Barton®7000 Series
Turbine Flowmeters
71xx, 72xx, & 73xx for Liquid
74xx for Gas
CE marked meters conform
to the European Union
Pressurized Equipment
Directive (PED), 97/23/EC
User Manual
Part No. 9A-11350, Rev. 04
August 2012
Table of Contents
Safety Information ............................................................................................ 2
Section 1—Introduction .................................................................................... 3
Barton 7000 Series Flowmeters.................................................................... 3
Specications—7000 Series Turbine Flowmeters ........................................ 3
Electrical Classication.............................................................................. 3
Pressure Boundary Certication................................................................ 4
Measurement Performance....................................................................... 4
Specications—Standard Pickup Coil ...................................................... 5
CE Markings (for PED owmeters only) ....................................................... 5
Section 2—Installation and Operation.............................................................. 7
Unpacking..................................................................................................... 7
Unpacking Procedure................................................................................ 7
Best Practices for Installation........................................................................ 9
Filtration..................................................................................................... 9
Electrical Installation.................................................................................. 9
Flowmeter Position.................................................................................... 9
Flowmeter Location................................................................................. 10
Bolt Size/Torque Requirements............................................................... 12
System Pressure .................................................................................... 13
Installation Procedure ................................................................................. 13
Section 3—Maintenance ................................................................................ 17
Routine Maintenance Checklist .................................................................. 17
Parts Replacement ..................................................................................... 18
Repair Kits .................................................................................................. 18
Disassembly/Assembly............................................................................... 21
Model 7100 Fractional-Sized Flowmeters............................................... 21
Model 7100/7300 Flowmeters (1 in. and larger)...................................... 22
Model 7200/7400 Flowmeters................................................................. 24
Electrical Pickup Coil Check ....................................................................... 25
Troubleshooting .......................................................................................... 25
Section 4—Dimensional Drawings ................................................................. 29

2
Safety Information
Before installing this instrument, become familiar with the installation in-
structions in Section 2.
!WARNING:Thissymbolidentiesinformationaboutpracticesorcircum-
stancesthatcanleadtopersonalinjuryordeath,propertydamage,or
economicloss.
CAUTION: Indicatesactionsorprocedureswhichifnotperformedcorrectly
mayleadtopersonalinjuryorincorrectfunctionoftheinstrument
orconnectedequipment.
IMPORTANT: Indicates actions or procedures which may affect instrument operation or
may lead to an instrument response that is not planned.

3
Model 7000 Series Turbine Flowmeter Section 1
Section1—Introduction
Barton 7000 Series Flowmeters
Barton 7000 Series owmeters are specially designed to accommodate a
broad range of precise uid measurement applications. They can accept larger
ow rates with lower pressure drops than other meters in their class, and fea-
ture a self-ushing design for longer sustained accuracy. Their high-frequency
digital output is ideal for interfacing with digital readout equipment. The 7000
Series' symmetrical bi-directional design supports reverse ow applications,
without reducing accuracy or ow capacity.
All meters are shipped with a pickup coil. Each meter assembly includes two
locknuts, two ow straightener tube assemblies, a center shaft, two diffus-
ers, and a rotor, and is factory-calibrated with water. Bearing type varies with
models: Models 7100 and 7300 feature wear-resistant tungsten carbide sleeve
bearings and thrust washers. Models 7200 and 7400 feature self-lubricating,
precision stainless steel ball bearings. The Model 7400 features bearings with
dry lubricant impregnated ball separators.
During operation, uid passes over the diffuser section and is accelerated onto
a multi-blade hydro-dynamically balanced turbine rotor. The rotor speed is
proportional to the volumetric ow rate. As the rotor turns, a reluctance type
pickup coil (mounted on the meter) senses the passage of each blade tip and
generates a sine wave output with a frequency that is directly proportional to
the ow rate.
The rotor is the only moving part of the Barton turbine owmeter. The small
lightweight rotor hubs ensure fast response to process ow changes. The rotor
is hydro-dynamically balanced during operation, eliminating the need for me-
chanical thrust leveling. This low-friction design improves metering linearity
and reduces wear and maintenance.
The pickup coil is inserted into a conduit adapter that is welded to the outside
of the turbine body. The boss is explosion-proof/ameproof with 3/4" male
NPT electrical threads. The pickup coil can be removed for troubleshooting
without depressurizing the meter or stopping uid ow.
Specications—7000SeriesTurbineFlowmeters
Electrical Classication
• Explosion-proof/Flameproof CSA listed Class I, Division 1, Group
B,C,D; Class II, E,F,G; Class III, Enclosure 4 waterproof to NEC (USA)
and CEC (Canadian) standards, including single seal certication to
ANSI 12.27.0-1

4
Section 1 Model 7000 Series Turbine Flowmeter
• ATEX certied, EEx d IIC (Model 7100, 7200, 7300)
• Measurement Canada Custody Transfer Certication G-0210 (Model
7400)
• Canadian Registration Number 0F0123.2C (Model 7400)
• Intrinsically Safe/Non-incendive approved to various standards as
governed by the certication of the readout device and the specic entity
parameters of the pickup coils listed with that device.
Pressure Boundary Certication
• Conformity to PED 97/23/EC
Measurement Performance
Refer to Cameron product literature (technical data sheets) for full descrip-
tions and capabilities.
• Linearity (Models 7100, 7200, 7300)*
- ±1.0% for 1/4-in. and 3/8-in. sizes
- ±0.5% for 1/2-in., 5/8-in., and 3/4-in. sizes
- ±0.25% for 1-in. and larger sizes
• Linearity (Model 7400)*
- ±1.0% for single K-factor
• Custody transfer approved by Measurement Canada
• Temperature Range
- Model 7100, 7300: -160°F to 850°F (-107°C to 454°C)
- Model 7200, 7400: -425°F to 570°F (-254°C to 299°C)
For temperature and pressure derating information, see Section 2, Table 2.3
and 2.4, page 15, and Table 2-5, page 16.
The temperature range required for any given application is dependent on the
bearing design, electronics/electrical selections and meter housing materials.
Contact Cameron for help in selecting a meter and components that are appro-
priate for high-temperature or low-temperature applications.
MeterPickupCoil(s)
A variable reluctance generating pickup coil contains a permanent magnet and
a wire winding. In Model 7100, 7200 and 7400 owmeters, the rotor blade of
the turbine meter is made of a ferritic stainless steel such as grade 430. The
movement of the rotor blade in proximity to the magnetic eld of the coil tip
produces an AC type voltage pulse within the coil winding. In Model 7300,
the ferritic bars imbedded in the rotor shroud interact with the pickup coil.
Because the bars on the shroud outnumber the blades on a standard rotor, the
7300 owmeter provides more pulses per unit volume (resolution). This fea-
ture is valuable when proving large-capacity meters with a small-volume prover.

5
Model 7000 Series Turbine Flowmeter Section 1
Shielded wire cable conveys the output of the pickup coil to compatible elec-
tronic instruments to indicate ow rate, record, and/or totalize the volumet-
ric ow. Since the coil itself does not require electrical power, the standard
pickup coil incorporates connection pins that mate to a quick connector.
The pickup coil can drive a variety of instruments including ow rate indica-
tors, totalizers, preampliers or ow computers/RTUs. Preampliers are used
to transmit the coil signal over extended distances to remote-mounted instru-
ments.
The meter may be factory-tted with multiple coils for redundancy, indication
of ow direction or pulse train verication.
The pickup coil type and magnetic strength vary with application require-
ments. For coil replacement, refer to the part number etched on the coil body.
Specications—Standard Pickup Coil
Temperature Range........................ -450°F to +450°F (-268°C to +232°C) (not including
meter and mating connectors)
DC Resistance................................ 1200 ohms (nominal)
Inductance...................................... 450 mh (nominal)
Dielectric Strength Rating............... 500 VAC rms minimum
Insulation Resistance Rating.......... 100 megaohms @100V
Number of Pins............................... 2
Connector....................................... MIL-C-5015 (mates with MS31 06-10SL-4S)
Dimensions..................................... See Section 5 - ODD Drawing
Other models may be suitable, depending on the application. See the Spare
Parts List, page 18, for information on alternate models.
CEMarkings(forPEDowmetersonly)
Barton 7000 owmeters that are built to conform to the European Union Pres-
surized Equipment Directive (PED) are marked with the following:
•Part number
•Serial number
• Maximum working pressure
• Minimum working pressure
• Minimum temperature (°F, °C)
• Nominal diameter
• Material
• Manufacturer's name and address
• CE mark*
• Notied body identication number
*1-in. owmeters are not CE-marked. The basis for PED conformance is
Sound Engineering Practice (SEP).

6
Section 1 Model 7000 Series Turbine Flowmeter

7
Model 7000 Series Turbine Flowmeter Section 2
Section2—InstallationandOperation
Unpacking
All Barton owmeters are tested and inspected during manufacture. However,
the instrument should be inspected at time of unpacking to detect any damage
that may have occurred during shipment.
Unpacking Procedure
1. For applications requiring special cleaning/precautions, a polyethylene
bag is used to protect the instrument from contamination. This bag
should be removed only in an extremely clean environment.
2. Unpack the meter and verify the accuracy of the information listed on the
packing slip (proper model number, serial number, calibration data, etc.).
3. Remove the threaded protectors or ange covers from the meter housing.
4. For meters up to 3-inch size, place the meter in a horizontal position
and blow (lung pressure should be sufcient) into the inlet port. Place
larger meters in a horizontal position and turn the rotor by hand or with
a wooden dowel. In either instance, the rotor should turn freely with no
evidence of roughness or binding in the rotation.
5. Visually inspect the meter inside and outside (without disassembling the
meter). Report any visible damage to Cameron immediately.
6. Replace the thread protectors and ange covers, then place the meter
back inside the polyethylene bag. Note: Meters may be stored indenitely
in the polyethylene bag.
CAUTION: Cleanallupstreamlinesbeforeinstallingthemeter.Foreigndebris
willdamageorcollectontherotor.Donotblowoutliquidlineswith
compressedairorgasoncethemeterhasbeeninstalled.
Donotslugliquidmeterswithuid.Carefullyllthelineafter
installingthemeter.Afterstartup,keepthemeterfullofliquid.
DonotexposeModel7400gasowmeterstoliquids.Theywill
damagethemeter.
Iftheendconnectionleaksatthetimeofinstallation,removepres-
surebeforeattemptingtotightentheseal.
UseappropriateboltsandhardwareperANSIB16.5and,ifappli-
cable,perNACEMRO175/ISO15156.
Where processtemperaturesarehigh,theturbinemetersurfaces
maybehazardoustotouch.Exercisecautionwhenoperatingor
servicing.

8
Section 2 Model 7000 Series Turbine Flowmeter
!WARNING:
Thecustomerisresponsibleforensuringchemicalcompatibilitybetween
theowmeterandanyuidsbeingmetered.
Neverexceedthemaximumrecommendedpressureandtemperature
limits.
Neverexceedthemaximumrecommendedowrateforthemeter.
Forinstallationswherethepressurecouldexceedtheratedmaximum
safeworkingpressureoftheturbinemeterhousingoranges,thepiping
systemmustincludeprotectivemeasurestopreventoverpressure,in
accordancewithapplicablelocalandnationalpipingcode.
Theturbinemeterisnotdesignedforhighstaticordynamicloadsatthe
endconnections.Thepipingsystemmustbedesignedwithadequate
supportstominimizetheloadsattheturbinemeter,inaccordancewith
applicablelocalandnationalpipingcode.
Theturbinemetermaybeunderpressure.Ensurethatthepipingsystem
iscompletelydepressurizedbeforeremovingthemeterformaintenance
orinspection.

9
Model 7000 Series Turbine Flowmeter Section 2
BestPracticesforInstallation
Before installing a Barton turbine owmeter, read the following best practices
in their entirety.
Filtration
All meters should be installed with upstream ltration to isolate the meter
from damage from foreign objects in the piping system. See the Barton 7000
Series product data sheet for recommended ltration size. Cameron offers
start-up screens as an optional accessory to prevent damage from foreign
objects.
Avoid the use of Teon® tape on body threads. Strands can enter the ow-
stream and collect on the rotor, causing measurement error.
All meters should be isolated from gas or liquid “slugs” which can cause
damage by over-speed and water hammer.
Electrical Installation
Consider the process operating temperature when selecting the type and
location of electric tting and instrument components. Heat conducted and
radiated from the turbine can damage wiring, connectors, electrical housing
and circuit boards. The meter can be installed so that the pickup coil is in any
plane. Avoid orienting the pickup coil in a 12 o'clock position in applications
with elevated temperatures.
Where possible, minimize the length of signal transmission cables from the
pickup. The signal from the turbine is a low-voltage AC sine wave that can be
as low as 30mV peak-to-peak. Electrical noise on the wires will cause false
counts on the readout instruments. Direct-mounting a totalizer or preampli-
er is preferred. If this is not possible, ensure that the signal cable is not near
power cables, other signal cables, or routed where electrical noise may inter-
fere with signal transmission.
Follow common wiring installation practices, using quality cable (twisted
pair, shielded with ground wire).
Flowmeter Position
Barton turbine owmeters are calibrated in a horizontal position. Therefore,
the best correlation of calibration occurs when the meter is operated in this
plane. However, the meter will operate satisfactorily in any position.

10
Section 2 Model 7000 Series Turbine Flowmeter
Flowmeter Location
See Figure 2.1 for reference. Location of the owmeter to obtain optimum
accuracy is dependent upon several factors.
• Relative to the System—When the ow is expected to be intermittent, the
meter should not be mounted at a low point in the piping system since
solids can settle on, or congeal around the rotor. These solids can cause
the rotor to freeze or otherwise be damaged.
• Tolerance to Mechanical Vibration—The turbine meter is constructed
to withstand rugged service. However, meter life can be increased by
locating the meter so as to protect it from the direct shock or mechanical
vibration.
• Tolerance to Electrical Interference—To obtain the best electrical signal
output from the meter, locate the meter at a distance from sources of elec-
trical interference. A preamplier is recommended for use on all installa-
tions to reduce the effect of undesired noise.
• Where practical, install the meter upstream of control valves and pres-
sure regulators. Where necessary, the meter should be at least 100 pipe
diameters from the valves.
Model 7400 owmeters feature a pressure tap on the body opposite the rotor.
For compliance with international measurement standards, any pressure sen-
sor used for computation of corrected volume should sense pressure from this
tap.

11
Model 7000 Series Turbine Flowmeter Section 2
Figure 2.1—Flowmeter piping arrangements

12
Section 2 Model 7000 Series Turbine Flowmeter
Bolt Size/Torque Requirements
Bolt sizes vary with meter size and ange rating. See Table 2.4 for bolt speci-
cations recommended in ASME B16.5-2003.
Torque requirement vary with meter size, threads, and tting/nut material. See
Table 2.2 for recommended torque values.
Table2.1—RecommendedBoltSizes
Meter
Size
(in.)
FlangeRating
150LB 300LB 600LB 900LB 1500LB 2500LB
1/2 2-1/4x1/2 2-1/2x1/2 3x1/2 4-1/4x3/4 4-1/4x3/4 —
3/4 2-1/2x1/2 3x5/8 3-1/2x5/8 4-1/2x3/4 4-1/2x3/4 —
1 2-1/2x1/2 3x5/8 3-1/2x5/8 5x7/8 5x7/8 5-1/4x7/8
1-1/4 2-3/4x1/2 3-1/4x5/8 3-3/4x5/8 5x7/8 5x7/8 5-3/4x1
1-1/2 2-3/4x1/2 3-1/2x3/4 4-1/4x3/4 5-1/2x1 5-1/2x1 6-1/2x1-1/8
2 3-1/4x5/8 3-1/2x5/8 4-1/4x5/8 5-3/4x7/8 5-3/4x7/8 6-3/4x1
2-1/2 3-1/2x5/8 4x3/4 4-3/4x3/4 6-1/4x1 6-1/4x1 7-1/2x1-1/8
3 3-1/2x5/8 4-1/4x3/4 5x3/4 5-3/4x7/8 7x1-1/8 8-1/2x1-1/4
4 3-1/2x5/8 4-1/2x3/4 5-3/4x7/8 6-3/4x1-1/8 7-3/4x1-1/4 9-3/4x1-1/2
5 3-3/4x3/4 4-3/4x3/4 6-1/2x1 7-1/2x1-1/4 9-3/4x1-1/2 11-1/2x1-3/4
6 4x3/4 4-3/4x3/4 6-3/4x1 7-1/2x1-1/8 10-1/4x1-3/8 13-1/2x2
8 4-1/4x3/4 5-1/2x7/8 7-1/2x1-1/8 8-3/4x1-3/8 11-1/2x1-5/8 15x2
10 4-1/2x7/8 6-1/4x1 8-1/2x1-1/4 9-1/4x1-3/8 13-1/4x1-7/8 19x2-1/2
12 4-3/4x7/8 6-3/4x1-1/8 8-3/4x1-1/4 10x1-3/8 14-3/4x2 21x2-3/4
Table2.2—TorqueValues
Dash
No.
O.D.
Tubing
(inches)
FittingsThreads
(UniedThreads
Class 3A may be
used)
Torque*inch-lbs(N-m)
Aluminum & Other
Non-Ferrous Alloy
Fittings&Nuts
Steel & Other
Ferrous Alloy
Fittings&Nuts
8 1/2 3/4-16 NF-3 150-200 (17-22.6) 220-300 (24.8-33.9)
10 5/8 7/8-14 NF-3 205-275 (23.2-31) 300-410 (33.9-46.3)
12 3/4 1-1/16-12 N-3 300-400 (33.9-45.2) 450-600 (50.8-67.8)
16 1 1-5/16-12 N-3 450-600 (50.8-67.8) 675-900 (76.3-101.7)
20 1-1/4 1-5/8-12 N-3 540-720 (61-81.3) 825-1100 (93.2-124.3)
24 1-1/2 1-7/8-12 N-3 680-900 (76.8-101.7) 1010-1350 (114-152.3)
Notes: Completely dry nuts should be torqued to the high value given. When nuts are
lubricated, they should be torqued to the lower value given.
* The applicable torque is determined on the basis of the nut and related tting re-
gardless of the material that the tting passes through.

13
Model 7000 Series Turbine Flowmeter Section 2
System Pressure
The maximum and minimum system pressures must be considered when
installing the turbine meter into the system.
• Minimum Meter Pressure—To obtain proper response, a back pressure
should be applied to the meter. This back pressure should be at least
twice the pressure drop of the meter at maximum ow (all meters). For
liquid meters, the back pressure should be twice the pressure drop of the
meter at maximum ow, plus twice the uid vapor pressure.
Minimum Pressure at the Meter = (2 x Net Pressure Drop at Maximum
Flow) + (2x Vapor Pressure of Fluid)
Some piping arrangements cause this amount of back pressure on the me-
ter due to downstream restriction, valves, etc. If additional back pressure
is needed, a downstream orice or valve can be added in accordance with
the piping arrangements shown in Figure 2.1, page 11.
InstallationProcedure
Prior to installing the turbine meter into the system, perform the following:
1. Install a “spool piece” and allow sufcient ow through the system to
completely ush any foreign material from the system. If foreign mate-
rial is expected in the ow the uid should be ltered. This is especially
important for ball bearing meters.
2. Remove gas "slugs" from liquid meter ow lines and liquid "slugs" from
gas meter ow lines.
3. If the meter is used in a cryogenic application, (available by special order
only; limited to model 7200 meters), install a bypass for cooling the pip-
ing without passing uid through the meter (Figure 2.2). This prevents
gasication of the cryogenic uid and ensures all ow passing through
the meter is liquid.
Figure 2.2—Flowmeter bypass
4. If liquid meters are to be "proved" for accuracy in-situ using a portable
prover, install prover taps per API standards.
5. Install a straight section of pipe on either side of the meter. This pipe
must be the same nominal pipe size as the meter with a length of at least
10 pipe diameters upstream and 5 pipe diameters downstream. (For
example, a owmeter with a 2-in. nominal diameter requires a 2-in. pipe.

14
Section 2 Model 7000 Series Turbine Flowmeter
The section of straight pipe upstream must be 20 in.; the section down-
stream must be 10 in.) Do not install throttling valves within 100 pipe
diameters upstream of the owmeter.
6. Install a ow straightener upstream and downstream of the meter. The
applicable lter should be selected according to ISA Standard RP31.1.
All uids to be used with a Model 7200 turbine meter should be free of
particles larger than approximately 10 microns.
7. Align the meter bore with the pipe, ensuring that the direction of ow
corresponds with the direction of the arrow engraved on the meter body.
All Barton turbine owmeters have “IN” and “OUT” stamped into the
housings to identify the direction of ow in which the meter was cali-
brated.
8. Insert bolts and apply torque for a leak-proof seal. See Tables 2.1 and 2.2,
page 11, for bolt size and torque requirements.
9. Install the magnetic pickup as follows.
a. If the meter will be used in a Class I, Div. 1 area, apply an industrial
thread-locking compound to the threads of the magnetic pickup. This
step is not required for non-hazardous installations.
b. Screw the magnetic pickup clockwise into the conduit adapter until
nger-tight. Do not tighten with pliers.
c. Attach the signal cable connector to the pickup and turn the swivel
nut until the connection is snug. Do not over-tighten.
CAUTION: Themeterpressureratinghasbeendeterminedusingstandard
methodsandstressallowablevalueswithoutspecicconsideration
forcorrosion(neitherinternalnorexternal)orfatigue.Thepiping
systemdesignershouldappropriatelyderateanymeterwherethese
considerationsaresignicantissues.
IMPORTANT: Any marked maximum working pressure (MWP) rating refers to the
meter room temperature pressure rating. For operation at other tempera-
tures, see the pressure derating information in Tables 2.3 and 2.4, page
15, and Table 2.5, page 16.

15
Model 7000 Series Turbine Flowmeter Section 2
Table2.3—PressureRatings(PSI)
Flange
Class
Type316SST7000SeriesTurbineMeterswithASMEB16.5Flanges
-20°F
(-29°C)
100°F
(38°C)
200°F
(93°C)
300°F
(149°C)
400°F
(204°C)
500°F
(260°C)
600°F
(316°C)
650°F
(343°C)
700°F
(371°C)
750°F
(399°C)
CL 150 275 275 235 215 195 170 140 125 110 95
CL 300 720 720 620 560 515 480 450 440 435 425
CL 400 960 960 825 745 685 635 600 590 580 570
CL 600 1440 1440 1240 1120 1025 955 900 885 870 855
CL 900 2160 2160 1860 1680 1540 1435 1355 1325 1305 1280
CL 1500 3600 3600 3095 2795 2570 2390 2255 2210 2170 2135
CL 2500 6000 6000 5160 4660 4280 3980 3760 3680 3620 3560
Size Type316SST7000SeriesTurbineMeterswithNPT/BSPThreads
-20°F
(-29°C)
100°F
(38°C)
200°F
(93°C)
300°F
(149°C)
400°F
(204°C)
500°F
(260°C)
600°F
(316°C)
650°F
(343°C)
700°F
(371°C)
750°F
(399°C)
1" * 4400 4400 3791 3417 3136 2926 2762 2715 2645 2621
1-1/4" 4000 4000 3447 3106 2851 2660 2511 2468 2404 2383
1-1/2" 3200 3200 2757 2485 2281 2128 2009 1974 1923 1906
2" 2650 2650 2284 2058 1889 1762 1663 1635 1593 1579
* 1-in. owmeters are not CE marked. The basis for PED conformance is Sound Engineering Prac-
tice (SEP).
Table2.4—PressureRatings(MPa)
Flange
Class
Type316SST7000SeriesTurbineMeterswithASMEB16.5Flanges
-29°C 38°C 50°C 100°C 150°C 200°C 250°C 300°C 325°C 350°C
CL 150 1.9 1.9 1.8 1.6 1.5 1.4 1.2 1.0 0.93 0.84
CL 300 5.0 5.0 4.8 4.3 3.9 3.6 3.3 3.2 3.1 3.0
CL 400 6.6 6.6 6.4 5.6 5.1 4.8 4.5 4.2 4.1 4.0
CL 600 9.9 9.9 9.6 8.4 7.7 7.1 6.7 6.3 6.2 6.1
CL 900 15.0 15.0 14.0 13.0 12.0 11.0 10.0 9.5 9.3 9.1
CL 1500 25.0 25.0 24.0 21.0 19.0 18.0 17.0 16.0 15.0 15.0
CL 2500 41.4 41.4 40.1 35.2 32.1 29.7 27.8 26.4 25.7 25.3
Size Type316SST7000SeriesTurbineMeterswithNPT/BSPThreads
-29°C 38°C 93°C 149°C 204°C 260°C 316°C 343°C 371°C 399°C
1" * 30.3 30.3 26.1 23.6 21.6 20.2 19.0 18.7 18.2 18.1
1-1/4" 27.6 27.6 23.8 21.4 19.7 18.3 17.3 17.0 16.6 16.4
1-1/2" 22.1 22.1 19.0 17.1 15.7 14.7 13.9 13.6 13.3 13.1
2" 18.3 18.3 15.8 14.2 13.0 12.2 11.5 11.3 11.0 10.9
* 1-in. owmeters are not CE marked. The basis for PED conformance is Sound Engineering Prac-
tice (SEP).

16
Section 2 Model 7000 Series Turbine Flowmeter
Table2.5—PressureRatings(Bar)
Flange
Class
Type316SST7000SeriesTurbineMeterswithASMEB16.5Flanges
-29°C 38°C 50°C 100°C 150°C 200°C 250°C 300°C 325°C 350°C
CL 150 19.0 19.0 18.4 16.2 14.8 13.7 12.1 10.2 9.3 8.4
CL 300 49.6 49.6 48.1 42.8 38.5 35.7 33.4 31.6 30.9 30.3
CL 400 66.2 66.2 64.2 56.3 51.3 47.6 44.5 42.2 41.2 40.4
CL 600 99.3 99.3 96.2 84.4 77.0 71.3 66.8 63.2 61.8 60.7
CL 900 148.9 148.9 144.3 126.6 115.5 107.0 100.1 94.9 92.7 91.0
CL 1500 248.2 248.2 240.6 211.0 192.5 178.3 166.9 158.1 154.4 151.6
CL 2500 413.7 413.7 400.9 351.6 320.8 297.2 278.1 263.5 257.4 252.7
Size Type316SST7000SeriesTurbineMeterswithNPT/BSPThreads
-29°C 38°C 93°C 149°C 204°C 260°C 316°C 343°C 371°C 399°C
1" * 303.4 303.4 261.4 235.6 216.2 201.7 190.4 187.2 182.4 180.7
1-1/4" 275.8 275.8 237.7 214.1 196.6 183.4 173.1 170.2 165.7 164.3
1-1/2" 220.6 220.6 190.1 171.3 157.3 146.7 138.5 136.1 132.6 131.4
2" 182.7 182.7 157.5 141.9 130.2 121.5 114.7 112.7 109.8 108.9
* 1-in. owmeters are not CE marked. The basis for PED conformance is Sound Engineering Prac-
tice (SEP).

17
Model 7000 Series Turbine Flowmeter Section 3
Section3—Maintenance
Barton 7000 Series owmeters have a proven history of providing long cycle
periods between maintenance intervals. It is recommended the meters be
inspected every 3 to 5 years unless measurement anomalies occur. Many
installations are suitable for much longer maintenance cycles.
RoutineMaintenanceChecklist
Perform the following steps as part of your routine maintenance.
1. Before removing internal components from the meter, check the rotor to
determine if it turns freely.
2. Disassemble the meter and check for evidence of erosion or other me-
chanical damage to the interior of the meter body or internal components.
a. The rotor blade edges should be dened and not excessively round-
ed.
b. The rotor should be uniform and symmetrical.
c. Models 7100 and 7300 tungsten carbide bushings and bearings
should be free of radial play.
d. Model 7400 tungsten carbide bushings and bearings are dry lubricat-
ed and may emit a uniform sound and may not feel perfectly smooth
when rotated. This is normal.
e. Model 7400 and Model 7200 bearings should be free of axial and
radial play.
3. In a vented area, clean each part thoroughly in di-chlorethylene or any
similar cleaning solvent before reassembling the meter.

18
Section 3 Model 7000 Series Turbine Flowmeter
PartsReplacement
See Table 3.1 for a list of recommended spare parts.
!WARNING: Useonlysparepartsidentiedinthismanual.Cameronbears
nolegalresponsibilityfortheperformanceofaproductthathasbeen
servicedorrepairedwithpartsthatarenotauthorizedbyCameron.
Table3.1—ElectricalSpareParts
PickupCoils
Meter Size Temperature Rating Part Number
1/4-in. through 3/4-in. -450°F to +450°F
(-268°C to +232°C)
9A-2112-0001A-01
-58°F to +347°F
(-50°C to +175°C)
9A-2113-0001A-01*
-450°F to 850°F
(-268°C to +454°C)
9A-2114-0001A-01**
1-in. through 12-in. -450°F to +450°F
(-268°C to +232°C)
9A-2112-0001A-02
-58°F to +347°F
(-50°C to +175°C)
9A-2113-0001A-02*
-450°F to 850°F
(-268°C to +454°C)
9A-2114-0001A-02**
ConnectorsandCables-PartialListing
Connector Only (MS 3106-10SL-4S or
equivalent - rubber boot included)
9A-8001-1009B
Connector w/12" wires 9A-0818-1020B
Connector w/12" wires (required in some
intrinsicallly safe installations)
9A-0818-1050B
Adapter/Reducer, 1" MNPT x 3/4" FNPT 9A-0159-1008T
* Suitable for Intrinsically Safe/ATEX approved meters
** Suitable only for owmeters that have been approved by Cameron for use at
extreme temperatures. Contact Cameron for details.
RepairKits
Should an internal component of a Barton turbine owmeter require replace-
ment, replace all internals with a repair kit. See Tables 3.2 through 3.4, page
19, and Table 3.5, page 20, for a complete list of repair kits.
Repair kits are factory-calibrated with water using eight data points and two
repeat points. They are calibrated with the meter in which they are to be in-
stalled. Therefore, they should be purchased with the meter to prevent down-
time. If the repair kit has not been calibrated and on-site proving (calibration)
cannot be performed, return the meter and the repair kit to the factory for
calibration.

19
Model 7000 Series Turbine Flowmeter Section 3
Table3.2—Model7100Kits
Model Meter Size Part Number
7184 1/2" 9A-7084-9001-BA-01
7185 5/8" 9A-7085-9001-BA-01
7186 3/4" 9A-7086-9001-BA-01
7101 1" 9A-7001-9001-BA-01
7145 1-1/4" 9A-7045-9001-BA-01
7146 1-1/2" 9A-7046-9001-BA-01
7102 2" 9A-7002-9001-BA-01
7103 3" 9A-7003-9001-BA-01
7104 4" 9A-7004-9001-BA-01
7106 6" 9A-7006-9001-BA-01
7108 8" 9A-7008-9001-BA-01
7110 10" 9A-7010-9001-BA-01
7112 12" 9A-7012-9001-BA-01
Table3.3—Model7200Kits
Model Meter Size Part Number
7282 1/4" 9A-7082-9001-BA-02
7283 3/8" 9A-7083-9001-BA-02
7284 1/2" 9A-7084-9001-BA-02
7285 5/8" 9A-7085-9001-BA-02
7286 3/4" 9A-7086-9001-BA-02
7201 1" 9A-7001-9001-BA-02
7245 1-1/4" 9A-7045-9001-BA-02
7246 1-1/2" 9A-7046-9001-BA-02
7202 2" 9A-7002-9001-BA-02
7203 3" 9A-7003-9001-BA-02
7204 4" 9A-7004-9001-BA-02
7206 6" 9A-7006-9001-BA-02
Table3.4—Model7300Kits
Model Meter Size Part Number
7102 2" 9A-7002-9001-BA-01
7103 3" 9A-7003-9001-BA-01
7304 4" 9A-7004-9001-BA-03
7306 6" 9A-7006-9001-BA-03
7308 8" 9A-7008-9001-BA-03
7310 10" 9A-7010-9001-BA-03
7312 12" 9A-7012-9001-BA-03

20
Section 3 Model 7000 Series Turbine Flowmeter
Table3.5—Model7400Kits
Model Meter Size Part Number
7486 3/4" 9A-7086-9001-BA-04
7450 1" 9A-7050-9001-BA-04
7475 1" 9A-7075-9001-BA-04
7401 1" 9A-7001-9001-BA-04
7445 1-1/4" 9A-7045-9001-BA-04
7446 1-1/2" 9A-7046-9001-BA-04
7402 2" 9A-7002-9001-BA-04
7403 3" 9A-7003-9001-BA-04
7404 4" 9A-7004-9001-BA-04
7406 6" 9A-7006-9001-BA-04
7408 8" 9A-7008-9001-BA-04
7410 10" 9A-7010-9001-BA-04
7412 12" 9A-7012-9001-BA-04
