INSTRUCTIONS FOR:
LONG STROKE AIR HAMMER
MODEL No: SA11.V3
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions
and properly maintained, give you years of trouble free performance.
 WARNING! Ensure Health & Safety, local authority and general workshop practice regulations are adhered to when using this equipment.
 WARNING!Disconnect the hammer from the air supply before changing accessories, servicing or performing any maintenance.
 Keep the hammer clean and maintain it in good condition (use an authorised service agent).
Replace or repair damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
 Keep the work area clean and uncluttered. Ensure that there is adequate lighting.
Ensure chisels are correctly rated for the job. DO NOT use damaged or suspect chisels.
WARNING! Wear approved safety eye or face protection, ear defenders and, if dust is generated, respiratory protection.
Keep hands and body clear of the work when operating the hammer.
 Maintain correct balance and footing. Ensure that the floor is not slippery and wear non-slip shoes.
Remove ill fitting clothing. Remove ties, watches, rings and other loose jewellery and contain and/or tie back long hair.
Keep children and unauthorised persons away from the work area.
 Check moving parts alignment on a regular basis.
 Secure unstable workpiece with a clamp, vice or other adequate holding device.
 Avoid unintentional starting.
WARNING! Ensure that the correct air pressure is maintained and not exceeded.
Keep air hose away from heat, oil and sharp edges. Check air hose for wear before
each useand ensure that all connections are secure.
 DO NOT use the hammer for a task it is not designed to perform.
 DO NOT operate the hammer if any parts are damaged or missing as this may cause
failure and/or personal injury.
WARNING! DO NOT chisel into any materials containing asbestos.
 DO NOT switch the hammer on whilst the chisel is in contact with the workpiece.
 DO NOT carry the by the hose, or pull the hose from the air supply.
DO NOT hold the workpiece by hand. Use clamps or a vice (not included) to secure
the workpiece. Available from your Sealey dealer.
 DO NOT allow untrained persons to operate the hammer.
 DO NOT operate the hammer when you are tired or under the influence of alcohol, drugs or intoxicating medication.
 DO NOT use hammer where there is flammable liquid, solid or gas such as paint solvent, including waste wiping or cleaning rags etc.
 DO NOT leave the hammer operating unattended.
 DO NOT carry the hammer with your finger on the trigger.
 DO NOT direct air from the air hose at yourself or others.
When work is complete ensure that the air supply is turned off.
 When not in use disconnect from the air supply and store in a safe, dry, childproof area.
The recommended hook-up is shown in fig. 1.
2.1. Ensure the trigger is in the "off" position before
connecting to the air supply.
2.2. You will require an air pressure of 90psi and an
available air flow of 4cfm to operate the unit.
2.3. WARNING! Ensure the air supply does not exceed
120psi while operating the hammer. Too high an air
pressure and/or unclean air will shorten the product
life due to excessive wear and may be dangerous,
causing damage and/or personal injury.
2.4. Drain the air tank daily. Water in the air line will
damage the hammer.
2.5. Clean the air inlet filter screen weekly.
2.6. Line pressure should be increased to compensate for
unusually long air hoses (over 8 metres). The
minimum hose diameter should be 10mm I.D. and
fittings must have the same inside dimensions.
2.7. Keep hose away from heat, oil and sharp edges.
Check hoses for wear, and make certain that
all connections are secure.
2. AIR SUPPLY
1. SAFETY
Original Language Version SA11.V3 Issue: 5 (L) - 05/02/15
© Jack Sealey Limited
fig. 1
Refer to
Instructions
Wear Eye
Protection
Wear Ear
Protection
Wear Protective
Gloves

Note: Numbers in brackets refer to item numbers in the parts list.
The air hammer is designed primarily for use on vehicle bodywork. We do not recommend any other use. Ensure you read, understand and
follow the safety instructions in Section 1.
5.1. Attach the retaining spring (17) by screwing it onto the Cylinder (16).
5.2. Insert the chisel using the hooked end of the spring to hold the chisel in place.
5.3. Attached the tool to the air supply (see Section 2).
5.4. To operate the hammer, squeeze the trigger (6). The air regulator (5) may be used as a means of throttle control.
WARNING!Disconnect the hammer from the air supply before changing chisels, servicing or performing any maintenance.
6.1. Keep the hammer oiled for optimum performance.
Lubricate with a good grade of air tool oil such as Sealey ATO/500 or ATO/1000. If there is no oiler in the air system then a teaspoon of
oil can be poured into the air inlet of the hammer, or into the hose at the nearest connection to the air supply. Then run the hammer for
a short time.
Note: The following external factors may cause loss of power and effect hammer performance:
The air supply
Reduced compressor output, excessive drain on the air line, moisture or restrictions in air pipes or the use of hose connectors
having too small a bore. Correct as necessary.
The hammer
Grit or gum deposits in the tool. Correct by cleaning the air strainer and flushing out the tool with gum solvent oil or an equal mixture of
SAE No.10 oil and kerosene.
If, despite taking action as above, the tool function is still impaired, contact your local Sealey service agent.
GS/TUV approved quality long stroke air hammer supplied in carry case. Kit also includes spare retainer spring, long blade panel cutter,
special panel cutter, panel cutter, exhaust tail pipe remover, cold chisel, air hose connector and air tool lubricating oil.
5. OPERATION
7. PARTS LIST
6. MAINTENANCE
3. INTRODUCTION
4. SPECIFICATION
Chisel Shank .... 0.401” Parker Taper
Speed ...................3500bpm
Stroke ..................... 66mm
Operating Pressure ...........90psi
Air Consumption.............. 4cfm
Air Inlet ...................1/4”BSP
Weight .....................1.5kg
Noise Power ........... 112.49dB(A)
Noise Pressure..........101.5dB(A)
Vibration ................ 11.36m/s²
Uncertainty ............. 0.9816m/s²
Item Part No. Description
1 SA11R/01 Housing
2 SA11R/02 Pin
3 SA11R/03 Ball Seat
4 SA11R/04 0-ring
5 SA11R/05 Air Regulator
6 SA11R/06 Trigger
8 SA11R/08 Valve Stem
9 SA11R/09 Bushing
10 SA11R/10 Spring
11 SA11R/11 Air Inlet
12 SA11R/12 Valve Case
15 SA11R/15 Piston
16 SA11R/16 Cylinder
17 SA11R/17 Spring

WARNING! – Risk of Hand Arm Vibration Injury.
This tool may cause Hand Arm Vibration Syndrome if its use is not managed adequately.
This tool is subject to the vibration testing section of the Machinery Directive 2006/42/EC.
This tool is to be operated in accordance with these instructions.
Measured vibration emission value (a): .........11.36m/s²
Uncertainty value (k):..........................0.98m/s²
Please note that the application of the tool to a sole specialist task may produce a different average vibration emission. We recommend that a
specific evaluation of the vibration emission is conducted prior to commencing with a specialist task.
A health and safety assessment by the user (or employer) will need to be carried out to determine the suitable duration of use for each tool.
NB: Stated Vibration Emission values are type-test values and are intended to be typical.
Whilst in use, the actual value will vary considerably from and depend on many factors.
Such factors include; the operator, the task and the inserted tool or consumable.
NB: ensure that the length of leader hoses is sufficient to allow unrestricted use, as this also helps to reduce vibration.
The state of maintenance of the tool itself is also an important factor, a poorly maintained tool will also increase the risk of Hand Arm Vibration
Syndrome.
Health surveillance.
We recommend a programme of health surveillance to detect early symptoms of vibration injury so that management procedures can be
modified accordingly.
Personal protective equipment.
We are not aware of any personal protective equipment (PPE) that provides protection against vibration injury that may result from the
uncontrolled use of this tool. We recommend a sufficient supply of clothing (including gloves) to enable the operator to remain warm and dry
and maintain good blood circulation in fingers etc. Please note that the most effective protection is prevention, please refer to the Correct Use
and Maintenance section in these instructions. Guidance relating to the management of hand arm vibration can be found on the HSE website
www.hse.gov.uk - Hand-Arm Vibration at Work.
