INSTRUCTIONS FOR:
MODULAR WALL CABINETS
MODEL Nos: APMS13, APMS14
1.1. GENERAL SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using these
cabinets.
Locate the cabinets in a suitable area.
Keep the work area clean, uncluttered and ensure there is adequate lighting.
WARNING! Use the cabinets on level and solid ground, preferably concrete.
Keep the cabinets clean and tidy in accordance with good workshop practice.
Keep children and unauthorised persons away from the work area.
DO NOT use these cabinets for any purpose other than that for which they are designed.
DO NOT use the cabinets outdoors.
DO NOT place the cabinets in a damp or wet location or an area where there is condensation.
DO NOT clean the units with any solvents which may damage the surfaces or the protective coating.
Original Language Version APMS13, APMS14 Issue:1 10/10/14
© Jack Sealey Limited
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE THE
PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
1. SAFETY
2. INTRODUCTION
3. SPECIFICATION
4. ASSEMBLY
4.1. Assembly for APMS13 and APMS14 is the same process. It is recommended that adequate assistance from at least one other person
is used to lift the Wall Cabinets onto the posts.
4.2. Fit Handle
4.2.1. FithandleusingM4x5crossheadscrew(seeg.1).
4.3. Build Posts
4.3.1. Connectthepostsusing8xM6x12crossheadscrews(seeg.2).
4.3.2. FitpoststorearofFloorCabinetsusing6xM8x20hexagonsocketheadcapscrewsandwashers(seeg.3).
4.4. Fit Back Panel (BackPanel'A'ingures,separatepurchase(APMS10)775mm(APMS11)1550mm)
4.4.1. FittheBackPaneltothepostsusing8pairsofM8x20hexagonsocketcapscrewsandwashers(seeg.4).
4.5. Fit Wall Cabinet
4.5.1. Fit the Wall Cabinet to the posts from inside the Wall Cabinet, using 6 pairs of M8x20 hexagon socket cap screws and washers
 (seeg.5).
Heavy-duty high end Modular Garage Storage System with an appearance to enhance any garage/workshop. Built to withstand the rigours of
anygarageenvironment.Versatileanddurablesteelconstructionthatwilllastforyears.Easilyadjuststospecicneeds;purchaseasimple
base cabinet or create a full garage storage system.
