Apollo-155
Long Range Lantern Adjustable from 4-12nm+
Programming, Installation & Service Manual

Apollo-155
Integrated bird deterrent
spiked cap (colour of cap
designates light colour)
Automatic night activation
Independently controlled LEDs
can be congured to create
ashing or rotating lantern
155mm diameter lens &
integrated anodised aluminium
heat sink (patents pending)
PC programming port
12v DC power supply
Apollo-155 1-TierApollo-155 2-Tier

Latest products and information available at www.sealite.com
3
Apollo-155
Long Range Lantern Adjustable from 4-12nm+
Table of Contents
Introduction..........................................................................................Page 4
Technology...........................................................................................Page 4
Apollo-155 Model.................................................................................Page 5
Product Components..........................................................................Page 7
Programming Instructions..................................................................Page 8
1. Run the Programming Software..............................................Page 8
2. Connect the Apollo-155 Lantern to a Power Source
& the Computer.....................................................................Page 10
3. Establish the Programmer-to Lantern Computer
Connection (COM Port).........................................................Page 10
4. Programming the Lantern......................................................Page 12
5. Finalising the Lantern Programming .....................................Page 26
Power Requirements.........................................................................Page 27
Lantern Testing..................................................................................Page 28
Lantern Installation ...........................................................................Page 28
Option 1. Installation of Lantern to Mains Power.......................Page 28
Option 2. Installation of Lantern to Solar Powered System.......Page 29
Flash Code Reference List ...............................................................Page 34
Maintenance and Servicing..............................................................Page 39
Trouble Shooting...............................................................................Page 40
Sealite LED Light Warranty ..............................................................Page 42
Version No. Description Date Author Approved
1.0 Manual launch May 2010 K. Paton
1.1 Warranty and Tech Image Update July 2010 K. Paton
1.2 Power Requirement Update August 2010 K. Paton
1.3 General Corrections December 2010 A. Burns
2.0 Addition of 2-tier model April 2012 C. Procter
2.1 General Update Feb 2017 A.Dixon M.Nicholson

Latest products and information available at www.sealite.com
4
Apollo-155
Long Range Lantern Adjustable from 4-12nm+
Introduction
Congratulations! By choosing to purchase the APOLLO-155 lantern, you have
become the owner of one of the most advanced LED marine lantern in the world.
Sealite Pty Ltd has been manufacturing marine lanterns for over 25 years, and every care has been
taken to ensure your lantern gives years of reliable service.
As a commitment to producing the highest quality products for our customers, Sealite has been
independently certied as complying with the requirements of ISO9001:2008 quality management
system for the design and manufacture of marine lanterns.
Sealite lanterns comply with the requirements of the US Coast Guard in 33 CFR part 66 for Private
Aids To Navigation.
By taking a few moments to browse through this booklet, you will become familiar with the versatility of
your lantern, and be able to maximise it’s operating function.
Technology
Sealite is the world’s fastest growing manufacturer of marine aids to navigation.
We employ leading mechanical, optical, hardware & software engineers to create
innovative products to service the needs of our customers worldwide, and offer the
widest range of solar-powered LED lanterns in the marketplace.
Electronics
Sealite employs leading in-house electronic engineers in the design and development of software and
related circuitry. All individual electronic components are sourced directly by Sealite procurement staff
ensuring that only the highest quality components are used in our products.
LED Technology
All marine lanterns use the latest advancements in LED (Light Emitting Diode) technology as a
light source. The major advantage of LED’s over traditional light sources is well established in that
they typically have an operational life in excess of 100,000 hours, resulting in substantial savings to
maintenance and servicing costs.
Precision Construction
Commitment to investing in the design and construction of injection-moulded parts including optic
lenses, light bases and a range of other components ensures that all Sealite products are of a
consistent and superior quality.
Optical Performance
Sealite manufactures a range of marine LED lenses moulded from multi-cavity dies. Complex shapes
such as the SL70, BargeSafe™ and 16-segment multi-focus lenses are a testament to the company’s
superior in-house lens manufacturing capabilities and outstanding optical performance.
Award-winning, Patented Technology
Several United States and Australian patent registrations are held on Sealite’s range of innovative
designs, with other regional patents pending in Canada, United Kingdom and Europe.

Latest products and information available at www.sealite.com
5
Apollo-155
Long Range Lantern Adjustable from 4-12nm+
Apollo-155 Model
The Apollo-155 is the next generation in marine aids to navigation.
To utilise the latest technology, Sealite has designed a lantern using the world’s most
advanced LEDs. These highly efcient LEDs can be congured individually to create not just a
ashing lantern, but also a sectored lantern, rotating lantern, and even more complex sectors
with multiple ash codes in the same lantern.
The Apollo-155 incorporates a sophisticated thermal management system. Sealite’s in-house
engineers custom designed this complex aluminium extrusion which is used as a heat sink for
the LEDs and LED driver board.
The distinct lens of the Apollo-155 has 16 optical elements controlling the light emissions for
the LED in a two-dimensional manner; completely unique to the industry. The 16x LEDs in each
lens individually cover 45° horizontally and 5° vertically.
The optic also facilitates internal sectoring across broad range of output requirements.
Like all Sealite marine lanterns the Apollo-155 has a specically designed circuit board that
controls automatic dusk to dawn operation, LED operation and many functions that can be
specically requested, such as current monitoring, GSM, GPS or radio-control.
The lantern can be congured using a simple, user-friendly computer program.
Sealite Apollo-NPS
Sealite’s APOLLO SL-155-NPS non-precision sector lantern is adjustable from 4–9M+ and has
been designed to suit a range of applications.
The distinctive lens of the SL-155-NPS has 16 optical elements controlling the light emissions
for the LED in a two-dimensional manner; completely unique to the industry.
The optic facilitates internal sectoring across a broad range of output requirements.
Sealite can produce almost any combination of colours and angles and meet the requirements
of our customers.
Customers need to identify each colour and angle, Flash codes, range and any other specic
requirements.
The Apollo-NPS is hand built to each set of unique customer requirements. Due to the unique
build of each light, the Apollo-NPS cannot be recongured as much as a standard Apollo.

Latest products and information available at www.sealite.com
6
Apollo-155
Long Range Lantern Adjustable from 4-12nm+
SPECIFICATIONS •
•Specications subject to change or variation without notice
*Subject to standard terms and conditions
†Intensity setting subject to solar availability
‡Higher outputs at increased current draw
Light Characteristics
Light Source 16 ultra bright LEDs per tier
Available Colours Red, Green,White,Yellow, Blue
Intensity at maximum wattage
(cd)†‡
1-tier: Red - 1140 Green - 2127 White - 2110 Yellow - 677
2-tier: Red - 2052 Green - 3743 White - 3587 Yellow - 1164
Visible Range (nm) 4–12+
Horizontal Output (degrees) 0 - 360
Vertical Divergence (degrees) 5 ± 2.5 at 50% peak
Available Flash Characteristics Up to 256 IALA recommended (PC programmed)
Intensity Adjustments 32 levels (PC programmed)
LED Life Expectancy (hours) >100,000
Electrical Characteristics
Current Draw (mA) Refer to Sealite Power Calculator
Circuit Protection Polarity protected
Nominal Voltage (v) 12v DC only
Temperature Range -40 to 80°C
Physical Characteristics
Body Material Anodised 6060nSeries Aluminium
Lens Material LEXAN® Polycarbonate – UV-stabilised
Lens Diameter (mm/inches) 155 / 61/8
Lens Design Sealite 16 segment, multi-focus LED lens (patents pending)
Mounting 3 & 4 hole bolt pattern on 200mm OD base
Height (mm/inches) 1-tier: 300 / 114/5 2-tier: 395 / 151/2
Width (mm/inches) 1-tier: 235 / 91/3 2-tier: 235 / 91/3
Mass (kg/lbs) 1-tier: 3.8 / 83/8 2-tier: 6 / 13.2
Product Life Expectancy Up to 12 years
Certications
CE M091133
Quality Assurance ISO9001:2008
Waterproof IP68
Intellectual Property
Patents Australian Provisional Patent 1004289015
Trademarks SEALITE® is a registered trademark of Sealite Pty Ltd
Warranty * 3 years
Options Available • Rotating beacon
• Sectored light
• Wreck marking light
• GPS Synchronisation
• RF Synchronisation
• AIS Remote Monitoring
• Radio Control System

Latest products and information available at www.sealite.com
7
Apollo-155
Long Range Lantern Adjustable from 4-12nm+
The following components come standard with each lantern:-
• Apollo-155 lantern
• USB drive (loaded with lantern programming software & other important information)
• Programming cable (to connect the lantern to your computer via serial port/comm port)
• Installation & service manual
• Warranty registration card
These components are securely packaged within foam in a carton, and shipped to you.
PLEASE NOTE: The programming cable provided is suitable for use with PC’s. If you require
connection to your notebook/laptop, a Serial Port to USB cable may need to be purchased.
Please check that ALL of these components are included with your order, and
contact your Sealite representative as soon as possible if anything is missing.
Product Components

Latest products and information available at www.sealite.com
8
Apollo-155
Long Range Lantern Adjustable from 4-12nm+
The Apollo-155 lantern is available in a variety of LED colours (single or multiple colours) and sectors
to meet a range of installation and regulatory requirements. The LED colour(s) are set within each
lantern when manufactured, and then the lantern is pre-programmed to the customer’s specic
requirements for convenience (eg. ash & intensity setting, sectors etc).
The Apollo-155 is an extremely intelligent lantern with a number of features which can be programmed
directly via a user-friendly computer program (as supplied on USB drive with every lantern).
The specic setup of your lantern will determine which features are programmable.
To change/update the settings of your lantern, please read the following instructions.
1. Run the Programming Software
The programming software (Sealite Lantern Programmer) may be run directly from the USB drive
provided, or you may copy the software to your computer hard-drive for future use.
Running the Programming Software from the USB Drive
• Connect the USB drive to your computer
• Navigate to the USB drive folder & double-click the le called “Sealite Lantern Programmer”. A
new window will appear displaying the Sealite Lantern Programmer
Saving the Programming Software to Computer Hard-Drive
• Connect the USB drive to your computer
• Navigate to the USB drive folder
• Right-mouse-click the le called “Sealite Lantern Programmer” and select “copy”
• Navigate to the hard-drive location where you would like to save this program, and then right-
mouse-click and select “paste”. A copy of the programming software will now be saved to your
computer hard-drive (to add the programmer to your computer desktop for ease of future access,
right-mouse-click and select “Send to desktop”)
• Double-click the le called “Sealite Lantern Programmer”. A new window will appear displaying the
Sealite Lantern Programmer
PLEASE NOTE: other documents have been saved on the USB drive for your information &
convenience including the latest product specications sheet, power calculator, and an electronic
version of the installation and service manual. You may wish to view these documents to read more
about the innovative features and benets of the Apollo-155.
IMPORTANT: the Sealite Lantern Programmer is designed for Windows Platforms only.
Programming Instructions

Latest products and information available at www.sealite.com
9
Apollo-155
Long Range Lantern Adjustable from 4-12nm+
Image 1. Sealite Lantern Programmer

Latest products and information available at www.sealite.com
10
Apollo-155
Long Range Lantern Adjustable from 4-12nm+
2. Connect the Apollo-155 Lantern to a Power Source & the Computer
Now that the programming software has been run, you will need to connect the Apollo-155 lantern to
your computer & power supply so that it can receive programming commands.
Once connection is made, the software automatically determines whether the lantern is single or
2-Tier.
Connecting the Lantern to a Power Source
Option 1: Battery
• Connect the blue negative wire of the lantern to the battery negative terminal
• Connect the brown positive wire of the lantern to the battery positive terminal
Option 2: 12v Power Supply
• Connect the blue negative wire of the lantern to the power supply negative termainal
• Connect the brown positive wire of the lantern to the power supply positive terminal
CAUTION: to avoid personal injury do not position the Apollo-155 lantern at eye level.
Connecting the Lantern to the Computer
• Plug the Bulgin connector end of the the programming cable into the lantern PC Programming Port,
and the serial port end of the cable into your computer serial/communication port (RS232-E)
PLEASE NOTE: The programming cable provided is suitable for use with desktop PC’s. If you require
connection to your notebook/laptop, a Serial Port to USB cable may need to be purchased.
3. Establish the Programmer-to-Lantern Computer Connection (COM Port)
Now that the lantern is connected to the computer and the Sealite Lantern Programmer software has
been run, the user must create the programmer-to-lantern connection.
The COM Port is the hardware port which the computer accesses when communicating with the lantern.
• From the Sealite Lantern Programmer select the appropriate COM Port from the drop down eld at
the top left of the menu page
• Click the “Open COM Port” button to initiate the connection
The Sealite Lantern Programmer will then attempt to connect/interrogate the lantern.
Correct Connection Established
If the connection is established data about the lantern conguration will appear under the headings
“Lantern Information” & “Existing Conguration” (eg. Lantern Colour, Peak Intensity, Operating Mode
etc).
Connection NOT Established
If the connection is not available, the Sealite Lantern Programmer will not display any lantern
specic information under the headings “Lantern Information” & “Existing Conguration”
(eg. Lantern Colour = ?). If this error occurs, please check the following:
• Reconnect the lantern to the computer
• Check that the lantern power supply has sufcient charge (eg. battery is charged), and then
reconnect it to the lantern
• Re-run the Sealite Lantern Programmer. The connection should now become established.
The Sealite lantern is now ready to be programmed to your specic requirements.

Latest products and information available at www.sealite.com
11
Apollo-155
Long Range Lantern Adjustable from 4-12nm+
Sealite Lantern Programmer “Information” tab – showing COM Port connection established, Lantern
Name & Lantern Information
Sealite Lantern Programmer Matrix.
Programming Operation
Apollo
Apollo-NPS
4.1 Naming the Lantern


4.2 Operation Setting


4.3 Advanced Operation Settings


4.4 Standard Flash Codes


4.5 Custom Flash Codes


4.6 Intensity Selection


4.7 Effective Intensity Correction


4.8 Light Sensor


4.9 Battery Sensor


4.10 Temperature Sensor


4.11 Pulse Shape


4.12 LED Specific –Programming for Advanced Users



Latest products and information available at www.sealite.com
12
Apollo-155
Long Range Lantern Adjustable from 4-12nm+
4. Programming the Lantern
Now that the Sealite Lantern Programmer is running and connected to a specic lantern, the user may
congure individual settings of the lantern to suit their particular requirements.
Programming Options Available Include:
• Naming the Lantern (up to 44 characters)
• Operation Setting
o Standby
o Always On
o Dusk to Dawn
• Advanced Operation Settings (congure individual banks of LEDs eg. sectored, rotating & wreck-
marking lights)
• Standard Flash Codes (up to 304 pre-dened codes available)
o IALA Flash Characteristic Selection
o Sealite Flash Characteristic Selection
• Custom Flash Codes (set the lantern to your exact ash requirements)
• Intensity Selection
o Range (nm)
o Candela (cd)
o Pulse Width Modulation (PWM)/Talbot-Plateau Intensity
• Effective Intensity Correction
o Schmidt-Clausen
o Allard
o Blondel-Rey-Douglas
o Allard-Ohno-Couzin
• Lantern Sensor Thresholds
o Ambient Light Threshold/Lux Level (select the ambient light levels for lanterns set to Dusk
to Dawn mode)
o Low Battery Sensor (select the battery voltage thresholds)
o Temperature Threshold (select the internal lantern temperature levels in which the lantern
will automatically reduce it’s intensity)
• Pulse Shape (select the way the light displays eg. soft glow of incandescent)
o Leading Edge
o Trailing Edge
• LED Specic Programming for sectored lights only (for advanced users, congure each individual
LED to suit your specic requirements)
o Flash Code
o Intensity
o Sync Offset
The following information describes in detail how to customise/control each of the
above lantern programming options.

Latest products and information available at www.sealite.com
13
Apollo-155
Long Range Lantern Adjustable from 4-12nm+
IMPORTANT: the programmer will only send/update certain lantern features when the user clicks
the relevant “SET” button. Eg. When navigating between different tab sections of the Sealite Lantern
Programmer, ensure that you click the SET button of the feature before moving to the next tab.
The programmer will automatically gather/request information form the lantern on occasion. Please be
aware that slight page update delays may occur when the programmer is refreshing the information on
the screen.
4.1 Naming the Lantern
The user can allocate a specic name for each lantern for ease of recognition when programming. Eg.
Sealite Lantern 01, North Cardinal #1 etc (see Image 2). This name may be up to 44 characters in
length.
To program the lantern name (see Image 2):
• Click the “Information” tab at the top of the Sealite Lantern Programmer
• From the “Lantern Name” box, type in the name you wish to allocate to the lantern
• Click the “Set Name” button
• The lantern name will appear above where you typed the new name
4.2 Operation Setting
The user may select the operation setting in which they would like the lantern to be set (see Image 3).
Options include:
Standby
The lantern is still with power but will not ash the selected ash code (this mode is NOT suitable for
long term storage).
Always On
The lantern is active and will always ash the selected ash code day and night. The lantern will only
turn off when the battery is at.
Dusk to Dawn
The lantern will be active and ash the selected ash code only at night. During daylight hours the
lantern will be in standby mode.
To program the lantern operation setting (see Image 3):
• Click the “Operation” tab at the top of the Sealite Lantern Programmer
• From the “Operation Setting” box, select the desired lantern operation setting from the drop down
eld
• Once selected from the drop down eld, the lantern will automatically send the setup instruction to
the lantern (eg. lantern will automatically change setup)
PLEASE NOTE: to test lantern setting for “Dusk to Dawn” mode, cover the lantern with a dark cloth/
jacket for approximately 1min. The lantern will then begin ashing to the selected ash code.
IMPORTANT: when programming the lantern it may be necessary to use the “Always On” Operation
Setting so there is no delay when sending a message to the lantern and viewing/testing the new
setting. To maximise the lantern operational life, Sealite recommends setting the lantern
operation setting to dusk to dawn.

Latest products and information available at www.sealite.com
14
Apollo-155
Long Range Lantern Adjustable from 4-12nm+
Image 3. Sealite Lantern Programmer “Operation” tab – showing Operation Setting
& Advanced Operation Setting
4.3 Advanced Operation Settings
The Apollo-155 comes standard with 16 ultra bright 3watt CREE® LEDs and are available in a range
of IALA recommended colours & congurations (eg. sectored lights or rotating beacons).
CREE® LEDs are leading the LED lighting revolution with their unprecedented lighting-class
brightness, efcacy, lifetime and quality of light. These features provide a viable alternative to
traditional lighting products, and save money with energy-efciency and long service life.
Each individual LED within the Apollo-155 has a number of pre-dened “Advanced Operation Settings”
(as determined by the positioning of the LEDs during manufacture and the programming set). Users
may activate/deactivate particular advanced operation settings using the Sealite Lantern Programmer
including:
All LEDs – the lantern will ash the selected ash code using all the LEDs. All LEDs will ash with
the same ash characteristic, with the same sync offset, at the same intensity. This is the default
conguration for the lantern.
Bank 1 Only – the lantern will ash the LEDs of Bank 1 only. All LEDs found in banks 2, 3 & 4 will be
turned off. All LEDs in bank 1 will ash with the same ash characteristic, with the same sync offset, at
the same intensity. This is used on a lantern that contains two or more coloured LEDs.

Latest products and information available at www.sealite.com
15
Apollo-155
Long Range Lantern Adjustable from 4-12nm+
Bank 2 Only – the lantern will ash the LEDs of Bank 2 only. All LEDs found in banks 1, 3 & 4 will be
turned off. All LEDs in bank 2 will ash with the same ash characteristic, with the same sync offset, at
the same intensity. This is used on a lantern that contains two or more coloured LEDs.
Shipwreck 1,2 – alternating bank 1 & bank 2. The lantern will ash one complete ash characteristic
using the LEDs of bank 1. It will then ash a complete ash characteristic using the LEDs of bank 2. It
will then ash using the LEDs of bank 1 again. All LEDs positioned in banks 3 & 4 will be turned off. All
LEDs in banks 1 & 2 will ash with the same ash characteristic, at the same intensity. This is used on
a shipwreck lantern.
Cycle 1,2,3,4 – cycle bank 1 to 4. The lantern will ash one complete ash characteristic using the
LEDs of bank 1. It will then ash a complete ash characteristic using the LEDs of bank 2. Then bank
3, and then bank 4. This was used to make a rudimentary rotating lantern; it has been included for
legacy support only.
Sector – the lantern can ash a different ash characteristic on each sector. Each LED can be run at a
different intensity.
Complex Sector – the lantern can ash a different ash characteristic, at a different sync delay, at a
different intensity for each LED. This provides complete independent control over each LED on the
lantern.
Rotating, Full Speed (CCW) – the lantern will rotate anti-clockwise at full speed on the selected ash
character.
Rotating, Half Speed (CCW) – the lantern will rotate anti-clockwise at half speed on the selected
ash character.
Rotating, Bank 1 (CCW) – using bank 1 LEDs only, the lantern will rotate anti-clockwise at full speed
on the selected ash characteristic.
Rotating, Bank 2 (CCW) – using bank 2 LEDs only, the lantern will rotate anti-clockwise at full speed
on the selected ash characteristic.
Rotating, Full Speed (CW) – the lantern will rotate clockwise at full speed on the selected ash
character.
Rotating, Half Speed (CW) – the lantern will rotate clockwise at half speed on the selected ash
character.
Rotating, Bank 1 (CW) – using bank 1 LEDs only, the lantern will rotate clockwise at full speed on the
selected ash characteristic.
Rotating, Bank 2 (CW) – using bank 2 LEDs only, the lantern will rotate clockwise at full speed on the
selected ash characteristic.
Rotating, VOR (CW) – the lantern will rotate clockwise as a VOR lantern on the selected ash
characteristic. Bank 1 will rotating clockwise, bank 2 will ash in sync at time, t = zero.

Latest products and information available at www.sealite.com
16
Apollo-155
Long Range Lantern Adjustable from 4-12nm+
To activate/deactivate a particular Advanced Operation Setting (see Image 3):
• Click the “Operation” tab at the top of the Sealite Lantern Programmer
• From the “Advanced Operation Setting” box, select the desired advanced operation
setting required from the drop down eld
• Once selected from the drop down eld, the lantern will automatically send the setup
instruction to the lantern (eg. lantern will automatically change setup)
PLEASE NOTE: advanced operation settings not supported will NOT display in the selection list
available.
4.4 Standard Flash Codes
Using the Sealite Lantern Programmer, Sealite lanterns may be set to any of up to 304 pre-dened
standard ash codes including a complete range of IALA recommended ash codes. The ash code
may be programmed by selecting from the IALA Flash Characteristic range, or by typing in the specic
Sealite Flash Characteristic setting (see Image 4).
Image 4. Sealite Lantern Programmer “Flash Code” tab – showing IALA Flash Characteristic
Selection, Sealite Flash Characteristic Selection & Custom Flash Codes

Latest products and information available at www.sealite.com
17
Apollo-155
Long Range Lantern Adjustable from 4-12nm+
Option 1: IALA Flash Characteristic Selection
• Click the “Flash Code” tab at the top of the Sealite Lantern Programmer
• From the “IALA Flash Characteristic Selection” box, select the desired IALA ash characteristic
class from the drop down eld. Eg. FL
• Next select the desired ash timing interval from the subclass drop down eld. Eg. FL 2 S will set
the lantern to ash ON & then OFF once within a 2sec interval
• Next select the specic ON & OFF ash timing setting from the drop down eld. Eg. 20: 0.2, 1.8
will set the lantern to ash for 0.2sec ON & 1.8sec OFF
• Click the “Set Flash Code” button at the bottom of the page to send the new setup instruction to
the lantern
PLEASE NOTE: when selecting the IALA Flash Characteristic, elds in the “Sealite Flash
Characteristic” & “Custom Flash Code” elds below will populate with the particular information. Once
set, information about the selected ash code will also be updated in the “Existing Conguration” box.
IALA Flash Code Symbols
FL Flash followed by number Eg. FL 1 S represents one ash every second
F Fixed
Q Quick ash
VQ Very quick ash
OC Occulting; greater period ON than OFF
ISO Isophase; equal period ON and OFF
LFL Long ash long
MO Morse code ( ) contains letter
For example, VQ (6) + LFL 10 S represents 6 very quick ashes followed by a long ash, during a 10
second interval.
Recommended Rhythm for Flashing Light - IALA Regions A and B
MARK DESCRIPTION RHYTHM
Port Hand & Starboard Marks: Any, other than Composite Group Flashing (2+1)
Preferred Channel Starboard: Composite Group Flashing (2+1)
Preferred Channel Port: Composite Group Flashing (2+1)
North Cardinal Mark: Very quick or quick
East Cardinal Mark: Very quick (3) every 5 seconds or quick (3) every 10 seconds
South Cardinal Mark: Very quick (6) + long ash every 10 seconds or quick (6) + long ash every 15 seconds
West Cardinal Mark: Very quick (9) every 10 seconds or quick (9) every 15 seconds
Isolated Danger Mark: Group ashing (2)
Safe Water Mark: Isophase, occulting, one long ash every 10 seconds or Morse Code “A”
Special Marks: Any, other than those described for Cardinal, Isolated Danger or Safe Water Marks

Latest products and information available at www.sealite.com
18
Apollo-155
Long Range Lantern Adjustable from 4-12nm+
Option 2: Sealite Flash Characteristic Selection
• Click the “Flash Code” tab at the top of the Sealite Lantern Programmer
• From the “Sealite Flash Characteristic Selection” box, type in the desired Sealite ash code
reference. Eg. 51 (this code may be up to 3 hexadecimal characters eg. 0 to 9 and A to F)
• Click the “Set Flash Code” button at the bottom of the page to send the new setup instruction to
the lantern
PLEASE NOTE: when selecting the Sealite Flash Characteristic, elds in the “Custom Flash Code”
elds below will populate with the particular information. Once set, information about the selected ash
code will also be updated in the “Existing Conguration” box.
IMPORTANT: the amount of power your lantern draws through the night depends on the duty cycle,
i.e. the amount of time ON as a proportion to the timing cycle. For example, 0.5 seconds ON and 4.5
seconds OFF equals a 10% duty-cycle. Sealite recommends lantern ash setting to be set to the
lowest duty-cycle appropriate to the actual needs of the application.
For a complete list of Sealite Flash Codes available, please refer to the “Flash Code Reference
List” at the end of this manual.
4.5 Custom Flash Codes
If you cannot nd the appropriate ash code from the Standard Flash Codes available, the user
may custom set the lantern to ash in any sequence required. Any ash code characteristic up to 10
ashes with a total characteristic no longer than 10 minutes may be set.
To set a Custom Flash Code (see Image 4):
• Click the “Flash Code” tab at the top of the Sealite Lantern Programmer
• From the “Custom Flash Code, Type A” box, type in “ON time” and “OFF time” timing information
required (in seconds – available in steps of 10 milliseconds (0.01))
• Click the “Set Flash Code” button at the bottom of the page to send the new setup instruction to
the lantern
PLEASE NOTE: when a custom ash code is programmed into the lantern, the code will display as
“FFF”.

Latest products and information available at www.sealite.com
19
Apollo-155
Long Range Lantern Adjustable from 4-12nm+
4.6 Intensity Selection
Using the Sealite Lantern Programmer, Sealite lanterns may be set to a standard light intensity to
meet installation requirements. The desired intensity range may be set in nautical miles (nm - with
dependence on listings of atmospheric transmissivity and background lighting conditions), candela
(cd) or direct pulse width modulation (PWM) (see image 5).
Atmospheric Transmissivity (AT) – when a light beam passes through the atmosphere the atmospheric
transmissivity factor indicates how much light is absorbed by the atmosphere. For example, when AT =
0.85 this means that 85% of the original light intensity is visible after 1nm. Consequently 15% of light is
lost to atmospheric absorption.
Image 5. Sealite Lantern Programmer “Intensity” tab – showing Intensity Selection (nm),
Intensity Selection (cd), Intensity Selection (PWM) & Effective Intensity Correction

Latest products and information available at www.sealite.com
20
Apollo-155
Long Range Lantern Adjustable from 4-12nm+
Option 1: Desired Lantern Range (Nautical Miles)
• Click the “Intensity” tab at the top of the Sealite Lantern Programmer
• From the “Intensity Selection” box, type in the desired lantern range (nautical miles)
• Next select the “Atmospheric Transmissivity” level from the drop down eld
• Next select the “Background Lighting Conditions” level from the drop down eld (for standard
marine applications select “Night, No Background Lighting”)
• Once selections entered/made, the lantern will automatically send the setup instruction to the
lantern (eg. lantern will automatically change setup)
Option 2: Desired Lantern Intensity (Candela)
• Click the “Intensity” tab at the top of the Sealite Lantern Programmer
• From the “Intensity Selection” box, type in the desired lantern intensity (candela)
• Once selections entered, the lantern will automatically send the setup instruction to the lantern
(eg. lantern will automatically change setup)
Option 3: Direct Pulse Width Modulation (PWM) Value
• Click the “Intensity” tab at the top of the Sealite Lantern Programmer
• From the “Intensity Selection” box, either type in the desired pulse width modulation value (%) into
the eld OR/ move the horizontal scroll bar to the desired PWM
• Once selections entered/made, the lantern will automatically send the setup instruction to the
lantern (eg. lantern will automatically change setup)
For more information about intensity settings please review IALA Recommendation E-200 Part
2. Contact Sealite today for an electronic version.
4.7 Effective Intensity Correction
Depending on the ash code selected, the effective intensity may be adjusted.
As per IALA Recommendation E-200 Part 4, effective intensity is dened as: “The luminous intensity
of a xed (continuous) light, of the same relative spectral distribution as a ashing light, which would
have the same luminous range as a ashing light under identical conditions of observation”.
Sealite has provided you with the most common methods for effective intensity adjustment as follows:
• Schmidt-Clausen
• Allard
• Blondel-Rey-Douglas
• Allard-Ohno-Couzin
PLEASE NOTE: the lantern Effective Intensity Correction is set to “None” as default. No effective
intensity correction will therefore be applied to the lantern setting.
To program the lantern Effective Intensity Correction (see Image 5):
• Click the “Intensity” tab at the top of the Sealite Lantern Programmer
• From the “Effective Intensity Correction” box, select the desired lantern effective intensity
correction mode from the list available
• Click the “Set Intensity” button to send the new setup instruction to the lantern
For more information about intensity settings and effective intensity correction methods please
review IALA Recommendation E-200 Part 4. Contact Sealite today for an electronic version.
