SEI Mission Computer Desk HO9239 User manual

For assistance with assembly contact:
Southern Enterprises, Inc.
Customer Service 1-800-633-5096
[email protected]om www.seidal.com
HO9239 –Mission
Computer Desk
Assembly Instructions

A Quantity
of 1
Desk Top
B Quantity
of 4
Drawer Guide
C Quantity
of 1
Right Side Frame
D Quantity
of 1
Left Side Frame
E Quantity
of 1
Lower Brace
F Quantity
of 1
Keyboard Drawer Frame
G Quantity
of 1
Upper Brace
H Quantity
of 1
Keyboard Drawer
I Quantity
of 1
Keyboard Drawer Front
J Quantity
of 2
Drawer Back
K Quantity
of 2
Drawer Bottom
L Quantity
of 2
Drawer Side
M Quantity
of 2
Drawer Front Panel
Care and Cleaning Instructions:
Before using, wipe with a clean, dry cloth.
Periodically apply furniture wax to renew
the finish . Avoid rubbing or scratching the
surface with rough or abrasive objects.
For replacement parts or questions, please
Call Customer Service at 1-800-633-5096
Do not return product to store, please call
Manufacturer for assistance, questions or
Parts.
Assembly Tool Required
No.2 Phillips Screwdriver (Not
Included)
Mi
ss
i
on
C
ompu
t
er
D
es
k
Parts List
Please review all parts and hardware before disposing of any packaging.
Call Customer Service if missing hardware. Do not return to store/retailer.
Screws shown in actual size. Using a screw that is too long will cause damage.
Before beginning assembly, separate each type of screw. Carefully study
the screw diagrams below (SHOWN ACTUAL SIZE). You may receive extra
hardware with your unit.

1 Quantity
of 15
Bolt(1/4”*1-1/8”)
2 Quantity
of 2
Bolt(1/4”*1-3/4”)
3 Quantity
of 14
Wood Dowel
4Quantity
of 12
Wood Screw(8#*1-1/4”L)
5 Quantity
of 16
Wood Screw(6#*3/4”L)
6 Quantity
of 24
Wood Screw(3*10mmL)
7 Quantity
of 4
Plastic Drawer Stopper
8 Quantity
of 2
Hinge
9 Quantity
of 4
Bolt(5/32”*7/8”)
10 Quantity
of 4
Knob
11 Quantity
of 2
Wood Plug
Care and Cleaning Instructions:
Before using, wipe with a clean, dry cloth.
Periodically apply furniture wax to renew
the finish . Avoid rubbing or scratching the
surface with rough or abrasive objects.
For replacement parts or questions, please
Call Customer Service at 1-800-633-5096
Do not return product to store, please call
Manufacturer for assistance, questions or
Parts.
Assembly Tool Required
No.2 Phillips Screwdriver (Not
Included)
Mi
ss
i
on
C
ompu
t
er
D
es
k
Parts List
Please review all parts and hardware before disposing of any packaging.
Call Customer Service if missing hardware. Do not return to store/retailer.
Screws shown in actual size. Using a screw that is too long will cause damage.
Before beginning assembly, separate each type of screw. Carefully study
the screw diagrams below (SHOWN ACTUAL SIZE). You may receive extra
hardware with your unit.
Mi
ss
i
on
C
ompu
t
er
D
es
k
Assembly Instructions

Figure 1
Assembly Instructions:
Wood may scratch easily, Be
careful when assembling. Do not
scratch.
Step 1 Unpack and lay parts on
clean, padded surface like
carpet or blanket. Check
that you have all parts
indicated on the front
page.
Step 2 Set the Desk Top (A)
upside down on smooth
padded surface.
Step 3 Attach the Drawer Guides
(B) to the Desk Top (A)
with 8pcs Wood Dowels
(3) and 12pcs Wood
Screws (4) as shown.
Figure 2
Connect the Upper/Lower Braces
(E/G),Keyboard Drawer Frame(F)
to the Left/Right Side Frames
(C/D) by using 2pcs Wood Dowel
(3), 6pcs Bolt (1) and 2pcs Bolt
(2) as figure shown.
3333
333
3
444
444
444
444
A
BBBB
1
1
1
1
1
1
2
3
3
D
E
F
G
2
C
Figure 3
Attach the unit assembled at STEP
2 to the Desk Top (A) with 9pcs
Bolt (1) and 4pcs Wood Dowel (3)
by using the Screwdriver as figure
shown.
1
111
1
111
1

Figure 4
Assemble the Keyboard drawer
(H/I) by using 2pcs Hinge (8) and
12pcs Wood Screw (6).
Attach the Plastic Drawer
Stoppers (7) to the Drawer with
6pcs Wood Screw (6).
Fix the Knob (10) onto the
Keyboard Drawer Front (I) with
2pcs Bolt (9) as figure shown.
Figure 5
Assemble the drawer (L/J/M/K) by
using 8pcs Wood Screw (5).
Attach the Plastic Drawer Stopper
(7) to the Drawer with 3pcs Wood
Screw (6).
Fix the Knob (10) onto the Drawer
Front (M) with 1pc Bolt (9) as
figure shown.
Figure 6
Put the Keyboard Drawer(I) and
the Drawer (M) into the right
Position.
Mi
ss
i
on
C
ompu
t
er
D
es
k
Assembly Instructions
6
666
77
8
899
10 10
H
I
5
55
5
5
55
57
6
9
10
J
K
L
L
M
I
M
M

Figure 7
Insert 2pcs Wood Plugs (11) to
the Side Frames as figure shown.
Mi
ss
i
on
C
ompu
t
er
D
es
k
Assembly Instructions
11
11

Customer Service 1-800-633-5096
serv[email protected] Southern Enterprises, Inc.
2915 Merrell Road
Dallas, Texas 75229
Customer Information
Name
Address
City/State/Zip Code
Phone Number
Please indicate where you purchased this item: Store/Website/Catalog
Please indicate color/size/style number:
StyleNo Parts Letter PartsDescription Quantity Needed
H
O
9239- Parts Replacement Form
Missing or damaged hardware and/or parts will be replaced free of charge. We do not sell parts. Southern
Enterprises Inc. will provide replacement parts for only those items purchased within the last 9 months. If
this product has not been purchased from our retail affiliates (within 9 months), we are under no obligation
to provide parts or replacement merchandise. Parts will not be available for items arriving fully assembled.
