SEI HO929000TX-Espresso User manual

HO929000TX-Espresso/
HO929000MP-Espresso/
HO929100TX-Black
Fold-out Convertible Desk
Assembly Instruction
For assistance with assembly contact:
Southern Enterprises Inc.
Customer Service 1-800-633-5096
[email protected]
www.seidal.com
© Southern Enterprises Inc. All Right Reserved
.
Max top load 20 lb.

HO929000TX-Espresso/HO929000MP-Espresso/HO929100TX-Black
Fold-out Convertible Desk
Parts List
Please review all parts and hardware before disposing of any packaging.
Call Customer Service if missing hardware. Do not return to store/retailer.
Screws shown actual size. Using a screw that is too long will cause damage.
Before beginning assembly, separate each type of screw. Carefully study
the screw diagrams below.
Suggested tools: Phillip head screw driver, power drill,
3/16
” drill bit,
24” level, and a tape measure. Unit needs to be hung on wall stud for
more security and stability.
(1) Cabinet
1 PC
(2) Shelf
2 PCS
(3) Pin
8 PCS
(4)Bracket 1PC (5) Phillip Head Screw 1PC
￠
￠￠
￠4mm ×3/4″
(6) Phillip Head Screw
1PC
￠
￠￠
￠4mm ×1-1/4″
(7) Plastic Wall Anchor 3PCS (8) Washer 2PCS
3/16″x3/4”
(9) Screw 2PCS
￠
￠￠
￠4mm ×2”
Care and Cleaning Instructions:
Before using , wipe with a clean , dry cloth.
Periodically apply furniture wax to renew
The finish. Avoid rubbing or scratching the
surface with rough or abrasive objects.
For replacement parts or questions, please
call Customer Service at 1-800-633-5096.
Do not return product to store. Please call
manufacturer for assistance, questions or
parts.
Assembly Tool Required
No.2 Phillips Screwdriver

HO929000TX-Espresso/HO929000MP-Espresso/HO929100TX-Black
Fold-out Convertible Desk-Brown
Assembly Instructions
Step 1: Locate fold-out
convertible desk on a solid wall
and at a comfortable height off
the floor, normally eye level.
Step 2: Measure the wall and
mark the width and height of
desk as Figure 1.
Figure 1-Installation Measurements
Eye Level
22
2222
22"
""
"
32"

Step 3: Measure the wall and
mark the location of the center of
each mounting holes. See
Figure 2.
NOTICE
The top 2 holes must be
located on wall stud.
Using the level, make sure that
all marks are level on the wall.
Step 4: Using power drill and
3/16″drill bit, drill three 3/16″
holes through the wallboard at
the mounting hole marks.
Step 5: Attach bracket (4) by
using screw (5) as shown.
Figure 2-Screw Hole Location
Drill three
3
/
16
"
holes
into wall
Figure3

Step 6: Insert plastic anchors (7)
into the three mounting holes.
(When doing this, you will need
a hammer help you).
Step 7: Open cabinet (1) and
attach cabinet (1) to the wall by
using washer (8), screw (9) and
screw (6) as shown.
7
8
9
Figure 4

Step 7: Insert pin (3) into the
hole of cabinet (1) as shown
then put on shelf (2).
Figure 5
Customer Service 1-800-633-5096
[email protected]
Southern Enterprises, Inc.
600 Freeport Parkway,Suite 200
Coppell,Texas 75019

We'd love to hear from you! Email us photos of our products in your home at
[email protected] and we might feature it on our site or use it to model one of our inspirational
photos.
“PARTS WILL BE SENT IF AVAILABLE FROM SEI”
Parts Replacement Form
Customer Information
Name
Address
City/State/Zip Code
Phone Number
Please indicate where you purchased this item: Store/ Website/ Catalog
Please indicate color/size/style number:
Style No Parts Letter Parts Description Quantity Needed
Missing or damaged hardware and/ or parts will be replaced free of charge. We do not sell parts.
Southern Enterprises Inc. will provide replacement parts for only those items purchased within the last
9 months. If this product has not been purchased from our retail affiliates (within 9 months), we are
under no obligation to provide parts or replacements merchandise. Parts will not be available for items
arriving fully assembled.
