3.1 ASSEMBLY
3.1.1 The jack comprises the following parts:
Steel chassis.
Two-part pumping handle with M6x35 bolt.
3.1.2 Insert the upper handle into the lower handle. Secure the
two pieces together with the bolt (A). (Fig.1).
3.1.3 Undo the handle socket screw (B) until it no longer
protrudes into the handle socket (Fig.2).
3.1.4 Insert the pump handle into the handle socket hole,
engaging the hexagonal drive of the release valve.
3.1.5 Ensure that the handle is correctly inserted into the socket,
then tighten the handle socket screw (B).
INSTRUCTIONS FOR:
TROLLEY JACK 3TONNE
LOW ENTRY
MODEL No: 3075LE
Your new Jack is produced and manufactured to a high standard of dependability and will, if used according to these instructions and properly
maintained, give you years of trouble free performance.
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS ANDCAUTIONS. USE
THIS JACK CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/
OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. RETAIN THESE INSTRUCTIONS FOR FUTURE USE.
1. SAFETY PRECAUTIONS
2. INTRODUCTION / SPECIFICATION
3. ASSEMBLY
Ensure the jack is in sound condition and good working order.
Take action for immediate repair or replacement of damaged
parts. Use genuine parts only. The use of improper parts may be
dangerous and will invalidate the warranty.
Locate the jack in a suitable, well lit working area.
Keep working area clean and tidy and free from unrelated
materials.
Use jack on level and solid ground, preferably concrete.
Avoid tarmacadam as jack may sink in.
Chock wheels of vehicle.
Ensure the vehicle handbrake is engaged, engine is switched off
and transmission is in gear (or “PARK” if automatic).
Ensure minimum distance of 0.5m between vehicle and static
objects such as doors, walls, etc., to allow for vehicle tilting.
Ensure all non-essential persons keep a safe distance whilst the
jack is in use.
Ensure there are no passengers in the vehicle.
Place jack under only those lifting points recommended by
vehicle manufacturer (see vehicle handbook).
Check that the lifting point is stable and centred on the jack
saddle.
 Ensure the jack wheels are free to move and that there are no
obstructions.
 DANGER: Use the jack for lifting only, NOT for supporting the
lifted load.
 Ensure there are no persons or obstructions beneath the vehicle
before lowering.
Use suitable axle stands under the vehicle before proceeding with
any task.
Use a qualified person to lubricate and maintain the jack.
 Ensure that only hydraulic jack oil is used in the jack.
 DO NOT operate the jack if damaged.
 DO NOT allow untrained persons to operate the jack.
 DO NOT exceed the rated capacity of the jack.
 DO NOT allow the vehicle to move during lifting or lowering, or
use the jack to move the vehicle.
 DO NOT jack vehicle if there is a risk of spillage of fuel, battery
acid, or other dangerous substances.
 DO NOT work under the vehicle until appropriately rated axle
stands have been correctly positioned.
 DO NOT use the jack for purposes other than that for which it is
intended.
 DO NOT top up hydraulic system with brake fluid. Use hydraulic
jack oil only. (Sealey Part No: HJO500MLS or HJO5LS)
 DO NOT adjust the safety overload valve.
 When not in use store jack, fully lowered, in a safe, dry, childproof
location.
Model No: ........................................................................3075LE
Capacity............................................................................3tonne
Minimum saddle height.....................................................95mm
Maximum saddle height....................................................540mm
Maximum chassis height ..................................................135mm
Length...............................................................................685mm
Weight...............................................................................44.5kg
4. HYDRAULIC SYSTEM PURGING
4.1 Open the release valve by turning it two full turns
counter-clockwise.
4.2 Pump the handle a minimum ten full strokes.
4.3 Close the release valve by turning it clockwise.
Twin piston 'Rocket Lift' feature brings lifting arm straight into contact
with the jacking point in 1-2 strokes. Universal joint release
mechanism allows safer, more controlled lowering of the jack.
Profiled lifting arm gives low clearance height of just 95mm x 390mm
deep making this unit suitable for sports and custom cars. Heavy-duty
chassis with strengthening flanges along the top edge for extra
torsional rigidity under load. Fitted with heavy-duty one-piece
hydraulic unit with pump-through action preventing handle locking at
maximum ram extension. Large sized saddle aids positioning under
vehicle and safety valve prevents overloading. Supplied with foam
jacking sleeve to prevent damage to vehicles bodywork and integral
saddle pad.
Original Language Version 3075LE Issue: 1 - 16/07911
Fig.2
Fig.1

IMPORTANT: Only fully qualified personnel should attempt
maintenance or repair.
6.1 Monthly Maintenance
Lubrication is critical to jacks, since they support heavy
loads. Any restriction due to dirt or rust can cause either
slow jack movement, or extremely rapid jerks, causing
damage to the internal components. To keep the jack well
lubricated, carry out the following steps.
6.1.1 Lubricate the ram, the linkages and the saddle and pump
mechanism with light oil.
6.1.2 Grease the wheel bearing and axles.
6.1.3 Keep all jack surfaces and warning labels clean.
6.1.4 Check and maintain the ram oil level (Section 6.3).
6.2 Three Monthly Maintenance
6.2.1 At three monthly intervals, check the ram for any signs of
rust or corrosion. Clean the ram as required and wipe with
an oil cloth.
6.3 Checking the Oil Level
6.3.1 Fully retract the ram by turning the release valve
counter-clockwise.
6.3.2 Undo the four top plate retaining screws and remove the top
plate.
6.3.3 With the jack in the level position, remove the oil filler plug.
6.3.4 The oil should be level with the bottom of the oil filler hole.
If it is not top up with clean hydraulic jack oil. (Sealey Part
No: HJO500MLS or HJO5LS)
6.3.5 Replace the oil filler plug (C) and check the jack operation.
6.3.6 Purge air from the hydraulic unit as required. Refer to
Section 4.
6.3.7 Replace the top plate and secure with the four screws.
NOTE: Always store the jack in the fully lowered position. This
will protect critical areas from excessive corrosion.
IMPORTANT: NO RESPONSIBILITY IS ACCEPTED FOR
INCORRECT USE OF THIS PRODUCT.
Hydraulic products are only repaired by local service agents. We
have service/repair agents in all parts of the UK.
DO NOT RETURN JACKS TO US.
Please telephone us on 01284 757500 to obtain the address and
phone number of your local agent. If jack is under guarantee you can
also contact your local dealer.
6. MAINTENANCE
 WARNING! Before use ensure you have read,
understood and apply Section 1 safety instructions.
IMPORTANT: Before use, the operator is to visually inspect
the jack for cracked welds, damaged or missing parts or
hydraulic leaks.
5.1 Raising a Vehicle
5.1.1 Ensure that the jack and the vehicle are on a hard, level
surface.
5.1.2 Always ensure that the vehicle handbrake is engaged and
that the vehicle wheels are chocked.
5.1.3 Consult the vehicle manual to determine the location of
jacking points. Position the jack under a suitable lifting point.
5.1.4 Turn the release valve clockwise, to the closed position
(Fig.3). DO NOT over-tighten.
5.1.5 Raise the vehicle to the desired height by pumping the
handle up and down.
5.1.6 Place axle stands beneath the locations recommended by
the vehicle manufacturer.
5.1.7 Turn the release valve slowly counter-clockwise to lower the
vehicle on to the axle stands.
5.2 Lowering a Vehicle
5.2.1 Turn the release valve clockwise to the closed position.
5.2.2 Pump the handle to raise the vehicle off the axle stands.
5.2.3 Remove the axle stands from beneath the vehicle.
5.2.4 Turn the release valve slowly counter-clockwise to lower the
vehicle to the ground.
NOTE: When not in use, ALWAYS leave the saddle and ram fully
retracted.
5. OPERATING INSTRUCTIONS
De-commissioning the Jack
Should the jack become completely unserviceable and require
disposal, draw off the oil into an approved container and dispose of
the jack and the oil according to local regulations.
Parts support is available for this product. To obtain a parts
listing and/or diagram, please log on to www.sealey.co.uk, email
[e-mail] or phone [phone].
7. TROUBLESHOOTING
PROBLEM CAUSE REMEDY
Jack will not lift to full height Oil level low Check / top up oil level
Jack will not hold the load Release valve not closing Contact authorised service agent
Hydraulic jack oil is contaminated
Pump valves not sealing
Lift arm will not lower Cylinder ram binding Contact authorised service agent
Parts worn
Internal component damage
Broken or unhooked return spring
Lift arm linkage either bent or binding
Jack feels spongy when lifting System requires purging Refer to air purge procedure at Section 4
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: For a copy of our latest catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.
01284 757500
01284 703534
[e-mail]
Sole UK Distributor, Sealey Group,
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk,
IP32 7AR
www.sealey.co.uk
Web
email
Original Language Version 3075LE Issue: 1 - 16/09/11
Fig.3
