SDC Excel E1200 User manual

P:\INST INSTRUCTIONS\EMLOCKS\INST-E1200 REV A.4 10-21 Page 1
Any suggestions or comments to this instruction or
product are welcome. Please contact us through
our website or email [e-mail]
E1200
MAGNETIC LOCK
Use properly fused U. L. Listed Power Supply
Do not install a diode in parallel with any magnetic lock. A diode
will cause a delay when releasing the door and residual magnetism
to occur.
Although SDC recommends the use of a DC power supply, a
transformer with an adjacent mounted full wave bridge rectifier may
be used. A significant drop will occur when using a full wave
bridge rectifier.
Any low voltage condition will cause erratic operation of the
optional board sensor.
When using a full wave bridge rectifier all access controls and/or
release contacts must be located between the EMlock and rectifier
to ensure quick release.
Dual Voltage:
Power Consumption:
DS Door Status Sensor:
LS Lock Status Sensor:
Outswing
Quick Mount
Interlocking
Mounting Assembly
Mounting Screws
Armature
Interlocking
Mounting Plate
Frame
SECURITY DOOR CONTROLS ■ WWW.SDCSECURITY.COM
[t] 800.413.8783 ■ 805.494.0622 ■ E-mail: [email protected] ■ 801 Avenida Acaso, Camarillo, CA 93012 ■ PO Box 3670, Camarillo, CA 93011
INST INSTRUCTIONSRUCTIONS
Electrical Instructions: Electrical Specifications:
12 or 24VDC
.505mA @ 12VDC
.260mA @ 24VDC
SPDT, 500mA @ 30VDC
SPDT, 2A @ 30VDC

P:\INST INSTRUCTIONS\EMLOCKS\INST-E1200 REV A.4 10-21 Page 2
1. Inspect the frame header to determine if mounting accessories are required (refer to page 4).
2. Fold template as indicated on dotted line. For single doors locate template against the door and header on the
lock jamb side of the frame.
3. Mark and drill holes as indicated by the template.
4. Mount armature to door.
STEP 4
STEPS 2 & 3
5. Install magnet onto the header with the magnetic stripes towards the door side of the stop.
Assure that the magnet and armature line up properly, then tighten down ALL mounting screws.
STEP 5
SECURITY DOOR CONTROLS ■ WWW.SDCSECURITY.COM
[t] 800.413.8783 ■ 805.494.0622 ■ E-mail: [email protected] ■ 801 Avenida Acaso, Camarillo, CA 93012 ■ PO Box 3670, Camarillo, CA 93011
HOLLOW METAL DOOR
From Sexnut side of door, drill exactly 1/2” hole thru one metal
thickness only. From Armature side of door, drill 5/8” hole to insert
reinforcement tube. Press in sexnut and reinforcement tube all the
way and mount armature to door using hardware provided.
REINFORCEMENT
TUBE 1-3/4“ HOLLOW
METAL DOOR
5/8“ DRILL
STEEL WASHER 2X
RUBBER WASHER
5/16-18 SOC HD
SCREW
WITH 3/16 (5MM)
ALLEN HEX
ARMATURE 1/2” DRILL
SEXNUT

P:\INST INSTRUCTIONS\EMLOCKS\INST-E1200 REV A.4 10-21 Page 3
6. Holding the magnet housing at each end, engage the entire length of the interlock detail, by pushing towards the
door. Tap with a soft hammer to ensure proper alignment and engagement.
7. Select jumper position for 12VDC or 24VDC. Connect power to magnetic lock.
8. Test operation. When all is operating properly, tighten all screws as
shown. Install security pins and screws as shown. Install anti-
tamper plugs over socket head screws using a soft hammer to
avoid damage to the housing.
SECURITY DOOR CONTROLS ■ WWW.SDCSECURITY.COM
[t] 800.413.8783 ■ 805.494.0622 ■ E-mail: [email protected] ■ 801 Avenida Acaso, Camarillo, CA 93012 ■ PO Box 3670, Camarillo, CA 93011
COM
NC
NO
Door Position Sensor (Reed switch)
ORANGE (open with door closed)
YELLOW (closed with door closed)
WHITE
A/C
MAINS
POWER
SUPPLY
12VDC
or
24VDC
SWITCH or
ACCESS
CONTROL
+
-
ATTACH THE RED SIDE OF THE CONNECTOR HERE
FOR A GREEN LED ENERGIZED & SECURE (RED=ENERGIZED & UNSECURE)
ATTACH THE GREEN SIDE OF THE CONNECTOR HERE
FOR A RED LED ENERGIZED AND UNSECURE (GREEN=ENERGIZED & SECURE)
R G B
W
G B R
Door
Position
Sensor
Lock
Status
Switch
(Relay)
Power
Supply
Voltage Jumper
8
NC
7 C
6
NO
5
NC
4
C
3
NO
2 -
1
+
12VDC 24VDC
LED RED
GRN
STEP 6
CAUTION: The lock body must be held in place until secured with mounting screws. Secure socket head screws
provided inside the housing at each end. Start screws into threads carefully to avoid stripping the threads. Check
alignment and tighten screws. Pull wires through frame, mounting plate and magnet housing

P:\INST INSTRUCTIONS\EMLOCKS\INST-E1200 REV A.4 10-21 Page 4
 Do not touch the lock face with your hands.
 Clean lock face with Scotch-Brite pad by 3M (do not use
sandpaper).
 Apply a thin film of rust inhibitor (LPS-3) on lock face.
 Repeat application on armature plate.
Supplied Mounting Hardware
MOUNTING ACCESSORIES:
SECURITY DOOR CONTROLS ■ WWW.SDCSECURITY.COM
[t] 800.413.8783 ■ 805.494.0622 ■ E-mail: [email protected] ■ 801 Avenida Acaso, Camarillo, CA 93012 ■ PO Box 3670, Camarillo, CA 93011
ANGLE BRACKET
E12L
Inches: 10.5" L x 0.5" H x 1" D
STOP FILLER PLATE
FP15
Lock: 10-1/2" L x 2-7/8" H x 1-5/8" D
Filler Plate: 11" L x 1-1/4 H x 5/8" D
GLASS DOOR ARMATURE BRACKET
E12U
For use with Model E600 Series
Field adjustable for glass thickness
TOP JAMB MOUNTING BRACKET
E12Z
For use with Model E1200 Series
To maintain surface plating from corrosion:
OPTIONAL MOUNTING HARDWARE:
