGH‐PRESSURE
WATERPUMP*
MULTI‐FUNCTION
!
NOTAPPLICABLE
SWITCH
AUXILIARYPANEL
AUXILIARYENGINE
OPTIONS*
OPTIONS*
SIDEBRUSH
LEFTHAND
SIDEBRUSH
LEFTHAND
SUCTIONNOZZLE
WIDESWEEPBRUSH
RIGHTHAND
SUCTIONNOZZLE
RIGHTHAND
SIDEBRUSH
LEFTHAND
WORKLIGHT
LEFTHAND
WATER
WIDESWEEP
WATER
RIGHTHAND
WATER
RIGHTHAND
WORKLIGHT
REDUCE
ENGINESPEED INCREASE
ENGINESPEED
OPTIONS* OPTIONS*
NOZZLETILT
SUCTIONFAN
FAVOURITESETTING
SUCTIONFAN 
ON
HOPPERNOT
DOWN
H‐PWATER 
PUMP
WATER TAN K
LOW
H‐PPUMP
NOWATER
HYDRAULICOIL
LOW
HYDRAULICOIL
TEMP
SERVICE
REMINDER
ACTIVEFAULT
PRESENT
MAJORON‐SCREENINFORMATION
ANDWARNINGSYMBOLS
START/STOP+SWEEPMODE
DOWNPRESSURE*
WIDESWEEP
DOWNPRESSURE*
RAISEHOPPER
LOWERHOPPER
OPENDOOR
CLOSEDOOR
NOTAPPLICABLE
SAFETYINTERLOCK
ONRIGHTHANDDRIVEVEHICLES
Movetheswitchtotherighttoswingthe
sidebrush(es)OUT.
Movetheswitchtothelefttoswingthe
sidebrush(es)IN.
Oppositeforlefthanddrive.
NOZZLE‐TILTFUNCTION
Movetheswitchbacktomomentarilytilt
thesuctionnozzleortocloseitfrom
LOCKEDOPEN. PressandholddowntheSafetyInterlockandthe
appropriatecontrolswitch.
ForsafetyreasonsonlyoperatetheRemote
Controlcontrolsfromoutsidethevehicle,
fromavantagepointthataffordsagoodview
ofthesweeperanditssurroundings.
Beforeclosingthereardoor,ensureadequate
clearanceandsealcleanliness.
!
C
REMOTECONTROL
*OPTIONS
MULTI‐FUNCTIONLEVER
OFF
SIDE
BRUSH SIDE BRUSH
ON
NOZZLE
TILT
NOTAPPLICABLE
PLEASEREFERTOREVERSEFORHEALTH&SAFETYADVICE

E&OE
HEALTHANDSAFETY
•Onlytrainedoperativesshouldbeallowedtodriveorworkonthismachine.
•Neverworkunderaraisedhopperorreardoorwithouttheappropriatesafetypropinposition.
•Donotdrivethevehiclewiththehopperraised.TheredwarningsymbolontheLCDmonitorremainsilluminateduntilthehopperis
fullydown.
•Beforeworkingonthevehicleensurethatitisonfirm,levelground,applythehandbrake,stoptheengineandremovetheignitionkey.
•Beforeraisingthehopperoropeningthereardoor,ensurethatthereissufficientclearanceanditissafetodoso.
•Beforestartingtheauxiliaryengine,ensurethatallcontrolsareswitchedoffandthevehicle’sgearboxisinneutral.
•Beforedrivingthevehicle,ensurethatallvehiclecheckshavebeencarriedoutandthatallequipmentisstowedandthatthebrush(es)
areraised.
•Donotoverloadthehopper.
•Highpressurewatercanbedangerous,alwayswearsuitableeyeprotectionwhenoperatingthehighpressurewaterpumpnadwhen
usingthelance.Donotdirectthewaterjetatotherpersons.Bewareofelectricalinstallationsonpublicbuildingsandlamppostsetc.
andalwaysexiceseextremecautioninpublicplaces.
•Thesuctionfanisanextremelyheavyrotatingmass.Vibrationscomingfromthesuctionfanmustbeinvestigated,thecause
determinedandrectifiedimmediately.
•Whenworkingonthesuctionfan.Neverattempttosloworstopthefanbyusingthehandsorbyinsertinganyitemintothefan
chamber,evenatlowspeed.Failuretocomplycanresultinseriousinjury.
•Whenoperatingthemachineinanymode,alwaysbeawareofobjectsandpeopleintheimmediatevicinity,especiallytherearofthe
machinewhenreversing.
•Whateverthesituation,rememberthattherulesoftrafficandroadsafetymustbeobserved.
•Whileoperatingthismachinethesafetyandwellbeingofotherpeoplearethesoleresponsibilityoftheoperator.
CAUTIONS
Ifthesuctionfanvibrates,itshouldbecleanedimmediately(RefertotheOperatingManual).Prolongedvibrationwillresultindamageto
thefan,bearingsand,inextremecases,thehopper.
Intheeventofahydraulicleak,stoptheauxiliaryengineandinvestigate.
Thehighandlowpressurewaterpumpsmustneverbepermittedtorundryotherwisethesealsinthepumpwillbedamaged.
Donotdirectthehighpressurejetatpaintworkorelectricalconnectionsonthevehicle.
ROUTINEDAILYMAINTENANCE
1. Checkthevehicle’sgeneralcondition(Including:‐Tyres,lightsandallfluidlevels)inaccordancewiththechassismanufacturers’
recommendations.
2. Checkhydraulicoillevel.(Note:‐Iftheoillevelisnotmaintained,thesweepingpanelwillautomaticallyshutdownuntiltheoilleveliscorrect.)
3. Checktheconditionofthebrushesandremoveanyitemssuchasstringthatmaybeentangled.
4. Checkgroundclearanceofsuctionrubberflaps,20mmfront/30mmrearandsidearesuitableclearances,suctionpowercanbelostifclearance
areincorrectbutitispossibletoslightlyvarythesesettingstobettersuitspecificsweepingconditionsaccordingtotheoperator’sexperience.
5. Checkwatersprayjetsforblockages.
6. Cleantheoilcoolerandcheckthatcoolingfanfunctions(Note:‐Iffitted,redwarninglightandbuzzerwilloperatewhenthemaxtemperature
isreached).
7. Washvehicle,ensuringthatthesuctionfanandhopperfilterscreenarecleaned.
8. Lubricatebrushlinks,pivotpointsandwidesweepbearings.
9. Removeandcleanwaterstrainerelements.
10. Alwaysleavethevehiclewithreardoorslightlyopentoallowwatertodrainout.
11. Infrostyweather,drainpumpsandtanks,removewaterstrainerelements,turnonallwatersprays.
Hydraulicoil:HPL32oranequivalent.
Coolant:EthyleneGlycol(Eskimolonglife).
Engineoil:SAE15W‐40
HOPPERSAFETYPROP
REARDOORSAFETYPROP
Wheninsertingthe
doorprop,ensureit
iscorrectlypositioned
inthelocatingslot.
Z039986Issue6.0.0
Ensurethepropiscompletely
unlatchedwhenthehopperis
intheraisedposition.
Neverworkunderapartially
raisedhopperorifthehopper
Pullleverasshown,until
thehopperpropiscorrectly
latched,beforeloweringthe
hopper.
propislatched.
!
C
