Sencor STM 6377CH Repair manual

- 1 - 04/2021 Copyright © 2021, Fast ČR, a.s.
EN Food Processor
Translation of the original manual
STM 6377CH / STM 6378BK

- 2 - 04/2021 Copyright © 2021, Fast ČR, a.s.
EN Food Processor
Important safety instructions
READ CAREFULLY AND STORE FOR FUTURE USE.
■This appliance may not be used by children. Keep the appliance
and its power cord away from children.
■The appliance may be used by persons with reduced physical,
sensory or mental capabilities or with alack of experience and
knowledge, if they are supervised or have been instructed
to use the appliance in a safe manner and understand the
potential dangers.
■Children must not play with the appliance.
■Cleaning and maintenance performed by the user must not be
performed by unsupervised children.
■In the event that the power cord is damaged, have it repaired
at aprofessional service centre to prevent causing adangerous
situation. It is forbidden to use the appliance if it has adamaged
power cord.
Warning:
Incorrect use may lead to injuries.
■Be careful when handling and cleaning the attachments.
■The surfaces of the appliance that come into contact with food
must always be cleaned according to the instructions in this
user’smanual.
■Always turn off the appliance and disconnect it from the power
socket if you will not be using it and if you will be leaving it without
supervision, before assembly, disassembly, cleaning or moving it.
■Before replacing the accessories or accessible parts that move
during use, turn the appliance off and disconnect it from the
power supply.

- 3 - 04/2021 Copyright © 2021, Fast ČR, a.s.
■ This appliance may be used by persons with physical or mental impairments or by inexperienced persons, if they are properly supervised or have been
informed about how to use the appliance in asafe manner and understand the potential dangers.
■ Children must not use this appliance or play with it. Keep this appliance and the power cord out of reach of children.
■ Before connecting this appliance to apower socket, make sure the rated voltage stated on its rating label corresponds to the voltage in your power socket.
■ Never use accessories, which have not been supplied with this appliance or which have not been explicitly recommended by the manufacturer for this type
of appliance.
■ This appliance is designed for household use. Do not use it for commercial purposes, in industrial surroundings, or outdoors, or for purposes other than those
for which it is intended.
■ Always place the appliance on an even, dry and stable surface. Do not place it on an electric or gas stove, in the vicinity of an open flame or appliances that
are sources of heat.
Do not put your hands into an area marked by this symbol. Otherwise injury could result when the multi-function head is tilted out and is not
properly locked in the top position.
■ Never use multiple attachments at the same time.
■ Before putting the appliance into operation, check that it is correctly assembled and that the multi-function head is tilted down in the horizontal position. For
safety reasons, this appliance is equipped with asafety mechanism that prevents the motor from being started when the multi-function head is tilted out.
■ In the event that the multi-function head tilts out during operation, the appliance will automatically stop running. When the multi-function head is tilted to
the horizontal working position, the appliance will not automatically resume operation. To resume operation, it is necessary to set the speed control knob to
the OFF position and then re-select the desired speed.
■ Do not touch rotating parts of the appliance and ensure that foreign items such as clothing, hair, etc. are kept away. An injury could occur or the appliance
could be damaged.
■ In the event that an item, such as aspoon, falls into the bowl during operation, immediately set the speed control knob to the OFF position (stand-by mode),
and disconnect the power cord from the power socket. Wait until the rotating parts come to astop and then remove the item.
■ If ingredients stick to the attachment or the sides of the bowl, turn the appliance off, disconnect it from the power socket, and wait until the rotating parts
come to astop. Use asilicone spatula to clean the attachment and the inside of the bowl. Then you can restart the appliance.
■ Make sure that no hair, clothing or other items enter the feed tube of meat grinder while it is running. Do not put anything other than the ingredients that
are to be processed into the feed tube.
■ Never use your fingers or other items to push ingredients through the meat grinder feed tube. For this purpose there is apusher included as an accessory.
■ If the grating and slicing attachment is in operation, ensure that hair, clothing and other items are kept away from the feed tube. Do not put anything other
than the ingredients that are to be processed into the feed tube.
■ Do not use fingers or other utensils to push ingredients through the feed tube of the grating and slicing attachment. For this purpose there is apusher
included as an accessory to this attachment.
■ The grating and slicing attachment is not intended for processing frozen food, nut shells, coffee beans, hard fruit stones, etc.
Warning:
Incorrect use may lead to injuries.
■ To prevent injury caused by sharp edges, be especially careful when handling the grinding blade of the meat grinder and the blade assembly of the blender.
Increased attention must also be paid when emptying out the blending jar, when removing the blade assembly from the blending jar, when removing the
grinding blade from the chamber, and when cleaning the appliance.
■ Do not attempt to grind bones, nut shells or other hard ingredients.
■ Hot liquids up to atemperature of 55 °C may be processed in the blending jar. Be especially careful when handling hot liquids. Hot steam or splashing hot
foods and liquids may cause scalding. Never start the blender without the lid properly seated in position. When processing hot liquids, do not remove the
inner cap during operation. Do not touch the hot surface. Use the handle to carry the blending jar when it is hot.
■ The maximum continuous operating time is 10 minutes. Do not exceed the maximum operating time of 5 minutes when in the kneading mode and do not
exceed the maximum operating time of 2 minutes when using the blender. Before starting it again, allow the appliance to cool down for 30 minutes.
■ Always turn off the appliance, disconnect it from the power socket when not be using it, when leaving it without supervision, and before assembling,
disassembling, cleaning or moving it. Prior to disassembling the appliance and replacing accessories or accessible parts that move during use, wait until all
moving parts come to astop.
■ Clean it according to the instructions in chapter Cleaning and maintenance.
■ Never wash the appliance under running water or submerge it in water or another liquid.
■ Do not turn on the appliance when it is empty. Incorrect use of the appliance may negatively affect its lifetime.
■ Ensure that the power plug contacts do not come into contact with water or moisture. Do not place heavy items on the power cord. Make sure that the power
cord does not hang over the edge of atable or that it is not touching ahot surface.
■ Disconnect the power cord from the power socket by pulling on the plug, never pulling on the cord. Otherwise, this could damage the power cord or the
socket.
■ If the power cord is damaged, have it replaced at aprofessional service centre. It is forbidden to use the appliance if it has adamaged power cord.
■ To avoid the danger of injury by electrical shock, do not repair the appliance yourself or make any adjustments to it. Have all repairs performed at an authorised
service centre. By tampering with the appliance, you risk voiding your legal rights arising from unsatisfactory performance or quality warranty.

- 4 - 04/2021 Copyright © 2021, Fast ČR, a.s.
STM 6377CH / STM 6378BK
A
1
2
3
11
10
9
7
6
12
14
8
15
4
513

- 5 - 04/2021 Copyright © 2021, Fast ČR, a.s.
B
1
2
3
4
5
6
7
8
9
14
13
12
11
10
15
16
C1
3
2
4
5
6

- 6 - 04/2021 Copyright © 2021, Fast ČR, a.s.
1
2
3
D
6
4
7
510
8
9
E
45˚

- 7 - 04/2021 Copyright © 2021, Fast ČR, a.s.
EN Food Processor
User'smanual
■ Prior to using this appliance, please read the user’smanual thoroughly, even if you already
have experience in using similar appliances. Only use the appliance in the manner described
in this user’smanual. Keep this user’smanual in asafe place where it can be easily retrieved
for future use.
■ We recommend saving the original cardboard box, packaging material, purchase receipt
and responsibility statement of the vendor or warranty card for at least the duration of the
legal liability for unsatisfactory performance or quality. In the event of transportation, we
recommend that you pack the appliance in the original box from the manufacturer.
DESCRIPTION OF THE APPLIANCE AND ACCESSORIES
A1 Button for releasing the meat grinder
from the front attachment hub
A2 Removable cover of the front meat
grinder attachment hub
A3 A-shaped beater
A4 Balloon whisk
A5 Kneading hook
A6 Removable cover of the top blender
attachment hub
A7 Tilt-out multi-function head
A8 Attachment hub for mounting
attachments A3–A5
A9 Bowl cover with ahole for adding
ingredients
A10 4.5-litre stainless steel bowl
A11 Base unit
A12 Speed control knob
Serves to gradually set the speed level
MIN-1-2-3-4-5-6-MAX, set the pulse
level (PULSE) and to turning off the
appliance (OFF).
A13 Multi-function head release lock
A14 Anti-slip feet for stability of the
appliance during operation
A15 Lid
serves to close the stainless steel bowl
A10 for short term storage of processed
ingredients.
DESCRIPTION OF MEAT GRINDER ACCESSORIES
B1 Pusher
B2 Stainless steel hopper
B3 Feed tube
B4 Grinding chamber
B5 Screw shaft
B6 Grinding blade
B7 Screw ring
B8 Fine grinding plate
B9 Medium fine grinding plate
B10 Coarse grinding plate
B11 Separator
B12 Sausage stuffer attachment
B13 Moulder
B14 Conical attachment
B15 Cookie maker
B16 Cookie maker holder
Note:
Parts B11–B14 are contained inside the pusher B1.
Certain models are only equipped with ane and coarse grinding disc B8
and B10.
DESCRIPTION OF THE BLENDER ACCESSORIES
C1 Inner cap of the blending jar
C2 Outer lid of the blending jar with ahole
for adding ingredients
C3 Handle
C4 Glass blending jar with 1.5l capacity
C5 Cu
C6 Blade assembly
DESCRIPTION OF THE GRATING AND SLICING ATTACHMENT
D1 Pusher
D2 Feed tube
D3 Grating cone chamber
D4 Locking pin
serves to fasten the grating cone to
the chamber
D5 Very fine grating cone
D6 Fine grating cone
D7 Coarse grating cone
D8 Thin slice cut cone
D9 Thick slice cut cone
D10 Chute for directing grated food into
a container
BEFORE FIRST USE
1. Take the appliance and its accessories out of the packaging materials.
2. Thoroughly wash all accessory parts that are intended to come into contact with food using
warm water and aneutral kitchen detergent. Then rinse under clean running water and
thoroughly wipe dry with ane wiping cloth or allow them to dry naturally. After washing
and drying, we recommend to coat the grinding blade B6 and the grinding plates B8–B10
with cooking oil.
3. Do not submerge the food processor or its power cord in water or any other liquids.
Attention:
The metal parts of the meat grinder and attachments A3–A5 are
not intended for washing in adishwasher. Other removable parts
may be washed in adishwasher.
When handling the grating cones D5–D9, be very careful not to injure
yourself on their sharp blades.
BEATING, WHIPPING AND KNEADING
SELECTING ATTACHMENT TYPES
Attachment type Purpose of use
Beater A3
It is used for beating light and medium heavy yeast-free doughs,
for preparing sauces, creams, llings, etc. Do not use it for
kneading heavy doughs.
Balloon whisk A4
It is used for whisking whole eggs or egg whites, whipped
cream, foamy creams, etc. Do not use it for beating or
kneading doughs.
Kneading hook A5
It is used for kneading various types of doughs including heavy
and thick doughs such as for example bread dough, pizza
dough, fresh pastry doughs, etc.
ASSEMBLING AND DISASSEMBLING THE FOOD PROCESSOR
■ Before you start assembling or disassembling the food processor, check that it is turned o
and disconnected from the el. power socket.
1. Inserting the bowl and attaching the cover
1.1 Place the food processor on an even, dry and stable surface, for example on a kitchen
countertop.
1.2 Use the lock A13 to release the multi-function head A7 and tilt it out all the way. After tilting
out the multi-function head A7 release the lock A13. Locking of the multi-function head A7
inthe top open position is indicated by the lock A13 returning to the default position, which
is accompanied by an audible click.
1.3 Insert the stainless steel bowl A10 into the base unit A11 and secure it in place by turning it
clockwise. When the bowl A10 is properly attached, it cannot be separately lifted out of the
base unit A11.
1.4 On to the bottom part of the multi-function head A7 with attachment hub A8, slide the
cover A9 so that the latches along the perimeter of the round opening in the cover A9 slide
into the grooves along the perimeter of the attachment hub A8.
1.5 The lid A15 is used for covering the bowl A10 for short term storage of processed
ingredients.
2. Mounting attachments
2.1 When attaching an attachment, the multi-function head A7 must be locked in the open
position, see point 1.2 in the previous chapter. To attachment hub A8, attach one of
the attachments A3–A5 in such away that the attachment hub shaft A8 slides into the
attachment. Push the attachment towards the attachment hub A8 and turn it anticlockwise
to secure it in place. Lightly pull the attachment downwards with one hand to check that it
is properly attached.
2.2 Place the ingredients that you wish to process into the bowl A10. Release the lock A13 and
tilt the multi-function head A7 to ahorizontal position. After tilting down the multi-function
head A7, release the lock A13. The locked status of the multi-function head A7 in the tilted
down work position is indicated by the lock A13 returning to the default position. This is
accompanied by an audible click.
3. Disassembly
3.1 Use the lock A13 to release the multi-function head A7 and tilt it out all the way. After tilting
out the multi-function head A7, release the lock A13. Locking of the multi-function head A7
inthe top open position is indicated by the lock A13 returning to the default position, which
is accompanied by an audible click.
3.2 Push the attachment towards the attachment hubA8 andturn it clockwise to release it,
and then remove it. Turn the bowl A10 anticlockwise and remove it from the base unit A11.
Remove the cover A9 by pulling it downwards. Move the multi-function head A7 back to the
horizontal position.
USING THE FOOD PROCESSOR
1. Select the right type of attachment based on its intended use and assemble the appliance
according to the instructions in the chapter Assembling and disassembling the appliance.
Place the ingredients into the bowl A10.
Attention:
In asingle batch, it is possible to precess no more than 2.2 litres of light
dough or 0.8 litres of thick, heavy dough. The maximum number of egg
whites that can be whisked at once is 12. We recommend that you do not
ll the bowl A10 past the level of the 3l mark. If an insucient amount of
ingredients are put in the bowl A10 (less than 0.3 litres of dough), then
they may not be optimally processed.
2. Make sure that the multi-function head A7 is tilted down in the horizontal working position
and that the speed control knob A12 is set to the OFF position. Connect the power cord to
apower socket.
3. Set the required speed using the speed control knob A12. Gradually turn the speed control
knob A12 clockwise to increase the speed, turning it in the opposite direction will reduce
the speed. To initially stir in the ingredients, rst set alower speed and then adjust it as
required. Electronic speed regulation ensures that the set speed will be maintained under
various loads. While it is running, ingredients may be added into the bowl A10 through the
hole in the cover A9.
4. The pulse mode is used for increasing the speed to maximum for ashort time. To activate
the pulse mode, turn the speed control knob A12 to the PULSE position and to ensure
continuous operation hold it down in this position. As soon as you release the speed control
knob A12, it will automatically return to the OFF position.
5. If it is necessary to wipe ingredients o the inside of the mixing bowl A10 and the
attachment, rst turn o the food processor by setting the speed control knob A12 to the
OFF position and then disconnect it from the power socket. Wait until the rotating parts
come to astop and only then scrape away the ingredients with aspatula.

- 8 - 04/2021 Copyright © 2021, Fast ČR, a.s.
6. After you have nished using the appliance, set the speed control knob A12 to the OFF
position and disconnect the power cord from the power socket.
7. Wait until the rotating parts come to astop and disassemble the food mixer according to
the instructions included in chapter Assembling and disassembling the appliance. Use asoft
plastic spatula to empty out the contents of the bowl A10.
8. Clean out the food processor after each use according to the instructions in chapter
Cleaning and maintenance.
LED LIGHT
■ The multi-function head A7 has a LED light that turns on automatically when the food
processor is connected to a power socket. The LED light turns o automatically after
2.5 minutes of inactivity, i.e. when the appliance is not running or when the speed is not set
during this time. The LED light turns on again automatically when the food processor is put
into operation by the control knob A12 being set to a desired speed level.
QUICK GUIDE TO PROCESSING INGREDIENTS
Attachment type Ingredients Maximum
load
Processing
time
Speed
selection
Balloon whisk A4 Egg whites 12 pcs 4 min 5–6
Balloon whisk A4 Whipping cream 1l 6–8 min 5–6
Beater A3 Cake dough 2.2l 6 min 3–4
Kneading hook A5 Bread dough
Pizza dough 0.8l 4–5 min MIN to 2
Note:
The above processing times are only areference.
When whipping egg whites, the bowl A10 and the beater A4 must be
perfectly clean and dry. Even asmall amount of fat may cause the egg whites
not be whipped to the desired snowy consistency.
Whipping cream should be cooled to atemperature of 6 °C prior to being
whipped.
Prior to processing them, allow the ingredients used for making various
doughs to rest at room temperature.
GRINDING MEAT, MAKING SAUSAGES AND KEBABS, AND
MAKING COOKIES
ASSEMBLING AND DISASSEMBLING THE MEAT GRINDER
1. Insert the screw shaft B5 into the grinding chamber B4 with the cogged wheel entering rst.
2. Place the grinding blade B6 on to the shaft B5 (with the edge facing outwards from the
chamber) and on to it attach agrinding plate B8, B9 or B10 depending on the preferred
the grind. Make sure that the notch in the grinding chamber B4 slides into the groove in the
grinding plate.
Attention:
When attaching the blade B6, be very careful not to injure yourself
on the sharp edge.
3. Place the screw ring B7 on to the grinding chamber B4 and tighten it securely by screwing
it clockwise. Place the stainless steel hopper B2 on to the feed tube B3.
4. Make sure that the food processor is turned o and disconnected from the power socket.
The multi-function head A7 must be tilted down in the horizontal position and the whisk,
beater or kneading attachments must be removed. Remove the front cover A2 from the
multi-function head A7. Place the assembled attachment against the attachment hub
so that the feed tube B3 is tilted to the right at an angle of approximately 45° from the
vertical axis and secure the attachment in vertical position by turning it anticlockwise.
The attachment is locked in place when the button A1 slides out. This is accompanied by an
audible click.
5. When disassembling the meat grinder, rst remove the hopper B2. Then press the button
A1 and remove the meat grinder by turning it clockwise. After removing the grinder, put the
cover A2 back in its place.
6. When disassembling the meat grinder into its individual parts, proceed in the reverse
sequence.
USING THE MEAT GRINDER
1. First prepare the meat for grinding in the following way. Remove all bones, tendons,
cartilage and cut the meat into 2 × 2 × 6 cm size pieces that will freely pass through the feed
tube B3.
Attention:
Do not process frozen meat. Allow it to defrost before grinding it.
2. Make sure that the food processor is correctly assembled and that the speed control knob
A12 is set to the OFF position.
3. Place the bowl A10 or another suitable container under the meat grinder. Insert the power
plug into apower socket.
4. Use the speed control knob to set the desired speed. We recommend to initially set speed
3 and then increase it as required. Gradually place the meat pieces into the feed tube B3
and push them in using the pusher B1. Take care not to clog up the feed tube B3 by alarge
amount of meat. Do not process more than 5 kg of meat per batch. The processing time is
only several minutes.
Attention:
Do not use ngers or other items to push the meat in. Always use
the pusher B1 designed for this purpose.
5. The ground meat will fall into the prepared bowl. The meat that remains in the grinding
chamber B4 can be removed by grinding aslice of bread or abread roll.
6. To turn o the food processor, set the speed control knob A12 to the OFF position.
7. Clean out the meat grinder after each use according to the instructions in chapter Cleaning
and maintenance.
ASSEMBLING AND DISASSEMBLING THE SAUSAGE STUFFER ATTACHMENT
1. Proceed in the same way as when assembling the meat grinder, only with the dierence that
instead of the grinding blade B6 and the grinding plate B8, B9 or B10, only parts B11 aB12
are used.
2. Place the separator B11 on to the screw shaft so that the notch in the grinding chamber B4
ts into the groove in the separator B11. Place the sausage stuer attachment B12 on to the
separator B11 and complete the entire sausage stuer assembly by screwing the screw ring
B7 on to the grinding chamber B4. Place the stainless steel hopper B2 on to the feed tube
B3.
3. Attach the attachment to the food processor in the same way as described in point 4 in
chapter Assembling and disassembling the meat grinder.
4. When disassembling, rst remove the hopper B2. Then press the button A1 and remove the
attachment by turning it clockwise. After removing the attachment, put the cover A2 back
in its place.
5. When disassembling the attachment into its individual parts, proceed in the reverse
sequence.
USING THE SAUSAGE STUFFER ATTACHMENT
1. Make sure that the food processor is correctly assembled and that the speed control knob
A12 is set to the OFF position. Insert the power plug into apower socket.
2. Prepare a sausage casing that you will stu with ground meat and allow it to soak in
lukewarm water for approx. 10 minutes. Place the ground meat mixture on to the hopper
B2. Take the sausage casing out of the water and skewer or tie up one end and slide the
other end like asock on to the sausage stuer attachment B12.
3. Use the speed control knob A12 to set the desired speed. We recommend to initially set
the lowest speed and then increase it as required. With one hand hold the sausage casing
on the attachment B12 and use the other hand to push the ground meat mixture with the
pusher B1 through the feed tube B3. If the sausage casing sticks to the attachment B12, it is
necessary to moisten it with water again.
Attention:
Do not use ngers or other items to push the ground meat in.
Always use the pusher B1 designed for this purpose.
4. To turn o the appliance, set the speed control knob A12 to the OFF position.
5. Clean out the individual parts of the attachment after each use according to the instructions
in chapter Cleaning and maintenance.
ASSEMBLING AND DISASSEMBLING THE KEBAB MAKER ATTACHMENT
1. Proceed in the same way as when assembling the meat grinder, only with the dierence that
instead of the grinding blade B6 and the grinding plate B8, B9 or B10, only parts B13 aB14
are used.
2. Place the moulder B13 on to the screw shaft B5 so that the notch in the grinding chamber
B4 ts into the groove in the moulder B13. Place the kebab moulder attachment B13 on to
the conical attachment B14 and complete the entire kebab maker assembly by screwing the
screw ring B7 on to the grinding chamber B4. Place the stainless steel hopper B2 on to the
feed tube B3.
3. Attach the attachment to the food processor in the same way as described in point 4 in
chapter Assembling and disassembling the meat grinder.
4. When disassembling, rst remove the hopper B2. Then press the button A1 and remove the
attachment by turning it clockwise. After removing the attachment, put the cover A2 back
in its place.
5. When disassembling the attachment into its individual parts, proceed in the reverse
sequence.
USING THE KEBAB MAKER ATTACHMENT
1. Make sure that the food processor is correctly assembled and that the speed control knob
A12 is set to the OFF position. Insert the power plug into apower socket.
2. Place the prepared kebab meat mixture on to the hopper B2. Use the speed control knob
A12 to set the desired speed. We recommend to initially set the lowest speed and then
increase it as required. Using the pusher B1, push the mixture through the feed tube B3.
The result will be ahollow meat tube that is then cut into smaller pieces. The kebab is
atraditional meal from the Middle East made predominantly from ground meat and whole
grain wheat.

- 9 - 04/2021 Copyright © 2021, Fast ČR, a.s.
Attention:
Do not use ngers or other items to push the ground meat in.
Always use the pusher B1 designed for this purpose.
3. To turn o the appliance, set the speed control knob A12 to the OFF position.
4. Clean out the individual parts of the attachment after each use according to the instructions
in chapter Cleaning and maintenance.
ASSEMBLING AND DISASSEMBLING THE COOKIE MAKER ATTACHMENT
1. Proceed in the same way as when assembling the meat grinder, only with the dierence that
instead of the grinding blade B6 and the grinding plate B8, B9 or B10 only parts B11,B15
and B16 are used.
2. Place the separator B11 on to the screw shaft so that the notch in the grinding chamber B4
ts into the groove in the separator B11. Insert the cookie maker holder B16 into the screw
ring B7. Screw the screw ring B7 clockwise on to the grinding chamber B4. Complete the
assembly by inserting the cookie maker B15 into the holder B16 and attaching the hopper
B2 to the feed tube B3.
3. Attach the attachment to the food processor in the same way as described in point 4 in
chapter Assembling and disassembling the meat grinder.
4. When disassembling, rst remove the hopper B2. Then press the button A1 and remove the
attachment by turning it clockwise. After removing the attachment, put the cover A2 back
in its place.
5. When disassembling the attachment into its individual parts, proceed in the reverse
sequence.
USING THE COOKIE MAKER ATTACHMENT
1. Place the prepared dough on to the hopper B2. Slide the cookie maker B15 to the left or
right to set the desired cookie shape.
2. Insert the power plug into apower socket. Set the required speed using the speed control
knob A12. When starting it for the rst time, we recommend that you set speed 3 and then
increase or decrease it as required.
3. Use the pusher B1 to push the dough through the feed tube B3. The food processor will
push the dough out in the required shape that you set using the cookie maker B15.
We recommend that you place atray or your palm underneath the pushed out dough. Then
cut the formed dough into smaller pieces.
Attention:
Do not use ngers or other items to push the dough in. Always
use the pusher B1.
4. When you have nished using the food processor, turn it o by setting the speed control
knob A12 to the OFF position.
5. Clean out the attachment after each use according to the instructions in chapter Cleaning
and maintenance.
BLENDING
ASSEMBLING AND DISASSEMBLING THE BLENDER
1. On to the blending jar C4, place the outer lid C2 so that its edges copy the neck of the jar,
and push it down thoroughly along its entire perimeter. Into the hole in the lid C2, place the
inner cap C1 and push it down all the way.
2. Make sure that the food processor is turned o and disconnected from the power socket.
The multi-function head A7 must be tilted down in the horizontal position and the whisk,
beater or kneading attachments must be removed. Release and remove the top attachment
hub cover A6. Place the assembled blending jar on to the top hub and pulling it gently
turn it in the direction of the symbol all the way. The safety mechanism will prevent the
blender from starting unless it is correctly secured to the multi-function head A7.
3. To disassemble proceed in the reverse sequence.
USING THE BLENDER
1. The blender is intended for preparing meals and drinks such as milkshakes, creamy soups,
sauces, spreads, fresh baby foods, etc. It is not intended for juicing fruit and vegetables,
preparing potato purée, yeast dough or for whipping egg whites.
2. Assemble the blender according to the instructions in chapter Assembling and
disassembling the blender, and put the ingredients (larger pieces need to be cut up in
advance) into the blending jar C4.
Note:
The maximum capacity of the blending jar C4 is 1.5 litres. Never ll it past
the maximum mark. When processing hot liquids or liquids that expand in
volume during the blending process, it is recommended to ll the blending
jar to no more than ⅔ of its maximum capacity.
3. Make sure that the food processor is correctly assembled and that the speed control knob
A12 is set to the OFF position. Connect the power cord to apower socket. Set the required
speed using the speed control knob A12. We recommend to rst set aslower speed to
allow the ingredients to mix together. Then the speed may be increased. The pulse level
is appropriate when you wish to blend food only very quickly. To start the pulse level, turn
the speed control knob A12 to the PULSE position and hold it in this position for amoment.
As soon as you release the speed control knob A12, it will automatically return to the OFF
position.
Attention:
Hot liquids up to a temperature of 55 °C may be processed in
the blending jar. The maximum operating time of the blender is
2 minutes. Do not leave the appliance in continuous operation
for longer than indicated above. Then allow it to cool down for
30 minutes.
4. While blending, you may add food or liquids to the blending jar C4 through the hole in the
lid C2 after removing the inner cap C1. Never open the outer lid C2 during operation. When
processing hot liquids, the inner cap C1 must remain closed.
5. In the event that food is sticking to the blade assembly C6 or the walls of the blending jar
C4, turn the appliance o by turning the speed control knob A12 to the OFF position and
disconnect it from the power socket. Make sure that the blade assembly C6 has stopped
rotating. Carefully remove the assembled blending jar from the multi-function head A7 by
turning it in the direction of the symbol . Take o the lid and using aplastic spatula,
clean the blade assembly C6 and the inside of the blending jar C4. Put the lid back on and
reattach the blender assembly to the multi-function head A7. Plug the power cord into
apower socket and continue blending.
6. After you have nished using the appliance, set the speed control knob A12 to the OFF
position and disconnect the power cord from the power socket. Check that the blade
assembly C6 has stopped rotating and carefully take the blending jar assembly o the multi-
function head A7. Put the cover A6 back in its place and use asoft plastic spatula to remove
food from the blending jar C4.
7. Disassemble the assembled bowl and clean the individual parts after each use according to
the instructions in chapter Cleaning and maintenance.
ADVICE AND TIPS FOR BLENDING
■ First cut food with a rm consistency such as fruit and vegetables into smaller pieces
measuring 3 cm and only then blend it.
■ First, blend a smaller amount of ingredients and then gradually add more ingredients
through the hole in the lid C2 while blending. In this way, you will achieve better results
than by adding all ingredients into the blending jar C4 at once.
■ If you need to blend food of asolid consistency together with liquids, we recommend that
you rst blend the food of solid consistency and apart of the liquids.Then gradually add the
remaining liquids through the hole in the lid C2 while blending.
■ To blend very thick liquids, we recommend using the pulse level so that the blade assembly
C6 does not get jammed too often. Start the blender repeatedly in short intervals.
■ Ice cubes must be processed immediately upon being removed from the freezer. When the
ice starts to melt, the ice cubes will stick together and it will not be possible to blend them.
QUICK GUIDE TO PROCESSING INGREDIENTS
Ingredients Speed selection Recommended
blending time
Fruit, vegetables cut into smaller pieces 5–6 30 s
Baby food 5–6 40 s
Spreads, dressings, marinades 3–4 30 s
Smoothies and cocktails 6 to MAX 40 s
Soups 6 to MAX 30 s
Ice cubes PULSE
Note:
The above food processing times are only areference. The actual blending
time depends on the size of the ingredients, their amount and the required
nal consistency.
GRATING AND SLICING
PURPOSE OF THE GRATING AND SLICING ATTACHMENT
■ The attachment is designed for slicing and grating fruit and vegetables, cheeses, chocolate,
nuts, for making breadcrumbs, etc.
■ The table Choosing the right type of grating cone will help you to select the right type.
ASSEMBLING AND DISASSEMBLING THE GRATING AND SLICING ATTACHMENT
1. Select one of the grating cones B5–B9 and insert it into the chamber B3, so that the shaft
inside the chamber B3 slides into the pentagonal hole in the centre of the grating cone.
Seat the locking pin B4 on to the shaft, and then turn it to secure the grating cone inside
the chamber B3. Attach the chute B10 to the chamber B3.
2. Make sure that the food processor is turned off and disconnected from the power socket.
The arm of the food processor must be tilted down in the horizontal position and the
blender, beater or kneading attachments must be removed. Remove the front cover
from the multi-function head of the food processor, and push the assembled attachment
at an angle of 45° against the front attachment hub and secure it in place by turning it
anticlockwise, see figure D.
3. The attachment is securely mounted in the vertical position when the button located on
the left of the front attachment hub slides out. An audible click is made when the button
slides out. The attachment is assembled when the pusher B1 is inserted in the feed tube
B2. The attachment is now assembled and ready for use.
4. When removing an attachment, first press the button located on the left of the front
attachment hub, and then remove the attachment by turning it clockwise. When
disassembling the attachment into its individual parts, proceed in the reverse sequence.
USING THE GRATING AND SLICING ATTACHMENT
1. Prepare the ingredients and cut them into pieces that will pass through the feed tube B2.
Remove hard kernels or stones from the fruit and vegetables. Remove shells from nuts.

- 10 - 04/2021 Copyright © 2021, Fast ČR, a.s.
Attention:
Under no circumstances should you attempt to process frozen food, nut
shells or hard stones that are found, for example, in mango or avocado.
2. Make sure that the food processor is correctly assembled and that the speed control knob
is set to the OFF position. Insert the power plug into an electrical power socket.
3. Place the the bowl A2 or another suitable container underneath the attachment. Use the
speed control knob to set the desired speed. We recommend to initially set the lowest
speed and then you may increase it as required.
4. Gradually add the ingredients into the feed tube B2 and push them through using the
pusher B1.
5. In the event that the attachment becomes blocked, turn off the food processor and
disconnect it from the power socket. Wait until rotating parts come to acomplete stop.
Remove the attachment and clean it out. Then assemble the attachment and reattach it
to the food processor. Connect the food processor to apower socket, turn it on and you
may continue working with it.
Attention:
When handling the grating cones B5–B9, be very careful not to injure
yourself on their sharp blades.
6. After you have finished using the appliance, set the speed control knob to the OFF position
and disconnect the power cord from the power socket.
7. Clean out the individual parts of the attachment after each use according to the instructions
in chapter Cleaning and maintenance.
CHOOSING THE RIGHT TYPE OF GRATING CONE
Food type Slicing cone
B8–B9
Coarse
grating
cone B7
Fine grating
cone B6
Very fine
grating
cone B5
Fruit
Apples • • •
Pears • • •
Vegetables
Red and white cabbage • • •
Carrot • • •
Zucchini • •
Cucumbers • •
Celery • • •
Onion • •
Potatoes • • •
Radish • • •
Sweet potatoes • • •
Other foods
Hard cheese
(e.g. Parmesan cheese) •••
Chocolate • • •
Hard baked goods
(for breadcrumbs) •
Nuts without shells •
Note:
The provided table only recommends the suitable type of grating cone for the
given type of food. If necessary, it is possible to use your preferred grating cone
for the given type of food.
The table includes the most common types of food that can be processed. However,
you can also use the grating and slicing cone for other types of food, for which it
generally applies that it can be normally cut using aknife.
CLEANING AND MAINTENANCE
■ Before cleaning the food processor, always switch it o by setting the speed control knob
A12 to the OFF position and disconnect it from the power socket.
■ Disassemble the food processor into its individual parts. Wait until moving parts come to
acomplete stop before disassembly.
■ Thoroughly wash the used removable parts after every use using warm water with aneutral
dishwashing detergent.Then rinse them under clean running water and wipe them dry with
ane wiping cloth or allow them to dry naturally. After washing and drying, we recommend
to coat the grinding blade B6 and the grinding plates B8, B9 andB10 with cooking oil.
■ If you whisked egg whites, rst rinse the bowl A10 and the beater A4 under cold water.
If you were to use hot water, the egg white remains would harden and their removal would
be more dicult.
■ Clean the mixing container C4 by lling it with 0.5 litre of clean water and afew drops of
kitchen detergent and then assemble the blender and run it for 10 to 15 seconds. Then turn
o the food processor, disconnect it from the power socket, and after the rotating parts have
come to astop, remove the blending jar assembly. Empty out the contents of the blending
jar C4 and then thoroughly rinse out the blending jar C4 with clean water and wipe dry.
■ If more thorough cleaning is required, the cu C5 with blade assembly C6 may be removed
using aspecial wrench that can be ordered free of charge at an authorised service centre.
After cleaning, it is necessary to install the cu C5 with blade assembly C6 back in its place
and to properly tighten it using the wrench.
Attention:
When cleaning, be very careful not to injure yourself on the sharp cutting
edge.
■After every use, it is necessary to thoroughly clean any used attachments D6–D9 in
hot water and neutral kitchen detergent. Then rinse it under clean running water and
thoroughly wipe dry with ane wiping cloth.
■ The metal parts of the meat grinder, the blade assembly C6 and attachments A3–A5
are not intended for washing in adishwasher. Other removable parts may be washed in
adishwasher.
■ For cleaning the base unit A11 and the multi-function head A7, use acloth lightly dipped
in a weak detergent solution. Then wipe everything with a clean dampened cloth and
thoroughly wipe dry.
■ For cleaning, do not use solvents or cleaning agents with abrasive eects. Otherwise, the
surface of the appliance may be damaged.
■ Do not submerge the food processor or its power cord in water or any other liquids.
STORAGE
■ When not using the food processor, store it in a clean, dry place out of children’sreach.
Make sure that the multi-function head A7 is tilted down into the horizontal position.
TECHNICAL SPECIFICATIONS
Rated voltage range............................................................................................................................... 220−240 V
Rated frequency...........................................................................................................................................50/60 Hz
Rated power input........................................................................................................................................1 000 W
Noise level.......................................................................................................................................................85 dB(A)
The declared noise emission level of the appliance is 85 dB(A), which represents alevel Aof
acoustic power with respect to areference acoustic power of 1 pW.
INSTRUCTIONS AND INFORMATION REGARDING THE
DISPOSAL OF USED PACKAGING MATERIALS
Dispose of used packaging material at asite designated for waste in your municipality.
DISPOSALOF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on products or original documents means that used electric or
electronic products must not be added to ordinary municipal waste. For
proper disposal, renewal and recycling hand over these appliances to
determined collection points. Alternatively, in some European Union states or
other European countries you may return your appliances to the local retailer
when buying an equivalent new appliance.
Correct disposal of this product helps save valuable natural resources and
prevents potential negative eects on the environment and human health,
which could result from improper waste disposal. Ask your local authorities or
collection facility for more details.
In accordance with national regulations penalties may be imposed for the incorrect disposal
of this type of waste.
For business entities in European Union states
If you want to dispose of electric or electronic appliances, ask your retailer or supplier for the
necessary information.
Disposal in other countries outside the European Union
This symbol is valid in the European Union. If you wish to dispose of this product, request the
necessary information about the correct disposal method from the local council or from your
retailer.
This product meets all the basic requirements of EU directives related to it.
