SDMO R44C3 Operating instructions

User and maintenance manual
for generating sets
R44
C
3
33504024301NE_0_1

1. Preface .................................................................................................................................................................................................. 3
1.1. General recommendations....................................................................................................................................................... 3
1.2. Pictograms and their meanings................................................................................................................................................ 4
1.3. Instructions and safety regulations........................................................................................................................................... 6
1.3.1 General advice ......................................................................................................................................................................... 6
1.3.2 Risks related to exhaust gases and fuels................................................................................................................................. 7
1.3.3 Risks related to toxic products.................................................................................................................................................. 7
1.3.4 Risk of fire, burns and explosion............................................................................................................................................... 8
1.3.5 Risks related to electrical networks .......................................................................................................................................... 8
1.3.6 Dangers presented by electric currents (first aid)..................................................................................................................... 9
1.3.7 Risks related to moving the set................................................................................................................................................. 9
1.3.8 Risks related to noise .............................................................................................................................................................. 9
2. General description.............................................................................................................................................................................. 10
2.1. Technical specifications......................................................................................................................................................... 13
2.2. Identifying sets....................................................................................................................................................................... 15
2.3. Fluid retention........................................................................................................................................................................ 16
2.4. Fuel and consumables........................................................................................................................................................... 16
2.4.1 Specifications ......................................................................................................................................................................... 17
2.4.1.1. Oil grades ................................................................................................................................................................. 17
2.4.1.2. Specifications of coolants ......................................................................................................................................... 18
3. Installation-Connections ...................................................................................................................................................................... 19
3.1. Unloading............................................................................................................................................................................... 19
3.1.1 Safety during unloading.......................................................................................................................................................... 19
3.1.2 Instructions for unloading ....................................................................................................................................................... 20
3.2. Choice of location .................................................................................................................................................................. 21
3.3. Moving the genset.................................................................................................................................................................. 21
3.4. Connections........................................................................................................................................................................... 22
3.4.1 Connections - general information.......................................................................................................................................... 22
3.4.2 Power cables.......................................................................................................................................................................... 22
3.4.3 Power connections................................................................................................................................................................. 23
3.4.4 Battery installation ................................................................................................................................................................. 24
3.5. Protection for individuals and equipment ............................................................................................................................... 24
3.5.1 Earth connection..................................................................................................................................................................... 24
3.5.2 Earthing system principle ....................................................................................................................................................... 25
3.5.3 TT system............................................................................................................................................................................... 26
3.5.4 Differential protection.............................................................................................................................................................. 26
3.5.5 Adjusting the genset differential protection............................................................................................................................. 27
3.6. Connection summary............................................................................................................................................................. 28
3.7. Special arrangements............................................................................................................................................................ 29
4. Trailer .................................................................................................................................................................................................. 29
4.1. Trailer linkage ........................................................................................................................................................................ 29
4.2. Check before towing.............................................................................................................................................................. 29
4.3. Operation............................................................................................................................................................................... 30
4.4. Unhitching the trailer.............................................................................................................................................................. 30
4.5. Implementation for installation ............................................................................................................................................... 31
4.6. Break transmission adjustment.............................................................................................................................................. 31
4.7. Faults and repairs.................................................................................................................................................................. 33
4.8. Electrical connection diagram................................................................................................................................................ 34
4.9. Complete wheels technical information.................................................................................................................................. 34
5. Preparation before operating the set................................................................................................................................................... 35
5.1. Installation checks.................................................................................................................................................................. 35
5.2. Checks after starting the generating set ................................................................................................................................ 35
1/202

6. Using the generator set ....................................................................................................................................................................... 36
6.1. Pre-Start Inspection............................................................................................................................................................... 36
6.2. Generator set with NEXYS control panel............................................................................................................................... 39
6.2.1 Control panel presentation ..................................................................................................................................................... 39
6.2.1.1. Introduction to pictograms......................................................................................................................................... 40
6.2.2 Manual starting....................................................................................................................................................................... 41
6.2.3 Switching off .......................................................................................................................................................................... 42
6.2.4 Alarms and faults................................................................................................................................................................... 42
6.2.5 Faults and alarms - Details..................................................................................................................................................... 42
6.3. Generator set with TELYS control panel................................................................................................................................ 44
6.3.1 Control panel presentation ..................................................................................................................................................... 44
6.3.1.1. View of the front panel.............................................................................................................................................. 44
6.3.1.2. Description of the screen.......................................................................................................................................... 46
6.3.1.3. Description of the pictograms in zone 1.................................................................................................................... 47
6.3.1.4. Description of the pictograms in zone 2.................................................................................................................... 48
6.3.1.5. Description of the pictograms in zone 3.................................................................................................................... 49
6.3.1.6. Display of messages in zone 4 ................................................................................................................................. 51
6.3.2 Starting................................................................................................................................................................................... 55
6.3.3 Switching off .......................................................................................................................................................................... 56
6.3.4 Alarms and faults.................................................................................................................................................................... 56
6.3.4.1. Viewing alarms and faults......................................................................................................................................... 56
6.3.4.2. Activation of an alarm or fault ................................................................................................................................... 57
6.3.4.3. Activation of an alarm and a fault.............................................................................................................................. 58
6.3.4.4. Engine fault codes display........................................................................................................................................ 59
6.3.4.5. Horn reset................................................................................................................................................................. 60
7. Maintenance schedule......................................................................................................................................................................... 60
7.1. Reminder of use..................................................................................................................................................................... 60
7.2. Maintenance safety instructions............................................................................................................................................. 60
7.3. Table of maintenance operations........................................................................................................................................... 61
7.4. Fault finding ........................................................................................................................................................................... 62
7.5. No load and under load tests................................................................................................................................................. 62
8. Battery................................................................................................................................................................................................. 63
8.1. Storage and transport ............................................................................................................................................................ 63
8.2. Battery setting into service..................................................................................................................................................... 64
8.3. Check..................................................................................................................................................................................... 64
8.4. Load preconization................................................................................................................................................................. 65
8.5. Faults and remedies .............................................................................................................................................................. 66
9. Appendix.............................................................................................................................................................................................. 67
9.1. Appendix A – Engine user and maintenance manual ............................................................................................................ 67
9.2. Appendix B - Alternator user and maintenance manual.......................................................................................................165
2/202

1. Preface
1.1.General recommendations
Thank you for choosing an electrical generating set from our company.
This manual has been designed to help you operate and maintain your electrical generating set correctly.
The information contained in this manual is taken from technical data available at the time of print. In line with our policy of continually
improving the quality of our products, this information may be amended without warning.
Read the safety instructions attentively in order to prevent any accidents, faults or damage. These instructions must always be
followed.
You are likely to encounter several warning symbols in this manual.
This symbol indicates an immediate danger to human health and life in case of exposure. Failure to follow
the corresponding advice entails serious consequences for human health and life in case of exposure.
Danger
This symbol draws attention to the potential risks to human health and life in case of exposure. Failure to
follow the corresponding advice entails serious consequences for human health and life in case of exposure.
Warning
This symbol indicates a dangerous situation if the warning is not heeded.
Failure to follow the corresponding advice risks resulting in minor injury of personnel or damage to any other
object in case of exposure.
Important
In order to obtain optimum efficiency and the longest possible life for the electrical generating sets, maintenance operations must be
carried out according to the periods indicated in the attached preventative maintenance tables. If the electrical generating set is used
under dusty or unfavourable conditions, some of these periods will be shorter.
Ensure that all repairs and adjustments are carried out by personnel who have received appropriate training. Dealers have this
qualification, and can answer all of your questions. They can also supply you with spare parts and other services.
The left and right sides can be seen from the back of the electrical generating set (the radiator is at the front).
Our electrical generating sets have been designed so that damaged or worn parts can be replaced by new or reconditioned parts
thereby reducing the out of action period to a minimum.
For any replacement of parts, contact your nearest dealer for our company who will have the necessary equipment and can offer
properly trained and informed staff to carry out maintenance, parts replacement and even total reconditioning of generating sets.
Contact your local dealer for the available repair manuals and to make the necessary arrangements for training personnel in
implementation and maintenance.
Some user and maintenance manuals for the engines fitted to generating sets cover control units and
include the start-up and shutdown procedures for the engines.
As the generating sets are fitted with control units that are specific to the generating sets, only the
information that appears in the documentation for the generating sets' control units should be taken into
consideration.
In addition, according to the manufacturing criteria of the generating sets, some engines may be fitted with
specific electrical wiring different to that described in the engine documentation.
Important
3/202

1.2.Pictograms and their meanings
Safety notices are clearly mounted on the equipment to draw the operator's or maintenance technician's attention to the potential
dangers and explain the action to be taken in the interest of safety. These notices are reproduced in this publication for ease of
identification by the operator.
Replace any notice that is missing or illegible.
Warning: danger Publications delivered
with the generating set
must be referred to
Warning: risk of explosion
Warning: risk of
electric shock
Protective clothing
must be worn
Naked flames and
unprotected lights
prohibited.
No smoking
Warning: toxic
materials
Your eyes and ears
must be protected
Entry prohibited to non-
authorised persons
Warning:
pressurised fluids
Periodic maintenance
must be carried out
Jet washing prohibited
Warning: high
temperature, risk
of burns
Battery level must be
checked
Earth
Warning: rotating
or moving parts
(risk of getting
caught in the
machinery)
Lifting point required
Warning: corrosive product
Figure 1.1: Pictograms and their meanings
4/202

Battery isolating
switch
Fuel
External fuel connections
Inspection hatch
Retention container
drainage
Fuel drainage
Oil drainage Oil filling Coolant filling
Coolant drainage
Forklift required for
lifting Bulk tank level high
Fuel supply selection valves During any operation on the
batteries, wear protective
glasses and protective clothing
Rinse any splashes of acid on the
skin or in the eyes using clean water.
Consult a doctor immediately.
Contaminated clothes must be
washed with water
Important: refer to the documentation accompanying the generating set.
Warning: emission of toxic exhaust gases. Do not use in a confined or badly
ventilated area.

Figure 1.1 ( continued ) : Pictograms and their meanings
5/202

1.3.Instructions and safety regulations
THESE SAFETY GUIDELINES ARE IMPORTANT
If you do not understand or have any questions about any point in this manual, contact your dealer who will explain it to you or give you
a demonstration. A list of risks and precautionary measures to take follows. You should also refer to any local and national regulations
that apply in accordance with your own jurisdiction.
KEEP THIS MANUAL
This manual contains important instructions which must be followed when installing or carrying out maintenance on a generating set or
batteries.
1.3.1 General advice
Use
The operating and safety instructions must be made known to operating personnel. They will be regularly updated.
Read and understand the manuals provided with the generating set, pump unit or lighting column properly. The manufacturer's
instructions must remain at the disposal of technicians, if possible in situ.
The facility must be operated under the direct or indirect supervision of a person appointed by the operator, who is familiar with the
operation of the facility, and the dangers and drawbacks of the products used or stored in the facility.
Do not wear loose clothing, or get close to machines in operation. Note that the fans are not clearly visible when the engine is
running.
Warn personnel present to keep their distance during operation.
Do not run the generating set, pump unit or lighting column without refitting the protective covers and closing all the access doors.
Never let a child touch the generating set, pump unit or lighting column, even when shut down.
Avoid operating the generating set, pump unit or lighting tower in the presence of animals (disturbance, scares, etc.).
Engage the parking brake when the generating set or lighting tower on its trailer is installed on the operating site. When chocking
the trailer on a slope; ensure that there is nobody in the path of the trailer.
Never start the engine without an air filter or exhaust.
Engine with turbocharger: never start the engine without fitting the air filter. The compressor wheel rotating inside the turbocharger
may cause serious bodily injury. Foreign objects in the inlet pipe may cause mechanical damage.
Engine with air preheating (starting components): never use a starting spray or any other similar starter assistance product. Upon
contact with the starting component, an explosion may occur in the inlet tube, causing bodily injury.
Do not touch the lighting column lights when they are switched on.
Maintenance
Follow the maintenance table and its instructions.
Always use tools in good condition which are suited to the work to be done. Ensure you have understood the instructions before
beginning any operation.
Goggles should be worn when carrying out maintenance operations and watches, bracelets etc. should be removed.
Fit only original parts.
Disconnect the battery and the pneumatic starter (if fitted) before undertaking any repairs, to prevent the engine from starting
accidentally. Fit a panel over the controls to prevent any attempt to start.
Only use the correct crankshaft turning techniques for turning the crankshaft manually. Do not try to turn the crankshaft by pulling it
or levering the fan. This method may cause serious bodily or material damage, or damage the vanes of the fan, reducing the
service life of the fan.
Clean off any trace of oil, fuel or coolant using a clean cloth.
Do not use a soapy solution containing either chlorine or ammonia, as these two chemicals prevent bubble formation.
Never use petrol or other inflammable substances to clean the parts. Use only approved cleaning solvents.
Do not use a high pressure cleaner for cleaning the engine and equipment. The radiator, hoses, electrical components, etc. may be
damaged.
Avoid accidental contact with parts at high temperatures (exhaust manifold, exhaust).
Before any maintenance operation on a lighting column light, cut the electrical power supply and wait for the bulbs to cool down.
Consumables
Observe regulations in force concerning use of fuel before using your generating set, pump unit or lighting tower.
Under no circumstances use seawater or any other corrosive or electrolytic product in the cooling circuit.
Environment
The operator must take the necessary measures to comply with the aesthetics of the site of use. The whole site must be maintained
in a good state of cleanliness.
The premises must be kept clean, and be regularly cleaned so as to avoid accumulation of dangerous materials or pollutants and
dust, which could ignite or cause an explosion. The cleaning equipment must be suited to the risks posed by the products and dust.
The presence of dangerous or combustible materials inside premises housing combustion devices shall be limited to the operating
requirements.
Facilities must be operated under the constant supervision of a qualified person, who must regularly check that the safety devices
are operating correctly and ensure that the combustion devices have the correct fuel supply.
Apart from the combustion devices, it is prohibited to use fire in any form. This restriction must be clearly displayed.
6/202

Spreading of waste water, sludge and waste is prohibited.
The fuels to be used must correspond to those featured in the declaration file and the specifications recommended by the
combustion device manufacturer.
The fuel is considered to remain in the same physical state as when it is introduced into the combustion chamber.
Burning of waste in the open air is prohibited.
Always protect your hands when checking for leaks. Pressurised liquids may penetrate body tissue and cause serious damage.
Risk of blood contamination.
Drain and dispose of engine oil in a specially provided container (fuel distributors can collect your used oil).
Except by special agreement, once closed, the gas supply main unit must only be re-opened by the gas distributor. However, the
user may access it under certain conditions. Check these for each site.
1.3.2 Risks related to exhaust gases and fuels
The carbon monoxide present in exhaust gases may cause death if the concentration levels in the air
breathed are too high.
Always use generating sets, pump units or lighting towers in a well-ventilated place where gases cannot
accumulate.
In case of indoor use:
Be sure to evacuate exhaust gases outdoors.
Provide appropriate ventilation so that personnel present are not affected.
Danger
Observe the local regulations in force for generating sets, pump units or lighting towers, as well as local regulations for use of fuel
(petrol, diesel fuel and gas) before using your generating set, pump unit or lighting tower.
Fuel filling should be carried out when the engine is off (except for generating sets with an automatic filling system).
Engine exhaust gases are toxic: do not run the generating set, pump unit or lighting column in unventilated premises. If installed in
a ventilated room, additional requirements for fire and explosion protection must be observed.
A leaking burnt gas exhaust may increase the sound level of the generating set, pump unit or lighting column. To check on its
efficiency, regularly examine the burnt gas exhaust.
Pipes must be replaced as soon as their condition demands it.
1.3.3 Risks related to toxic products
The corrosion inhibitor contains alkali.
Do not swallow it.
This substance should not come into contact with the
eyes. In the event of contact with the eyes, rinse
immediately with plenty of water for at least 15
minutes.
Avoid prolonged or repeated contact with the skin. In
the event of contact with the skin, wash thoroughly
with water and soap. CONSULT A DOCTOR
IMMEDIATELY. KEEP THE PRODUCT OUT OF
THE REACH OF CHILDREN.
The anti-rust product is toxic and dangerous if
absorbed. Avoid all contact with the skin and eyes.
Read the instructions on the packaging.
Glycol is a toxic product and dangerous if absorbed.
Avoid all contact with the skin and eyes. Read the
instructions on the packaging.
Warning
Caution: fuels and oils are dangerous to inhale. Ensure proper ventilation, and use a protective mask.
Never expose the equipment to liquid splashes or rainfall, and do not place it on wet ground.
The battery electrolyte is harmful to skin and especially eyes. If splashes get into eyes, rinse immediately with running water and/or
a 10% diluted boric acid solution.
Wear protective eyewear and strong base resistant gloves for handling the electrolyte.
7/202

1.3.4 Risk of fire, burns and explosion
The engine should not be operated in environments containing explosive products. As not all of the
electrical and mechanical components are shielded, there is a risk of sparks forming.
Danger
Make sure not to create sparks or flames, and not to smoke near the batteries, as the electrolyte gases are highly flammable
(especially if the battery is charging). Their acid also poses a risk to the skin, and in particular to the eyes.
Never cover the generating set, pump unit or lighting tower with any material during operation or just after shutdown (wait for the
engine to cool).
Do not touch hot parts such as the exhaust pipe, or put combustible materials on it.
Keep all flammable or explosive materials (e.g. petrol, oil, cloth, etc.) out of the way when the set is running.
Proper ventilation is required for your generating set, pump unit or lighting column to work properly. Without this ventilation, the
engine would very quickly rise to an excessively high temperature, causing accidents or damage to the equipment and to
surrounding property.
Do not remove the radiator cap if the engine is hot and the coolant is pressurised, due to risks of burns.
Depressurise the air, oil and cooling circuits before removing or disconnecting all the fittings, pipes or connected components.
Watch out for the possible presence of pressure when disconnecting a device from a pressurised system. Do not try to find
pressure leaks by hand. Oil at high pressure can cause bodily damage.
Some preservative oils are flammable. Also, some are dangerous to inhale. Ensure proper ventilation. Use a protective mask.
Hot oil causes burns. Avoid contact with hot oil. Check that the system is no longer pressurised before carrying out any procedures.
Never start or run the engine with the oil filler cap off (oil may splash out).
Never coat the generating set, pump unit or lighting column with a thin layer of oil to protect it from rust.
Never top up the oil or coolant if the generating set, pump unit or lighting column is running, or if the engine is hot.
A generating set can only operate when stationary, and cannot be installed on a vehicle or other mobile equipment, without a prior
study taking into account the various specific features of using the generating set.
1.3.5 Risks related to electrical networks
The electrical equipment supplied with the generating set complies with standard NF C15.100 (France), or with the standards of the
countries in question.
The earth connection must be installed in accordance with the standards in force in each country in question, and with the neutral
system sold.
Read the manufacturer's identification plate carefully. The values for voltage, power, current and frequency are shown. Check that
these values match the supply use.
Never accidentally touch stripped cables or loose connections.
Never handle a generating set with wet hands or feet.
Maintain electrical wires and connections in good condition. Using equipment in poor condition can lead to electrocution and
damage to equipment. 
Always disconnect the power to the equipment or facility (generating set voltage, battery voltage and network voltage) before any
operation.
The electrical connections must be made in accordance with current standards and regulations in the country of use.
Do not use faulty, poorly insulated or provisionally connected wires.
Never reverse the positive and negative terminals on batteries when connecting them. This could cause severe damage to the
electrical equipment. Follow the wiring diagram supplied by the manufacturer.
The generating set should not be connected to any other power sources, such as the mains supply network. In specific cases
where there is to be a connection to existing electrical networks, this must only be installed by a qualified electrician, who should
take the operating differences of the equipment into account, according to whether the mains supply network or generating set is
being used.
8/202

Protection against electric shocks is ensured by an assembly of specific equipment. If this needs to be replaced, it should be by
components with identical nominal values and specifications.
If the protective plates (blanking covers) need to be removed to route cables, the protector (blanking cover) must be refitted when
the operations are finished.
Due to high mechanical stresses, use only strong flexible wiring with rubber sheathing, compliant with IEC 245-4, or equivalent
wiring.
1.3.6 Dangers presented by electric currents (first aid)
First aid
In the event of an electric shock, shut off the power immediately and activate the
emergency stop on the generating set or lighting column. If the voltage has not yet
been cut off, move the victim out of contact with the live conductor as quickly as
possible. Avoid direct contact both with the live conductor and the victim's body. Use
a dry plank of wood, dry clothes or other non-conductive materials to move the victim
away. The live wire may be cut with an axe. Take great care to avoid the electric arc
that will be generated by this.
Begin emergency procedures
Resuscitation
If breathing has stopped, begin artificial respiration at once in the same place the accident took place unless the victim or operator's life
could be endangered by this.
In the event of cardiac arrest, carry out cardiac massage.
1.3.7 Risks related to moving the set
To unload the generating sets, pump units or lighting columns from their transport support brackets under optimum safety and
efficiency conditions, you must ensure that the following points are observed:
The lifting machinery or equipment is suited to the work required, in good condition and with sufficient lifting capacity.
The slings are positioned in the rings provided for this operation, the forklift arms are resting fully underneath all of the base frame
cross-beams, or the lifting bars are inserted in the apertures provided for this purpose in the base to lift the entire generating set
(according to models).
For completely safe working conditions and to prevent damage to the components fitted on the upper edge of the set, pump unit or
lighting column, the generating set, pump unit or lighting column must be lifted up with an adjustable boom. All the chains and
cables must be parallel with each other, and as perpendicular as possible with the upper edge of the generating set, pump unit or
lighting column.
If other equipment fitted on the generating set, pump unit or lighting column alters its centre of gravity, special lifting devices may be
necessary to maintain correct balance and completely safe working conditions.
The ground must be able to withstand the load of the generating set, pump unit or lighting column and its lifting machinery without
stress (otherwise, put down beams of sufficient strength in a stable configuration).
Position the generating set, pump unit or lighting column as close as possible to its place of use or transport, in a clear space with
free access.
Never perform work on a generating set, pump unit or lighting tower just hanging from a lifting device.
1.3.8 Risks related to noise
Dangerous noise
Risk of hearing loss
Important
Prolonged exposure to a noise level above 80dB (A) can lead to permanent hearing damage.
Therefore, it is recommended that ear defenders are used when working in close proximity to a generating set which is in operation.
9/202

2. General description
Overview
Figure 2.1.1 : General description of the generating set
1 Acces to maintenance area 4 Acces to control unit
2 Lifting ring 5 Acces to power connections
3 Forklift grooves 6 Drawbar
6
2
4
1
3
5
10/202

Figure 2.1.2 : General description of the generating set
1 Protective grille 4 Alternator
2 Battery isolating switch 5 External fuel supply combined tap
(optional)
3 Starter battery 6 Charging alternator
3
1
2 4
6
5
11/202

Control
Figure 2.1.3 : General description of the generating set
Note : Photo presented with the Nexys control unit.
1 Control unit 4 Working hours counter
2 Emergency stop 5 Power circuit breaker
3 Socket control panel 6 Connection terminal block
6
5
2
3
1 4
12/202

2.1.Technical specifications
Range / Generating set type RENTAL POWER / R44C3
Weights and Dimensions
Dimensions with high autonomy tank
Dimensions l x w x h
2200 mm x 1000 mm x 1528 mm
Weight:
1150 kg dry weight / 1350 kg in operating configuration
Hood:
M3127
Sound pressure level:
at 1 m: 73 dB(A)
measurement uncertainty : 0.70
Output
Voltage Hz Phase Load factor Max current (A)
Emergency
power 1
kW / kVA
Prime power 2
kW / kVA
400/230 50 3 0.8 58 32 / 40 29 / 36
(1) ESP: Stand-by output available for emergency use under variable charge up to 200hrs per year as per lSO 8528-1, no overload availabl
e
under these service conditions.
(2) PRP: Main output available continuously under variable load for an unlimited time period per year as per ISO 8528-1, an overload of 10
%
one hour every 12 hours is available, as per ISO 3046-1.
- Term of use :
Standard reference conditions ESP/PRP 40° / 40°, Air Intlet Temp, 1000m / 1000m mA.S.L. 60 % relative humidity.
Engine data
Manufacturer / model MITSUBISHI S4S-Z3DT61SD
Type 4 Cycles Naturally aspirated
Cylinder configuration 4 XL
Cubic capacity 3.33 L
Rotation speed 1500 Rpm
prime power at nominal speed 36 kW
Adjustment type Mechanical
Fuel consumption
100 % main power 10.4 L/h
Fuel
Fuel type Diesel
High autonomy fuel tank 220 L
Lubrication
Oil capacity 10 L
Min. Oil pressure 1 bar
Nominal oil pressure 3.9 bar
Oil consumption (100 % load) 0.11 L/h
Oil sump capacity 9 L
Type of lubricant Genlub
Cooling
Engine capacity with radiator 9.5 L
Max coolant temperature 102 °C
Fan power 0.8 kW
Refrigerant type Gencool
Thermostat 76.5 – 90 °C
13/202

Alternator data
●Compliant with NEMA MG21 standards, UTE NF C51 111,
VDE 0530, BS 4999, IEC 34.1, CSA ●The alternator is protected against short circuits ●Vacuum impregnation, epoxy winding, IP23 protection rating
Type LEROY SOMER LSA43.2S159
Number of phases 3
Power factor (cos Phi) 0.8
Number of poles 4
Excitation type AREP
Insulation classe H
Number of bearings 1
Coupling Direct
Control unit(s)
NEXYS
Standard specifications:
Frequency meter, Voltmeter, Ammeter
Alarms and faults:
Oil pressure, Coolant temperature, Fail to start, Overspeed,
Alternator min/max, Fuel level low, Emergency shutdown
Engine parameters:
Working hours counter, Engine speed, Battery voltage, Fuel
Level, Air Preheating
TELYS
Standard specifications:
Voltmeter, Ammeter, Frequency meter
Alarms and faults:
Oil pressure, Water temperature, Start failure, Overspeed,
Alternator min/max, Battery voltage min/max, Emergency stop
Engine parameters:
Timer, Oil pressure, Water temperature, Fuel level, Engine
speed, Battery voltage
14/202

2.2.Identifying sets
Generating sets and their components are identified by means of identification plates.
The precise rules for identifying each major component (engine, alternator etc.) are set out in each manufacturer's documentation
contained in the appendices of this manual.
1 - Generating set
2 - Manufacturer name
3 - Model
4 - Serial number
5 - Year of manufacture
6 - Rated output (kVA and kW) according to the ISO
8528-1 standard
PRP: main power
ESP: emergency power
7 - Rated power factor
8 - Maximum altitude of the site above sea level (m)
for the rated power
9 - Maximum ambient temperature for the rated power
(°C)
10 - Rated frequency (Hz)
11 - Generating set rotation speed (RPM)
12- Rated voltage (V)
13 - Rated current (A)
14 - Weight (kg)
15 - CE marking
16 - Non CE standard marking e.g.: GOSSTANDART)
17 - Sound pressure
18 - Sound power
Figure 2.2: Example of generating set identification plate
15/202

2.3.Fluid retention
Any outflow of the fluids contained in the generating sets (fuel, oil and coolant, or rainwater or condensation) will be collected in a
retention container.
The containers have a capacity which allows 110% of the fluids contained in the generating set fitted with this option to be collected.
Diagram 2.3: Fluid retention container
The generating sets are fitted with a visual alarm warning when the upper limit of the retention container has been reached.
In all cases, the retention containers must be regularly checked to ensure they contain no fluid (fuel, oil and coolant, or rainwater or
condensation). If necessary, drain the containers via the drain port.
Note: Never allow these fluids to drain onto the ground; ensure they are collected in a designated container.
2.4.Fuel and consumables
All specifications (product features) are given in the engine maintenance manuals attached to this manual.
Fuels:
The specifications refer to European or international standards. Fuels complying with the standards indicated in the engine
maintenance manuals can be used without any contraindications. Only these fuels may be used.
Consumables:
In addition to the specifications indicated in the engine maintenance manuals, the consumables mentioned in the section entitled
"Specifications" are recommended.
16/202

2.4.1 Specifications
2.4.1.1. Oil grades
Engine Oil
Make Type Make Type
John Deere All John Deere John Deere PLUS-50
GenPARTS GENLUB TDX 15W40
MITSUBISHI All GenPARTS GENLUB TDX 15W40
Volvo All GenPARTS GENLUB TDX 15W40
GENLUB TDX 15W-40
Top-of-the-range lubricant recommended for diesel engines: for generating sets used under severe conditions.
USES:
Particularly suited to more modern engines with or without turbochargers, intercoolers, or sophisticated injection systems (e.g.
HEUI, injector-pumps).
All types of use: can cope with the most demanding applications.
Depolluted engines: complies with EURO 2 and EURO 3 technology and can be used with all types of diesel fuel, especially
ecological diesel with low sulphur content.
PERFORMANCE:
ACEA E3
API CH-4
Meets level E3 of the specifications defined by European manufacturers in the ACEA standards 98 edition.
ADVANTAGES:
Less frequent oil services: this product has been put to the test during thousands of hours of use on worksites under varying
conditions, demonstrating its high quality.
Conformity with new environmental legislation: adherence to new anti-pollution standards required for new EURO 2 and
EURO 3 engines.
SPECIFICATIONS:
SAE Grade 15W-40
Density at 15°C 0.883
Cinematic viscosity at 40 °C
Cinematic viscosity at 100 °C 105 14.1 mm2/s (cSt) mm2/s (cSt)
Viscosity index 140
Dynamic viscosity at -15 °C 3000 mPa.s(cP)
Pour point - 30 °C
Flash point 220 °C
Sulphated ash content 1.4 % weight
(Values given as examples only)
17/202

2.4.1.2. Specifications of coolants
Engine Coolants
Make Type Make Type
John Deere All GenPARTS GENCOOL PC -26°C
MITSUBISHI All Mitsubishi LLC
GenPARTS GENCOOL PC -26°C
Volvo All GenPARTS GENCOOL PC -26°C
GenCOOL PC -26
High-protection coolant, approved by manufacturers.
GenCOOL PC -26 is a ready-to-use, highly protective coolant which is produced from an antifreeze recommended by the majority of
European manufacturers.
It is made from antifreeze and G 48 inhibitors.
It protects up to -26°C.
It is free from nitrates, amines and phosphates.
It is a clear, fluorescent orange liquid.
REFERENCES/APPROVALS (for the antifreeze):
HEAVY GOODS VEHICLE LIGHTER VEHICLES
Approved by MTU, MERCEDES BENZ, MAN, KHD,
GENERAL MOTORS
Conforms with VOLVO, IVECO, VAN HOOL and STAYR
TRUCK specifications
Approved by BMW, VOLKSWAGEN, MERCEDES, PORSCHE
Conforms with VOLVO, OPEL, SEAT and SKODA
specifications
Conforms with the NF R 15.601 standard
REINFORCED ANTI-CORROSION FEATURES:
Protects against high-temperature corrosion by oxidisation of ethylene (cylinder head protection).
Protects against high-temperature cavitation (top of cylinder and coolant pump protection).
Non-corrosive for seals and hoses.
Improves the efficiency and longevity of the cooling system.
GenCOOL PC -26 is especially recommended for engines fitted with aluminium or light alloy radiators.
HIGH TEMPERATURE SUITABILITY:
Provides good conditions for thermal exchange.
Perfect stability at high temperatures.
GenCOOL PC -26 is specially adapted for engines with high power densities.
LONG LASTING PROTECTION:
High alkaline reserve/stability and longevity of corrosion inhibitors.
Maintains its technical properties during prolonged use at high temperatures (neutralisation of acids).
Ensures maximum heat transfer without the build up of deposits in the cooling system.
GenCOOL PC -26 ensures optimum protection against overheating and corrosion in extreme conditions of vehicle use.
18/202
