Scheppach Workzone Titanium+ AERO 2 SPADE User manual

Original instructions
User Manual
AIR DEMOLITION BREAKER 5 IN 1
AERO2SPADE
Contents
Overview 04
Utilisation 05
Contents of Box 06
Explanation of symbols 07
Introduction 08
Layout 09
Unpacking 09
Intended use 10
Safety regulations 11
Before starting the equipment 16
Operation 18
Cleaning and maintenance 20
Technical data 20
Storage/Transport 21
Disposal and recycling 21
Troubleshooting 22
Warranty Details 25
Repair and Refurbished Goods or Parts Notice 26
ALDI guarantees that our exclusive brand products are developed to
our stringent quality speci cations. If you are not entirely satis ed with this
product, please return it to your nearest ALDI store within 60 days from
the date of purchase for a full refund or replacement, or take advantage of
our after sales support by calling the supplier’s Customer Service Hotline.
Made in China
WORKZONE TITANIUM is a registered trademark of ALDI Stores
DISTRIBUTED BY:
ALDI STORES
1 SARGENTS ROAD
MINCHINBURY NSW 2770
www.aldi.com.au
MODEL:AERO2SPADE PRODUCT CODE: 59540 04/2018
AFTER SALES SUPPORT
 1300 855 831  [e-mail]
AUS
5Vers.No. 171212

UtilisationOverview
45Pack contents/parts 6
1
1x Spade
1x Pointed Chisel
1x Flat Chisel
1x Scraper blade
1x Holder
2
3
4
6
7
11
12
Contents of Box
1x Air Demolition Breaker
1x Manual
1x Warranty Certicate
1x Wide Chisel
5
2
E
A
C D
B
8
9
2x Nut
2x Screw
10 2x Ring
1
4
56
1
2
3
711
A
B
C
D
E
8 9 10
3
1
2
7 8 9 10 11

AFTER SALES SUPPORT 07
 1300 855 831  [e-mail]
MODEL:AERO2SPADE PRODUCT CODE: 59540 04/2018
AUS
AERO2SPADE Explanation of symbols
Explanation of symbols
Caution - Read the operating instructions to reduce the risk of
injury.
Wear safety goggles!
Wear ear-muffs!
Wear a breathing mask!
Wear work gloves!
Wear safety footwear!

08 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL:AERO2SPADE PRODUCT CODE: 59540 04/2018
s
I. Introduction
Congratulations on choosing to buy a WORKZONE TITANIUM®product.
All products brought to you by WORKZONE TITANIUM®are manufactured to the
highest standards of performance and safety, and as part of our philosophy of cus-
tomer service and satisfaction, are backed by our comprehensive 5 Year Warranty.
We hope you will enjoy using your purchase for many years to come.
Note:
According to the applicable product liability law the manufacturer of this device is not
liable for any damages which arise on or in connection with this device in case of:
• improper handling,
• non-compliance with the instructions for use,
• repairs by third party, non-authorised skilled workers,
• installation and replacement of non-original spare parts,
• improper use,
Recommendations:
Read the entire text of the operating instructions prior to the assembly and operation
of the device.
These operating instructions are intended to make it easier for you to get familiar
with your device and utilise its intended possibilities of use.
The operating instructions contain important notes on how to work safely, properly
and economically with your machine and how to avoid dangers, save repair costs,
reduce downtime, and increase the reliability and working life of the machine.
In addition to the safety regulations contained herein, you must in any case comply
with the applicable regulations of your country with respect to the operation of the
machine.
Put the operating instructions in a clear plastic folder to protect them from dirt and
humidity, and store them near the machine. The instructions must be read and
understood by each operator prior to starting the work. Only persons who have been
trained in the use of the machine and have been informed on the related dangers
and risks are allowed to use the machine. The required minimum age must be met.
In addition to the safety notes contained in the present operating instructions and
the special regulations of your country, the generally recognised technical rules for
the operation of machines must be observed.
AUS
Introduction AERO2SPADE

AFTER SALES SUPPORT 09
 1300 855 831  [e-mail]
MODEL:AERO2SPADE PRODUCT CODE: 59540 04/2018
II. Layout (Fig. 1)
1 Tool receiver
2 Sliding sleeve
3 Shaft
4 Trigger lever
5 Connection
6 Handle
Tools:
7 Spade
8 Pointed chisel
9 Flat chisel
10 Wide chisel
11 Scraper
A Holder
B Screw
C Ring
D Nut
E Scraper blade
III. Unpacking
• Open the packaging and remove the device carefully.
• Remove the packaging material as well as the packaging and any transport brac-
ing.
• Check that all listed parts are complete.
• Check the device and accessory parts for transport damage.
• If possible, store the packaging until the warranty period has expired.
m Attention!
The device and packaging materials are not toys!
Children must not be allowed to play with plastic bags, lm and small parts!
There is a risk of swallowing and suffocation!
AUS
AERO2SPADE Layout/Unpacking

AUS
Intended use/Safety regulations AERO2SPADE
10 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL:AERO2SPADE PRODUCT CODE: 59540 04/2018
IV. Intended use
Depending on the tool being used, the device described are suitable exclusively for:
- Spade (1): Digging, removing roots.
- Pointed chisel (2): Demolition works.
- Flat chisel (3): Demolition works; removing tiles; removing plaster.
- Wide chisel (4): Demolition works; removing tiles; removing plaster.
- Scraper (5): Removing old carpets, adhesive residue, concrete residues, PVC oors,
linoleum oors
Any other use is not in compliance with the proper intended use and as such is forbid-
den. Alterations, use of third-party tools or tampering with or altering controls or actu-
ators is likewise forbidden. Use in potentially explosive areas is forbidden. Working in
or under water is not permitted.
V. Safety regulations
General Safety Warnings
m Warning! Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference.
a) The user must evaluate the specic risks associated with each application of the
device.
b) You must read and understand the safety instructions before installing, opera-
ting, repairing or maintaining the device, and also before replacing any accesso-
ry parts or carrying out any work in the vicinity of the device. Failure to read and
follow the instructions may lead to serious injury.
c) Only qualied, trained operators are authorised to install, adjust or use the de-
vice.
d) The device must not be modied. Any modications implemented may reduce
the efciency of the safety measures and increase risks for the operator.
e) Never use devices that have been damaged. Look after your device carefully.
Regularly check that all moving parts are functioning correctly without jamming.
Also regularly ensure that no parts are broken or damaged to an extent that they
affect the operation of the device. Check that all signs and labels are legible and
intelligible. Have damaged parts repaired or replaced before using the device.
Many accidents are caused by poorly maintained devices.

AUS
AERO2SPADE Safety regulations
AFTER SALES SUPPORT 11
 1300 855 831  [e-mail]
MODEL:AERO2SPADE PRODUCT CODE: 59540 04/2018
Special Safety Instructions
Risks associated with ejected parts
a) Disconnect the device from the compressed air supply before replacing the
mounted tool or accessory parts, and also before carrying out repairs or set-
tings.
b) If either the workpiece, accessory parts or the device breaks, parts may be
ejected at high speed.
c) While operating, maintaining or repairing the device, or replacing accessory
parts, you must always wear impact-resistant safety goggles. The degree of pro-
tection required for each individual task must be evaluated separately in each
case.
d) Wear a safety helmet if carrying out work above your head. Also ensure that no
other people are placed at risk.
e) Ensure that the workpiece is securely attached.
f) Only switch on the device after the mounted tool has been locked correctly in
the device with the locking device.
g) To avoid injury, all parts of the locking device displaying signs of wear, or that
are broken or bent, must be replaced.
h) Place the mounted tool rmly on the surface to be worked on before switching
on the device.
Risks associated with recurring movements
a) When working with the device, you may experience an uncomfortable sensation
in your hands, arms, shoulders, neck or other body parts.
b) Make sure you are in a comfortable position to carry out work with the device,
check that the device is held securely, and avoid any awkward positions that
make it difcult, for example, to keep your balance. If carrying out work over an
extended period, you/the operator should change position occasionally. This
should help to avoid fatigue and any unpleasant sensation.
c) If the operator experiences persistent symptoms such as feeling unwell, aches,
pains or throbbing, a prickling or burning sensation, loss of hearing, or joint
stiffening, these warning signs must not be ignored.
Risks associated with accessory parts
a) Disconnect the device from the air supply before securing or replacing the
mounted tool or accessory part.

AUS
Safety regulations AERO2SPADE
12 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL:AERO2SPADE PRODUCT CODE: 59540 04/2018
b) Only use accessories that are designed for this device and that full the require-
ments and the specications listed in these operating instructions.
c) Never use the chisel as a hand tool. They are specially designed for application
in non-rotating impact air tools and are correspondingly heattreated.
d) Never use blunt chisels: they require an excessive amount of pressure and this
can result in fatigue breakage. Blunt tools can cause increased vibration, which
is why you should always use mounted tools that are sharp.
e) Never cool hot accessory parts in water. This can lead to brittleness and prema-
ture failure.
f) Never misuse the mounted tool as a lever (e.g. for mortising); this can result in
chisel breakage or damage. Work in small partial sections to avoid getting stuck.
g) Avoid any direct contact with the mounted tool both during and after use becau-
se it may be hot or have sharp edges.
Risks in the workplace
a) Slipping, tripping and falling are the main reasons for accidents in the workpla-
ce. Pay attention to surfaces that may have become slippery as a result of using
the device, and also be careful that the air hose does not cause someone to trip.
b) Proceed carefully when working in unfamiliar environments. Power cables and
other supply lines may represent a hidden risk.
c) The device is not designed for use in explosive environments and is not insula-
ted against contact with sources of electric power.
d) Ensure that the area where you wish to work is free of power cables, gas lines
or water pipes (e.g. by using a metal detector).
Risks associated with dust and vapours
a) The dust and vapours generated when the device is used may carry health risks
(e.g. cancer, birth defects, asthma and/or dermatitis); it is therefore imperative
that a risk assessment is carried out in relation to these risks and that suitable
controls are then implemented.
b) The risk assessment should take into account both the dust generated while the
device is used and any existing dust that may be raised during operation.
c) The device must be operated in accordance with the recommendations set forth
in these instructions and must be maintained in order to minimise the release of
dust and vapours.
d) The extracted air must be discharged in such a way that, in a dust-lled environ-

AUS
AERO2SPADE Safety regulations
AFTER SALES SUPPORT 13
 1300 855 831  [e-mail]
MODEL:AERO2SPADE PRODUCT CODE: 59540 04/2018
ment, the minimum of dust is raised.
e) If dust or vapours are generated, the main priority is to control these at the point
where they are released.
f) All integral or accessory parts on the air tool that are designed to collect, extract
or prevent airborne dust or vapours must be used and maintained in accordance
with the manufacturer‘s instructions.
g) To avoid increasing the amount of dust or vapours generated unnecessarily, the
consumables and the mounted tool must be selected, maintained and replaced
in accordance with these instructions.
h) Use protective breathing apparatus in accordance with the instruction manual or
in accordance with health and safety regulations.
Risks associated with noise
a) Failure to use adequate ear protectors when the noise level is high can result
in lasting damage to hearing, hearing loss and other problems, such as tinnitus
(ringing, whistling or buzzing in the ear).
b) It is vital to carry out a risk assessment in relation to these risks and to imple-
ment appropriate control measures that take the risks into account.
c) Appropriate risk control measures may include, for example, the use of sound-in-
sulating materials to prevent the knocking sounds that occur on the workpieces.
d) Use ear protection in accordance with the instruction manual or in accordance
with health and safety regulations.
e) The device must be operated in accordance with the recommendations provi-
ded in these instructions and must be maintained in order to avoid unnecessa-
rily raising the noise level.
f) To avoid increasing the noise level unnecessarily, the consumables and the
mounted tool must be selected, maintained and replaced in accordance with
these instructions.
g) The integrated sound absorber must not be removed. You must ensure the
sound absorber is in good working order.
Risks associated with vibration
a) The effects of vibration can damage nerves and impair blood circulation in the
hands and arms.
b) When working in cold environments, you must wear warm clothing and keep
your hands warm and dry.

14 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL:AERO2SPADE PRODUCT CODE: 59540 04/2018
AUS
Safety regulations AERO2SPADE
c) If you notice that the skin on your ngers or hands is numb, prickling or turning
white, stop working with the air tool immediately and consult a doctor.
d) The device must be operated in accordance with the recommendations provi-
ded in these instructions and must be maintained in order to avoid unnecessa-
rily raising the level of vibration.
e) Do not hold the mounted tool with your free hand because this results in an
increased vibration effect.
f) When working on concrete, knock out small parts with crushers to avoid jam-
ming of the tool.
g) Move the cutting tool of crushers every couple of seconds. Stop the crusher
when you raise the air tool to change its position. Otherwise strong vibrations
can result when you lift up the air tool by the handles.
h) Hold the device rmly but not too tightly using the required manual torque reacti-
on: the risk of vibration is increased when the grip force is higher.
Additional safety instructions
a) Compressed air can cause serious injury.
b) Whenever the device is not in use, and before replacing accessory parts or
when carrying out repairs, you must ensure that air supply is shut off, that the air
hose is depressurised and that the air tool is disconnected from the compressed
air supply.
c) Never direct the air jet at yourself or other people.
d) Whiplashing hoses can cause serious injury. Therefore always check that the
hoses and their xtures are in good condition and that they have not become
loose.
e) Cold wind should be directed away from the hands.
f) Do not use quick-lock couplings on the tool inlet. For threaded hose connec-
tions, only use those made with hardened steel (or a material with similar shock
resistance).
g) If universal swivel couplings (claw couplings) are being used, locking pins are
also required. You should also use whip check hose restraints in case there is
a problem with the connection between the hose and air tool or between the
hoses themselves.
h) Ensure that the maximum pressure specied on the device is not exceeded.
i) Never carry air tools by the hose.

AUS
AERO2SPADE Safety regulations
AFTER SALES SUPPORT 15
 1300 855 831  [e-mail]
MODEL:AERO2SPADE PRODUCT CODE: 59540 04/2018
j) Secure the device if it is operated in a holder. Loss of control can cause perso-
nal injury.
Further safety instructions
a) If applicable, observe any particular health and safety or accident prevention
regulations governing the use of compressors and compressed devices.
b) Ensure that the maximum supply pressure specied in the Technical Data is not
exceeded.
c) Do not overload the device – use it only within the performance range for which
it was designed (see “Technical Data”).
d) Use non-hazardous lubricants. Ensure the workplace is adequately ventilated.
If there is a large amount of discharge: check the device and have it repaired if
necessary.
e) Do not operate the tool unless you are completely focused. You must be alert,
pay attention to what you are doing and proceed cautiously when working with
a device. Never use a device when you are tired or under the inuence of drugs,
alcohol or medication. Just one moment‘s carelessness when using the device
can cause serious injury.
f) Make sure your workplace is clean and well lit. Untidy or poorly lit workplaces
can cause accidents.
g) Keep devices away from children.
h) Do not store the device outdoors or in damp conditions without protection.
i) Protect the device, especially the compressed air connection and the control
elements from dust and dirt.
Residual risks
Even if you use this device in accordance with instructions, certain residual risks
cannot be rules out. The following hazards may arise in connection with the device
construction and layout:
1) Lung damage if no suitable protective dust mask is used.
2) Damage to hearing if no suitable ear protection is used.
3) Health damage caused by hand-arm vibrations if the equipment is used over a
prolonged period or is not properly guided and maintained.

16 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL:AERO2SPADE PRODUCT CODE: 59540 04/2018
AUS
Before starting the equipment AERO2SPADE
VI. Before starting the equipment
Check the device, all tools and accessory parts for visible damage before use. Da-
maged tools shall not be used.
An adequately powerful compressed air source (e.g. compressor) of 3 to 6.3 bar
and a suction performance of at least 160 l/min is required for the air supply for the
compressed air device.
m Attention! Danger of device damage if the operating pressure at the device is
more than 6.3 bar.
The following compressors are recommended:
24 litres Light work
50 litres Moderate work
100 litres and more Heavy work
The compressor should be operating type S1 (continuous operation)
Connection
Connect a complete compressed air maintenance unit with a mist lubricator, bet-
ween the compressed air source and the device. A maintenance unit can be obta-
ined from specialist dealers and is not included in the delivery.
The compressed air hose (not included in the delivery) should not be longer than 15
metres and should have an internal diameter of at least 9 mm in order to minimise
pressure loss. mAttention! Danger of tripping due to improperly laid compressed
air hoses! Lay the compressed air hoses such that they do not cross paths and such
that they are at to the oor. Always lay the compressed air hoses such that there is
a reasonable amount of spare hose length in the work area.
Note that the line oiler should be attached at the same oor level or storey as the
working device.
Lubrication
• If the insertion end (hex.) of the tool being used is lightly moistened with oil after
operation, the oiler is correctly set.
• If oil emerges at the valve on the actuation body or if it runs along the tool attach-
ment, the oil quantity is set too high.
• Adjust oil quantity and top up oil
• Please use special compressed air oil - important: Use only resin-free oil!

AFTER SALES SUPPORT 17
 1300 855 831  [e-mail]
MODEL:AERO2SPADE PRODUCT CODE: 59540 04/2018
AUS
AERO2SPADE Before starting the equipment
Mounting the scraper (Fig. 2)
Mount the scraper scraper blade (E) with the holder (A), by using the screws (B), the
rings (C) and the nuts (D) .
Required tool: Open end wrench, 17 mm. (not included)
Inserting/replacing tool (Fig. 3)
m Risk of injury due to tools! To insert or replace tools, the device must be
rendered pressure-less as a matter of principle as otherwise the device could
be unintentionally started up if handled incorrectly. When dealing with sharp,
pointed or hot tools, always wear suitable protective gloves in order to avoid
injuries.
Use only original tools or tools that have been expressly approved by the manu-
facturer for use with this device.
• Hold the device with the tool receiver (1) upwards. Support the other end on
the ground. If the device has already been in operation, check whether the tool
receiver (1) is oily.
• Insert the requested tool (7; 8; 9; 10 or 11) into the tool receiver (1) with the hex.
in the required orientation.
• Slide the sliding sleeve (2) downwards with the other hand until the tool (7; 8; 9;
10 or 11) slides into the receiver. Guide the sliding sleeve back into place again
(2).
• Pull the tool (7; 8; 9; 10 or 11) to check that it is correctly latched into the tool
receiver (1). Check whether the hexagon of the tool (7; 8; 9; 10 or 11) is posi-
tively locked into the tool receiver.
• Slide the sliding sleeve (2) halfway downwards.
• Pull the tool (7; 8; 9; 10 or 11) out with the other hand. Guide the sliding sleeve
back into place again (2).
m Attention! Danger of injury through tools ying out. Every time the tool
is changed, ensure that the tool receiver (1) has no signs of severe wear or
heavy impacts. Also, ensure that the hex. on the tool is in awless condition.
After every tool change, check that the tool is rmly seated.

18 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL:AERO2SPADE PRODUCT CODE: 59540 04/2018
AUS
Before starting the equipment/Operation AERO2SPADE
Connect hose
• Connect the hose (not included in the delivery) to the compressed air source
(e.g. on the compressor) and open the compressed air feed.
• Check the compressed air hoses and couplings for leaks. In the event of leaks,
interrupt the compressed air supply and replace the hose!
• Connect the hose to the connection (5) on the device. In doing so, ensure that
the device does not start up autonomously. If this is the case, disconnect the
compressed air coupling immediately. Have the device repaired by a specialist
workshop or the manufacturer.
VII. Operation
Working with the device (Fig. 1)
mAttention! Danger of extremely serious or even fatal injuries if the device
is pointed at people or animals and if persons or animals are located within
the hazard area - even if there is no tool tted. Never point the device at people
or animals. The operator is personally responsible for ensuring that there are no
persons or animals in the hazard area of the device. As soon as persons or animals
enter the hazard area, the operator must immediately stop the device and ensure
that these persons or animals are kept at an adequate safety distance. The hazard
area is always dependent on the work and the tool. For this reason, it is the respon-
sibility of the operator to determine the hazard area.
Note! The striking mechanism of the device only operates when the tool is in
contact with the material to be processed. This function is designed to protect the
device against damage.
1. Press the trigger lever (4) to supply the impact mechanism with compressed air
and start the device.
2. Always hold the device with both hands during work:
- Hold the device with one hand on the shaft (3) or handle (6) and the other hand
on the trigger lever (4)
3. Note! Hold the tool (7; 8; 9; 10 or 11) against the material to be worked. Do not
operate the device when it is not in contact with the material! Strokes with no
load lead to increased wear on the tool hex. and on the sliding sleeve (2) of the
tool receiver (1).
4. The grip (6) and shaft (3) are used to guide the device and not to exert additio-
nal force on the material.
Only use enough muscle strength as is required for the device to overcome the

resistance of the tool guide so that the impact drives forwards and the device
does not jump up but rather works the material instead.
5. A limited degree of levering is possible. Too powerful levering can result in the
shaft (3) or the tool (7; 8; 9; 10 or 11) breaking. mRisk of injury! Danger of
stumbling if the shaft or tool breaks, due to an unexpected weight shift.
Do not lever too severely.
6. If you release the trigger lever (4), the compressed air feed is interrupted. The
device stops with a brief run-on time. m Risk of injury! Danger of extremely
serious or even fatal injuries or damage to the device or tool if the trigger
lever is permanently locked. Never lock the trigger lever with cable ties,
adhesive tape or by other means.
Check that the tool receiver (1) has been furnished with an oil lm, after 2 hours of
operation at the latest. If this is not the case, introduce a few drops of special oil into
the connection hose. We recommend operating the device in conjunction with a
maintenance unit with mist oiler as a matter of principle.
It is useful to grease the hex. tool receiver with large pressing forces.
Excessive oil damps the impact performance. Drops are forming on the trigger lever
or on the tool receiver. In this case, reduce the oil quantity on the oiler and clean
the device if necessary. Inadequate oil will result in damage to the device and tool.
Check oil feed and top up oil or adjust oiler if required.
End of work
Interrupt the compressed air supply from the compressed air hose to the device.
With breaks in work:
Place the device safely to one side.
If there are sharp or pointed tools in the device, cover these up.
At the end of work:
Interrupt the compressed air supply.
Remove the tool from the device.
Check that the tool receiver has been furnished with an oil lm.
If this is not the case, introduce a few drops of special oil into the connection hose
and operate the device without tool for ca. 15 seconds.
Clean the device, the tools, the hose and any other accessories with a dry or oily,
clean cloth.
AFTER SALES SUPPORT 19
 1300 855 831  [e-mail]
MODEL:AERO2SPADE PRODUCT CODE: 59540 04/2018
AUS
AERO2SPADE Operation

20 AFTER SALES SUPPORT
 [e-mail]  1300 130 570
MODEL:AERO2SPADE PRODUCT CODE: 59540 04/2018
VIII. Cleaning and maintenance
mAttention! Always disconnect the device from the air supply before starting any
cleaning work.
Cleaning
• Keep the device free of dirt and dust as far as possible. Wipe the device with a clean
cloth or blow it with compressed air at low pressure.
• We recommend that you clean the device immediately each time you have nished
using it.
• Clean the device regularly with a moist cloth and some soft soap. Do not use clean-
ing agents or solvents; these could attack the plastic parts of the device. Ensure
that no water can seep into the device.
Maintenance
If the regular oil supply to the device is assured, the device is maintenance-free.
IX. Technical data
Overall length (without connected tool) 820 mm
Operating pressure 6.3 bar
Air consumption, min. approx. 220 l/min
Air consumption, max. (at 6.3 bar) 280 l/min
Stroke rate, approx. 1800 - 1900 bpm
Tool receiver 18 mm
Recommended hose internal diameter 9 mm
Sound and vibration
The noise and vibration values have been developed with a standardised measure-
ment process.
Sound pressure level LpA 89.59 dB(A)
Uncertainty KpA 3 dB
Guaranteed sound power level LWA 105 dB(A)
measured sound power level LWA 100.59 dB(A)
Uncertainty KWA 3 dB
Vibration left handle ahd 16.22 m/s2
AUS
Cleaning and maintenance/Technical data AERO2SPADE
1300 855 831

AUS
AERO2SPADE Technical data/Storage/Transport/Disposal and recycling
AFTER SALES SUPPORT 21
 1300 130 570  [e-mail]
MODEL:AERO2SPADE PRODUCT CODE: 59540 04/2018
Vibration right handle ahd 15.53 m/s2
Uncertainty K 1.5 m/s2
Wear ear-muffs.
The impact of noise can cause damage to hearing. Keep the noise emissions and
vibrations to a minimum.
• Only use devices which are in perfect working order.
• Service and clean the device regularly.
• Adapt your working style to suit the device.
• Do not overload the device.
• Have the device serviced whenever necessary.
• Switch the device off when it is not in use.
• Wear protective gloves
X. Storage/Transport
Store the device and accessories out of children’s reach in a dark and dry place
above freezing temperature. The ideal storage temperature is between 5 and 30 °C.
If possible store the device, manual and accessories in the original packaging. This will
ensure you will always have all information and parts at your disposal when required.
Transport
Pack the device carefully or use the original packaging in order to prevent damage
during transport.
XI. Disposal and recycling
The device is supplied in packaging to prevent it from being damaged in transit. The
raw materials in this packaging can be reused or recycled. The device and its acces-
sories are made of various types of material, such as metal and plastic. Never place
defective devices in your household refuse. The devices should be taken to a suitable
collection centre for proper disposal. If you do not know the whereabouts of such a
collection point, you should contact your local council ofces.
1300 855 831

XII. Troubleshooting
Problem Possible Cause Help
Device does
not start or lacks
power.
Piston jammed (rusted) in the
housing due to a lack of oil.
Press the piston back with a strik-
ing bolt through the tool receiver.
Introduce a little oil into the
connection hose and into the tool
receiver.
Run the device briey without a
tool.
Repeat this process a few times.
Dirt has penetrated via the air
hose.
Repair must be carried out by a
specialist workshop.
Too much lubricating oil used or
water in the striking mechanism.
Run the device briey without a
tool.
Pressing force too high. Grease tool receiver and reduce
pressing force.
Output power of the air source
too low.
Use an air source with a higher
output power.
Tool no longer
latches into the
tool receiver or
does not lock into
place.
Tool or tool receiver worn out.
(Most often caused by excessive
pressure or no-load strokes).
Repair must be carried out by a
specialist workshop.
Tool cannot be in-
serted or removed.
Dirt in the sliding sleeve pre-
vents unlocking.
Repair/cleaning must be carried
out by a specialist workshop.
Device operates
continuously
without the trigger
lever being actu-
ated.
Valve defective. Repair must be carried out by a
specialist workshop.
AUS
Troubleshooting AERO2SPADE
22 AFTER SALES SUPPORT
 [e-mail]  1300 130 570
MODEL:AERO2SPADE PRODUCT CODE: 59540 04/2018
1300 855 831

AUS
AERO2SPADE
AFTER SALES SUPPORT 23
 1300 130 570  [e-mail]
MODEL:AERO2SPADE PRODUCT CODE: 59540 04/2018
1300 855 831

24 AFTER SALES SUPPORT
 [e-mail]  1300 130 570
MODEL:AERO2SPADE PRODUCT CODE: 59540 04/2018
AUS
AERO2SPADE
1300 855 831
