Sealey Mk66.v3 User manual

Original Language Version

Numbers in BOLD refer to the diagram in Fig.1

2.1 To assemble the side frames compress the silver latch

button at the top of the front frame 1and insert the tube

into the back frame tube 1A until they snap together.

2.2 Onto each end of the two paper bars 20 slide a paper

holding ring 5followed by a washer 16, holding spring

17 and another washer 16, followed by a paper holding

ring 5. Insert a screw 12 into the threaded block on each

holding ring.

2.3 Attach the side frames to each end of the paper bars as

shown in the main drawing using the four wing bolts 13.

2.4 Fit the bottom tool tray between the side frames and bolt

it to each leg using screw 10, nut 22 and washer 23.

2.5 Attach the upper paper blade 7to the front of the frame

using two screws 10, two nuts 22 and two washers 23.

2.6 Attach the lower cutting blade 7to the front of the frame

using two screws 10, two nuts 22 and two washers 23.

2.7 Attach a paper spring 7A to the back edge of each

cutting blade. Hook one end of the spring to the notched

back corner of the metalwork and stretch it across and

hook it to the other back corner. Take care to avoid the

cutting blade teeth when doing this.

2.8 To assemble the four tape reels as shown in Fig.2 take a

long bolt 14 and screw on to it a wing nut 6 then drop a

washer 23 onto it followed by a metal bush 21. Slide a

reel 8over the bolt and onto the bush ensuring that it is

the right way round. Retain the assembly using another

washer followed by a wing nut 6. After the nut has been

tightened the reel should still run freely on the bush.

Attach another nut to the bolt and insert the bolt through

the frame in one of the four places indicated on the main

drawing. Retain the assembly in place using a nut 22

and a washer 23.

2.9 Attach the small tool tray 15 to the side of one of the

frames using two screws 10, two nuts 22 and two

washers 23. The nuts and washers should be on the

inside of the tray.

2.10 Attach the hanger 9to the side of the opposite frame

at the same level as the top tray. Insert the ends of the

hanger into the holes in the side of the frame, tip the

hanger forwards so that the first bend in either end of

the hanger is inside each frame tube.

2.11 The MK66.V3 has a solid rod axle 4with holes at either

end to accept cotter pins 11. Slide the axle through the

holes near the bottom of each rear leg and retain it with

a cotter pin. Secure by bending the pin back onto itself.

2.12 Slide a wheel spacer 24, then a wheel 3onto each end

of the axle and retain them with a cotter pin 11 through

the axle. Secure by bending the pin back onto itself.

INSTRUCTIONS FOR:

MASKING PAPER DESPENSER

MODEL No: MK66.V3

Thank you for purchasing a Sealey Product. Manufactured to a high standard this product will, if used according to these instructions and properly

maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS AND CAUTIONS.

USE THIS PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE

OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.

1 FRONT FRAME

1A REAR FRAME

2 TOOL TRAY (LARGE)

3 WHEEL

4 AXLE

5 PAPER HOLDING RING

6 WING NUT

7 CUTTING BLADE

7A CUTTING BLADE SPRING

8 TAPE REEL

9 HANGER BAR

10 SCREW

11 COTTER PIN

 Ensure the dispenser is on a reasonably flat, level floor before loading.

 Ensure that all fittings are tight and secure.

 Be aware that the paper cutting blades are sharp, handle with care.

 DO NOT use the dispenser for any purpose other than that for which it is designed.

1. SAFETY INSTRUCTIONS

2. ASSEMBLY

12 HEX SCREW (5*12)

13 BOLT THREAD WING NUT

14 LONG BOLT

15 SMALL TOOL TRAY

16 PAPER HOLDING WASHER

17 PAPER HOLDING SPRING

18 HANDLE GRIP

19 FRAME FOOT

20 PAPER BAR

21 BUSHING FOR TAPE REEL

22 NUT M6

23 WASHER M6

24 SPACER

Fig.1

MK66.V3 Issue: 1 - 08/10/09

Original Language Version

3.1 Remove either the upper or lower paper bar from the frame by unscrewing and

removing the wing bolts at either end.

3.2 On one side of the bar loosen the screws of the black paper holding rings and

remove the rings, spring and washers from the end of the bar. Remove the card

board tube centre of the last roll from the bar.

3.3 Slide the the paper bar through the centre of the new paper roll and refit the

washers, spring and rings to the end of the bar. Temporarily tighten the screws in the

holding ring.

3.4 To refit the loaded bar to the frame get a second person or persons to support the

paper roll while the wing bolts are fitted at either end of the bar. The paper should be

coming off the top of the roll. Once loaded, check that the roll is centrally placed on

the paper bar and make any necessary adjustments using the black holding rings.

3.5 Push a roll of masking tape onto each tape dispensing reel and spin it to make sure

the tape is running true. Check that the tape dispensers are aligned with the ends

of the paper roll as shown in Fig.3. (The centre line of the tape should align with the

edges of the paper roll.) The position of the tape dispensers can also be adjusted as

shown in Fig.2. To increase or decrease dimension ’X’ loosen the wing nut ‘Z’ and

wing nut ’Y’ up or down the bolt as required. Retighten the wing nut.

3.6 Pull about 450mm of paper from the roll and feed it between the paper spring and the

back edge of the adjacent cutting blade.

3.7 Pull tape from each dispenser in turn and stick it to the paper roll so that it is half on and half off the paper edges. Check the alignment of the

tapes and make any further adjustments required to the positions of the tape dispensers.

3.8 Slowly pull the paper from the roll and check that the tapes feed correctly onto the edges of the paper.

3.9 Tear the paper off with an upward movement against the down facing teeth of the paper blade. Keep hands well away from the blade when

doing this.

3.10 Load the other paper bar as described above.

NOTE: A fully loaded frame is quite heavy. Take care when moving it and always leave it in a stable position.

Fig.2

Fig.3

3. USING THE DISPENSERS

01284 757500

01284 703534

sales@sealey.co.uk

Sole UK Distributor, Sealey Group,

Kempson Way, Suffolk Business Park,

Bury St. Edmunds, Suffolk,

IP32 7AR

www.sealey.co.uk

Web

NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
