Sealite TRIDENT-1400 Supplement

Version 1.0
TRIDENT-1400
1400mm dia. Navigation Buoy
Installation & Service Manual

Technical Specications
Figure 1.
A
PCD 200.0
PCD 150.0
0.15
30.00°
DETAIL A
SCALE 1 : 10
1/2 "- 13 UNC X 3/4" Deep
6 Places
1/4 "- 20 UNC X 3/4" Deep
3 Places
150mm
50.0
mm
0.22m
Operational
Reserve
0.32m
1.40m
0.89m
1.8m
2.4m
3.3m
5.2m
Waterline at max mooring

Latest products and information available at www.sealite.com
3
TRIDENT-1400
1400mm dia. Navigation Buoy
Table of Contents
Introduction..........................................................................................Page 4
Sealite Buoy Division..........................................................................Page 4
Why Choose Polyethylene Buoys? ...................................................Page 4
Mooring Requirements & Regulations ..............................................Page 4
TRIDENT-1400 Navigation Buoy.........................................................Page 5
Product Components...................................................................Page 6
Assembly Instructions .................................................................Page 7
Mooring Table ....................................................................................Page 10
Marine Buoy Maintenance ................................................................Page 11
Repair Prodedures ............................................................................Page 12
Anode Replacement..........................................................................Page 12
Disposal Plan.....................................................................................Page 13
Sealite Buoy Warranty ......................................................................Page 15
Version No. Description Date Approved
1.0 Manual Launch January 2014 M. Henry

Latest products and information available at www.sealite.com
4
TRIDENT-1400
1400mm dia. Navigation Buoy
Introduction
Congratulations! By choosing to purchase a Sealite Buoy, you have become the
owner of one of the most advanced rotationally-moulded polyethylene marine buoys
in the world.
Sealite Pty Ltd has been manufacturing buoys for over 25 years, and particular care has been taken to
ensure your buoy gives years of service.
As a commitment to producing the highest quality products for our customers, Sealite has been
independently certied as complying with the requirements of ISO 9001:2008 quality management
system.
By taking a few moments to browse through this booklet, you will become familiar with the versatility of
your buoy, and be able to maximise its operating function.
Sealite Buoy Division
Sealite marine buoys are manufactured on-site from rotationally-moulded UV-stabilised polyethylene,
and are designed to offer a low-maintenance, high visibility solution to marine navigation.
The Sealite buoy division provides turn-key production of navigation buoys. From tooling development,
raw materials selection, and production, to nal testing and inspection, Sealite guarantees superior
quality and fast turn-around times.
Sealite’s buoy products are available in a wide range of congurations and sizes, and can be
economically shipped worldwide.
Why Choose Polyethylene Buoys?
• No painting
• Inhibits growth
• Increased interval between servicing
• Routine maintenance on location
• Easily repaired in the unlikely event of damage
• Lightweight for ease of deployment and maintenance
• Environmentally friendly – no use of toxic antifouling paint
4. Mooring Requirements & Regulations
Please contact your local authority for any specic requirements regarding the deployment of buoys.
IALA also has guidelines and recommendations that should be followed.
All information given in this manual is advisory only. Please consult with your local authority before
deploying your buoy products.
Local conditions that need to be considered include:-
• Water depth
• Maximum currents
• Maximum wind speeds
• Sinker size and weight

Latest products and information available at www.sealite.com
5
TRIDENT-1400
1400mm dia. Navigation Buoy
SPECIFICATIONS•* TRIDENT-1400
General Characteristics
Available Colours Red, Green,White,Yellow as per IALA Recommendations
Focal Plane Height (mm/inches) 2700 / 106¼ (nominal)
Total Float Volume (ltrs/US gallon) 1888 / 498
Nominal Freeboard (mm/inches) 540 / 21¼
Nominal Draft (mm/inches) 1580 / 62¼
Reserve Buoyancy (kgs/lbs) 570 / 1256
Draft, Maximum (mm/inches) 1800 / 707/8
Freeboard, Minimum (mm/inches) 320 / 125/8
Safe Working Load, lift (kgs/lbs) 4000 / 8818 (per eye)
Safe Mooring Load, (kgs/lbs) 2400 / 5290 (per mooring point)
Submergence (kg/cm, lb/inches) 15 / 84
Visual Area (m2/ft2) 2.4 / 25.8 (nominal)
Water Area (m2/ft2) 1.3 / 14.0
Mooring Details
Minimum recommened anchor
size (kg/lbs)
Wet weight: 1300 / 2866
Recommened mooring mass
(kg/lbs)
Minimum: 250 / 551
Maximum: 600 / 1323
Physical Characteristics
Material Rotationally-moulded UV-stabilized virgin polyethylene oat section, tower
assembly and top marks.
316-grade stainless steel xtures.
Wall Thickness (mm/inches) 13 / ½
Ballast (kg/lbs) 490 / 1080 (external steel)
Overall Height (mm/inches) 5200 / 204¾
Width (mm/inches) 1400 / 551/8
Mass with Ballast(kg/lbs) 907 / 2000 (depending on payload)
Radar Reector Echomax EM230
Product Life Expectancy >20 years
Certications
Quality Assurance ISO9001:2008
Intellectual Property
Trademarks SEALITE® is a registered trademark of Sealite Pty Ltd
Warranty * 5 years
Lantern Options Sealite SL-C310, SL-C410, SL-C415, SL-C420, SL-125 Series or SL-155 Series
Options Available • Mould-in graphics
• Monitoring Systems (AIS, GSM)
TRIDENT-1400 Navigation Buoy
The TRIDENT-1400 is a rotationally-moulded navigation buoy with a oat diameter of 1.4 meters
and lantern focal height of of at least 2.7 meters.
The oat section of the TRIDENT-1400 is built from two (2) rotationally-moulded sections,
which fasten together to form an incredibly robust 1.4 meter wide oat section. Each hull
section is moulded from UV-stabilized, virgin polyethylene, and has a 13mm wall thickness.
Each section is lled with closed-cell polyurethane, which prevents the ingress of moisture in
the unlikely event of damage.
•Specications subject to change or variation without notice *Subject to standard terms and conditions
