Senco SCN55S User manual

SCN55S Siding Coil Nailer
Applications:
Features:
For siding, sheathing, decking, subfloors, exterior trim,
fencing, and wood shingle application in on-site and
manufactured housing. Also for industrial pallet
construction, pallet repair, crate and box assembly
and wood storage sheds.
The rugged SCN55S Siding Coil Nail from Senco has
the capacity to drive full round head nails up to 2½"
long. This lightweight, powerful tool holds up to 350
nails and is designed for hours of use with minimal
operator fatigue.
• Drives full round head nails 1¼" to 2½" long
• Nail coils available in wire weld. Flagless plastic 
collated nails will be available in the near future
• High load capacity (350 nails)
• Adjustable depth-of-drive for consistent and  
controllable nail countersink
• Balanced 5.8 lb. weight for one-handed operation
• Comfort-grip handle for hours of comfortable use
• One full year warranty
R
R

SCN55S Siding Coil Nailer
Tool Specifications:
Fastener Specifications:
Tool Weight: 5.8 lbs. (2.6 kg)
Height: 12 " (327 mm)
Length: 10½" (267 mm)
Width: 5¼" (133 mm)
Nail Capacity: 200-350
Nail Collation: Wire Weld
Operating Pressure: 70-100 psig (4.8-6.9 bar)
Mode of Operation: Tools are available with either
Restrictive Trigger or Dual Action activating
mechanism. *
Hose Fitting: ¼" NPT
For additional information on how Senco fastening
systems will save you time, reduce costs, and increase
quality, call your nearest Authorized Senco Dealer or
Distributor listed in the Yellow Pages under “Staples,” or
call our toll-free Action Line: 1-800-543-4596.
7
/8
Lengths Inches 2"
50
.092
ED21
2¼"
57
.092
ED23
2¼"
5748
.092.092
EL23EL20
Millimeters
Shank
Product Code
Available In •Regular Galv. •Reg. Galv. •Reg. Galv.
•Brt. Basic•Weatherex II Galv.
Smooth Shank Nails
Wire Collated**
Ring Shank Nails
1 "
7
/8
NOTE: The SCN55S has the capacity to drive nails ranging in size from 1¼" to 2½" in length, and
the capability to drive flagless plastic collated nails.
**Other sizes available by special order
22¼ 2¼1
7
/8
.092
.092
.092
.092
EL20 EL23 ED21 ED23
(6d) (7d) (6d) (7d)
* “Restrictive Trigger” activated tools are
used for applications where precision nail or
staple placement is desired. You must first
depress the safety element where you want
to drive a nail or staple and then pull the
trigger. After each nail or staple is driven,
completely release the trigger and lift the
tool off the work surface.
“Dual Action” activated tools are used for
applications where high-production work is
desired. There are two modes of operation:
Bottom Fire Method: This method of
operation is sometimes called bounce
firing. You must keep the trigger pulled
while moving the tool along the work
surface with a bouncing motion, depressing
the safety element where you want to drive
a nail or staple.
Trigger Fire Method: First depress the
safety element where you want to drive a
nail or staple and then pull the trigger.
For instructions on safe use of tools with
either of these activating mechanisms,
please refer to the Operating Instructions or
Customer Satisfaction and Safety
Reminder contained in your tool carton.
