Sealey LED038 User manual

INSTRUCTION MANUAL FOR:
UNDER BONNET LAMP 36 SMD & 230V
TRANSFORMER
MODEL NO: LED038
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions and properly maintained, give
you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS,
WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS
INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY.
PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL
 WARNING! Disconnect lamp from mains power before
performing any maintenance.
 DO NOT shine lamp directly into your, other person’s
or animal’s eyes.
 DO NOT allow children to use the lamp.
Maintain the lamp in good condition.
 DO NOT use the lamp if the lamp if damaged.
 When not in use store the light in a safe, dry,
childproof location.
 WARNING! Ensure Health and Safety, local authority
and general workshop practice regulations are
adhered to when using this light.
 Wear eye protection. A full range of safety equipment
is available from your Sealey dealer.
 Wear suitable clothing to avoid snagging.
 DO NOT wear jewellery and tie back long hair.
Account for all tools being used and DO NOT leave
them in or near the engine.
1.2. ELECTRICAL SAFETY FOR USE OF
TRANSFORMER. USE ONLY THE SUPPLIED
TRANSFORMER PLUG FOR CONNECTING LAMP TO THE POWER
SUPPLY.
 WARNING! It is the user’s responsibility to read,
understand and comply with the following electrical instructions: You
must ensure the risk of electric shock is minimised by the installation
of appropriate safety devices. An RCCB (Residual Current Circuit
Breaker) should be incorporated in the main distribution board. We
also recommend that an RCD (Residual Current Device) is used with
all electrical products, particularly portable equipment which is
plugged into an electrical supply not protected by an RCCB.
You must also read and understand the following instructions
concerning electrical safety.
1.2.1. The Electricity At Work Act 1989 requires all portable electrical
appliances, if used on business premises, to be tested by a qualified
electrician, using a Portable Appliance Tester (PAT), at least once a
year.
1.2.2. The Health & Safety at Work Act 1974 makes owners of electri-
cal appliances responsible for the safe condition of the appliance and
the safety of the appliance operator. If in any doubt about electrical
safety, contact a qualified electrician.
1.2.3. You must ensure that you:
Inspect the transformer plug, cable and connector for
wear and damage to ensure items are safe before
connecting to the mains power supply. If worn or
damaged DO NOT use.
Important: Check that the voltage marked on the
transformer plug is the same as the power supply to
be used.
Uncoil the cable between transformer plug and lamp.
 DO NOT pull the transformer plug from the mains
socket by the lead.
 DO NOT use any other type of transformer with this
product.
 DO NOT try to take the transformer plug apart.
 DO NOT use the transformer plug to power any other
electrical item.
 DO NOT get the transformer plug wet, or use in
wet, damp conditions (for indoor use only).
 WARNING! NEVER substitute a standard 13amp
3 pin plug, or any other type of plug, for the
transformer plug.
This transformer plug reduces and rectifies the mains voltage
(230 volts AC) to 12 volts DC.
WARNING: The warnings, cautions and instructions discussed in this instruction manual cannot cover all possible conditions and
situations that may occur. It must be understood that common sense and caution are factors which must be applied by the operator.
Original Language Version LED038 Issue: 1 - 06/03/13
© Jack Sealey Limited

3.1.3. To use the lamp, plug the transformer plug into the mains socket to turn the light on.
3.1.4. When finished, disconnect the transformer plug from the mains supply, fold the lamp and store it in a safe, dry and childproof location.
3. OPERATION INSTRUCTIONS
4. MAINTENANCE
3.1. ATTACHING LAMP TO BONNET.
3.1.1. Fold the lamp out straight and tighten the thumbwheel. Place the padded hook at the end off the lamp, over one edge of the bonnet, and
gently pull the lamp towards the other side of the bonnet.
3.1.2. Steady the lamp with one hand, whilst extending the hook over the other side of the bonnet.
4.1. Keep lamp clean and check for damage before every use. If damage is observed remove from use until unit is repaired.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: For a copy of our latest catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.
01284 757500
01284 703534
[e-mail]
Sole UK Distributor, Sealey Group,
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk,
IP32 7AR
www.sealey.co.uk
Web
email
Original Language Version LED038 Issue: 1 - 06/03/13
Robust design with built-in spring loaded telescopic mounting brackets. Soft padded hooks provide good protection against bonnet. 36 SMD LEDs
give complete engine bay illumination. Supplied with 5mtr cable and transformer plug, reducing down to 12V for added safety. Foldable design for
easy storage when not in use.
Model No: ................................................................................... LED038
Voltage:............................................................................................230V
Power: ..............................................................................................12W
Minimum/ Maximum Bonnet Width: .............................. 1230/1940mm
Lamp Type:..................................................................... 36 x 3528 SMD
2. INTRODUCTION
© Jack Sealey Limited
Environmental Protection.
Recycle unwanted materials instead of disposing of them as
waste. All tools, accessories and packaging should be sorted,
taken to a recycle centre and disposed of in a manner which
is compatible with the environment.
WEEE Regulations.
Dispose of this product at the end of its working life in compliance
with the EU Directive on Waste Electrical and Electronic Equipment.
When the product is no longer required, it must be disposed of in an
environmentally protective way. Contact your local solid waste
authority for recycling information.
