INSTALLATION INSTRUCTIONS
Copy Part# 810038 Rev. C, 09/2009 Page 1 of 2
M A R I N E
Installation:
CYLINDER HC5331-3
The Teleflex HC5331-3 steering cylinder is NOT com atible with
some early model ower steering rams. Although the cylinder
will still mount to these rams, loss of articulation and ossible
damage to the steering ram may result. Please identify your
ower steering cylinder by com aring your clevis bracket to the
4 drawings shown below. The HC5331-3 IS com atible with
units identified by figures A to C below, it is NOT com atible
with the clevis bracket in figure D shown below.
✓
SHOWA
(LATE MODEL)
ALWAYS INSTALL CYLINDER
HC5331 IN THE OUTER HOLE
COMPATIBLE
✓
HOERBIGER
COMPATIBLE
TELEFLEX
✓
COMPATIBLE
✗
SHOWA
(EARLY MODEL
PRE 1992)
NOT COMPATIBLE
Figure A Figure B
Figure C Figure D
NOTICE

© 2004 Teleflex Canada Limited Partnership 3831 N . 6 R ad, Richm nd, B.C, Canada V6V 1P6 Fax: [phone] Web: www.seastarsteering.com
INSTALLATION INSTRUCTIONS
Copy Part# 810038 Rev. C, 09/2009 Page 2 of 2
M A R I N E
CYLINDER MOUNTING AND PARTS LIST
2
1
3
6
789
10
1
11
12
5
13
TORQUE TO
90 IN.LB.
(10. Nm)
1
CABLE TUBE
When replacing any seals, make sure shaft is
clear of any abrasions.
WARNING
CUT CLEVIS PIN, ITEM 10 TO A LENGTH
OF 2" WHEN MOUNTING CYLINDER IN
LOWER POSITION.
CAUTION
Rotate Cable Tube into threads of Item until tight.
NOTICE
Item 10 must pass through Items 12 and 15 before
being secured by Item 11.
NOTICE
Always mount cylinder in lower mount position of item
and with out spacer item 16, unless mechanical
interference prevents you from doing so.
NOTICE
*1 731720 2 Nut 7/16" NF
*2 731625 1 Washer 7/16"
*3 343051 1 Support Bracket
*4 343057 1 Mounting Stud
*5 343120 1 Stud Gland
6 HF6002 2 Hose/Bleed Fitting (2 per kit)
*7 343608 1 Barrel
8 343150 1 End Gland
ITEM PART# QTY DESCRIPTION
343424 1 Piston Shaft
*10 562 23 1 Clevis Pin
*11 020 26 1 Cotter Pin
*12 343052 1 Clevis Block
*13 7 0625 1 Set Screw, 1/4"
14 HP60 2 1 Tube Support
*15 321446 1 Support Rod
*16 63721 1 Clevis Block
ITEM PART# QTY DESCRIPTION
Figure E
15 16
* Replacement parts cannot be ordered by individual part number. Contact Teleflex Marine for kits that included these items.
