Overview
5
PRODUCT INFORMATION
Overview
You can find information about the individual products in the ew IEM G4
series under “ew IEM G4 series products”.
For information about the available accessories, see “Accessories”.
You can find information about the ew IEM G4 series frequency bank sys-
tem under “The frequency bank system”.

ew IEM G4 series products
6
ew IEM G4 series products
Click the name of the particular product to learn more about it.
You can also find more information here:
• A variety of frequency variants are available from the individual prod-
ucts. You can find more information under “Product variants”.
• You can find technical specifications about the individual products un-
der “Specifications”.
• You can find information about installing the products under “Installing
and starting up ew IEM G4 series devices”.
• You can find information about operating the products under “Using
ew IEM G4 series devices”.

7
EK IEM G4 stereo diversity receiver
You can find more detailed information about the EK IE MG4 in the follow-
ing sections:
• Installation and Startup: “Installing the EK IEM G4”
• Operation: “Using the EK IEM G4”
• Technical Data: “EK IEM G4”

8
SR IEM G4 stereo transmitter
You can find more detailed information about the SR IEM G4 in the follow-
ing sections:
• Installation and Startup: “Installing the SR IEM G4”
• Operation: “Using the SR IEM G4”
• Technical Data: “SR IEM G4”

Accessories
9
Accessories
A variety of accessories are available for the ew IEM G4 series.
Earphones
IE 4
Article no. 500432
►
You can find more information about the earphones on their product
page at www.sennheiser.com.

Accessories
10
Rechargeable battery and charger
BA 2015 rechargeable battery
The BA 2015 rechargeable battery is designed for use with evolution wire-
less G4 series handheld transmitters, bodypack transmitters and
bodypack receivers.
Article no. 009950
►
L2015charger
The BA 2015 rechargeable battery can be charged in the L 2015 charger on
its own or inside of the bodypack transmitter/bodypack receiver.
Article no. 009828
►

Accessories
11
Accessories for rack mounting
GA 3 rack mount kit
19” rack adapter for mounting the EM 100 G4, EM 300 G4, EM 500 G4 or
SR IEM G4 in a 19” rack.
Article no. 503167
►
AM 2 antenna front mounting kit
Antenna front mounting kit for installing antenna connections on the front
of the rack when using the EM 100 G4, EM 300 G4, EM 500 G4 or
SR IEM G4 together with the GA 3 rack mounting kit.
Article no. 009912
►
►

Accessories
12
Antennas and accessories
The following antenna components are available as accessory parts.
Omni-directional antennas
•A 1031-U, passive omni-directional antenna, article no. 004645
Directional antennas
•A 2003 UHF, passive directional antenna, article no. 003658
Antenna combiner
►
•AC 41, active antenna combiner
•ASA 41-EU, 470 – 870 MHz, article no. 508243
•AC 41-UK, 470 – 870 MHz, article no. 508295
•AC 41-US, 470 – 608 MHz, article no. 508244
Antenna cables
•GZL 1019, BNC/BNC coaxial cable, antenna cable with 50 ? character-
istic (wave) impedance
•GZL 1019-A1 variant, 1 m (3 ft), article no. 002324
•GZL 1019-A5 variant, 5 m (16 ft), article no. 002325
•GZL 1019-A10 variant, 10 m (16 ft), article no. 002326

The frequency bank system
13
The frequency bank system
There are different frequency ranges in the UHF band available for trans-
mission.
The following frequency ranges are available for the ew IEM G4 series:
•A1 range: 470 – 516 MHz
•A range: 516 – 558 MHz
•AS range: 520 – 558 MHz
•G range: 566 – 608 MHz
•GB range: 606 – 648 MHz
•B range: 626 – 668 MHz
•C range: 734 – 776 MHz
•D range: 780 – 822 MHz
•E range: 823 – 865 MHz
Every frequency range has 26 frequency banks with up to 16 channels:
►
You can find information about the frequency presets in the frequen-
cy tables of the respective frequency ranges under “Frequency ta-
bles”.

Installing and starting up ew IEM G4 series devices
14
INSTALLATION
Installing and starting up ew IEM G4 se-
ries devices
You can find information about installing and connecting ew IEM G4 series
devices in the following sections.
•EK IEM G4 diversity receiver >> “Installing the EK IEM G4”
•SR IEM G4 stereo transmitter >> “Installing the SR IEM G4”
•ASA 214 antenna combiner >> “Installing the AC 41”
You can find information about operating the products under “Using
ew IEM G4 series devices”.

Installing the EK IEM G4
15
Installing the EK IEM G4
These sections contain detailed information about installing and starting
up the EK IEM G4.
You can find information about operating the EK IEM G4 under “Using the
EK IEM G4”.
Inserting and removing the batteries/rechargeable
batteries
You can operate the diversity receiver either with batteries (AA, 1.5 V) or
with the rechargeable Sennheiser BA 2015 battery.
▷Press the two catches and open the battery compartment cover.
▷Insert the batteries or the rechargeable battery as shown below. Please
observe correct polarity when inserting the batteries.
▷Close the battery compartment.
The cover locks into place with an audible click.

Installing the EK IEM G4
16
Battery status
Charge status of the batteries:
►
Charge status is critical (LOW BATT):
►

Installing the EK IEM G4
17
Connecting earphones to the EK IEM G4
ATTENTION
Danger due to high volume levels
Volume levels that are too high may damage your hearing.
▷Turn down the volume of the headphone output before you put on the
headphone.
To connect the earphones to the receiver:
▷Insert the cable’s 3.5 mm jack plug into the PHONES socket on the re-
ceiver as shown in the diagram.
►
The ground connection of the earphone cable acts as an antenna for
the second diversity branch. For details on the pin assignment, see
“Pin assignment”.

Installing the EK IEM G4
18
Attaching the diversity receiver to your clothing
You can use the belt clip to attach the diversity receiver to your waistband
or on a guitar strap.
The belt clip is detachable so that you can also attach the diversity receiver
with the antenna pointing downwards. To do so, withdraw the belt clip
from its fixing points and attach it the other way round.
►
The belt clip is secured so that it cannot slide out of its fixing points acci-
dentally.
To detach the belt clip:
▷Lift the belt clip as shown in the diagram.
►
▷Press one side of the clip downward on the fixing hole and pull it out of
the housing.
▷Do the same thing on the other side.

Installing the SR IEM G4
19
Installing the SR IEM G4
These sections contain detailed information about installing and starting
up the SR IEM G4.
You can find information about operating the SR IEM G4 under “Using the
SR IEM G4”.
Connectors on the rear of the device
SR IEM G4 rear side product overview
►
1Strain relief for the cable of the power supply unit
• See “Connecting/disconnecting the SR IEM G4 with/from the power
supply”
2DC INsocket
• For connecting the power supply unit
• See “Connecting/disconnecting the SR IEM G4 with/from the power
supply”
3LAN connection socket (ETHERNET RJ 45)
• See “Creating a data network”
46.3 mm jack socket LOOP OUT BAL L(I)
•Audiooutput,left
• See “Daisy chaining audio signals”
56.3 mm jack socket LOOP OUT BAL R(II)
•Audiooutput,right
• See “Daisy chaining audio signals”
6XLR-3/6.3 mm jack combo socket BAL AF IN L(I)
• Audio input, left
• See “Connecting audio signals”
7XLR-3/6.3 mm jack combo socket BAL AF IN R(II)
• Audio input, right
• See “Connecting audio signals”
8RF OUT BNC socket
• Antenna output with remote power supply input
• See “Connecting antennas”
