Sealey SL1D.V2 User manual

INSTRUCTIONS FOR:
LOCKERS - 1 DOOR, 2 DOOR, 4 DOOR
MODEL No's: SL1D.V2, SL2D.V2, SL4D.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions and
properly maintained, give you years of trouble free performance.
1. SAFETY INSTRUCTIONS
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS.
USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE
DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
2. INTRODUCTION
WARNING! Ensure Health & Safety, local authority, and
general workshop practice regulations are adhered to when
using these lockers.
Locate locker in a suitable work area.
Keep the work area clean, uncluttered and ensure there is
adequate lighting.
WARNING! Use locker on level and solid ground, preferably
concrete.
Keep the locker clean and tidy in accordance with good
workshop practice.
Keep children and unauthorised persons away from the work area.
DO NOT use the locker for any purpose other than that for
which it is designed.
DO NOT use the locker outdoors.
DO NOT get the locker wet or use in damp or wet locations or
areas where there is condensation.
DO NOT clean the locker with any solvents which may damage
the surfaces or the protective coating.
2.1. Introduction:
A range of lockers suitable for a variety of commercial
 applications.Singleandtwodoormodelsttedwithahanging
bar, single door model also has single shelf. Doors on all models
 areventilatedandttedwithcylinderlocks,2setsofkeys
 suppliedperlock.Suppliedatpacked.
2.2. Dimensions:
Width: 380mm, Depth: 450mm, Height: 1850mm.
3. ASSEMBLY
3.1. Lay out the back panel and the two side panels. The side
panels have a cut-out at the front and a lip at the bottom.
Slide the back panel into one of the side panels from the top
 (fig.1)andslideitallthewaydown(fig.2)-notethattheshelf
brackets line up.
fig.1
fig.2
3.2. Fit the other side panel to the back panel following the same
procedure. Ensure that the side panels are supported in an
upright position so that the panels are not twisted.
3.3. Carefully stand the unit up, again ensuring that the panels are
not twisted, two people may be required for this.
fig.2
Original Language Version SL1D.V2,SL2D.V2,SL4D.V2 Issue: 1 - 13/08/13
© Jack Sealey Limited

3.6. Fit the shelves into the locker following the same procedure
as for the locker top.
3.7. Placehangingbarinposition(SL1DandSL2Donly)by
pushing it into position (fig.4) and fit the mirror in its position
inside the door.
fig.3
SL1D SL2D SL4D
fig.4
3.4. Fit the door frame panel into the unit from the inside, locating
the frame with the side panels at the top (fig.3) and bottom.
Once located push fit them together until they lock into place.
3.5. Fit the locker top from the top, ensuring that the three lips
locate within the brackets at the back and sides, when they are
lined up, apply pressure and lock the top into place (fig.4).
NOTE: the shelves and top are identical.
