4-WAY ALUMINIUM SCAFFOLD LADDER EN 131
MODEL NO: ASCL2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURYAND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9Ensure Health and Safety and local authority regulations are adhered to when using this
equipment.
WARNING! Risk of falling from the ladder.
9Refer to instructions.
9Inspect the ladder after delivery.
9Before every use visually check the ladder is not damaged and is safe to use.
8DO NOT use a damaged ladder.
9Observe maximum total load 150kg.
8DO NOT use the ladder on a unlevel or unrm base.
8DO NOT over reach.
8DO NOT erect ladder on contaminated ground.
9Observe maximum number of users.
8DO NOT ascend or descend unless you are facing the ladder.
9Keep a secure grip on the ladder when ascending or descending. Maintain a handhold
whilst working from a ladder or take additional safety precautions if you cannot.
9Avoid work that imposes a sideways load on ladders, such as side on drilling through
solid materials.
8DO NOT carry equipment which is heavy or di󰀩cult to handle whilst using a ladder.
8DO NOT wear unsuitable footwear when climbing a ladder.
8DO NOT use a ladder if you are not t enough. Certain medical conditions or medication,
alcohol or drug abuse could make ladder use unsafe.
8DO NOT spend long periods on a ladder without regular breaks (tiredness is a risk).
9Prevent damage of the ladder when transporting e.g. by fastening and, ensure they
suitably placed to prevent damage.
9Ensure the ladder is suitable for the task.
8DO NOT use the ladder if contaminated, e.g. with wet paint, mud, oil or snow.
8DO NOT use the ladder outside in adverse weather conditions, such as strong wind.
9For professional use a risk assessment shall be carried out respecting the legislation in the country of use.
9When positioning the ladder take into account risk of collision with the ladder e.g. from pedestrians, vehicles or doors. Secure doors
(not re exits) and windows where possible in the work area.
WARNING! ELECTRICITY HAZARD
9Identify any electrical risks in the work area, such as overhead lines or other exposed electrical equipment and DO NOT use the ladder
where electrical risks occur.
9Use non-conductive ladders for unavoidable live electrical work.
8DO NOT use the ladder as a bridge.
8DO NOT modify the ladder design.
8DO NOT move a ladder while standing on it.
9For outdoor use caution to the wind.
9 If a ladder is delivered with stabiliser bars these bars should be xed by the user before the rst use, see assembly section overleaf.
9 Check if ladder is suitable for domestic/professional use.
1.1. SAFETY REQUIREMENTS FOR LEANING LADDERS
9Leaning ladders with rungs shall be used at the correct angle.
9Leaning ladders with steps shall be used so that the steps are in a horizontal position.
9Ladders used for access to a higher level shall be extended at least 1 metre above the landing point and secured, if necessary.
8DO NOT lean the ladder against unsuitable surfaces.
8Ladder must never be moved from the top.
8DO NOT stand on the top three steps/rungs of a leaning ladder.
1.2. SAFETY REQUIREMENTS FOR STANDING LADDERS
8DO NOT step o󰀨 the side of a standing ladder onto another surface.
9Open the ladder fully before use.
9Use the ladder with restraint devices engaged only.
Refer to
instruction
manual
Work platform symbols
ASCL2 Issue:2 (H,F) 11/11/21
Original Language Version
© Jack Sealey Limited

9Standing ladders shall not be used as a leaning ladder unless it is designed to do so.
8DO NOT stand on the top two steps/rungs of a standing ladder without a platform and a hand/knee rail.
1.3. SAFETY REQUIREMENTS FOR EXTENDING LADDERS
9 Check the extending ladder rung locking device before use.
2. INTRODUCTION
EN 131 Approved 4-way sca󰀨old ladder. Two 6-rung aluminium ladders can be used as extending ladder, single ladders, step ladder or complete
sca󰀨olding unit. Supplied with hand rail.
3. SPECIFICATION
Model No: ...................................................................ASCL2
Closed Length:.........................................................1670mm
Extension Ladder:....................................................2700mm
Maximum Load: ........................................................... 150kg
Maximum Platform Height:.........................................950mm
Maximum Width (across feet): ...................................950mm
Platform Length:.......................................................1320mm
Step Ladder Height:.................................................1600mm
4. ASSEMBLY
4.1. Bolt the foot cross members to the bottom of each ladder.
The feet are already attached to the cross members. Refer to g.1.
4.2. WORK PLATFORM
WARNING! Assembling the work platform is a two-man task.
4.2.1. Attach the platform, at the desired height, to one ladder only, g.2.
Note: Ensure that the hole for the hand rail is nearest to the outer face of the ladder.
4.2.2. Attach the support stay between the platform and the ladder by inserting it rst into the platform and then attaching it to the ladder,
g.2.
4.2.3. Lift the platform assembly to the horizontal position and attach the second ladder.
Note: Ensure that the hole for the hand rail is nearest to the outer face of the ladder.
4.2.4. Fit hand rail, g.3.
WARNING! The platform height must not exceed 0.95 metres for reasons of stability.
Note: The maximum loading of the platform when assembled is 150kg.
4.2.5. STAIRWAY WORK PLATFORM
WARNING! Assembling the stairway work platform is a two-man task.
4.2.6. Bolt the foot cross members to the bottom of each ladder. The feet are already attached to the cross members, g.1.
4.2.7. Attach the stairway work platform, at the desired height, to the ground-based ladder.
4.2.8. Attach the support stay between the stairway work platform and the ground-based ladder by inserting it rst into the platform and
then attaching it to the ladder, g.2.
4.2.9. Lift the other end of the work platform to the horizontal position and attach it to the second ladder, located on the upper step of the
stairway.
4.2.10. Attach the second support stay between the stairway ladder and the work platform, fig.2.
4.2.11. The maximum height above the ground of the steps on which the stairway ladder is to located when assembled is 0.56 metres, g.2.
▲DANGER! Never attempt to climb the sca󰀨olding to get onto the work platform. Always access the work platform using a
separate set of steps.
Note: The maximum loading of the stairway work platform when assembled is 150kg.
fig.1
fig.2
fig.4 fig.3
Original Language Version
© Jack Sealey Limited ASCL2 Issue:2 (H,F) 11/11/21

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
4.3. EXTENSION LADDER
IMPORTANT! ALWAYS position the ladder at an angle between 65° and 75° to the horizontal.
The ladder will be within this range if the base is one third of the effective ladder length away from the foot of the wall.
Refer to fig.5.
4.3.1. Assemble the extension ladder with the two lower rungs of the extension section set in the retaining hooks of the top part of the ground
based section.
Refer to g’s.6 & 7.
4.3.2. The maximum height of the extension ladder is 2.7 metres (minimum overlap of two rungs), g.7.
4.4. STEP LADDER
4.4.1. Assemble the step ladder by connecting the top rung of one ladder to the retaining hooks located on the top rung of the other ladder.
Refer to g.8.
4.4.2. Connect the support stays to each side of both ladders, g.8.
4.4.3. The height of the step ladder when assembled is 1.6 metres.
5. MAINTENANCE
5.1. Repair and maintenance shall be carried out by a competent person.
5.2. Ladders should be regularly inspected for damage, loose, non-functioning, missing or worn components.
5.3. If any of the about faults are noticed the ladder should NOT be used.
6. STORAGE
6.1. The ladder should be stored away from exposure to dampness, excessive heat or exposure to the elements.
6.2. Ladders should be stored in a position which helps it to remain straight, where it cannot be damaged, caused an obstruction or trip
hazard and secured where it cannot be easily used for criminal purposes.
Original Language Version
© Jack Sealey Limited
fig.6
fig.5
fig.7
fig.8
fig.9
ASCL2 Issue:2 (H,F) 11/11/21
