SecureAire APS-1000XL User manual
www.secureaire.com | Proudly made in the U.S.A. | APS-1000XL-Rev A
Installation, Operating
and Maintenance Guide
Congratulations on selecting the most advanced
Portable Air Purication System!
SecureAire’s Patented ACTIVE Particle Control™ Technology
removes airborne contaminants while INACTIVATING™
(killing) viable airborne pathogens including bacteria, viruses
and mold.
Air
Purication
for a Safe,
Healthy,
and Clean
Environment™
Portable Air Purication System
APS-1000XL
www.secureaire.com | Proudly made in the U.S.A. | APS-1000X-Rev A2
Advanced Technology Overview
The APS-1000XL is a State-of-the-Art Elevator Air Purication System that utilizes SecureAire’s ACTIVE
Particle Control Technology (APC). The patented process is described in the following diagram:
STEP 1: CONDITION
Particles entering the SecureAire System become
electrically CONDITIONED.
STEP 2: COLLISION
Conditioned Particles are forced to COLLIDE, gaining mass
in the process.
STEP 3: CAPTURE & INACTIVATE
Collisions make particles easier to CAPTURE within the air
purication cartridge media. Once CAPTURED, any viable
pathogens will be INACTIVATED or destroyed.
STEP 4: TRANSPORT
Particles escaping CAPTURE, are again CONDITIONED and
are thereby used to TRANSPORT contaminants from the
treated space to the SecureAire air purication cartridge.
ACTIVE Particle Control: How it works
The Advanced and Patented 4-Step process
Most particles
are too small to be
transported because
of their lack of weight.
–
+
+
+
+
+
+
+
–
–
–
–
–
–
–
1
2
+
–
+
–
–
4
3
Legal Notices
The information contained in this document is
subject to change without notice.
This document contains proprietary information that
is protected by copyright. All rights are reserved. No
part of this document may be photocopied, reproduced,
or translated to another language without the prior
written consent of SecureAire Incorporated.
SecureAire Technologies, LLC
1968 Bayshore Blvd, Dunedin, Florida 34698
www.secureaire.com, Phone: 813-300-6077
Technical Support
Please contact us at 813-300-6077 with any
questions.
Printing History
This manual was rst printed in October 2021. The
edition number will change when a new edition is
printed. Minor changes may be made at reprint
without changing the edition number. The part
number will change when extensive changes
are made.
Preface
www.secureaire.com | Proudly made in the U.S.A. | APS-1000X-Rev A 3
Overview
System Overview
The APS-1000XL is a State-of-the-Art Portable Air Purication System that utilizes SecureAire’s Advanced
Collector System Technology (ACS). The System consists of the following: Vertical cabinet, SCM (system
control module), replaceable SecureAire lter and the fan. The system has been tested to deliver the
following performance metrics:
1. A very high particle collection eciency rate (MERV 15).
2. ACS INACTIVATE™ Technology kills up to 99% of captured biological pathogens.
Further information on SecureAire’s Technologies can be found at www.secureaire.com.
22” 20”
22”
Unpacking:
The APS-1000XL unit comes complete and is pre-tested at the factory. Once uncrated, the unit is ready to run.
Startup:
1. Place the APS-1000XL in an appropriate location.
2. Plug the APS-1000XL into a 110-V receptacle.
3. Turn the unit on via the push button ON/OFF power switch. The system will run through its self-diagnostics
and calibration. The light bar will illuminate indicating that the APS-1000XL is running and at what speed.
4. The variable-speed push button will cycle through the three available speeds in conjunction with the
light bar. Note that the higher the fan speed, the faster the cleanup rate.
The APS-1000XL Unit set up is now complete!
4
APS System Maintenance
Maintenance
Filter Cartridge Change Outs:
Filter Media change outs are made easy due to the APS-1000XL Systems design. An access door allows for
quick lter changes. The following steps explain how to change the lter:
Replacement Filter Cartridges can be purchase through your local SecureAire Dealer.
1. Turn o the power and unplug the APS-1000XL unit.
2. Unscrew the secured lter door as shown below in Figure 2.
3. Carefully remove the Filter and Filter Housing from the APS-1000XL, using the pull-out notch
as shown in Figure 3.
4. Remove the dirty lter from the housing, and replace it with a SecureAire Replacement Filter, Part
Number APS-1000XL-FR.
5. Insert the housing with new replacement lter back into the APS-1000XL and secure the lter door.
6. Turn the system power back on.
The lter change is now complete!
www.secureaire.com | Proudly made in the U.S.A. | APS-1000X-Rev A 5
APS System Maintenance
Additional Maintenance
While no further maintenance is specically required, it is advised to occasionally check for dirt buildup on
the units. If dirt buildup does occur it can simply be blown o with an air gun or wiped o with a soft
paintbrush while units are not powered.
WARNING
Risk of Electric Shock!
To reduce the risk of electric shock, do not perform any
servicing other than that contained in this Guide.
Technical Support / Warranty
Technical Support
Please contact your local representative or SecureAire at 813-300-6077 with any questions.
SecureAire Product Warranty
Limited Warranty. SecureAire products are expressly warranted for normal product use for twelve (12) months
from the date of shipment (as shown on proper purchase paperwork) or manufactured date code (if purchase
paperwork is unavailable, the “Warranty Period”) against failure due to defects in workmanship and materials.
SecureAire’s exclusive obligation under this limited warranty shall be to supply, without charge, a new or like new
replacement for any product part that fails due to defect during the Warranty Period. Replacement of a part shall
not extend the original product Warranty Period and any replacement part provided under this warranty shall only
be subject to the remainder of the original warranty for the product, including the original twelve (12) month
Warranty Period. This limited warranty shall not obligate SecureAire for any labor costs associated with replacing
product parts.
Warranty Exclusions. Filter media is considered a disposable item and is not covered under this limited warranty.
SecureAire is not responsible should the product (i) fail to be maintained properly, or (ii) be modied in any fashion
whatsoever, or (iii) fail to function properly as a result of misuse, abuse, improper installation, neglect, damage
caused by disaster such as re, ood and lightning, improper electrical current, or (iv) be repaired other than by
SecureAire or an Authorized SecureAire Services Representative, or (v) be repaired using parts other than those
supplied by SecureAire, or (vi) be used with non-SecureAire lter media, or (vii) be damaged due to acts of war or
terrorism. Additionally, this limited warranty shall not apply if purchaser has not paid all invoiced amounts due.
SecureAire Products are for installation and operation in the United States and Canada only. Installation and
operation of the SecureAire Products outside of the United States and Canada voids all warranties
SecureAire Technologies, LLC
1968 Bayshore Boulevard, Dunedin, FL 34698
813.300.6077 | www.secureaire.com
© 2021 SecureAire Technologies, LLC. All rights reserved. Made in USA. 10.15.21
