OWNER’S
MANUAL
Schwinn® A.C.™ Power
Core Health & Fitness

Page 1
INTRODUCTION ............................................................................................................................................. 2
PRODUCT SPOTLIGHT ............................................................................................................................................. 3
Features .......................................................................................... 4
SAFETY INSTRUCTIONS ............................................................................................................................................. 5
Compliance and Certications .......................................................................................... 6
Important Label Locations .......................................................................................... 7
OPERATIONS ............................................................................................................................................. 8
Locking Pop Pins / Seatpost & Handlebar Adjustment....................................................... 9
Emergency Stop ........................................................................................10
Slider Tension Knob ........................................................................................11
SUPPORT & SERVICE ...........................................................................................................................................12
PREVENTATIVE MAINTENANCE ...........................................................................................................................................13
TABLE OF CONTENTS

Page 2
Congratulations on the purchase of a Schwinn A.C.™ Power! This manual will acquaint you with the
operation, safety, and maintenance of your Schwinn® group cycling bike, and covers the following
units:
• 9-7300 - A.C.™ Power & A.C.™ Power Custom
Refer to the Assembly Instructions in the box for your specic model for proper assembly of your
bike.
INTRODUCTION

Page 3
9-7300
9-7300
A.C.™ Power
A.C.™ Power Custom
Overall Weight Width Length Height User Weight
110 lbs (50 kg) 54” (137 cm) 54” (137 cm) 51” (130 cm) 0-350 lbs (0-159 kgs)
Product Conformity
• EN957-1 (S,H)
• EN957-10 (S,H)
• ASTM F1250-13
• ASTM F2276-10
• The A.C.™ Power contains an on-board generator which powers the Echelon2G console, eliminating the need
to replace batteries as part of its maintenance schedule. As the rider begins to pedal, an LED light illuminates to
provide positive feedback that the generator is powering the console.
• If a battery replacement is required, they are available through Core Connect. Regular use of the A.C.™ Power is
ideal to maintain a charge to the internal battery and maximize its life.
All products may be covered by US and Foreign Patents and Patents Pending.
PRODUCT SPOTLIGHT

Page 4
Features
A
C
K
B
D
L
OM N
E
I
F
J
G
H
A
C
K
B
D
L
OM N
E
I
F
J
G
H
ALocking Pop Pin BSeat Post CSeat Slider
DSeat EBrake Adjustment Knob and
Emergency Brake FHandlebar Slider
GHandlebar HEchelon2G Console IFlywheel
JStabilizer KLeveling Foot LTransport Wheels
MGenerator Housing NPedal with Morse Taper O4iiii Crank

Page 5
SAFETY INSTRUCTIONS
This symbol indicates a potentially hazardous situation, which, if not avoided, could result in
death or serious injury.
Before using this equipment, obey the following warnings:
• This machine is not intended to be used by children.
• It is not intended to be used by persons with reduced physical, sensory, or mental
capabilities or lack of experience and knowledge, unless given instruction and under the
personal supervision concerning use of the machine by a person responsible for their
safety. Do not leave children unsupervised around the machine
• Consult a physician before you start an exercise program. Stop exercising if you feel pain
or tightness in your chest, become short of breath, or feel faint. Contact your doctor before
you use the machine again. Use the value calculated or measured by the console for
reference purposes only.
• If you have a pacemaker or other implanted electronic device, consult your physician
before using a wireless chest strap or other telemetric heart rate monitor.
• Do not use or put the device into service until it has been fully assembled and inspected
for correct performance in accordance with the Owner’s Manual and Installation Guide.
Caution: Read and understand the complete Owner’s Manual supplied with the device before
using the device. Keep the Owner’s Manual for future reference.
Danger: There is risk of explosion if the battery is replaced with an incorrect type. Dispose of
used batteries according to the manufacturer’s instructions.
Danger: Pedals that have not been tested and qualied by Schwinn should never be used on
Schwinn bikes. Unqualied pedals can lead to pedal failure and serious injury to the rider.
Warning: Do not open the generator chain guard unless instructed to by a Service Bulletin.
Caution: Refer to Echelon2G Manual at https://support.corehandf.com/Echelon2G for further
safety information on the console.

Page 6
Compliance and Certications
FCC Compliance
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide a reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that inter-
ference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment o and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
Note: That changes or modications not expressly approved by the party responsible for compli-
ance could void the user’s authority to operate the equipment.
FCC ID: 06RFIT1
DO NOT dispose of this product as refuse. This product is to be recycled. For information on the
proper method of disposal, contact a Customer Service representative. Contact information is avail-
able in the Contacts section of this manual. For additional information, please visit: www.SchwinnE-
quipment.com.
• This console is for indoor use only.
• This device conforms to European safety standards
• This console is ANT+ certied.
NOTE: The users’ device must be ANT+ compatible and capable of receiving the data les broadcast
by the ANT+ chip. Users should consult with the documentation for their device, or check the ANT+
website at www.thisisant.com for compatibility.
Patent Information: This product may be covered by US and foreign patents and patents pending.

Page 7
Important Label Locations
Serial Label
Warning Label
Serial Label
Warning Label

Page 8
Locking Pop Pins
Emergency Stop
Handlebar
Seatpost
Slider Tension Knob
Locking Pop Pins
Emergency Stop
Handlebar
Seatpost
Slider Tension Knob
To operate the features shown, see the directions on the following pages.
For bike t and coaching resources, refer to https://www.corehandf.com/schwinn-resources/
For Schwinn Group Cycle Education and Certication, refer to https://corehandf.com/certication
OPERATIONS

Page 9
Locking Pop Pins / Seatpost & Handlebar Adjustment
1. Turn pin counterclockwise and pull to loosen.
2. Adjust tube.
Warning: Do not lift the Seatpost or
Handlebar posts above the stop mark on the
tube.
3. Release pin and turn clockwise to lock. Tighten
knob until snug and post is secure without
wobble.

Page 10
Emergency Stop
1. Push down on red knob to stop ywheel.

Page 11
Slider Tension Knob
1. Turn pin counterclockwise to loosen.
2. Adjust slider.
3. Turn pin clockwise to lock. Tighten knob until
snug and post is secure without wobble.

Page 12
SUPPORT & SERVICE
• 24 hour self service access
• Real time communication
• Seamless Order Experience
• Intuitive user experience
• Mobile friendly technology
• Asset management
• Automated partner payment
• Seamless access to technical library
• Transparency on service performance
• Fast, reliable, quality service every time
CORE
CONNECT
Get world class support for all brands with our new support portal, Core
Connect. Get help with your general inquiries, warranty registration,
preventative maintenance, service requests and parts orders. You can
also make seamless service requests, get real time updates, manage your
assets and intuitively order parts for all brands direct from the site.
support.corehandf.com
Contact Information
CORE HEALTH & FITNESS
4400 NE 77th Avenue, Suite 300
Vancouver, WA 98662
Telephone: [phone]
http://www.corehandf.com
Customer Support
Contact your local distributor, or Core Health & Fitness
directly at: 1-800-503-1221
[e-mail]
Warranty information: https://corehandf.com/warranty

Page 13
Preventive maintenance (PM) is a schedule of planned maintenance actions aimed at the prevention
of failures. PM is the best way to preserve and enhance equipment reliability by keeping key com-
ponents clean and free of debris. PM activities may include cleaning, vacuuming, visual inspections
of key components, lubrication, etc. The better your PM program is, the more dramatically you can
increase the life of your product and signicantly reduce equipment failures.
To keep it in top condition, perform regular daily, weekly, and monthly preventative maintenance
routines outlined below. It is the sole responsibility of the owner of this equipment to ensure that
regular maintenance is performed. Worn or damaged parts must be replaced immediately, or the
equipment removed from service until the repair is made.
Maintenance Schedule
Some types of PM need to be performed more often than others. The frequency of PM depends a
great deal on the use and environment of the unit. Core has a baseline of procedures that should
be performed at pre-determined intervals as shown below, but it is imperative to understand that
this is a baseline and PM schedules should be adapted to the environment and usage that the unit
receives. Refer to Echelon2G Manual at https://support.corehandf.com/Echelon2G for further main-
tenance information on the console.
Daily Weekly Monthly Bi-Annually
General Maintenance
Inspect each console, sensor, and cables for loose parts or
damage. Adjust or replace as necessary. X
Inspect for loose assemblies, nuts or bolts and tighten as
necessary. X
Remove and replace any components that are damaged or
deemed unsafe. X
Inspect Pedal Bolts1X
Check ywheel alignment, realign ywheel nuts as necessary X
Check Powermeter battery level in 4iiii App2X
Inspect seat for wear X
Inspect Pedals3X
Tighten Seat Hardware X
Inspect and tighten pedal toe clips and shoe straps X
Inspect leveling feet X
PREVENTATIVE MAINTENANCE

Page 14
Daily Weekly Monthly Bi-Annually
Clean and seal frame4X
Lubricate horizontal and vertical seat sliders5X
Inspect welds for any signs of cracking X
Calibration
Perform 4iii Calibration X
Cleaning
Wipe down and clean Bike and Frame X
Clean Console6X
1 - Verify that pedal bolts are tight after the rst 10 hours of use and every 100 hours of use thereafter. Pedal-to-crank-arm bolt torque is 33-37 ft-lbs
2 - See Fig. 1 for location of indicator in the 4iiii App. Replace batteries when low.
3 - Excessive side-to-side movement or bearing resistance indicates the pedals need to be replaced.
4 - Use water with a non-abrasive soap, car wash soap, or bike cleaner soap to clean. Wipe with water and dry. Seal with wax or bike polish.
5 - Dry lm lubricant with PTFE or wet lm lubricant with PTFE may be used. These products can be purchased online via pike companies, at bike shops, and at some hard-
ware stores. Apply a layer using a cloth to clean up excess.
6 - Wipe console with a soft, non-abrasive cloth to remove all sweat after each use. Use a soft, non-abrasive cloth and mild spray cleanser to clean the console. Never use
abrasive cleaning liquids, cleaning liquids with an oil base, ammonia, or alcohol.
Preventive Maintenance Cautions
• While maintaining equipment you will want to avoid spraying any
liquids directly onto any surface of the unit. Always spray cleaning
solutions onto a clean towel rst then wipe the unit.
• Do not use glass cleaners or any other household cleaners on the
console. The console should be cleaned with a damp cloth and dried
on a daily basis. Cleaning solutions can be made of a 5:1 dilution ratio,
where 5 parts water are mixed with 1 part of Simple Green®, Fan-
tastik®, or 409®. Do not spray water, or cleaner directly onto console
surfaces.
• Danger: Pedals that have not been tested and qualied by
Schwinn should never be used on Schwinn bikes. Unqualied pedals
can lead to pedal failure and serious injury to the rider.
Fig. 1

© 2019 CORE HEALTH & FITNESS, LLC PART NUMBER 620-8602, REV E
