Sencor STM 7870GG Operation instructions

05/2020
- 1 -
Copyright © 2020, Fast ČR, a.s.
EN Food Processor
Translation of the original manual
STM 7870GG / STM 7871GR / STM 7872BL
STM 7873VT / STM 7874RD / STM 7875RS
STM 7876GD / STM 7877CH / STM 7878BK

05/2020
- 2 -
Copyright © 2020, Fast ČR, a.s.
EN Food Processor
Important safety instructions
READ CAREFULLY AND STORE FOR FUTURE USE.
■This appliance may be used by children 8 years of age and older
and by persons with physical or mental impairments or by
inexperienced persons, if they are properly supervised or have
been informed about how to use the product in asafe manner
and understand the potential dangers.
■Children must not use this appliance or play with it. Keep this
appliance and the power cord out of reach of children.
■Before connecting this appliance to apower socket, make sure
the rated voltage stated on its rating label corresponds to the
voltage in your power socket.
■Never use accessories, which have not been supplied with this
appliance or which have not been explicitly recommended by
the manufacturer for this type of appliance.
■This appliance is designed for household use. Do not use it for
commercial purposes, in industrial surroundings, or outdoors,
or for purposes other than those for which it is intended.
■Always place the appliance on an even, dry and stable surface.
Do not place it on an electric or gas stove, in the vicinity of an
open flame or appliances that are sources of heat.
Do not put your hands into an area marked by this symbol.
Otherwise injury could result when the multi-function
head is tilted out and is not properly locked in the top
position.
■Never use multiple attachments at the same time.

05/2020
- 3 -
Copyright © 2020, Fast ČR, a.s.
■Before putting the appliance into operation, check that it
is correctly assembled and that the multi-function head is
tilted down in the horizontal position. For safety reasons, this
appliance is equipped with asafety mechanism that prevents
the motor from being started when the multi-function head is
tilted out.
■In the event that the multi-function head tilts out during
operation, the appliance will automatically stop running.
When the multi-function head is tilted to the horizontal
working position, the appliance will not automatically resume
operation. To start it again, it is necessary to press button A18
on the display.
■Do not touch rotating parts of the appliance and ensure that
foreign items such as clothing, hair, etc. are kept away. An injury
could occur or the appliance could be damaged.
■In the event that an item, such as aspoon, falls into the bowl
during operation, immediately set the speed control knob to
the OFF position (stand-by mode), and disconnect the power
cord from the power socket. Wait until the rotating parts come
to astop and then remove the item.
■If ingredients stick to the attachment or the sides of the bowl,
turn the appliance off, disconnect it from the power socket,
and wait until the rotating parts come to astop. Use asilicone
spatula to clean the attachment and the inside of the bowl.
Then you can restart the appliance.
■Make sure that no hair, clothing or other items enter the feed
tube of meat grinder while it is running. Do not put anything
other than the ingredients that are to be processed into the
feed tube.

05/2020
- 4 -
Copyright © 2020, Fast ČR, a.s.
■Never use your fingers or other items to push ingredients
through the meat grinder feed tube. For this purpose there is
apusher included as an accessory.
Warning:
Incorrect use may lead to injuries.
■To prevent injury caused by sharp edges, be especially careful
when handling the grinding blade of the meat grinder and the
blade assembly of the blender. Increased attention must also
be paid when emptying out the blending jar, when removing
the blade assembly from the blending jar, when removing
the grinding blade from the chamber, and when cleaning the
appliance.
■Do not attempt to grind bones, nut shells or other hard
ingredients.
■Hot liquids up to atemperature of 55 °Cmay be processed
in the blending jar. Be especially careful when handling hot
liquids. Hot steam or splashing hot foods and liquids may
cause scalding. Never start the blender without the lid properly
seated in position. When processing hot liquids, do not remove
the inner cap during operation. Do not touch the hot surface.
Use the handle to carry the blending jar when it is hot.
■The maximum continuous operating time is 10 minutes. Do not
exceed the maximum operating time of 5 minutes when in the
kneading mode and do not exceed the maximum operating
time of 2 minutes when using the blender. Before starting it
again, allow the appliance to cool down for 30minutes.
■Always turn off the appliance, disconnect it from the power
socketwhennotbeusingit,whenleavingitwithoutsupervision,
and before assembling, disassembling, cleaning or moving it.
Prior to disassembling the appliance and replacing accessories

05/2020
- 5 -
Copyright © 2020, Fast ČR, a.s.
or accessible parts that move during use, wait until all moving
parts come to astop.
■Clean it according to the instructions in chapter Cleaning and
maintenance.
■Never wash the appliance under running water or submerge it
in water or another liquid.
■Do not turn on the appliance when it is empty. Incorrect use of
the appliance may negatively affect its lifetime.
■Ensure that the power plug contacts do not come into contact
with water or moisture. Do not place heavy items on the power
cord. Make sure that the power cord does not hang over the
edge of atable or that it is not touching ahot surface.
■Disconnect the power cord from the power socket by pulling
on the plug, never pulling on the cord. Otherwise, this could
damage the power cord or the socket.
■If the power cord is damaged, have it replaced at aprofessional
service centre. It is forbidden to use the appliance if it has
adamaged power cord.
■To avoid the danger of injury by electrical shock, do not repair
the appliance yourself or make any adjustments to it. Have all
repairs performed at an authorised service centre. By tampering
with the appliance, you risk voiding your legal rights arising
from unsatisfactory performance or quality warranty.

05/2020
- 6 -
Copyright © 2020, Fast ČR, a.s.
STM 7870GG / STM 7871GR / STM 7872BL
STM 7873VT / STM 7874RD / STM 7875RS
STM 7876GD / STM 7877CH / STM 7878BK
18
15
16
17
9
7
12
13
8
10
11
14
19
2
1
3
4
5
6
20
21
A

05/2020
- 7 -
Copyright © 2020, Fast ČR, a.s.
B
1
2
3
4
5
6
7
8
9
14
13
12
11
10
15
16
C
1
3
2
4
5
6

- 8 - 05/2020 Copyright © 2020, Fast ČR, a.s.
EN Food Processor
User'smanual
■ Prior to using this appliance, please read the user’smanual thoroughly, even if you
already have experience in using similar appliances. Only use the appliance in the
manner described in this user’smanual. Keep this user’s manual in asafe place
where it can be easily retrieved for future use.
■ We recommend saving the original cardboard box, packaging material, purchase
receipt and responsibility statement of the vendor or warranty card for at least the
duration of the legal liability for unsatisfactory performance or quality. In the event
of transportation, we recommend that you pack the appliance in the original box
from the manufacturer.
DESCRIPTION OF THE APPLIANCE AND ACCESSORIES
A1 Button for releasing the meat
grinder from the front attachment
hub
A2 Removable cover of the front meat
grinder attachment hub
A3 A-shaped beater
A4 Balloon whisk
A5 Kneading hook
A6 Elastic A-shaped beater
A7 Removable cover of the top blender
attachment hub
A8 Tilt-out multi-function head
A9 Attachment hub for attaching
attachments A3-A6
A10 Transparent bowl cover with ahole
for adding ingredients
A11 4.5-litre stainless steel bowl with
handle
A12 Base unit
A13 Speed control knob serves to
variably set the speed level
MIN-1-2-3-4-5-6-MAX, sets the pulse
level
(PULSE) and turns the appliance off
(OFF).
A14 Multi-function head release lock
A15 Minus„-”button for decreasing time
A16 Plus„+” button for increasing time
A17 Display
A18 Start/Pause button
A19 Anti-slip feet for stability of the
appliance during operation
A20 3-litre stainless steel bowl without
handles
A21 Lid serves to close the stainless steel
bowl A11 for short term storage of
processed ingredients.
DESCRIPTION OF MEAT GRINDER ACCESSORIES
B1 Pusher
B2 Stainless steel hopper
B3 Feed tube
B4 Grinding chamber
B5 Screw shaft
B6 Grinding blade
B7 Screw ring
B8 Fine grinding plate
B9 Medium fine grinding plate
B10 Coarse grinding plate
B11 Separator
B12 Sausage stuffer attachment
B13 Moulder
B14 Conical attachment
B15 Cookie maker
B16 Cookie maker holder
Note:
Parts B11–B14 are contained inside the pusher B1.
Certain models are only equipped with afine and coarse grinding disc B8
and B10.
DESCRIPTION OF THE BLENDER ACCESSORIES
C1 Inner cap of the blending jar
C2 Outer lid of the blending jar with
ahole for adding ingredients
C3 Handle
C4 1.5-litre Tritan blending jar with
titanium blades
C5 Cuff
C6 Blade assembly
BEFORE FIRST USE
1. Take the appliance and its accessories out of the packaging materials.
2. Thoroughly wash all accessory parts that are intended to come into contact with
food using warm water and aneutral kitchen detergent. Then rinse under clean
running water and thoroughly wipe dry with ane wiping cloth or allow them to
dry naturally. After washing and drying, we recommend to coat the grinding blade
B6 and the grinding plates B8–B10 with cooking oil.
3. Do not submerge the food processor or its power cord in water or any other liquids.
Attention:
The metal parts of the meat grinder and attachments A3–A6 are
not intended for washing in adishwasher. Other removable parts
may be washed in adishwasher.
BEATING, WHIPPING AND KNEADING
SELECTING ATTACHMENT TYPES
Attachment type Purpose of use
Beater A3 and A6 It is used for beating light and medium heavy yeast-free
doughs, for preparing sauces, creams, fillings, etc. Do not use it
for kneading heavy doughs.
Balloon whisk A4 It is used for whisking whole eggs or egg whites, whipped
cream, foamy creams, etc. Do not use it for beating or
kneading doughs.
Kneading hook A5 It is used for kneading various types of doughs including heavy
and thick doughs such as for example bread dough, pizza
dough, fresh pastry doughs, etc.
ASSEMBLING AND DISASSEMBLING THE FOOD PROCESSOR
■ Before you start assembling or disassembling the food processor, check that it is
turned o and disconnected from the el. power socket.
1. Inserting the bowl and attaching the cover
1.1 Place the food processor on an even, dry and stable surface, for example on
akitchen countertop.
1.2 Use the lock A14 to release the multi-function head A8 and tilt it out all the way.
After tilting out the multi-function head release the lock A14. Locking of the multi-
function head inthe top open position is indicated by the lock returning to the
default position, which is accompanied by an audible click.
1.3 Insert the stainless steel bowl A11 into the base unit A12 and secure it in place by
turning it clockwise. When the bowl is properly attached, it cannot be separately
lifted out of the base unit.
1.4 On to the bottom part of the multi-function head A8 with attachment hub A9,
slide the cover A10 so that the latches along the perimeter of the round opening
in the cover A10 slide into the grooves along the perimeter of the attachment hub
A9.
1.5 The lid A21 is used for covering the bowl A11 for short term storage of processed
ingredients.
2. Mounting attachments
2.1 When attaching an attachment, the multi-function head A7 must be locked in
the open position, see point 1.2 in the previous chapter. To attachment hub A8,
attach one of the attachments A3–A5 in such a way that the attachment hub
shaft A8 slides into the attachment. Push the attachment towards the attachment
hub A8 and turn it anticlockwise to secure it in place. Lightly pull the attachment
downwards with one hand to check that it is properly attached.
2.2 Place the ingredients that you wish to process into the bowl A11. Release the lock
A14 and tilt the multi-function head A8 to ahorizontal position. After tilting down
the multi-function head A7, release the lock A13. The locked status of the multi-
function head in the tilted down work position is indicated by the lock returning to
the default position. This is accompanied by an audible click.
3. Disassembly
3.1 Use the lock A14 to release the multi-function head A8 and tilt it out all the way.
After tilting out the multi-function head, release the lock. Locking of the multi-
function head inthe top open position is indicated by the lock returning to the
default position, which is accompanied by an audible click.
3.2 Push the attachment towards the attachment hub A9 and turn it clockwise to
release it, and then remove it.Turn the bowl A11 anticlockwise and remove it from
the base unit A12. Remove the cover A10 by pulling it downwards. Move the multi-
function head A8 back to the horizontal position.
USING THE FOOD PROCESSOR
1. Select the right type of attachment based on its intended use and assemble
the appliance according to the instructions in the chapter Assembling and
disassembling the appliance. Place the ingredients into the bowl A11.
Attention:
In asingle batch, it is possible to precess no more than 2.2 litres
of light dough or 0.8 litres of thick, heavy dough. The maximum
number of egg whites that can be whisked at once is 12. We
recommend that you do not ll the bowl A11 past the level of
the 3l mark. If an insucient amount of ingredients are put in the
bowl A11 (less than 0.3 litres of dough), then they may not be
optimally processed.
2. Make sure that the multi-function head A8 is tilted down in the horizontal working
position and that the speed control knob A13 is set to the OFF position. Connect
the power cord to apower socket.
3. Set the required speed using the speed control knob A13. Gradually turn the
speed control knob A13 clockwise to increase the speed, turning it in the opposite
direction will reduce the speed. To initially stir in the ingredients, rst set alower
speed and then adjust it as required. Electronic speed regulation ensures that the
set speed will be maintained under various loads. While it is running, ingredients
may be added into the bowl A11 through the hole in the cover A10.
4. The pulse mode is used for increasing the speed to maximum for ashort time. To
activate the pulse mode, turn the speed control knob A13 to the PULSE position
and to ensure continuous operation hold it down in this position. As soon as you
release the speed control knob A13, it will automatically return to the OFF position.
5. If it is necessary to wipe ingredients o the inside of the mixing bowl A11 and
the attachment, rst turn o the food processor by setting the speed control knob
A13 to the OFF position and then disconnect it from the power socket. Wait until
the rotating parts come to astop and only then scrape away the ingredients with
aspatula.
6. After you have nished using the appliance, set the speed control knob A13 to the
OFF position and disconnect the power cord from the power socket.
7. Wait until the rotating parts come to a stop and disassemble the food mixer
according to the instructions included in chapter Assembling and disassembling
the appliance. Use asoft plastic spatula to empty out the contents of the bowl A11.
8. Clean out the food processor after each use according to the instructions in
chapter Cleaning and maintenance.
LED LIGHT
■ The multi-function head A8 has aLED light that turns on automatically when the
food processor is connected to apower socket. The LED light turns o automatically
after 2.5 minutes of inactivity, i.e. when the appliance is not running or when the
speed is not set during this time. The LED light turns on again automatically when
the food processor is put into operation by the control knob A13 being set to
a desired speed level. DISPLAY

- 9 - 05/2020 Copyright © 2020, Fast ČR, a.s.
■ The appliance is equipped with adisplay A14 that shows either the time that the
food processor has been running (count-up function) or shows the remaining
operating time (countdown function). The display is automatically lit when the
food processor is connected to apower socket and remains lit even after the LED
light turns o when no action is performed.
OPERATION WITH ELAPSED TIME DISPLAYED
■ After setting one of the speed levels using the speed control knob A13, the food
processor will start and the display A17 will automatically show the operating time
in one second intervals.
■ Pressing button A18 will stop the food processor and the counting up of time.
The current elapsed operating time of the food processor will remain shown on
the display. Pressing button A18 again will start the food processor and time will
continue counting up.
■ Setting the speed control knob A18 to the OFF position will stop the food processor
and the time on the display will reset to zero (00:00).
■ In the event that the multi-function head A8 is tilted open or the cover of the
top blender attachment hub A7 is removed, while the food processor is running,
then it will stop and the current elapsed time will flash on the display. To continue
processing food and counting up the time, first tilt down the multi-function head A8
into the working position or put the cover A7 back on, and then press button A18.
Note:
In the event that the food processor runs continuously for 30minutes, it will
stop automatically. The LED light will remain lit and the operating time will
flash.
OPERATION WITH COUNTDOWN
■ If you wish to use the food processor with the countdown function, it is necessary
to first set the time for which the food processor will run and after which it will stop
automatically.
Note:
The maximum time that can be set on the display is 30minutes.
■ If you wish the food processor to run for up to 10 minutes (time range 00:03 s– 10:00
min) then set the required time using button A16. Each time the button is pushed,
the time will increase in 30-second increments. If you wish to reduce the countdown
time, press button A15. The time will be reduced in 30-second increments.
■ If you want the food processor to run for alonger time, i.e. from 10 to 30minutes
(time range 10:00 – 30:00 min), then set the required time using button A16. Each
time the button is pressed, the time will increase in 1-minute increments. If you
wish to reduce the countdown time, press button A15. The time will be reduced in
1-minute increments.
Tip:
When the time 00:00 is shown on the display, then pressing button
A15 will set the time to 30minutes (30:00).
■ After setting one of the speed levels using the speed control knob A13, the
food processor will start and at the same time, the time on the display A17 will
countdown in one-second intervals.
■ Pressing button A18 will stop the food processor and the countdown.The remaining
operating time of the food processor will remain shown on the display. Pressing
button A18 again will start the food processor and time will continue counting
down.
■ In the event that the multi-function head A8 is tilted open or the cover of the top
blender attachment hub A7 is removed, while the food processor is running, then it
will stop and the remaining time will flash on the display.
■ To continue processing food and counting down the time, first tilt down the multi-
function head A8 into the working position or put the cover A7 back on, and then
press button A18.
SETTING THE TIME TO ZERO
■ If you wish to set the countdown time to zero without having to turn off the food
processor, simultaneously press buttons A15 and A18. The time will reset to 00:00.
QUICK GUIDE TO PROCESSING INGREDIENTS
Attachment type Ingredients Maximum
load
Processing
time
Speed
selection
Balloon whisk
A4 and A6
Egg whites 12 pcs 4 min 5–6
Balloon whisk
A4 and A6
Whipping cream 1l 6–8 min 5–6
Beater A3 Cake dough 2.2l 6 min 3–4
Kneading hook A5 Bread dough
Pizza dough
0.8l 4–5 min MIN to 2
Note:
The above processing times are only areference.
When whipping egg whites, the bowl A11 and the beater A4 or A6 must be
perfectly clean and dry. Even asmall amount of fat may cause the egg whites
not be whipped to the desired snowy consistency.
Whipping cream should be cooled to atemperature of 6 °Cprior to being
whipped.
Prior to processing them, allow the ingredients used for making various
doughs to rest at room temperature.
GRINDING MEAT, MAKING SAUSAGES AND KEBABS, AND
MAKING COOKIES
ASSEMBLING AND DISASSEMBLING THE MEAT GRINDER
1. Insert the screw shaft B5 into the grinding chamber B4 with the cogged wheel
entering rst.
2. Place the grinding blade B6 on to the shaft B5 (with the edge facing outwards from
the chamber) and on to it attach agrinding plate B8, B9 or B10 depending on the
preferred the grind. Make sure that the notch in the grinding chamber B4 slides
into the groove in the grinding plate.
Attention:
When attaching the blade B6, be very careful not to injure yourself
on the sharp edge.
3. Place the screw ring B7 on to the grinding chamber B4 and tighten it securely by
screwing it clockwise. Place the stainless steel hopper B2 on to the feed tube B3.
4. Make sure that the food processor is turned o and disconnected from the power
socket. The multi-function head A8 must be tilted down in the horizontal position
and the whisk, beater or kneading attachments must be removed. Remove the
front cover A2 from the multi-function head A8. Place the assembled attachment
against the attachment hub so that the feed tube B3 is tilted to the right at an
angle of approximately 45° from the vertical axis and secure the attachment in
vertical position by turning it anticlockwise. The attachment is locked in place
when the button A1 slides out. This is accompanied by an audible click.
5. When disassembling the meat grinder, rst remove the hopper B2. Then press the
button A1 and remove the meat grinder by turning it clockwise. After removing
the grinder, put the cover A2 back in its place.
6. When disassembling the meat grinder into its individual parts, proceed in the
reverse sequence.
USING THE MEAT GRINDER
1. First prepare the meat for grinding in the following way. Remove all bones,
tendons, cartilage and cut the meat into 2 × 2 × 6 cm size pieces that will freely
pass through the feed tube B3.
Attention:
Do not process frozen meat. Allow it to defrost before grinding it.
2. Make sure that the food processor is correctly assembled and that the speed
control knob A13 is set to the OFF position.
3. Place the bowl A11 or another suitable container under the meat grinder. Insert
the power plug into apower socket.
4. Use the speed control knob to set the desired speed.We recommend to initially set
speed 3 and then increase it as required. Gradually place the meat pieces into the
feed tube B3 and push them in using the pusher B1. Take care not to clog up the
feed tube B3 by alarge amount of meat. Do not process more than 5 kg of meat
per batch. The processing time is only several minutes.
Attention:
Do not use fingers or other items to push the meat in. Always use
the pusher B1 designed for this purpose.
5. The ground meat will fall into the prepared bowl. The meat that remains in the
grinding chamber B4 can be removed by grinding aslice of bread or abread roll.
6. To turn o the food processor, set the speed control knob A13 to the OFF position.
7. Clean out the meat grinder after each use according to the instructions in chapter
Cleaning and maintenance.
ASSEMBLING AND DISASSEMBLING THE SAUSAGE STUFFER ATTACHMENT
1. Proceed in the same way as when assembling the meat grinder, only with the
dierence that instead of the grinding blade B6 and the grinding plate B8, B9 or
B10, only parts B11 aB12 are used.
2. Place the separator B11 on to the screw shaft so that the notch in the grinding
chamber B4 ts into the groove in the separator B11. Place the sausage stuer
attachment B12 on to the separator B11 and complete the entire sausage stuer
assembly by screwing the screw ring B7 on to the grinding chamber B4. Place the
stainless steel hopper B2 on to the feed tube B3.
3. Attach the attachment to the food processor in the same way as described in point
4 in chapter Assembling and disassembling the meat grinder.
4. When disassembling, rst remove the hopper B2. Then press the button A1 and
remove the attachment by turning it clockwise. After removing the attachment,
put the cover A2 back in its place.
5. When disassembling the attachment into its individual parts, proceed in the
reverse sequence.

- 10 - 05/2020 Copyright © 2020, Fast ČR, a.s.
USING THE SAUSAGE STUFFER ATTACHMENT
1. Make sure that the food processor is correctly assembled and that the speed
control knob A13 is set to the OFF position. Insert the power plug into apower
socket.
2. Prepare asausage casing that you will stu with ground meat and allow it to soak
in lukewarm water for approx. 10 minutes. Place the ground meat mixture on to
the hopper B2. Take the sausage casing out of the water and skewer or tie up one
end and slide the other end like asock on to the sausage stuer attachment B12.
3. Use the speed control knob A13 to set the desired speed. We recommend to
initially set the lowest speed and then increase it as required. With one hand hold
the sausage casing on the attachment B12 and use the other hand to push the
ground meat mixture with the pusher B1 through the feed tube B3. If the sausage
casing sticks to the attachment B12, it is necessary to moisten it with water again.
Attention:
Do not use fingers or other items to push the ground meat in.
Always use the pusher B1 designed for this purpose.
4. To turn o the appliance, set the speed control knob A13 to the OFF position.
5. Clean out the individual parts of the attachment after each use according to the
instructions in chapter Cleaning and maintenance.
ASSEMBLING AND DISASSEMBLING THE KEBAB MAKER
ATTACHMENT
1. Proceed in the same way as when assembling the meat grinder, only with the
dierence that instead of the grinding blade B6 and the grinding plate B8, B9 or
B10, only parts B13 aB14 are used.
2. Place the moulder B13 on to the screw shaft B5 so that the notch in the grinding
chamber B4 ts into the groove in the moulder B13. Place the kebab moulder
attachment B13 on to the conical attachment B14 and complete the entire kebab
maker assembly by screwing the screw ring B7 on to the grinding chamber B4.
Place the stainless steel hopper B2 on to the feed tube B3.
3. Attach the attachment to the food processor in the same way as described in point
4 in chapter Assembling and disassembling the meat grinder.
4. When disassembling, rst remove the hopper B2. Then press the button A1 and
remove the attachment by turning it clockwise. After removing the attachment,
put the cover A2 back in its place.
5. When disassembling the attachment into its individual parts, proceed in the
reverse sequence.
USING THE KEBAB MAKER ATTACHMENT
1. Make sure that the food processor is correctly assembled and that the speed
control knob A13 is set to the OFF position. Insert the power plug into apower
socket.
2. Place the prepared kebab meat mixture on to the hopper B2. Use the speed control
knob A13 to set the desired speed. We recommend to initially set the lowest speed
and then increase it as required. Using the pusher B1, push the mixture through
the feed tube B3. The result will be ahollow meat tube that is then cut into smaller
pieces. The kebab is atraditional meal from the Middle East made predominantly
from ground meat and whole grain wheat.
Attention:
Do not use fingers or other items to push the ground meat in.
Always use the pusher B1 designed for this purpose.
3. To turn o the appliance, set the speed control knob A13 to the OFF position.
4. Clean out the individual parts of the attachment after each use according to the
instructions in chapter Cleaning and maintenance.
ASSEMBLING AND DISASSEMBLING THE COOKIE MAKER ATTACHMENT
1. Proceed in the same way as when assembling the meat grinder, only with the
dierence that instead of the grinding blade B6 and the grinding plate B8, B9 or
B10 only parts B11,B15 and B16 are used.
2. Place the separator B11 on to the screw shaft so that the notch in the grinding
chamber B4 ts into the groove in the separator B11. Insert the cookie maker
holder B16 into the screw ring B7. Screw the screw ring B7 clockwise on to the
grinding chamber B4. Complete the assembly by inserting the cookie maker B15
into the holder B16 and attaching the hopper B2 to the feed tube B3.
3. Attach the attachment to the food processor in the same way as described in point
4 in chapter Assembling and disassembling the meat grinder.
4. When disassembling, rst remove the hopper B2. Then press the button A1 and
remove the attachment by turning it clockwise. After removing the attachment,
put the cover A2 back in its place.
5. When disassembling the attachment into its individual parts, proceed in the
reverse sequence.
USING THE COOKIE MAKER ATTACHMENT
1. Place the prepared dough on to the hopper B2. Slide the cookie maker B15 to the
left or right to set the desired cookie shape.
2. Insert the power plug into apower socket. Set the required speed using the speed
control knob A13. When starting it for the rst time, we recommend that you set
speed 3 and then increase or decrease it as required.
3. Use the pusher B1 to push the dough through the feed tube B3. The food
processor will push the dough out in the required shape that you set using the
cookie maker B15. We recommend that you place atray or your palm underneath
the pushed out dough. Then cut the formed dough into smaller pieces.
Attention:
Do not use fingers or other items to push the dough in. Always
use the pusher B1.
4. When you have nished using the food processor, turn it o by setting the speed
control knob A13 to the OFF position.
5. Clean out the attachment after each use according to the instructions in chapter
Cleaning and maintenance.
BLENDING
ASSEMBLING AND DISASSEMBLING THE BLENDER
1. On to the blending jar C4, place the outer lid C2 so that its edges copy the neck of
the jar, and push it down thoroughly along its entire perimeter. Into the hole in the
lid C2, place the inner cap C1 and push it down all the way.
2. Make sure that the food processor is turned o and disconnected from the power
socket. The multi-function head A8 must be tilted down in the horizontal position
and the whisk, beater or kneading attachments must be removed. Release and
remove the top attachment hub cover A7. Place the assembled blending jar on to
the top hub and pulling it gently turn it in the direction of the symbol all the way.
The safety mechanism will prevent the blender from starting unless it is correctly
secured to the multi-function head A8.
3. To disassemble proceed in the reverse sequence.
4. Prior to starting the appliance, check that the blade assembly C6 is correctly seated
in the cu C5. Properly tighten the cu C5 on to the mixing container C4.
USING THE BLENDER
1. The blender is intended for preparing meals and drinks such as milkshakes, creamy
soups, sauces, spreads, fresh baby foods, etc. It is not intended for juicing fruit and
vegetables, preparing potato purée, yeast dough or for whipping egg whites.
2. Assemble the blender according to the instructions in chapter Assembling and
disassembling the blender, and put the ingredients (larger pieces need to be cut
up in advance) into the blending jar C4.
Note:
The maximum capacity of the blending jar C4 is 1.5 litres. Never ll it past
the maximum mark. When processing hot liquids or liquids that expand in
volume during the blending process, it is recommended to ll the blending
jar to no more than ⅔ of its maximum capacity.
3. Make sure that the food processor is correctly assembled and that the speed
control knob A13 is set to the OFF position. Connect the power cord to apower
socket. Set the required speed using the speed control knob A13. We recommend
to rst set aslower speed to allow the ingredients to mix together. Then the speed
may be increased. The pulse level is appropriate when you wish to blend food only
very quickly. To start the pulse level, turn the speed control knob A13 to the PULSE
position and hold it in this position for amoment. As soon as you release the speed
control knob A13, it will automatically return to the OFF position.
Attention:
Hot liquids up to a temperature of 55 °C may be processed in
the blending jar. The maximum operating time of the blender is
2 minutes. Do not leave the appliance in continuous operation
for longer than indicated above. Then allow it to cool down for
30minutes.
4. While blending, you may add food or liquids to the blending jar C4 through the
hole in the lid C2 after removing the inner cap C1. Never open the outer lid C2
during operation. When processing hot liquids, the inner cap C1 must remain
closed.
5. In the event that food is sticking to the blade assembly C6 or the walls of the
blending jar C4, turn the appliance o by turning the speed control knob A13
to the OFF position and disconnect it from the power socket. Make sure that
the blade assembly C6 has stopped rotating. Carefully remove the assembled
blending jar from the multi-function head A8 by turning it in the direction of the
symbol . Take o the lid and using aplastic spatula, clean the blade assembly C6
and the inside of the blending jar C4. Put the lid back on and reattach the blender
assembly to the multi-function head A8. Plug the power cord into apower socket
and continue blending.
6. After you have nished using the appliance, set the speed control knob A13 to the
OFF position and disconnect the power cord from the power socket. Check that
the blade assembly C6 has stopped rotating and carefully take the blending jar
assembly o the multi-function head A8. Put the cover A7 back in its place and use
asoft plastic spatula to remove food from the blending jar C4.

- 11 - 05/2020 Copyright © 2020, Fast ČR, a.s.
7. Disassemble the assembled bowl and clean the individual parts after each use
according to the instructions in chapter Cleaning and maintenance.
ADVICE AND TIPS FOR BLENDING
■ First cut food with arm consistency such as fruit and vegetables into smaller
pieces measuring 3 cm and only then blend it.
■ First, blend a smaller amount of ingredients and then gradually add more
ingredients through the hole in the lid C2 while blending. In this way, you will
achieve better results than by adding all ingredients into the blending jar C4 at
once.
■ If you need to blend food of a solid consistency together with liquids, we
recommend that you rst blend the food of solid consistency and a part of the
liquids. Then gradually add the remaining liquids through the hole in the lid C2
while blending.
■ To blend very thick liquids, we recommend using the pulse level so that the blade
assembly C6 does not get jammed too often. Start the blender repeatedly in short
intervals.
■ Ice cubes must be processed immediately upon being removed from the freezer.
When the ice starts to melt, the ice cubes will stick together and it will not be
possible to blend them.
QUICK GUIDE TO PROCESSING INGREDIENTS
Ingredients Speed selection Recommended
blending time
Fruit, vegetables cut into smaller pieces 5–6 30s
Baby food 5–6 40 s
Spreads, dressings, marinades 3–4 30s
Smoothies and cocktails 6 to MAX 40 s
Soups 6 to MAX 30s
Ice cubes PULSE
Note:
The above food processing times are only areference. The actual blending
time depends on the size of the ingredients, their amount and the required
nal consistency.
CLEANING AND MAINTENANCE
■ Before cleaning the food processor, always switch it o by setting the speed
control knob A13 to the OFF position and disconnect it from the power socket.
■ Disassemble the food processor into its individual parts. Wait until moving parts
come to acomplete stop before disassembly.
■ Thoroughly wash the used removable parts after every use using warm water
with a neutral dishwashing detergent. Then rinse them under clean running
water and wipe them dry with ane wiping cloth or allow them to dry naturally.
After washing and drying, we recommend to coat the grinding blade B6 and the
grinding plates B8, B9 andB10 with cooking oil.
■ If you whisked egg whites, rst rinse the bowl A11 and the beater A4 or A6 under
cold water. If you were to use hot water, the egg white remains would harden and
their removal would be more dicult.
■ Clean the mixing container C4 by lling it with 0.5 litre of clean water and afew
drops of kitchen detergent and then assemble the blender and run it for 10 to
15 seconds. Then turn o the food processor, disconnect it from the power socket,
and after the rotating parts have come to astop, remove the blending jar assembly.
Empty out the contents of the blending jar C4 and then thoroughly rinse out the
blending jar C4 with clean water and wipe dry.
■ If more thorough cleaning is required, the cu C5 with blade assembly C6 may
be removed using a special wrench that can be ordered free of charge at an
authorised service centre. After cleaning, it is necessary to install the cu C5 with
blade assembly C6 back in its place and to properly tighten it using the wrench.
Attention:
When cleaning, be very careful not to injure yourself on the sharp
cutting edge.
■ The metal parts of the meat grinder, the blade assembly C6 and attachments A3–
A6 are not intended for washing in adishwasher. Other removable parts may be
washed in adishwasher.
■ For cleaning the base unit A12 and the multi-function head A8, use a cloth
lightly dipped in aweak detergent solution. Then wipe everything with a clean
dampened cloth and thoroughly wipe dry.
■ For cleaning, do not use solvents or cleaning agents with abrasive eects.
Otherwise, the surface of the appliance may be damaged.
■ Do not submerge the food processor or its power cord in water or any other liquids.
STORAGE
■ When not using the food processor, store it in a clean, dry place out of
children’sreach. Make sure that the multi-function head A8 is tilted down into the
horizontal position.
TECHNICAL SPECIFICATIONS
Rated voltage range............................................................................................................ 220−240 V
Rated frequency........................................................................................................................50/60 Hz
Rated power input.....................................................................................................................1 000 W
Electrical shock protection class........................................................................................................ II
Noise level....................................................................................................................................85 dB(A)
The declared noise emission level of the appliance is 85 dB(A), which represents alevel
Aof acoustic power with respect to areference acoustic power of 1 pW.
Explanation of technical terminology
Safety class for electrical shock protection:
Class II – Electrical shock protection is provided by double or heavy-duty insulation.
INSTRUCTIONS AND INFORMATION REGARDING THE
DISPOSAL OF USED PACKAGING MATERIALS
Dispose of used packaging material at asite designated for waste in your municipality.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC
EQUIPMENT
This symbol on products or original documents means that used
electric or electronic products must not be added to ordinary
municipal waste. For proper disposal, renewal and recycling hand over
these appliances to determined collection points. Alternatively, in
some European Union states or other European countries you may
return your appliances to the local retailer when buying an equivalent
new appliance.
Correct disposal of this product helps save valuable natural resources
and prevents potential negative effects on the environment and
human health, which could result from improper waste disposal. Ask your local
authorities or collection facility for more details.
In accordance with national regulations penalties may be imposed for the incorrect
disposal of this type of waste.
For business entities in European Union states
If you want to dispose of electric or electronic appliances, ask your retailer or supplier
for the necessary information.
Disposal in other countries outside the European Union
This symbol is valid in the European Union. If you wish to dispose of this product,
request the necessary information about the correct disposal method from the local
council or from your retailer.
This product meets all the basic requirements of EU directives related to
it.
