SEBO FELIX
WORKS FOR ME
MADE IN GERMANY www.sebo.us

UPRIGHTS
FELIX 1 Premium
FELIX 4 Kombi
Fun
#9803AM
Fun
#9825AM
Ice Blue
#9806AM
FELIX 2
Premium
Ice Blue
#9813AM
Ice Blue
#9824AM
Classic
#9826AM
Classic
#9804AM
FELIX 1
Premium
Onyx
#9807AM
SEBO FELIX
Instant-use Suction Hose – The integrated instant-use suction
hose is always ready! Just pull it out to clean corners, crevices
or furniture. Two on-board tools and a
range of optional attachments can be fitted
to the hose, such as a 20-inch wand for
cleaning hard-to-reach areas or a nine-foot
extension hose, which creates a total length
of 15 feet . . . perfect for cleaning stairs.
A Flat-to-the-floor 6-inch Profile – The vacuum’s low profile makes
cleaning under furniture and beds easy!
Two Power Head Widths with One-sided Edge Cleaning –
The FELIX 1 Premium model is 12 inches wide with a
10 1⁄2-inch cleaning path. The FELIX 2 Premium - Ice Blue is 14 3⁄4
inches wide with a 13-inch cleaning path.
DESIGNED FOR CARPETS AND HARD FLOORS – The stylish FELIX offers all the flexibility of a canister vacuum in an upright
configuration! It has a "flex" neck with amazing 180° steering ability, an ultra-modern filtration system, a detachable suction
unit that becomes a hand-held vacuum, and an instant-use suction hose. The power head deep cleans carpets, or its spinning
brush roller can be shut off to clean delicate rugs and hard floors with straight suction. The FELIX also has a parquet brush,
which is perfectly designed for cleaning hard floors, or it can morph into a polisher using the DISCO head. It also has easy
brush roller removal, and an orange warning light illuminates when brush height is set too high for optimal cleaning, the
bristles are worn, or automatic shut-off occurs due to a brush obstruction.

UPRIGHTSSEBO FELIX
Multi-surface Cleaning Capabilities – With a
power head for carpets and a parquet
brush for hard floors, the FELIX provides
all the cleaning flexibility of a canister
vacuum! It also morphs into a hard floor
polisher, by adding a SEBO DISCO head.
Four-level Manual Brush Height Adjustment – The brush can be
adjusted up or down for optimal cleaning effectiveness.
Brush Obstruction Light with Automatic Brush Shut Off – If an
obstruction jams the brush roller, an orange warning light on
the power head illuminates and the brush roller stops spinning.
This feature prevents the belts from breaking and protects the
motor and carpet from damage.
Incorrect Height Setting or Worn Brush Light – When the brush
height is set too high for optimal cleaning or when the brush
roller should be replaced because of maximum bristle wear, an
orange warning light on the power head remains illuminated
during use. The light shuts off when the condition is corrected.
Easy Brush Removal and Cleaning – Cleaning
hair or other debris from the brush roller
or replacing it when its bristles are worn
is quick and easy, and no tools are required!
This feature ensures consistently effective
brush agitation of the carpet pile.
Manual and Automatic Brush Shut Off – The FELIX can clean
delicate rugs or hard floors with straight suction because the
brush roller can be manually switched off by pressing the green
illuminated on/off button on the power head cover. Also, the
brush roller automatically shuts off when the suction hose is
removed from its housing port or when the handle is in its
upright locked position.
Variable Suction Control on Handle with Soft
Start – The user can select the suction power
needed, from curtains to carpet. And its
gradual power-up extends motor life.
Three-level Adjustable Handle – This feature
provides compact storage, maneuverability
when suction unit is detached, and easy
adjustment to user height requirements.
Full Bag or Clog Indicator – When a full bag,
a clog in the airflow pathway, or an
excessively dirty microfilter is detected, an
indicator gauge on the bag housing lid “fills” with orange color
and an airflow bypass valve opens, to prevent overheating and
motor damage from a lack of adequate airflow.
Detachable Suction Unit Creates a Hand-held
Portable Vacuum – By removing its power
head, the FELIX instantly transforms from
an upright floor vacuum into a handheld
portable vacuum, ideal for cleaning stairs,
upholstery and car interiors. It can be
easily carried using its alternative side
handle or its shoulder strap attachment.
Superb Maneuverability – A unique 180° turning swivel neck
offers superb maneuverability around and under furniture.
Upholstery Nozzle
#1491DG
ATTACHMENTS
Included
Crevice Tool
#1092DG
Optional
20” Extension Wand*
#1084HG
9-Foot Extension Hose*
#1495AM
*All three items are available individually or
as a three-piece attachment kit, #1998AM.
BAGS, FILTERS & ACCESSORIES
10 Filter Bags
#7029ER
Exhaust Microfilter
Fun #7095ER01
Pre-motor Filter
#7012ER
12” Brush Roller
#5010AM
15” Brush Roller
#2838AM
Parquet Brush
#7200DG
Kombi Nozzle
#7240DG
Premium
Upholstery Nozzle
#1491DG
Crevice Tool
#1092DG
Kombi
Onyx & Ice
Blue #7200DG /
Fun #7200VO /
Classic
#7200SR
Ice Blue
#7240DG /
Fun #7240VO /
Classic
#7240SR
Exhaust Microfilter
Ice Blue #7095ER02
Exhaust Microfilter
Classic #7095ER03
Exhaust Microfilter
Onyx #7095ER04
Radiator Brush
#1496DG
Hand-held Turbo
Brush #6179DA
Wall & Floor Brush
#1325HG
Flat Upholstery
Nozzle #1090HG
Optional Kit
FELIX Shoulder
Strap #7158
Dusting Brush*
#1387DG
“FELIX Premium” Model Includes Power Head, Two On-
board Tools and Parquet Brush – Along with a commercial-
quality power head, the FELIX Premium comes standard
with a crevice tool, upholstery nozzle and a parquet brush.
“FELIX Kombi” Model Includes Combination Nozzle and Two
On-board Tools – The FELIX Kombi does not have a power
head. Instead, it includes a combination nozzle (a straight
suction nozzle for hard floors and rugs), crevice tool and
upholstery nozzle. The Kombi can accommodate a FELIX
Premium power head, which can be purchased separately.
Thirty-one Foot Cord with Rotating Quick-release Hook – It
is easy to quickly unwind the cord by rotating the hook!
Easy Maintenance – The clog removal door and brush roller
are easy to access on the power head.
Innovative Exhaust Filter . . . Design and Functionality –
Behind the stylish surface hides an ultra-modern
S-class exhaust microfilter that not only provides
excellent filtration, but it also absorbs motor noise,
resulting in extremely quiet operation.
SEBO FRESH
1 Pkg. of 5
#0496AM
Color Exception: Onyx - Crevice Tool #1092SW & Upholstery Nozzle #1491SW

Tightly Sealed Vacuums Ensure Effective Filtration – Dirty
air, which flows through a vacuum, can only be filtered
completely if it does not escape into the room through
seams or seals in the machine. This is why all
SEBO vacuums have tight seals throughout.
Many vacuum companies with high-filtration claims are
actually quoting specifications made by the manufacturer of
the filter material, as measured in the laboratory, not the
filtration effectiveness of the vacuum itself while operating.
Whether or not dirty air can escape through leaks in the
body of the machine is not considered. The filtration effec-
tiveness of SEBO vacuums is tested while they operate.
Save Money! SEBO Vacuums Last for Years and Extend
Carpet Life! – If properly maintained, SEBO vacuums save
ordinary residential users hundreds of dollars by providing
excellent performance for ten to fifteen years or more, and
their deep-cleaning power-brush technology extends the
life of carpets. Typical vacuums perform poorly, even when
new, and usually do not last beyond two years. So six or
seven “disposable vacuums” must be purchased during the
average life expectancy of just one SEBO machine.
Five-year Warranty Coverage – All SEBO
models include a five-year warranty on the
motor and all non-wear parts and a five-
year warranty on labor charges.
SEBO Microfilters Ensure Continuously
Strong Suction Performance – They are also long lasting,
inexpensive and easy to change in seconds.
Changing Bags is Easy and Clean – SEBO
filter bags can be changed in just a few
seconds, and a cap keeps dust sealed
inside during removal and disposal.
Effective Pet Hair Removal – All SEBO
vacuums easily remove pet hair!
Motors: 1500 watts total.
Suction Motor – 1300 watts,
ET-1 Power Head, 150 watts,
ET-2 Power Head, 175 watts.
Body Weight - 15.4 lbs.
Water Lift - 90 inches
Airflow - 102 CFM
Sound Level - 68 dB A
SEBO’sFILTRATIONSYSTEM:
StepOne.BagsareBetter!–Onallmodels,top-fill,three
and four-layerbagsarean integral partof SEBO’s filtration
systembecausetheyhold virtuallyalldirt
captured bythevacuum, whichimproves
theeffectivenessand usefullifeof the
microfilters.Theyalsoensurecontinuously
strongsuctionbecausedirtentersfromthe
top, depositsat thebottom,accumulates
upward, and airexitsthroughthesides,whichallows
unimpeded airflowas theyfillto capacity.And theycan be
sealed whenfull,sonodustcan escape into theair during
bag removal and disposal.
Incontrast,withoutbagsto holdnearly
allthecaptureddirt,themicrofilters
onbaglessvacuums quicklyclogfrom
excessivedirtbuild-up and mustbe
replacedoften,ora lossof suctionand
cleaningeffectivenesswilloccur.In
addition,dustand otherallergensbecome airbornewhen
emptyingbaglessdirtcontainers.Lastly,baglessvacuum
microfiltersareexpensive,usuallycostingmorethan a
multi-year supplyof SEBOfilterbags.
StepTwo.Pre-motorFilters–Pre-motorfilterscleansuction
air afterit passes throughthefilterbag,butbeforeit passes
over thevacuummotor.Coolingthe motor withcleanairis
importantbecause thisincreases usefullife expectancy.
StepThree.S-classExhaustMicrofilters–S-classExhaust
Microfilters(S=“Schwebstoff”=airborneparticles)are
made from electrostaticallycharged micro-fibermaterial,
whichattractsand capturesdustparticlesfrom theairflow
of thevacuum afterit passesoverthemotorto coolit.This
meansthat exhaustair is cleaned to thehighestlevel.The
S-classStandard requiresfiltersto
absorb greaterthan 99.9%of particles
downto 0.3micronsin diameter.For
comparison,100micronsis thediameter
of a human hair.Their advantagesarea
relativelyopentexturethatallows
smootherairflow forbettersuctionperformance,a longer
lifeexpectancy,and theycostlessthan HEPAfilters.
DesignedandManufacturedinGermany–Legendaryquality,
reliabilityand performance make SEBOvacuums the
choice of cleaningprofessionalsthroughouttheworld.
ExcellentforUsersWith AllergiesorAsthma–TheBritish
AllergyFoundationrecommends SEBOfilters.
MADE IN GERMANY
SEBO America, LLC • 7472 S. Tucson Way, Suite 190, Centennial, CO 80112 • 800-334-6614 • www.sebo.us
STANDARD FEATURES OF ALL SEBO VACUUMS:
FELIX TECHNICAL DATA:
