Sealey SD006 User manual

60W SOLDERING STATION
MODEL NO: SD006
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. ELECTRICAL SAFETY
WARNING! It is the responsibility of the owner and the operator to read, understand and comply with the following:
You must check all electrical products, before use, to ensure that they are safe. You must inspect power cables, plugs, sockets
and any other connectors for wear or damage. You must ensure that the risk of electric shock is minimised by the installation of
appropriate safety devices. A Residual Current Circuit Breaker (RCCB) should be incorporated in the main distribution board. You
must also read and understand the following instructions concerning electrical safety.
9Ensure that cables are always protected against short circuit and overload.
9Regularly inspect power supply cables and plugs for wear or damage and check all connections
to ensure that none are loose.
9Ensure that the voltage marked on the appliance matches the power supply to be
 usedandthattheplugisttedwiththecorrectfuse-seefuseratingatright.
8DO NOT use worn or damaged cables, plugs or connectors. Have any faulty item repaired or
replaced immediately by a competent electrician.
9It is recommended that this device is wired directly to a fused isolator switch. If, however, a plug
 istted,thefollowingapplies:
9Fit a new plug according to the following instructions (UK only).
a) Connect the GREEN/YELLOW earth wire to the earth terminal ‘E’.
b) Connect the BROWN live wire to the live terminal ‘L’.
c) Connect the BLUE neutral wire to the neutral terminal ‘N’.
d) After wiring, check that there are no bare wires, that all wires have been correctly connected,
that the cable restraint is tight.
1.2. GENERAL SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this
equipment.
9Familiarise yourself with the application, limitations and potential hazards of the soldering station.
9Replace or repair damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9Locate soldering station in a suitable working area, keep area clean and tidy and free from unrelated materials.
9Keep the work area clean, uncluttered and ensure there is adequate lighting.
9Keep the soldering iron clean for best and safest performance.
9 Ensuretherearenoammableorcombustiblematerialsneartheworkarea.
9Wear approved safety eye protection (standard spectacles are not adequate).
9Wear appropriate protective clothing.
9Ensure the workpiece is adequately held before operating the soldering iron.
9Always replace the soldering iron in its holder when not in use.
9Remove excess solder from the soldering iron by wiping the tip on a damp, natural sponge; not by abrupt force.
8DO NOT attempt to remove excess solder from the soldering iron by shaking it. Hot solder may become airborne and land on skin
causing burns and blisters.
8DO NOT allow children or pets into the area where the soldering is taking place.
8DO NOT attempt to cool the soldering iron with water.
NOTE: This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
2. INTRODUCTION
60W Soldering station with rapid heat up. MCU Controlled temperature calibration. LCD Display screen showing current temperature.
Maintainstemperaturesbetween50-480°C.Suppliedwithsolderingspongeandsolderingironstand.
Recommended fuse rating
3 Amp
SD006 Issue 1 28/01/2021
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Indoor use only Hot surfaces

3. SPECIFICATION
MODEL NO:...............................................................SD006
Electrical Plug Type: ................................................3-PinBS
Frequency:.....................................................................50Hz
Heating Element Voltage:........................................... 24VAC
Power:.............................................................................60W
4. OPERATION
4.1. Place the soldering iron in the holder.
4.2. Then connect the plug to the receptacle on the station and turn clockwise to tighten the plug nut.
4.3. Connect the control unit to the power supply and switch the power on.
4.4.  Aself-testiscarriedoutinwhichallthedisplayelementsareswitchedonbriey.
4.5. The electronic system then switches on automatically to the set temperature.
4.6. The display and temperature setting
4.7.  Pressthebutton“+UP”or“-DOWN”toadjustthetemperature.
4.8.  Inshortpress,theset-pointwillchange±1°C.
4.9.  Inlongpress,theset-pointwillchangequicklyandreachyourtargettemperature.
4.10. “°C/°F”isthetransferbuttonbetween°C/°F.
4.11. Thedefaultunitis°C,pressthe“°C/°F”buttontochangebetween°Cand°F.
5. MAINTENANCE
Beforefurtheruse,safetydevicesorslightlydamagedpartsmustbecarefullycheckedforerror-freeandintendedoperation.Inspect
movingpartsforerror-freeoperationandthattheydon’tbind,orwhetheranypartsaredamaged.Damagedsafetydevicesandpartsmust
berepairedorreplacedbyaqualiedtechnician,solongasnothingelseisindicatedintheoperationmanual.Useonlyaccessoriesor
attachmentswhicharelistedintheoperationmanual.Useofothertoolsandotheraccessoriescanleadtoadangerofinjury.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
