Fastening Solutions™
FramePro®601 Clipped Head Nailer
Compressor Combo Kit – Model PC0961
NEW FRAMING KIT!
Everything to get you started on the job is included in
this one package and at a price that creates an
excellent value.
The FramePro 601 Clipped Head Nailer is compact,
easy to handle and has excellent line of sight. This
powerful framer drives 2” to 31/2” nails in gauges from
.113 to .131.
The SENCO PC0967 Compressor is a 2 hp, 4 gallon,
oil-splash portable air compressor. Its' rugged design
will satisfy the needs of the pro!
Applications:
Framing, truss building, subflooring, sheathing,
decking, siding, fencing, pallets and crate assembly
Kit Contents:
• FramePro 601 Nailer
• 2 hp, 4 gallon compressor
• 3/8” x 25’ rubber hose
• Compressor oil
• Tool oil
• Safety glasses
• All necessary air fittings
• Tool wrenches
• Manuals
PC0967 Compressor Features and Benefits:
• 2 hp, Oil-splash motor for improved life
• 4 gallon capacity, twin stacked tanks
• 15 amps @ 115V, 125 PSI Max Output
• 3/8" quick disconnect coupler and regulator
• Individual gauges for tank and regulated output
pressure
• Hand carry – cushioned grip handle, compact,
rugged and designed for the pro
• One full year limited warranty
www.senco.com ©2005 by Senco Products, Inc.
FramePro® 601 Features and Benefits:
• Sawtooth safety for precision toenailing
• Shorter, straight-line 30˚ magazine for better line of
sight and superior maneuverability
• Adjustable exhaust
• Lightweight and powerful
• Adjustable depth-of-drive control
• Soft comfort grip handle reduces fatigue
• One year warranty
Fastener Specifications:
The FramePro 601 clipped head nailer drives ring ,
screw and smooth shank nails in four gauges (.113 –
.131) from 2" to 31/2" shank nails. Shank diameters
include.113, .120, and . 131.
HF (.120)
HC (.120)
KC (.131)
GC (.113)
GE (.113)
HE (.120)
2 21/4
23/821/2331/2
31/4

Fastening Solutions™
For additional information on how SENCO Power Fastening Systems will save you time, reduce costs, and increase quality, call our
toll-free Action Line: 1-800-543-4596 to find your nearest Authorized Senco Dealer or Distributor . Visit our web site at: www.senco.com
www.senco.com ©2005 by Senco Products, Inc.
Stainless Steel
Braided Discharge
Hose
15 amps @ 115V
4 gal Twin
Stacked Tanks
3/8" Quick
Disconnect Coupler
Tank Pressure Gauge
Regulator & Outlet
Pressure Gauge
125 PSI Max Output
Rugged -
Designed
for the Pro
Easy Grip
Rubber Handle
Ergonomic Design
Superb balance
for use all day
Reliable
Proven design for
long trouble-free
operation
Adjustable
Depth-of-Drive
Comes with
No-Mar Pad over
Toenail Safety
Adjustable Exhaust
Full Comfort Grip
Rear Two-Step
Loading
In-line Magazine for
improved line of sight
Dry Fire Lockout
FramePro 601 Clipped Head Nailer
PC0967 2hp, 4 gal, Oil-Splash Compressor
2 hp, Oil-Splash Motor
for Improved Life
Specifications:
Power: 884 in-lbs
Tool Weight: 8 lbs (3.6 kg)
Height: 13.5" (343 mm)
Length: 14.8" (376 mm)
Nail Capacity: 65
Reg. Operating Pressure: 70-120 psig
Specifications:
Power source: Electric
Max. amp: 15 amps @115V
Horsepower: 2.0
Pump: Oil-splash
SCFM @ 90 psi: 4.8
Pump-up time: 0 - 125 psi 46 seconds
Recovery time: 95 - 125 psi 12 seconds
Max pressure: 125 psi
Tank storage: 4.0 gallon
Weight: 63 lbs.
Dimensions: length 19", height 16.5",
width 17"
FramePro®601 Clipped Head Nailer
Compressor Combo Kit – Model PC0961
