Scarab Mistral Operating instructions

E&OE
SCARAB MISTRAL - Abbreviated Operating Instructions
SWEEP MODE
VEHICLE ENGINE RUNNING. AIR TANKS FULL.
1. Vehicle stopped and in Neutral gear. Hand brake ON. (L1)OFF.
2. Auxiliary Engine switch ON (Main Panel). Engine speed will change to 1100rpm.
If reduction gearbox fitted, Step 3. If not, Step 4.
3. Clutch de-pressed, F1 switch ON. symbol will change to the symbol on the LCD screen.
If the symbol flashes and a buzzer sounds, press the F1 switch. Drive the vehicle slightly
forward and repeat step 3.
4. Select required sweeping equipment (Main Panel). Fan ON. (L1) ON.
5. Engage a suitable gear. Hand brake OFF. Clutch released, commence sweeping.
All sweeping gear is stopped and raised automatically when REVERSE is selected. Reduction
gearbox will disengage. Sweeping equipment and reduction gearbox will re-engage, when
forward is selected.
LEAVING SWEEP MODE / DISENGAGING REDUCTION DRIVE
1. Vehicle stopped and in Neutral gear. Hand brake ON.
2. (L1) OFF. Fan OFF (Main Panel).
If reduction gearbox fitted, Step 3. If it has not, Step 4.
3. Clutch de-pressed, F1 switch OFF. symbol will change to the symbol on the LCD
screen. Clutch released.
If the symbol flashes and a buzzer sounds, press the F1 switch. Drive the vehicle slightly
forward and repeat step 3.
4. Auxiliary Engine switch OFF (Main Panel).
Before stopping the auxiliary engine, allow it to idle for at least 2 minutes to allow the turbo-
charger to cool down.
This document is designed as a quick reference guide, to allow the operator to drive the
vehicle in Normal or Reduction Gearbox Mode and operate the basic controls. It does not
constitute the full operating instructions.
M
C
C
C
M
M
EQUIPMENT NOT SELECTED
EQUIPMENT PRE-SELECTED
EQUIPMENT OPERATING
WATER PRE-SELECTED
EQUIPMENT + WATER PRE-SELECTED
MAIN EQUIPMENT COLOUR CODES
WIDE SWEEP WATER ACTIVE
NOZZLE TILT INDICTOR
WORK LIGHT ON
BRUSH ACTIVE
WATER ACTIVE
PRESS TO DISABLE
HOPPER RAISE/LOWER AND REAR
DOOR OPEN/CLOSE WARNING BUZZER
+
MAIN PANEL
M
+
!
OPTIONS*
OPTIONS*
BRUSH SPEED
LEFT
SIDE BRUSH
LEFT SUCTION
WIDESWEEP BRUSH
RIGHT SUCTION
RIGHT
SIDE BRUSH
LEFT
WORKLIGHT
LEFT WATER
WIDESWEEP
WATER
RIGHT WATER
RIGHT
WORKLIGHT
ENGINE SPEED ENGINE SPEED
LEFT ADDITIONAL RIGHT ADDITIONAL
C
CRAWLER
DRIVE
MAIN DRIVE
SUCTION FAN
ON
SUCTION FAN
BOOST
HOPPER NOT
DOWN
H-P WATER
PUMP
WATER TANK
LOW
H-P PUMP
NO WATER
HYDRAULIC OIL
LOW
HYDRAULIC OIL
TEMP
SERVICE
REMINDER
ACTIVE FAULT
PRESENT
MAJOR ON-SCREEN INFORMATION
AND WARNING SYMBOLS
HIGH-PRESSURE
NOT APPLICABLE
AUXILIARY PANEL
NOZZLE TILT
SUCTION FAN
SUCTION FAN BOOST
FAVOURITE
SETTING
WATER* WATER*
PUMP*
L1
*OPTIONS
MULTI-FUNCTION LEVER
ON RIGHT HAND DRIVE VEHICLES
Lever Right, side brush(es) OUT.
Lever Left, side brush(es) IN.
On machines fitted with variable extend and
retraction, move the lever momentarily in
the desired direction to ‘nudge’ the
brush(es).
Reversed on Left Hand Drive.
NOZZLE-TILT FUNCTION
Pull lever back and hold to OPEN. Release to
CLOSE.
Variable Tilt:-Pull lever back to ‘nudge’
DOWN from the LOCKED OPEN position.
Press and hold down the Safety Interlock and the
appropriate control switch.
For safety reasons only operate the Remote
Control controls from outside the vehicle,
from a vantage point that affords a good view
of the sweeper and its surroundings.
Before closing the rear door, ensure adequate
clearance and seal cleanliness.
!
C
AUXILIARY ENGINE
START/STOP + SWEEP MODE
OFF
ON
TILT
SIDE SIDE
BRUSH BRUSH
NOZZLE
= RAISE HOPPER
= LOWER HOPPER
= OPEN DOOR
= CLOSE DOOR
= SAFETY INTERLOCK
= OPTION
REMOTE CONTROL
PLEASE REFER TO REVERSE FOR HEALTH & SAFETY ADVICE

E&OE
Health and Safety advice
• Only trained operatives should be allowed to drive or work on this machine.
• Never work under a raised hopper or rear door without the appropriate safety prop in position.
• Do not drive the vehicle with the hopper raised. The red warning symbol on the LCD monitor remains illuminated until the hopper is fully
down.
• Before working on the vehicle ensure that it is on firm, level ground, apply the hand brake, stop the engine and remove the ignition key.
• Before raising the hopper or opening the rear door, ensure that there is sufficient clearance and it is safe to do so.
• Before starting the auxiliary engine, ensure that all controls are switched off and the vehicle’s gearbox is in neutral.
• Before driving the vehicle, ensure that all vehicle checks have been carried out and that all equipment is stowed and that brush(es) are
raised.
• Do not overload the hopper.
• High pressure water can be dangerous, always wear suitable eye protection when operating the high pressure water pump nad when using
the lance. Do not direct the water jet at other persons. Beware of electrical installations on public buildings and lamp posts etc. and always
exercise extreme caution in public places.
• The suction fan is an extremely heavy rotating mass. Vibrations emanating from the suction fan must be investigated, the cause
determined, and rectified immediately.
• When working on the suction fan. Never attempt to slow or stop the fan by using the hands or by inserting any item into the fan chamber,
even at low speeds. failure to comply can result in serious injury.
• When operating the machine in any mode always be aware of objects and people in the immediate vicinity, especially at the rear of the
machine when reversing.
• Whatever the situation, remember that the rules of traffic and road safety must be observed.
• While operating this machine the safety and well being of other people are the sole responsibility of the operator.
Cautions
If the suction fan vibrates, it should be cleaned immediately (refer to the operating instructions). Prolonged vibration will result in damage
to the fan, bearings and, in extreme cases, the hopper.
In the event of a hydraulic oil leak, stop the engine and investigate.
The high and low pressure pumps must never be permitted to run dry or the piston seals will be damaged.
Do not direct the high-pressure jet directly at paintwork or electrical connections on the vehicle.
Routine daily maintenance
1. Check vehicle’s general condition (including tyres, lights and all fluid levels) in accordance with chassis manufacturers’ recommendations.
2. Check hydraulic oil level. (note: if the oil level is not maintained, the sweeping panel will automatically shut down until the oil level is correct).
3. Check condition of brushes and remove any items such as string that may be entangled.
4. Check ground clearance of suction box rubber flaps (20 mm front / 30 mm rear & sides) suction power can be lost if clearances are incorrect
but it is possible to slightly vary these settings to better suit specific sweeping conditions according to operator’s experience.
5. Check water spray jets for blockages.
6. Clean the oil cooler and check that cooling fan functions (note: if fitted, red light and buzzer operate when maximum temperature is reached).
7. Wash the vehicle, ensuring that the suction fan and hopper screens are cleaned.
8. Lubricate brush links, pivot points and wide sweep bearings.
9. Remove and clean the water-strainer elements.
10. Always leave the vehicle with the rear door slightly open to allow water to drain out.
11. In frosty weather, drain pumps & tank, remove water-strainer elements, switch on all water sprays and run low-pressure pump until dry.
Hydraulic oil: HPL 32 or an equivalent.
Coolant: Ethylene Glycol (Eskimo long life).
Engine oil: 15w - 40
Z038152 5.3.0 English
Auto ratchet hopper safety prop
Rear door safety prop
When inserting the
door prop, ensure it is
correctly positioned
in the locating slot.
Ensure the prop is
correctly positioned
within the ratchet rack.
!
