Schaerer Coff ee Art C
Generic 24mo Preventative Maintenance
Standard Operating Procedures
Version RD20210723

Schaerer Coffee Art C - Generic 24mo Preventative Maintenance SOP
Table of Contents
Preventative Maintenance
Section Title
1. Contents of Receivables - Service Kit
2. Required Tools
3. Cleaning Procedure
4. Multi-Point Inspection
5. Part Replacements
6. Additional Adjustments
7. Calibration
7A. Calibration Overview
7B. Recipe Settings (By Blend)
7C. Touch Screen Calibration
7D. Reference Grinders
7E. Drink Time Calibration
7F. Pump Pressure and Drink Volume Check
7G. Air Valve Adjustment
8. Concluding Actions

Schaerer Coffee Art C - Generic 24mo Preventative Maintenance SOP
1. Contents of Receivables - Service Kit
Service Kit 1 Parts
Part Number Part Description Qty.
33.7007.3222 Red Automat UPPER Piston O-ring 1
33.7007.3223 Red Automat LOWER Piston O-ring 1
33.7006.2693 Black Automat O-ring 1
33.7006.3654 or
33.7006.5240 Overpressure Valve 12bar 1
Important Note:
• Please reference any additional memos provided in the PM work order email
from the SEB Professional PM team for any further parts and instructions re-
quired to complete this preventative maintenance.
• Please ensure any open service items previously dispatched by the SEB Pro-
fessional Dispatch team are covered during this PM and a separate work
order is  lled out.
• SP might receive FLUSH VALVE part number 33.7006.1029 or 33.7006.6246.
Service Kit 2 Parts
Part Number Part Description Qty.
33.7007.3300 Brewing Unit 30 Gram 1
33.7006.1029 or
33.7006.6246 Flush Valve 1

Schaerer Coffee Art C - Generic 24mo Preventative Maintenance SOP
2. Required Tools
1. Service Card
2. Gram Scale
3. Clamp Multimeter - for measuring AC Voltage and checking Current
4. USB Flashdrive pre-loaded with latest settings (8 gb or less)
5. Food Safe Lubricant (Part Number 33.7006.7339)
6. Basic Hand Tools
• Short Hex Screwdriver
• Long Hex Screwdriver
• Metric Nut Drivers Set 5-13mm
• Metric 1/4” Socket Set 5-13mm
• 3/16” Flat Blade Screwdriver
• 1/4” Flat Blade Screwdriver
• No. 1 Phillips Screw Driver
• No. 2 Phillips Screw Driver
• Combination Wrenches Metric 7mm - 17mm
• Adjustable Wrench 10”
7. Grinder Adjustment Knob
8. Measuring Cup (More than 40oz)
9. Cleaning Supplies
• Vacuum
• Automat brush

Schaerer Coffee Art C - Generic 24mo Preventative Maintenance SOP
3. Cleaning Procedure
1. Run a cleaning cycle with the cleaning tablet. Follow the
instructions on the screen.
• Clean the grounds bin, undercounter grounds bin, and
surrounding area.
• Clean the drip grill and drip tray
2. Remove the bean out of the hoppers. Remove and clean the empty
hoppers with a clean, moist cloth.
NOTE: It is advised to dispose of the beans (as the calibration
REQUIRE fresh beans), but this will be to the discretion of customer.
3. Once the cleaning cycle is complete, clean any remaining
components. Make sure the bean hoppers are completely dry
before re-inserting.

Schaerer Coffee Art C - Generic 24mo Preventative Maintenance SOP
4. Multi-point Inspection
1. Perform a water drainage of the boilers
CAUTION: Once the water drainage routine is started the machine will allow hot
water to be released from the hot water wand, coff ee spout, and steam wand (if
applicable). Please exercise caution when activating the routine to prevent injury.
Perform a water drainage using the water drainage function in the programming
menus:
1. Insert Service Card and type your pin (1000)
2. Tap System - Test/Calibration - Water drainage
3. Confi rm that you would like to perform the water drainage
A timer will appear on the screen and start counting down once the automat
moves into brewing position. Once this timer is below 2:00 minutes turn off the
water supply and allow the system to depressurize. Remove power from the
machine once there is no water fl owing from the hot water wand (and steam
wand if applicable).
2. Once the water drainage is complete, turn off water supply and
power off the machine to begin checking the coff ee boiler for
calcium.
• Remove the coff ee boilet inlet and clean any additional calcium with
wire brushes.
Checking for calcium
CAUTION: Please be aware that the boiler and its components may still be hot.
Please exercise caution when handling any of these components.

Schaerer Coffee Art C - Generic 24mo Preventative Maintenance SOP
3. Remove all panels for the machine. Check for any leaks or broken
parts and briefl y clean up any dirty areas.
• If additional issues or maintenance/ repairs are needed, please
contact Tech Support and ensure a separate work order is
created outside of this service.
Once power has been removed, proceed with disconnecting the center boiler nut
as shown in the following illustration.
Coff ee Boiler
Once the boiler nut is disconnected, you will have the ability to insert your long
Schaerer screwdriver until it touches the metal at the bottom of the boiler.
• If you feel any crunching or debris inside which impedes the movement of
the screwdriver to the bottom of the boiler then you have calcium present.
• If you can insert the screwdriver and feel the metal at the bottom of the
boiler then your check inside the boiler is complete.
Please note: if you can insert the screwdriver to the bottom of the boiler and
don’t feel any calcium, this is not a guarantee that there is no calcium present.
4. Multi-point Inspection (cntd)

Schaerer Coffee Art C - Generic 24mo Preventative Maintenance SOP
Next, using a 14mm and 17mm open ended wrench, remove the overpressure
valve from the boiler outlet manifold and replace with the new overpressure valve.
Please see the illustration below for the location of the coff ee overpressure valve.
Replace the overpressure valve - part number 3370063654 or 3370065240.
Coff ee Art C
What to do if calcium is present (next steps)
If you fi nd calcium inside the boiler(s), notify our Technical Support team
and request next steps
4. Check the drain and water supply hoses to ensure proper routing.
4. Multi-point Inspection (cntd)

Schaerer Coffee Art C - Generic 24mo Preventative Maintenance SOP
1. Replace the brew unit (automat) and thoroughly clean the automat
compartment.
5. Part Replacements
2. When fi nished, place the panels and bean hoppers back onto the
machine and power on.

Schaerer Coffee Art C - Generic 24mo Preventative Maintenance SOP
5. Part Replacements (cntd)
2. Flush Valve Replacement
Note: ensure the water is off and the
boiler is still cooled down from the
water drainage.
1. Remove drain hose clamp and drain
hose from the drip tray
2. Remove screw and knurling nut from
both sides of the drip tray, remove
drip tray from machine.
3A. Remove the center plate
3B. Remove both screws used for mounting
the center plate (2.5mm allen screwdriver)
3C. Remove both screws that hold the right
cover plate (3mm allen screwdriver or
Long Schaerer screwdriver)
Disconnect the manometer tube and remove
the right cover plate from machine.
• Gently swivel the fl ush
valve bracket back, toward
the pump and remove the
brass fi tting(s) (circled with
orange) from the bottom
port of the valve.
• Disconnect the Tefl on
tube from the top and the
electrical wires from the
side.
• Remove the valve and
replace
3A 3B
3C
Reassemble all components in reverse order
(See next page for instructions if the fl ush valve received diff ers than the fl ush valve
inside the machine.)

Schaerer Coffee Art C - Generic 24mo Preventative Maintenance SOP
5. Part Replacements (cntd)
Flush Valve Accomodations

Schaerer Coffee Art C - Generic 24mo Preventative Maintenance SOP
6. Additional Adjustments
1. Insert Service card (PIN 1000), press “System” tab, then press
“System Parameters.” Verify that the “0) Machine Number” matches
the machine number on the physical machine.
• The machine number can be found on either the back of the ma-
chine, on the left side of the automat compartment, and next to the
main board behind the left panel.
2. Record the machine’s total “Amount of cleanings” onto the checklist
(this MUST be done for each machine).
There are two ways of accessing this information:
• Insert the Service Card (PIN 1000), press “Information” then “Count-
ers and Statistics.” Select “Machine counters” then scroll down until
“Amount of cleanings”. Record the TOTAL amount from the rightmost
box.
• Put the machine on standby mode and press the menu icon in the
bottom left corner. Press “Quick Menu” then press “Counters and
Statistics.” Select “Machine counters” then scroll down until “Amount
of cleanings”. Record the TOTAL amount from the rightmost box.
3. Reset brewer counter.
• Insert service card and type pin (1000)
• Tap “Counters & Statistics”
• Tap “Service Counters”
• Locate “Brew cycles brewer” and tap the red x on the right to clear
the counter

Schaerer Coffee Art C - Generic 24mo Preventative Maintenance SOP
7: Calibration

Schaerer Coffee Art C - Generic 24mo Preventative Maintenance SOP
7A. Calibration Overview (PM)
Ensure bean hoppers are completely dry, then fi ll hoppers with fresh beans.
Machine is now ready for calibration, please refer to checklist and fi ll it out.
Throughout the entire calibration process, please refer to customer recipe specifi cations
and planogram layouts to avoid confusion.
2. Check Brew
Pump Pressure
(Req. 5 Bar)
Repeat steps 3-4
for all three
grinders/ blends
1. Reference
grinding for all 3
grinders
4. Is the
total time to
spec for that
blend?
7a. Adjust air
restrictor
clockwise on the
back of machine
4a. Adjust Grinder
Coarseness
END
YES
NO
START
If you have any technical questions or need assistance, please call our
Technical Support Team @ 888.989.3004 - Select option 1, option 2, then option 2
Is grinder adjusted 10
or more clicks?
YES
NO
3. Check Drink
Times for 20oz
Drink
NO
5. Check Drink
Volumes for all
drink sizes
6. Is the
fi ll volume
correct for the
drink?
6a. Adjust Water
Quantity
NO
Repeat steps 5-6
for all drink sizes
for all three
grinders/ blends
7. Run a few hot
drinks. Is there
spitting at the
end?
YES
YES
9. Backup machine
data onto USB
fl ashdrive found on
left panel
8. Run a two
iced drinks. Does
the second drink
start dispensing
and pause for
several
seconds?
8a. Adjust air
restrictor
counter-clockwise
on the back of
machine
YES
NO

Schaerer Coffee Art C - Generic 24mo Preventative Maintenance SOP
7B. Recipe Settings
Use appropriate planogram for customer and equipment layout.

Schaerer Coffee Art C - Generic 24mo Preventative Maintenance SOP
7C. Touch Screen Calibration
Items Needed:
1. Service Card
1.
• Insert “SERVICE” card into card reader
and enter ‘PIN CODE” to enter “Pro-
gramming Menu.
2. - Confi guration Menu ►
• After entering programming menu,
Press “Setup Touch It”, to advance to
next screen.
3. - Calibration Touch Screen Menu ►
• Press “Calibrate Touch Screen” and
wait for the white screen to appear as
shown in step 4.
4. ►
• After entering the White Screen,
follow instructions on screen.
5.
• After completing step 4, another white
screen will appear.
• Simply touch the screen to complete
the process.
• NOTE: Previous versions of Touch-
IT Software will not display the second
screen and will automatically reboot after
completing step 4.
6.
• After completing step 5, the machine
will reboot. Remove Service Card at this
time.
• After machine has completed the re-
boot process, test touch display function
and repeat process if necessary.

Schaerer Coffee Art C - Generic 24mo Preventative Maintenance SOP
7D. Reference Grinders
1. ► 2. - Programming Menu ► 3. ►
4. ► 5. ►
• Insert “SERVICE” card into card
reader and enter “PIN CODE” to en-
ter the programming menu.
• After entering programming menu,
press “Test / Calibration” button to en-
ter “Test / Calibration” sceen.
• Turn on scale and set to measure
grams.
• Place disposable cup on scale and
press “TARE”.
Items Needed:
1. Service Card
2. Digital Gram Scale
3. Disposable Cup
6. - Grinder output ►
1) Press “Left grinder” button
2) Press “Continue” button
• After entering “Test / Calibration”
screen, press “Calibrate grinders” but-
ton.
• When “Calibrate grinders” button is
pressed, brew chamber will raise.
• Remove grounds bin tray and metal
shield.
• Place cup on “Automat” as shown, to
capture grinder output for measuring.
1) Press “Left grinder”
2) Press “Continue”

Schaerer Coffee Art C - Generic 24mo Preventative Maintenance SOP
7. ► 8. ►
• After reference grinding has complet-
ed, remove cup from Automat and
weigh.
• Press “Continue” button on screen.
• NOTE: Do NOT press “Repeat”,
otherwise the grinder calibration
process must be restarted!
9. - Grinder calibrate ►
• If adjustment is required, press
“Reference quantity” button to dis-
play graphical thumb wheel.
• Compare weight of actual grounds
captured from Automat and “Cur-
rent reference quantity” displayed on
screen.
10. ► 11. ►
• Adjust reference quantity.
• Press “Green Check” icon.
• Press “Finish Button” to complete.
• Repeat all steps in this section
for the Right grinder and Front
grinder.

Schaerer Coffee Art C - Generic 24mo Preventative Maintenance SOP
7E. Drink Time Calibration
Items Needed:
1. Service Card
2. Digital Gram Scale
3. Grinder adjustment knob
1.
• Insert “SERVICE” card
into card reader and enter
‘PIN CODE” to enter pro-
gramming menu.
2. - Programming Menu ►
• After entering program-
ming menu, press “Bever-
age confi guration” button
on screen to enter Bever-
age confi guration screen.
• Select MEDIUM 20oz
drink in single cycle to test.
3. - Beverage Confi g. Menu ►
• From “Beverage Confi gu-
ration” screen, press “Modi-
fy beverage settings” button.
Refer to the recipe settings
on the following page for
customer specifi cations.
4. ►
• Place Measuring Cup under
dispensing spout.
• From “Single Beverage Confi g-
uration” screen, press “Walking
Man” icon in lower left to dispense
drink.
• Check drink volume and brew
time. Dispensing time will be dis-
played as shown in step 5.
5.
• If Brew Time and volume do not meet
customer specifi cations, adjust the
grinder in step 6.
•See customer specs (sec. 5B)
for dispensing time information
(Medium drinks needed only)
• Re-check Brew Time after
adjustments
6.
• If needed, directly adjust the grinder coarser/fi ner. Remove the black plug on
the side you are adjusting.
• Turn the grinder knob clockwise to adjust FINER, and counter-clockwise to
adjust COARSER. Re-check brew times after adjustments.
• NOTE: Listen for the clicks. If you adjust 10 or more clicks in a single
direction (total), please repeat the calibration process for the grinder you
are calibrating starting from step 2 of fl ow chart (see section 5a)
Brew Time too high?
Adjust COARSER
counter-clockwise
Brew Time too low?
Adjust FINER
clockwise

Schaerer Coffee Art C - Generic 24mo Preventative Maintenance SOP
7F. Pump Pressure and Drink Volume Check
1. ► 2. - Programming Menu ► 3. ►
4. ► 5. - Check Water Pump Pressure ►
• Insert “SERVICE” card into card
reader and enter “PIN CODE” to en-
ter the programming menu.
• After entering programming menu,
press “Beverage confi guration” button
to continue.
• After selecting drink button, press
“Modify beverage settings” button to
enter the “Single beverage confi gu-
ration” screen.
Items Needed:
1. Service Card
2. Digital Gram Scale
3. Measuring Cup
6. - Check Water Pump Pressure ►
• NOTE: Removal of right side cover
is required if adjustments are neces-
sary.
• Repeat step 5 and adjust water
pump pressure as necessary.
• After pressing “Beverage confi gu-
ration” button, select Medium sized
drink in single mode in a single cycle
for calibration
• Press “Walking Man” button and
and note pressure gauge.
• NOTE: the Save icon may appear
instead, press it and continue
• Pressure should read 4.75 - 5.25
BAR
while drink is dispensing.
• Press OK when shot is complete.
Medium
20oz
