Sealey AP6350 User manual

INSTRUCTIONS FOR:
RACKING UNIT WITH 5 SHELVES
(350KG CAPACITY PER LEVEL)
MODEL:AP6350
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions and
properly maintained, give you years of trouble free performance.
1. SAFETY INSTRUCTIONS
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS.
USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE
DAMAGE OR PERSONAL INJURY, AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
1.1 GENERAL SAFETY
!WARNING! Ensure Health & Safety, and local authority regulations
are adhered to when assembling and using these shelves.
"Locate shelves in a suitable area where they will not be an obstruction.
"Keep the general area clean, uncluttered and ensure there is
adequate lighting.
!WARNING! Erect shelves on a level and solid surface such as
concrete.
"Keep children and unauthorised persons away from the storage area.
#DO NOT use the shelves for any purpose other than that for
which they are designed.
#DO NOT site the shelves out of doors.
#DO NOT get the shelves wet or use in damp or wet locations or
areas where there is condensation.
#DO NOT clean the shelf suports with any solvents which may
damage the coated surface.
"Ensure that the shelves are properly assembled before loading
them with heavy items.
!Maximum load for each shelf is 350kg.
"Where possible the unit should be fixed to the wall with
suitable fixings
"Place heavier items on the lower shelves.
"Where possible heavier items should be evenly distributed across
the shelves.
AP6350 - 1 - 220207
3. CONTENTS
2. INTRODUCTION
Carefully unpack the product and check the contents against the
list below. Should any items be missing or damaged make
immediate contact with your Sealey dealer.
Part Description No Off
LEG ANGLE SECTIONS (900x70x1.2mm) 8
LEG ANGLE JOINERS (28x61x1.2mm) 8
PLASTIC FLOOR PROTECTORS 8
SHELF SUPPORT, LONG (910x70x1.2mm) 10
SHELF SUPPORT, SHORT (415x70x1.2mm) 10
MDF SHELF (900 x 400 x 12mm) 5
FASTENER KIT (Nuts & bolts for joining side by side sections) 4
01284 757500
01284 703534 [e-mail]
Sole UK Distributor
Sealey Group,
Bury St. Edmunds, Suffolk.
www.sealey.co.uk
Web
email
4. ASSEMBLY
4.1 Assemble the frame using a soft faced hammer or mallet as
shown in Fig.1. If only a hard faced hammer is available hammer
onto a piece of wood to avoid damaging the paint surface. Always
hammer gently as close as possible to the uprights. Make sure
that the shelf support tabs are in line with the leg angle slots. If
the tabs and slots are not lining up do not use force as this may
damage the tabs. If the tabs are out of line bend them slightly to
line up with the slots.
Fig.1
4.3 See Fig.2. Decide on the height of the second shelf. Fit another 2
short shelf supports at the desired height then fit 2 long shelf
supports at the same height.
Fig.2
4.2 See Fig.1. Decide on the position/height of the bottom shelf.
Make an end frame by fitting 1 short shelf support between 2 leg
angle sections. Make a second end frame ensuring that the shelf
support is at the same height as the first end frame. Join the two
end frames together using 2 long shelf supports fixed at the
same height as the short shelf supports.
Fully painted steel frame with five MDF shelves. 350kg capacity
per level giving a maximum capacity of 1750kg per rack. No nuts
and bolts means no tools required to assemble. Clips together in
minutes. Racking can be used as a single bay rack or split into
two separate shelf systems or workstations.
Height: 1805mm Width: 910mm Depth: 410mm

AP6350 - 1 - 220207
4.4 Decide the shelf positions for the upper section of the shelves
and assemble two more end frames, each using 2 leg angle
sections and 3 short shelf supports ensuring that the shelf
supports are at the same height on both frames. The upper part
of the shelves can be joined to the lower part of the shelves
using the lower shelf supports as shown in Fig.3. If the lower
shelf is not positioned at the centre of the frame use the special
joining pieces supplied as shown in Fig.4.
4.5 When both upper end frames are in place join them together with
the remaining 6 long shelf supports ensuring that they are at the
same height as the short shelf supports.
4.6 See Fig.5. When the frame is complete attach the plastic floor
protectors to the bottoms of the angle sections. Get a second
person to steady the frame while this is done.
4.7 See Fig.6. Move the frame into position in the chosen storage
area. Place the 5 MDF shelves onto the shelf supports.
4.8 See Fig.7. To assemble as a bench/low level shelving unit make
up two separate frames following steps 4.1 to 4.3 but with
different shelving positions. Make up one frame with 3 shelves
and one frame with two shelves as shown below. Ensure that the
middle and top shelves on both frames are at the same height.
Fix the frames together with the four nuts and bolts supplied.
Place the 5 shelves into position in the frames.
4.9 See Fig.8. To assemble as a corner unit make up two separate
frames following steps 4.1 to 4.3 but with different shelving
positions. Make up one frame with 3 shelves and one frame with
two shelves as shown below. Ensure that the middle and top
shelves on both frames are at the same height. Fix the frames
together with the four nuts and bolts supplied. Place the 5
shelves into position in the frames.
Fig.3
Fig.6
Fig.4 Fig.5
Fig.7
Fig.8
