USER’S GUIDE
Thermal Printer
DPU-S245 SERIES
Read this user’s guide carefully before using the printer.
Keep this user’s guide in a place where it can be
accessed quickly.
Seiko Instruments Inc.

DPU-S245 SERIES THERMAL PRINTER USER’S GUIDE
Document Number: U00117065201
First Edition: July 2009
Second Edition: January 2010
Copyright 2009, 2010 by Seiko Instruments Inc.
All rights reserved.
The information contained herein is the property of SII and shall not be reproduced in whole or in part
without prior written approval of SII.
SII reserves the right to make changes in the specifications and materials contained herein without
notice and shall not be responsible for any damages (including consequential) caused by reliance on
the materials presented, including but not limited to typographical, arithmetic, and listing errors.
is a trademark of Seiko Instruments Inc.
BHT-Ir is a trademark of DENSO CORPORATION
Bluetooth is registered trademarks of Bluetooth SIG, Inc.
IrDA Protocol Stack “μDeepCore(r)1.1” (c)ITX E-Globaledge Corp. All Rights Reserved.
All other trademarks are the properties of their respective companies.
This product complies with EU RoHS Directive(2002/95/EC).
For use in Turkey
Complies with Electrical and Electronic Equipment Directive.
Türkiye’ deki Kullanıcılar için
EEE Yönetmeliğine Uygundur.
Applicable EC Directive and Standards
Product: Thermal Printer DPU-S245-01A-E
Directive: Title
1999/5/EC EC Radio and Telecommunications Terminal Equipment Directive
Standards
EN 301 489-1 V 1.8.1
EN 301 489-17 V 1.3.2
EN 300 328 V1.7.1
EN 60950-1
This product may be used in following all EU and EFTA countries:
EU
Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia,
Finland, France, Germany, Greece, Hungary, Ireland, Italy, Latvia, Lithuania,
Luxembourg, Malta, Poland, Portugal, Romania, Slovakia, Slovenia,
Spain, Sweden, The Netherlands, United Kingdom
EFTA
Iceland, Norway, Switzerland, Liechtenstein

Product: Thermal Printer DPU-S245-00A-E, DPU-S245-01A-E
Directive: Title
2004/108/EC EC Electromagnetic Compatibility Directive
Standards
EN 55022
EN 61000-3-2
EN 61000-3-3
EN 55024
Product: AC adapter PW-0904-W2-E
Directive: Title
2004/108/EC EC Electromagnetic Compatibility Directive
2006/95/EC EC Low Voltage Directive
Standards
EN 55022
EN 61000-3-2
EN 61000-3-3
EN 55024
EN 60950-1
Product: Battery Charger PWC-L07A1-W1-E
Directive: Title
2004/108/EC EC Electromagnetic Compatibility Directive
2006/95/EC EC Low Voltage Directive
Standards
EN 55022
EN 61000-3-2
EN 61000-3-3
EN 55024
EN 60950-1

Federal Communications Commission (FCC) compliance statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
Any changes in this certified device could void your legal right to operate it.
RF exposure compliance
1) To comply with FCC/IC RF exposure compliance requirements, a separation distance of at least
20 cm must be maintained between the antenna of this device and all persons.
2) This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.

Industry Canada (IC) compliance statement
Operation is subject to the following two conditions: (1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operation of the device.

- 1-
INTRODUCTION
Thank you for purchasing the DPU-S245 thermal printer.
This USER’S GUIDE explains how to handle DPU-S245 thermal printer (hereinafter
referred to as printer), specified AC adapter, specified battery charger, specified battery
pack and specified AC cable (hereinafter, omit “specified”).
Read through the SAFETY PRECAUTIONS and OPERATING PRECAUTIONS
carefully before using the printer.
Keep this user’s guide in a place where it can be accessed quickly.
For more detailed technical information on this printer, refer to the DPU-S245 SERIES
THERMAL PRINTER TECHNICAL REFERENCE.
The User’s Guide consists of the following sections.
SAFETY PRECAUTIONS..............................................................................2
OPERATING PRECAUTIONS.......................................................................9
1 PREPARATION..................................................................................12
2 EACH PART OF PRINTER ................................................................13
3 POWER CONNECTION.....................................................................16
4 PAPER SETTING...............................................................................19
5 TEST PRINTING................................................................................20
6 FUNCTION SETTING ........................................................................21
7 CONNECTING TO THE HOST DEVICE............................................30
8 RECHARGING THE BATTERY PACK...............................................34
9 THERMAL HEAD MAINTENANCE ....................................................37
10 TROUBLESCHOOTING.....................................................................38
11 SPECIFICATIONS..............................................................................39
12 OPTIONS AND CONSUMABLE PARTS............................................42

- 2-
SAFETY PRECAUTIONS
The following symbols are used in this User’s Guide in order to make use of the printer
properly and prevent the printer from being damaged.
Follow the instructions marked with the symbol.
WARNING Failure to follow the guidelines marked with this
symbol could result in severe personal injury or
death.
CAUTION
Failure to follow the guidelines marked with this
symbol could result in minor personal injury or
product and/or peripheral damage.
Symbol Examples
The symbol indicates caution (including danger and warning).
The example on the left indicates warning or caution.
The symbol indicates prohibition.
The example on the left means prohibition of disassembling.
The symbol indicates requirement or what must be done.
The example on the left means “pull the power plug out of the outlet.”

- 3-
WARNING
DO NOT use the printer, the AC adapter, the AC cable and the battery
charger in countries where these items do not comply with the
regulations. See Section 11 SPECIFICATIONS, List of Compliance with
Regulation.
Doing so, we do not assure the safety of these products and you will be
responsible for violation of regulations.
POWER OFF the printer, unplug the power cable from the power outlet,
and remove the battery pack in any of the following cases:
The printer does not recover from an error.
Smoke, strange noise, overheat or smells erupt from the printer.
A piece of metal or any liquid touches the internal parts or slot of the
printer.
Case is broken.
Doing so may cause fire or electric shock. Please contact your vender to
repair the products.
DO NOT insert any foreign objects such as a piece of metal or any liquid
in the internal parts or slot of the printer.
Doing so may cause fire or electric shock.
DO NOT disassemble or remodel the printer. DO NOT REPAIR THE
PRINTER YOURSELF.
Doing so may cause fire, a failure or other accidents.
DO NOT use an AC adapter, AC cable, battery charger or battery pack
other than that which is specified.
Doing so may cause explosion, overheating or fire leading to serious
accidents.
DO NOT use any power supply of the AC adapter and the battery charger
other than specified range of one.
Doing so may cause fire, a failure or other accidents.
DO NOT touch the output terminal or metallic area of the connector to
avoid short-circuiting.
Doing so may cause fire, a failure or other accidents.

- 4-
DO NOT connect except specified battery pack with the battery charger.
Doing so may cause explosion, overheating or fire leading to fire or
injury.
DO NOT put the printer into water in a place where it could get wet.
Doing so may cause fire, a failure or other accidents.
DO NOT touch the printer by wet hand.
If not, it might cause electric shock.
Turn the printer off before removing/inserting the battery pack.
If not, it might cause electric shock.
UNPLUG the AC plug from the outlet when there is any AC cable of the
AC adapter or the battery charger damaged.
Doing so may cause fire, a failure or electric shock.
Keep the AC adapter and the AC plug of the battery charger away from
dust and metallic materials.
If not, it might cause fire or electric shock.
Plug the AC adapter and the AC plug of the battery charger completely.
If not, it might cause fire or electric shock.
DO NOT destroy the AC adapter, the AC cable or plug of the battery
charger. Moreover, DO NOT bend, pull or twist the AC cable forcibly, or
place heavy object on the cable.
Doing so may cause fire, a failure or electric shock.
When unplugging the AC adapter or AC cable of the battery charger from
the outlet, do not pull on the cable but hold onto the plug.
Exposure or disconnection of the cable might cause fire or electric shock.
The antenna(s) used for this transmitter must be installed to provide a
separation distance of at least 20 cm from all persons and must not be
co-located or operating in conjunction with any other antenna or
transmitter.

- 5-
CAUTION
If the printer is not used for a long time, unplug the AC plug from the
outlet and remove the battery pack from the printer.
If not, it might cause fire or electric shock.
When cleaning the printer, unplug the AC plug from the outlet and
remove the battery pack from the printer.
If not, it might cause fire or electric shock.
Keep the printer out of the reach of children.
If not, it might cause injury.
DO NOT subject the printer to the following places as it may lead to fire,
a failure or injury.
Places of direct sunlight or high temperature
Places of extreme humidity or any place where it can possibly be
splashed by any liquids.
Places with strong vibration or is inclined.
DO NOT cover the printer with any clothes.
Doing so may cause fire or a failure.
NEVER touch the thermal head immediately after printing because it
becomes very hot. Make sure that the thermal head is cool before
clearing a paper jam or cleaning the thermal head.
Doing so may cause injury.
NEVER touch the portions such as the thermal head or the paper sensor
or the platen roller directly while opening the paper cover to install the
paper for example.
Doing so may cause injury or other accidents.

- 6-
DO NOT touch the cutter.
Doing so may cause injury.
Be sure to hold the battery cover to the printer when the battery pack is
inserted in the printer.
Fall of the battery pack due to the battery cover slid off may cause injury
or any damages.
DO NOT make your hair, etc. which are easily entangled in the printer
approach to the printer during the operation
Doing so may cause injury.
For Model PWC-L07A1-W1-E CAUTION;
CHARGE ONLY WITH LITHIUM-ION RECHARGEABLE BATTERY
TYPE BP-L0715-A1-E. OTHER TYPES OF BATTERIES MAY BURST
CAUSING INJURY TO PERSONS AND DAMAGE. RISK OF FIRE AND
ELECTRIC SHOCK. DRY LOCATION.
For North American – Use only CSA/UL Certified power supply cord set,
Polarized, Type SPT-2 or heavier, minimum No. 18 AWG copper, rated
125 or 250 V, minimum 1 A, minimum 6 ft (1.8 m), maximum 10 ft (3 m)
long.
For Other Country – Must comply with requirements set out by the Safety
Approval/Certification Organization in each country of use.

- 7-
Precautions in the Battery pack (Option)
WARNING
If you find any of the following abnormalities in the battery pack, remove
the battery pack from the printer and keep away from fire.
When the battery pack gave out a nasty smell, reached an
extraordinarily high temperature or showed any unusual sign.
When the battery pack case was broken.
When leakage was found.
Doing so may cause liquid leakage, explosion, overheating or fire leading
to fire or injury.
NEVER disassemble, remodel, or solder the battery pack.
Doing so may cause liquid leakage, explosion, overheating or fire leading
to fire or injury.
DO NOT charge the battery pack except by specified battery charger.
Doing so may cause liquid leakage, explosion, overheating or fire leading
to fire or injury.
DO NOT touch the metallic area of the battery pack to avoid
shortcircuiting.
Doing so may cause overheating, fire or electric shock leading to fire or
injury.
DO NOT throw the battery pack into fire and DO NOT heat it.
Doing so may cause liquid leakage, explosion, overheating or fire leading
to fire or injury.
DO NOT charge the battery pack in a place at 35 °C / 95 °F or more
under burning scorching or in the close vicinity of fire.
Doing so may cause liquid leakage, explosion, overheating or fire leading
to fire or injury.

- 8-
DO NOT apply strong impact to the battery pack with a hammer or a nail,
and DO NOT crush it.
Doing so may cause liquid leakage, explosion, overheating or fire leading
to fire or injury.
DO NOT put the battery pack into water. Always keep it away from rain
and water.
Doing so may cause liquid leakage, explosion, overheating or fire leading
to fire or injury.
DO NOT touch the battery pack by wet hand.
Doing so may cause electric shock or a failure.
CAUTION
If liquid inside the battery pack reaches the eyes, immediately wash it
away with clean water and take a physician's medical treatment.
If not, the eyesight might be damaged.
Keep the battery pack away from children.
If not, it might cause injury.
DO NOT subject the battery pack to the following places as it may lead to
liquid leakage, explosion, overheating or fire leading to fire or injury.
Places of direct sunlight or high temperature
Places of extreme humidity or any place where it can possibly be
splashed by any liquids.
Places with strong vibration or is inclined.

- 9-
OPERATING PRECAUTIONS
Please follow the precautions below to enjoy and maintain the full performance of the
printer.
Using the Printer
Be careful not to drop or bump the printer on a hard surface.
DO NOT install the printer in direct sunlight or such areas. Suitable environment for
the use of the printer is as follows:
· Ambient temperature: 14 to 122F (-10 to 50C)
· Relative humidity: 30 to 80RH (noncondensing)
See the Technical Reference for details of applicable humidity at each temperature.
DO NOT install the printer near devices that generate strong electromagnetic fields
such as a copy machine.
DO NOT install the printer in a location that is subject corrosive gas or siloxane and
so on.
DO NOT connect the AC cables of the AC adapter and the battery charger to the
same outlet with devices that generate noise.
DO NOT open the paper cover during printing.
DO NOT remove or reinstall the interface cable during printing or transmission. DO
NOT touch the connectors of the interface cable during printing.
Switch the power off when not in use.
Clean the printer using soft, lint-free cloth. DO NOT use alcohol or other solvent.
Before use, always clean the terminals using a dry, soft, lint-free cloth. If the
terminals are dirty, it may not be possible to obtain proper contact.
When cleaning the TH, wipe the thermal head with a cotton swab or other soft
material.
Remove the battery pack from the printer if the printer is not used for a long time. If
not, it may cause overdischarge and shorten life span of the battery pack.
Store the battery pack in cool place. DO NOT store the battery pack for long time
with fully charged condition because it may shorten life span of the battery pack.
The battery pack should be recharged at 32 to 95°F (0 to 35°C) for optimum
performance.
The AC adapter, the battery charger and the battery pack may become warm when
in use. This is normal and is not a malfunction.

- 10 -
When the battery pack is used at low temperature, the length of time the printer can
be used may be shortened.
High-print-rate printing or using the printer under low temperature condition might
cause irregular printouts or generate loud noise. This is not a failure in the printer,
but an inherent paper phenomenon.
When using a Bluetooth interface, the radio environment around the printer may
cause a failure in communications. This is due to the specifications of Bluetooth,
which is a radio communications standard.
When handling this product, be aware of static electricity. If the static electricity is
discharged, this could case communication failure. When this problem occurs,
disconnect the USB connector that is connected to the host device and wait few
seconds before connect it again.
Use the paper cutter of the metal side if using the thermal paper 80μm or thicker as
shown below;
TL69KS-LH, KIP370 and KIP470
Thermal Paper Handling
Store the thermal paper in a cool, dry, and dark place.
DO NOT rub the paper with hard objects.
DO NOT leave the paper near organic solvents.
DO NOT allow plastic film, erasers, or adhesive tape to touch the paper for long
periods.
DO NOT stack the thermal paper with diazo copies immediately after copying or wet-
type copies.
DO NOT use chemical glue.
Always use the specified thermal paper. See Section 12, Options and Consumable
Parts, for details.
Precautions on Discarding
When discarding used printers, discard them according to the disposal regulations and
rules of each respective district.

- 11 -
Notations Used in this User’s Guide
The following two types of notations are used throughout this User’s Guide to denote
items of caution and items to remember:
NOTE
- Operation Precautions
This box contains items that when not followed may lead to a malfunction or to a
deterioration of performance.
HINT
Items To Remember
This box contains helpful hints to remember when using the printer.

- 12 -
1 PREPARATION
Once you have opened the carton, make sure it contains the printer and all accessories.
Keep the package and packing materials for future transportation or long-term storage.
The following are available as options:
The AC adapter and the battery charger is not bundled with an AC cable. Be sure to
purchase our specified options. Refer to 11 SPECIFICATIONS for using the options in
the countries which have complied with regulations.
Printe
r
Specified Battery pack
Specified AC adapter
Specified AC cable
Specified Battery charger Specified Interface cable
(USB) Specified Interface cable
(Serial)
Printer User’s Guide/ SAFETY
PRECAUTIONS
(
CD-ROM
)
1
(p
iece
)

- 13 -
2 EACH PART OF PRINTER
(1) POWER switch
The POWER switch turns the printer ON
or OFF. To turn the printer on, hold down
the POWER switch until the POWER lamp
lights. To turn the printer off, hold down
the POWER switch until the POWER lamp
goes off.
(2) FEED switch
In the Mark Roll Paper mode, the printer
feeds the paper until paper mark detection
by pressing this switch once. In the other
condition, the printer feeds a small amount
of thermal paper by pressing this switch
once and the switch is held down, the
thermal paper is fed continuously.
(3) POWER lamp
The POWER lamp lights when the printer
turns on. See the Lamp Display on the
next page for details.
(4) ERROR lamp
TheERRORlamp lights when something is
wrong with the printer. See the Lamp
Display on the next page for details.
(5) Infrared transmitter/receiver
The infrared transmitter/receiver is used to
communicate with the host device having
the IrDA which conforms to the standards
of the physical layer of IrDA (Ver1.2).
(1)
(2)
(5)
(3)
(4)
(6)
(
10
)
(7) (8) (9)
(12)
(11)
(13)
(14)

- 14 -
(6) Interface connector
The interface connector connects with the
interface cable. Open the rubber cover
and insert the connector.
(7) Paper outlet
Paper port with a paper cutter.
(8) Thermal head
The thermal head prints characters on the
thermal paper. Note that the thermal head
is very hot immediately after printing.
(9) Paper sensor
The sensor that detects thermal paper
existence or paper mark.
(10) Paper cover open button
The button that is used as opening the
paper cover when setting the thermal
paper.
(11) Paper cover
The platen roller is released from the
thermal paper after opening this cover.
Open this cover to replace the thermal
paper or to clean the thermal head.
(12) Platen roller
The platen roller brings the paper in
contact with the thermal head. The platen
roller is turned to feed the paper.
(13) Power connector
The power connector connects the AC
adapter to this connector.
(14) Battery cover
The battery cover is attached on the
printer to secure the battery pack.

- 15 -
Lamp Display
Lamp display POWER lamp
(Green)
ERROR lamp
(Orange)
Power OFF Off Off
Power ON (Print-ready) On Off
Initializing On On
Out-of-paper On Blink
Paper cover open On Blink twice
Battery low, power failure Blink On
Thermal head temperature error Blink twice On
Recharging Blink Off
Function setting mode Off On
Function setting mode shifting Blink Blink
FLASH memory accessing Short blink Short blink
Hardware error Off Blink
Display Pattern ○: On, ─: Off
Items Pattern
Blink ─ ○ ─ ○ ─ ○ ─ ........
Short blink ○─○─○─○─○─○─○─○─○─○........
Blink twice ○─○ ─ ○─○ ─ ○─○ ─.......
