Sensorex CS665 Series User manual

DESIGNED IN CALIFORNIA
ASSEMBLED IN CALIFORNIA AND CZECH REPUBLIC
11751 MARKON DRIVE • GARDEN GROVE, CA 92841 • 714.895.4344 • WWW.SENSOREX.COM
© Sensorex Corporation. All rights reserved. In the interest of improving and updating its equipment,
Sensorex reserves the right to alter specifications to equipment at any time.
CS665 Steam-Sterilizable
Contacting Conductivity Sensor
Product Manual
Table of Contents
Introduction............................................................................................................. 1
Model # CS665 Ordering Matrix ............................................................................ 1
Specifications .......................................................................................................... 2
Calibration .............................................................................................................. 2
Sensor Installation .................................................................................................. 2
Mechanical........................................................................................................................2
Electrical............................................................................................................................3
Sensor Cleaning ...................................................................................................... 3

1
CS665 Steam-Sterilizable
Contacting Conductivity Sensor
Form: InstrCS665-Rev A [Rev: 2020-04-23]
© 2020 Sensorex Corporation
Introduction
Thank you for choosing the Sensorex CS665 Steam-Sterilizable Contacting Conductivity Sensor. See below for ordering
configurations and product specifications.
For example, choosing “0.1/cm” under Cell Constant would be B, “PT1000 RTD” for Temperature Compensation would be 1, “10 feet (3m), Standard
Four-Wire Cable” under Cable Length would be BC, “Tinned Leads” under Cable Termination Connector would be 3, “Sensorex-Branded” under
Branding would be A, and “1.5” NPT Stainless Steel“ under Installation/Fitting Type would be 7. The order code would then be “CS665 – B – 1 – BC –
3 – A – 7”.
Model # CS665 Ordering Matrix
MODEL # CS665
Description Code
CELL CONSTANT
•0.01/cm
•0.1/cm
•1.0/cm
•Custom Modification (customer-specified)
•A
•B
•C
•M
TEMPERATURE COMPENSATION
•PT1000 RTD
•PT100 RTD
•1
•2
CABLE LENGTH
•10-ft. (3m) Cable, Standard Four-Wire Cable •BC
CABLE TERMINATION CONNECTOR
•Tinned Leads •3
BRANDING
•Sensorex-Branded
•No Branding
•Custom Modification (customer-specified)
•A
•B
•M
INSTALLATION / FITTING TYPE
•1.5” Flange Stainless Steel
•2.0” Flange Stainless Steel
•7
•8

2
CS665 Steam-Sterilizable
Contacting Conductivity Sensor
Form: InstrCS665-Rev A [Rev: 2020-04-23]
© 2020 Sensorex Corporation
Specifications
Temperature Rating 130° C (266° F)
Temperature
Compensation
•Pt1000 RTD
•Pt100 RTD
Wetted Materials •316 Stainless Steel
•Teflon
•EPDM
Surface Finish Min RA20
Cell Constants •0.01cm
-1
•0.1cm
-1
•1.0cm
-1
See ordering information for more details.
Specifications
Temperature Rating 130° C (266° F)
Temperature
Compensation
•Pt1000 RTD
•Pt100 RTD
Wetted Materials •316 Stainless Steel
•Teflon
•EPDM
Surface Finish Min RA20
Cell Constants •0.01cm
-1
•0.1cm
-1
•1.0cm
-1
See ordering information for more details.
CS665-A
Calibration
Calibrate sensor according to meter/controller manufacturer’s
instructions using known certified conductivity standards. Be
sure and calibrate in large beaker or bucket, stirring sample with
electrode. Avoid bubbles as much as possible; bubbles cause
erroneous readings.
Specifications
CS665-B
CS665-C

3
CS665 Steam-Sterilizable
Contacting Conductivity Sensor
Form: InstrCS665-Rev A [Rev: 2020-04-23]
© 2020 Sensorex Corporation
Sensor Installation
Mechanical
1. Mount electrodes in stainless steel sanitary tee (1.5” or
2”, depending on selected options). See FIG 1. Place seal
provided with tee in groove on tee flange as shown.
2. Seat electrode on top of seal so that seal’s raised edge sits
in groove on the underside of flange. See FIG 1. Attach clamp
around tee flange and electrode flange. Swing wing nut into slot
in flange and tighten clockwise to seal.
3. Align sensor hole as closely as possible with center of tee
outlet. See FIG 2.
Always shut off flow when installing or removing
electrodes.
Electrical
Follow conductivity meter/controller manufacturer’s instructions.
Please note the following sensor wiring configurations:
WhiteWhite: Conductivity (Outer Electrode)
Black: Conductivity (Inner Electrode)
Green and Red: Temperature Sensor
ClearClear: Shield
Follow wiring instructions supplied with your controller.
Sensor Cleaning
Do NOT clean sensors with an abrasive brush that
could scratch the surface of the stainless steel. This will
adversely affect the measurement.
INLET
TELTUO
OUTLET
ALIGN SENSOR
HOLE AS CLOSELY
AS POSSIBLE WITH
CENTER OF TEE
OUTLET
INLET
FIG 2
CAUTION
CAUTION
1
2
3
Tri-Clamp
(user supplied)
CS615TC or
CS620TC sensor
(user supplied)
Quad seal
(user supplied)
(user supplied)
FIG 1
