Sealite SL-C510 Supplement

SL-C510
Compact 5-9NM Solar Marine Lantern
V1.0
INSTALLATION & SERVICE MANUAL

2
Version No. Description Date Approved
1.0 Manual Launch March 2019 M.Nicholson

SL-C510
Compact 5-9NM Solar Marine Lantern
Latest products and information available at www.sealite.com 3
Table of Contents
Introduction............................................................................................................................................................ Page 4
Operating Principle .......................................................................................................................................... Page 4
Technology ............................................................................................................................................................ Page 4
SL-C510 Model .................................................................................................................................................... Page 5
Installation ............................................................................................................................................................ Page 7
Viewing Lantern Settings ........................................................................................................................... Page 9
Summary of Lantern Status ................................................................................................................. Page 10
Programming the Lantern ...........................................................................................................................Page 11
SealitePro®Bluetooth®Guide ................................................................................................................ Page 11
SealitePro®Bluetooth®Controller Functions ................................................................................ Page 12
Accessing the SealitePro®App for the first time .....................................................................Page 14
SealitePro®Password Reset Procedure ........................................................................................ Page 17
Lantern Status ................................................................................................................................................Page 19
Solar Calculations ........................................................................................................................................ Page 20
Programming Options .............................................................................................................................. Page 23
Manufacturing Data ........................................................................................................................................ Page 32
SealitePro®Troubleshooting ..................................................................................................................... Page 36
Optional IR Remote Control ....................................................................................................................... Page 38
Optional GPS Synchronisation ................................................................................................................ Page 47
Optional GSM Monitoring & Control System ..................................................................................Page 48
Lantern Status...................................................................................................................................................... Page 49
Lantern Thermal Management ............................................................................................................... Page 50
Lantern Data.................................................................................................................................................... Page 50
Thermal Limit Operation........................................................................................................................... Page 51
Appendix.................................................................................................................................................................. Page 52
Flash Codes...................................................................................................................................................... Page 52
Maintenance & Servicing............................................................................................................................. Page 59
Trouble Shooting................................................................................................................................................. Page 62
Sealite LED Light Warranty......................................................................................................................... Page 62
Notes............................................................................................................................................................................ Page 63

4
Introduction
Congratulations! By choosing to purchase a Sealite lantern you have become the owner of one of the
most advanced LED marine lanterns in the world.
Sealite Pty Ltd has been manufacturing lanterns for over 25 years, and particular care has been taken to
ensure your lantern gives years of service.
As a commitment to producing the highest quality products for our customers, Sealite has been independently
certified as complying with the requirements of ISO9001:2015 quality management system.
Sealite lanterns comply with requirements of the US Coast Guard in 33 CFR part 66 for Private Aids to
Navigation.
By taking a few moments to browse through this booklet, you will become familiar with the versatility of your
lantern, and be able to maximize its operating function.
Operating Principle
The solar module of the lantern converts sunlight to an electrical current that is used to charge the battery.
The battery provides power to operate the lantern at night.
The flasher unit has very low current requirements. A microprocessor drives multiple ultra-bright LED’s (Light
Emitting Diodes) through a DC/DC converter, which enables the LED’s to operate within the manufacturer’s
specifications. The battery is protected from over-charging within the circuit to ensure maximum battery life.
On darkness, the microprocessor will initiate a program check and after approximately 1 minute begin flashing
to the set Flash Code.
Technology
Sealite is the world’s fastest growing manufacturer of marine aids to navigation. We employ leading
mechanical, optical, hardware & software engineers to create innovative products to service the needs of our
customers worldwide and offer the widest range of solar-powered LED lanterns in the marketplace.
Electronics
Sealite employs leading in-house electronic engineers in the design and development of software and related
circuitry. All individual electronic components are sourced directly by Sealite procurement staff ensuring that
only the highest quality components are used in our products.
LED Technology
All marine lanterns use the latest advancements in LED technology as a light source. The major advantage of
LED’s over traditional light sources is well established in that they typically have an operational life in excess of
100,000 hours, resulting in substantial savings to maintenance and servicing costs.
Precision Construction
Commitment to investing in the design and construction of injection-moulded parts including optic lenses,
light bases and a range of other components ensures that all Sealite products are of consistent and superior
quality.
Optical Performance
Sealite manufactures a range of marine LED lenses moulded from multi-cavity dies. The company has
superior in-house lens manufacturing capabilities to support outstanding optical performance.
Award-winning, Patented Technology
Several United States and Australian patent registrations are held on Sealite’s range of innovative designs, with
other regional patents pending in Canada, United Kingdom and Europe.

SL-C510
Compact 5-9NM Solar Marine Lantern
Latest products and information available at www.sealite.com 5
SL-C510
Compact 5-9NM Solar Marine Lantern
The SL-C510 is a robust, completely self-contained 5-9 NM Solar LED Lantern specifically designed to
withstand the tough marine environment to provide years of reliable, low maintenance service. The 3 & 4
hole bolt pattern base fits directly onto existing 200mm bolt pattern industry standard mounts for ease of
installation.
The four (4) premium-grade solar modules are integrated into the assembly, and mounted to collect sunlight at
all angles.
The base and top of the lanterns are made from composite moulded polymer with UV-stabilised rubber
corners and gaskets providing a superior IP68 – the best in the industry. A handle is incorporated into the
chassis for safe lifting.
The tough, polycarbonate lens is specifically designed for use with LEDs and incorporates an environment-
friendly spike to deter unwelcome bird life. The lens design also ensures that vessel operators clearly see the
light from above when passing the AtoN. The design incorporates a conveniently located OLED (Organic
Light-Emitting Diode) screen with touchpad allowing maintenance personnel to check the diagnostics of the
lantern with the touch of a button.
Completely programmable via the new Bluetooth®connected SealitePro®mobile application, the SL-C510
can be configured and monitored from a distance up to 50 metres. An in-built solar calculator confirms the
lanterns ability to operate at the set location, ensuring optimal operating performance.
The SL-C510 is available with GPS Synchronisation as standard. Two (2) or more lights can be synchronised to
flash in unison via an internal GPS module.
The SL-C510 may also be fitted with Satellite Communications Module or GSM Module – enabling users to
access real-time diagnostic data and change lantern settings. The system can also be configured to send out
alarm messages to designated phone numbers. Users can also have alarms and reports sent to designated
email addresses.
All this is backed by Sealite’s industry leading 3-year warranty.
OLED Display for Lantern
Status check
LED Optic
Robust composite moulded base and
top with handle, Aluminium chassis
with rubber extruded corners
3 & 4 hole 200mm bolt pattern
base for ease of installation
4 x monocrystalline solar modules,
ensuring maximum light collection to
charge the battery
Internal Battery

6
The following components come as standard with each lantern:
• SL-LA510 lantern
• SL-SBA 510 Chassis
• Quick Start Guide
Optional
• IR programmer remote
These components are securely packaged within protective wrap, in a carton and shipped to you.
Please check that ALL of these components are included with your order and contact your
Sealite representative as soon as possible if anything is missing.
Product Components

SL-C510
Compact 5-9NM Solar Marine Lantern
Latest products and information available at www.sealite.com 7
Charging the Battery
New lanterns should be left in the sun for 1-2 days to ensure battery is charged before placing in service.
Preferred Installation Location
For best lantern performance, ensure solar modules are not covered and are in clear view of the sky with no
shadows.
Lantern Installations Settings
The lantern can be programmed via 2 methods,
1. Bluetooth®connectivity via the SealitePro®App (recommended);
2. Via the optional Sealite IR Controller (optional);
The SealitePro®and Sealite IR Controller Instructions are included in this manual.
Lantern Operation
The lantern is activated by connecting the 4-Pin Connector between the battery and the regulator. Flash Codes
and Intensity settings need to be set via the SealitePro®App or the Sealite IR Controller.
1. Remove the four socket-head screws on the top of the lens assembly and lift the SL-C510 (light head)
assembly from the solar chassis.
2. Join the 4-Pin connector together to join the battery and the solar panels to the light head. The battery is
disconnected to reduce discharge during transportation and for long term storage.
3. Feed all wiring back inside the solar chassis and make sure the O-ring is properly placed.
4. Replace the SL-C510 (light head) assembly and the four (4) socket head screws. Sealite recommends that
the light head be tightened onto the solar chassis base using a general purpose “grip tool”, similar in shape
to a screwdriver, however with the appropriate hex key head fitted. The torque setting applied to each of
the four (4) hex bolts, be applied sufficient enough, to ensure that the light head base is secured firmly, but
not over tightened with excessive force.
To achieve a satisfactory seal, it is recommended that a torque of 3Nm is applied to the bolts used for holding
down the Light Head to the Solar Base and that only the supplied bolts are used.
Applying a higher torque setting is not recommended and may void warranty. If in doubt, please contact your
local Sealite representative.
9. To test, place a dark cover (towel or jacket) on top of the light to activate sensor. The light will come on
within thirty seconds.
10. Ensure that the unit is bolted to an even, flat surface.
Installation

8
84
371
408
492
Ø234
201
120°
Slot 12.6 x 21.75
6 Locations
Slot 12.6 x 21.75
6 Locations
SL-C510
Extended
Chassis
84
648
565
528
Ø234
201
120°
SL-C510
Compact
Chassis

SL-C510
Compact 5-9NM Solar Marine Lantern
Latest products and information available at www.sealite.com 9
Viewing Lantern Settings
The SL-C510 models are equipped with a very low power consumption OLED display, providing a quick and
easy lantern status and diagnostic checks by maintenance staff.
To activate the OLED display simply touch the indicated location. Once activated, the OLED will display in
sequence the following information:
• Product Version;
• Product Model;
• Lantern Operational Mode;
• Lantern Flash Character;
• Lantern Intensity;
• Battery Voltage;
• Lantern Status;
• Lantern Hibernation Status and settings;
• Lantern last accessed date;
The OLED system will continue to display the lantern settings/status in a sequential manner unless the Touch
Pad is activated for a second time, this action will allow the OLED display to stop on the information showing
at the Touch Action. To visualise the remaining information simply “Tap” the Pad again then the system will
display the next set of information.
When the Touch Pad device is inactive for more than three minutes the OLED display will enter in sleep mode
and can only display the lantern settings/status if the Pad device is activated again.
NOTE – The OLED display and Touch Pad components are designed to provide lantern settings/status
readings only, the lantern programming can be achieved by one of the Sealite lantern programming methods,
the information is available in this product manual.

10
Info Tab
The following summary indicates the data that can be visualized on the Lantern OLED Display.
Display Description
Displays the manufacture revision number.
Indicates the lantern current operation mode:
Standby - The lantern is configured in a minimum current state;
Always on – The daylight sensor is disabled and lantern set to operate day/night time;
Dusk till Dawn – The daylight sensor is monitored and the lantern will only operate at
night time.
Indicates the lantern current Flash Code.
This information provides Sealite’s Flash Code in Hex decimal and the on/off flash
duration. Please refer to the provided list of Flash Codes included in the appendix.
Displays the lantern operating intensity in percentage. The SL-C510 can provide four
different intensity levels in percentage or with a step size of 3.125% (or 1/32%) nautical
miles when set by range.
• Low (25%)
• Medium (50%)
• Medium High (75%)
• High (100%)
Indicates the lantern real-time battery voltage level.
Displays the lantern current operating status. This include the information for:
• Battery health conditions;
• LED fault
Indicates if the Hibernation Mode is enabled or disabled. In the case of enabled the unit
will indicate the hibernation start and finish dates (day/month).
Indicates the last time the light has been accessed either via touch pad or SealitePro®
App.
On first touch test on, or when screen off, the screen will go into Test Mode for 5
seconds.
Sealite
V1.08
Standby
0.2 1.3
High (100%)
12V
OK
Disabled
10 MAR 2019
Test Off
Operation Mode
Flash Code:0F4
Range / Intensity
Battery Voltage
Status
Hibernation
Last Visit
Test LED

SL-C510
Compact 5-9NM Solar Marine Lantern
Latest products and information available at www.sealite.com 11
Programming the Lantern
SealitePro® Bluetooth®Guide
The SealitePro®application is used to communicate with Sealite lighting products that have Bluetooth®
technology fitted. To note, only one device may be connected at any one time.
The Bluetooth®control offers the following main functionality:
• Lantern Information
• Lantern Status
• Solar Calculations
• Programming Options
• Power Monitoring
• Manufacturing Data
• Advanced Operations
The SealitePro®Application is available on both Android®and iOS devices. Most functions between
platforms are identical and the majority of the screenshots in this manual where taken showing
an iOS device screen. Where the Android®device differs, both visual options have been provided.

12
Bluetooth®Controller Functions
The Sealite SL-C510 Bluetooth®Control System accessible via the SealitePro®App is divided into seven
simple sections as outlined below and displayed on the App home screen;
• Lantern Identification
• Lantern Type
• Lantern Name
• Bluetooth Authentication
• Lantern Colour
• Lantern Peak Intensity
• Lantern Battery Option
• Battery Voltage
• Status Flags
• Lantern Geolocation
• Solar Calculator Options
• Solar Charge
• Autonomy
• Operating Mode
• Flash Code
• Intensity
• Sync Offset
• GPS Mode
• Hibernation
• Lux Level
• GSM Power

SL-C510
Compact 5-9NM Solar Marine Lantern
Latest products and information available at www.sealite.com 13
• Load Current
• Load Current – Last Hour
• Load Current – Yesterday
• Charge Current
• Charge Current – Last Hour
• Charge Current - Yesterday
• Hardware
• Board Serial Number
• Manufacture Date
• Software Version
• Test LED
• Perform Factory Reset

14
Accessing the SealitePro®App for the first time
Start Menu
• Connect via Bluetooth - connect to a lantern.
• Support Tools - Solar Calculator to conduct simulations based on lantern settings and locations.
NOTE – This feature provides lantern simulations only in regard to battery autonomy on solar radiation.
Changes may be applied through “Connect via Bluetooth” option only.
• User Guides – Quick Start Guide and User Manual
Contact Sealite / Us – Provide product feedback and contact Sealite
Scan for Lanterns
When the “Connect via Bluetooth” option is selected, the App will automatically scan for lanterns equipped
with Bluetooth within range.
• Select the lantern which requires setting or verification.
Opening the SealitePro®App on an Android®or iOS Device
Download the SealitePro®App from Google Play (search for “Sealite” in the
store) on an Android®Tablet or Smartphone or via the App store on an iOS
tablet or phone. Open the App to prompt the Sealite Bluetooth control system.

SL-C510
Compact 5-9NM Solar Marine Lantern
Latest products and information available at www.sealite.com 15
Expand the “Lantern Information” section if collapsed.
Identify Bluetooth Radio ID
When “Identify” on the Tablet or phone is selected, the connected lantern will flash quickly (10 times). For
iOS, identify is represented by a flash / burst icon.
Set the Lantern Name
1. Press “Name” to change the lantern name. A user defined name, comprising up to 16 alpha- numeric
characters (and -, $, # @) can be typed into the dialogue box. It is recommended that the lantern be
programmed with a unique name.
2. Press apply and then Set to confirm.
1097 candela

16
Create Security Access PIN
The factory default does not set the lantern with a Security PIN.
1. To set a PIN, select “Authentication Level” (“Bluetooth Authentication for iOS”) then enter a New PIN and press
“OK”. A confirmation of the PIN will be prompted.
2. Re-enter the same PIN and press “OK”.
Modify Current Security Access PIN
1. To set a new Security Access PIN select “Authentication Level” (“Bluetooth Authentication for iOS”) and
type the current Security PIN.
2. After validation the App will request for the current PIN to be re-entered. After confirmation enter the new
Security PIN then confirm the new PIN.
Note - If the Security PIN is lost, see Password Reset Procedure. Also note that PIN ‘0000’ is reserved and will
result in the lantern having no PIN.
1097 candela 1097 candela 1097
1097 candela

SL-C510
Compact 5-9NM Solar Marine Lantern
Latest products and information available at www.sealite.com 17
SealitePro®Password Reset Procedure
In the event where the password set is unknown the procedure below should be followed:
Step 1 – Disconnect the power supply from the light head:
(a). Remove the four socket-head screws on the top of the lens assembly and lift the SL-C510 (lantern
head) assembly from the solar chassis.
(b). Disconnect the 4-Pin connector that joins the battery to the light head, then immediately re-connect
the battery and the lantern again.
Step 2 – Connect to the lantern using the SealitePro®:
Once the light head and battery are re-connected ensure the following procedure is conducted within one
minute. Otherwise the process at step 1 will need to be completed.
(a). Connect to a lantern by pressing “Connect via Bluetooth®”
(b). Select a lantern displayed on the “Connect via Bluetooth” screen.
Where examples are identified side by side, the left is applicable to Android®devices and the right
image to iOS devices.

18
(c). Expand the “Lantern Information” drop down menu then press select “Authentication Level” (“Bluetooth
Authentication for iOS”).
NOTE – If “User Authenticated” under “Authentication Level” or Bluetooth Authentication appears the
limited time that allows to modify the PIN has expired.
Therefore, start the process again at Step 1;
(d). If “No PIN Set” appears under Authentication Level, please press Change PIN;
(e). Enter a New PIN and press “OK”. A prompt to confirm PIN will appear. Re-enter the same PIN and
press “OK”.
(f). One the procedure is complete, ensure the 4 socket head screws are replaced to secure the light head
and solar chassis.
• Colour Menu
Displays the lantern colour (White, Red, Green, Blue or Yellow)
• Peak Intensity Menu
Displays the Lantern Maximum Intensity in candelas (cd) based on the LED Colour.
• Battery Option
This section displays the battery size capacity in Ampere hour (Ah) and is configurable.
Authenticated
5
5
1097 candela
White
White
1097 candela 1097 candela

SL-C510
Compact 5-9NM Solar Marine Lantern
Latest products and information available at www.sealite.com 19
Lantern Status
From the “Lantern Status” section the user can verify the current lantern status
• Voltage
The battery health status.
• Status
Displays the battery health status, the current light sensor state and if the GPS is enabled, synchronised or off
station. Any warning states will cause the status to be shown in amber or red.
• Lantern Geolocation
Displays the lantern coordinates and allows the location to be plotted on a map.

20
Solar Calculations
This function estimates the lantern autonomy based on the lanterns current settings and geolocation.
• Solar Calculator Options
The SL-C510 has options to be fitted with Satcoms and GSM modules to allow multiple lanterns
synchronisation and monitoring. The SealitePro®App offers the user the option to modify the GPS and
GSM by enabling or disabling the operation. In addition, it offers different levels of transmissivity
conditions for accurate solar calculations.
• Solar Charge
This function estimates whether the collected solar charge is sufficient to replenish battery
consumption and will indicate if the unit is viable for the selected location.
