Sealey CHARGE 106.V3 User manual
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. ELECTRICAL SAFETY
WARNING! It is the user’s responsibility to check the following:
Check all electrical equipment and appliances to ensure that they are safe before using. Inspect power supply leads, plugs and
all electrical connections for wear and damage. Sealey recommend that an RCD (Residual Current Device) is used with all electrical
products. You may obtain an RCD by contacting your local Sealey dealer.
If the product is used in the course of business duties, it must be maintained in a safe condition and routinely PAT (Portable
Appliance Test) tested.
Electrical safety information, it is important that the following information is read and understood.
1.1.1. Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
1.1.2. Regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that they are secure.
1.1.3. Important
correct fuse - see fuse rating in these instructions.
8DO NOT pull or carry the appliance by the power cable.
8DO NOT pull the plug from the socket by the cable.
8DO NOT use worn or damaged cables, plugs or connectors. Ensure that any faulty item is repaired or is
1.1.4.
If the cable or plug is damaged during use, switch off the electricity supply and remove from use.
Ensure that the cable outer sheath extends inside the cable restraint and that the restraint is tight.
1.1.5. If an extension reel is used it should be fully unwound before connection. A reel with an RCD fitted is
preferred since any appliance plugged into it will be protected. The cable core section is important and should be at least 1.5mm², but
to be absolutely sure that the capacity of the reel is suitable for this product and for others which may be used in the other output sockets,
we recommend the use of 2.5mm² section cable.
1.2. GENERAL SAFETY
DANGER! BE AWARE, LEAD-ACID BATTERIES GENERATE EXPLOSIVE GASES DURING NORMAL BATTERY OPERATION.
FOR THIS REASON, IT VERY IMPORTANT TO READ AND FOLLOW THESE INSTRUCTIONS CAREFULLY, EACH TIME YOU USE
THE CHARGING EQUIPMENT.
1.2.1. Follow these instructions and those published by the battery and vehicle manufacturers, and the maker of any equipment you intend to
use in the vicinity of the battery. Remember to review warning marks on all products and on engines.
WARNING! Modern vehicles contain extensive electronic systems.
YouarerequiredtocheckwiththevehicleManufacturer,foranyspecicinstructionsregardingtheuseofthistypeof
equipment on each vehicle.
1.2.2.
1.3. PERSONAL PRECAUTIONS
1.3.1. Ensure there is another person within hearing range and close enough to come to your aid, should a problem arise when working near a
lead-acid battery.
9
9Have fresh water and soap nearby in case battery acid contacts skin, clothing or eyes.
9
running water for at least 15 minutes and seek immediate medical attention.
9Remove personal metallic items such as rings, bracelets, necklaces and watches. A lead-acid battery can produce a short-circuit current
which is high enough to weld a ring or the like to metal, which would cause severe burns.
9Ensure hands, clothing (especially belts) are clear of fan blades and other moving or hot parts of engine, remove ties and contain long hair.
8DO NOT smoke or allow a spark or flame in the vicinity of battery or engine.
C
Original Language Version
ear
Protective
Gloves
arning:
Electricity
Protect
From
Rain
se in
ell
entilated
Areas
Keep away
from sources
of ignition:
attery could
explode
Refer to
Instruction
Manual
arning:
Explosive
Material
ear eye
Protection
arning:
Corrosive
substance
BATTERY CHARGERS 8/11/14/16/19/28AMP 230V
CHARGE 106.V3/107.V3/110.V3/112.V3/115.V3/124.V3
Recommended fuse rating
13 Amp
1.4. GENERAL SAFETY INSTRUCTIONS
9Familiarise yourself with the application and limitations of the charger as well as the potential hazards. Also refer to the vehicle
9Ensure the charger is in good order and condition before use. If in any doubt do not use the unit, contact your Sealey stockist.
9
9
9Keep tools and other items away from the engine and ensure you can see the battery and working parts of engine clearly.
9Ensure the output of the charger is the same voltage as the battery.
9Ensure that during charging, the charger is placed in a location where there is sufficient ventilation to prevent the build up of explosive
gases from a lead acid battery, and DO NOT cover or obstruct the charger ventilation louvres.
9If battery has caps to access the battery fluid, remove the caps and check the fluid level before connecting the power clamps.
9If necessary top-up the battery with distilled water by referring to the battery manufacturer’s instructions (Apply the personal safety
precautions described in part 1.3).
9If the charger receives a sharp knock or blow the unit must be checked by a qualified service agent before using.
9If the battery terminals are corroded or dirty clean them before attaching the power clamps.
9Keep children and unauthorised persons away from the working area.
8DO NOT dis-assemble the charger for any reason. The charger must only be checked by qualified service personnel.
8DO NOT try to charge a non-rechargeable battery.
8DO NOT try to charge battery if battery fluid is frozen.
WARNING! To prevent the risk of sparking, short circuit and possible explosion DO NOT drop metal tools in the battery area, or allow
them to touch the battery terminals.
8DO NOT allow power clamps to touch each other or to make contact with any metallic part of the vehicle.
8DO NOT
8DO NOT pull the cables or clamps from the battery terminals.
8DO NOT use the charger outdoors, or in damp, or wet locations and DO NOT operate within the vicinity of flammable liquids or gases.
8DO NOT use charger inside vehicle or inside engine compartment.
9Ensure there is effective ventilation to prevent a build-up of explosive gases, and do not cover or obstruct charger ventilation louvres.
8DO NOT use the charger for a task for which it is not designed.
WARNING! DO NOT simultaneously charge batteries of different capacities or discharge levels.
WARNING! If a fuse blows, ensure it is replaced with an identical fuse type and ra
9
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by
children without supervision.
2. INTRODUCTION
Steel case with a sturdy carry handle, these single phase chargers feature good ventilation to maintain low transfer temperatures. A large
ammeter displays rate of charge and a dash mounted fuse provides polarity protection in the event of the clips being connected incorrectly.
Rocker switches control variable output to the battery to maintain peak condition. Suitable for regular and low maintenance batteries.
3. SPECIFICATION
4. OPERATION
WARNING! Ensure all the safety instructions in section 1 are read and followed before using the charger.
4.1. PREPARATION
4.1.1. It is important to correctly prepare for charging, ensuring that you follow Section 1 safety requirements carefully.
4.1.2. Check that the capacity of the battery is compatible with charger output.
4.1.3. Charging current (amps) should not exceed one tenth of the value of the battery capacity (amp hours).
4.1.4.
vehicle.
4.1.5. Follow the vehicle manufacturer’s instructions for charging the battery. Disconnect and remove the battery from the vehicle and place
in an appropriate safe area ready for charging.
Remove the battery electrolyte cover or caps to allow the gases produced by charging to escape.
8DO NOT
Model no. C C CHARGE110 CHARGE112 CHARGE115 CHARGE124
utput
utput charge peak
(EN)
14A(10A) 19A(15A) 28A(24A)
attery range 10-95Ah 20-105Ah 20-120Ah 20-180Ah 20-250Ah 25-320Ah
Charging rates 22222 2
Supply
Polarity protection Fuse (1 x 15A) Fuse (1 x 15A) Fuse (1 x 20A) Fuse (1 x 30A) Fuse (1 x 30A) Fuse (1 x 40A)
Fuse S
of 50)
C
(single)
S
(pack of 50),
(single)
S
of 50)
C
(single)
MF3010
(pack of 10),
(single)
MF3010
(pack of 10),
(single)
MF4010 (pack
of 10),
C
(single)
C
Original Language Version
4.1.8. The correct charging status of the battery may be determined by using a hydrometer which
1.28 = Fully charged, 1.21 = Half charged, 1.14 = Fully discharged.
WARNING!
4.2. CONNECTING CHARGER TO BATTERY
4.2.1. Ensure that the battery charger is unplugged from the mains power supply before connecting power leads to the battery.
4.2.2. Select the charger voltage to match that of the battery by setting the rocker switch to either 12 or 24 volts. Initially, always set the
4.2.3. Check the charger clamps and battery terminals to ensure that they are clean and free from oxidation.
4.2.4.
4.3. CHARGING THE BATTERY
4.3.1.
4.3.2. Check the current delivery to the battery by reading the ammeter on the front of the battery charger. During charging the pointer on the
model.)
4.3.3.
4.3.4. To indicate that the battery is fully charged the reading on the ammeter should be at
the “0”output indicator. To correspond with this the electrolyte in the battery will begin
to gas. Stop charging at this point in order to protect the battery plates from damage.
WARNING! The charger will not switch off automatically. The state of charge should be
regularly monitored by the person with responsibility for charging the battery.
8DO NOT leave the charger operating unattended or overnight.
4.3.5.
the battery terminals. Clean and store the charger in a safe, dry area.
remembering that the electrolyte is a corrosive acid. Return the battery to the vehicle,
secure according the manufacturer’s instructions and re-connect the power leads.
Check to ensure that all tools are removed before closing the bonnet or boot.
4.3.8. SEALED BATTERIES
4.3.8.1. Charge a sealed battery very slowly, carefully monitoring the voltage across the battery terminals using a normal tester.
4.3.8.2.
4.4. MULTIPLE BATTERY CHARGING
WARNING! DO NOT simultaneously charge different types of battery or batteries with different capacities or levels of discharge.
4.4.1.
4.4.2.
fig.1
fig.2
fig.3
fig.4
C
Original Language Version
4.5. FUSE
4.5.1. The charger is equipped with two front panel mounted fuses. The output protection fuse on the left will interrupt the circuit in the
following circumstances:
b) Short circuit - clamps touch, or cross-connection to battery.
c) If the output fuse blows take the following action:
Disconnect the charger from the mains power supply.
Allow the unit to cool down, establish the reason for fuse blowing and correct.
Replace the fuse. DO NOT use a fuse with copper bridge or similar as these will damage your starter
fuses with the charger.
4.5.2.
the same value.
THERMAL PROTECTION
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
WEEE REGULATIONS
waste authority for recycling information.
