Sentera Controls RDCZ Series Service manual

Mounting and operating instructions
RDCZ RESIDENTIAL FAN
SPEED CONTROLLER

www.sentera.eu
MIW-RDCZ-EN-003 - 29 / 10 / 2020 2 - 12
Table of contents
SAFETY AND PRECAUTIONS 3
PRODUCT DESCRIPTION 4
ARTICLE CODES 4
INTENDED AREA OF USE 4
TECHNICAL DATA 4
STANDARDS 5
OPERATIONAL DIAGRAMS 5
WIRING AND CONNECTIONS 5
MOUNTING INSTRUCTIONS IN STEPS 6
OPERATING INSTRUCTIONS 7
MENU STRUCTURE 10
7-SEGMENT DISPLAY INDICATION 11
VERIFICATION OF INSTALLATION INSTRUCTIONS 12
TRANSPORT AND STORAGE 12
WARRANTY AND RESTRICTIONS 12
MAINTENANCE 12
RDCZ RESIDENTIAL FAN SPEED
CONTROLLER

www.sentera.eu
MIW-RDCZ-EN-003 - 29 / 10 / 2020 3 - 12
back to the table of contents
SAFETY AND PRECAUTIONS
Read all the information, the datasheet, mounting and operating instructions and
study the wiring and connection diagram before working with the product. For
personal and equipment safety, and for optimum product performance, make sure you
entirely understand the contents before installing, using, or maintaining this product.
For safety and licensing (CE) reasons, unauthorised conversion and/ or modifications
of the product are inadmissible.
e product should not be exposed to abnormal conditions, such as: extreme
temperatures, direct sunlight or vibrations. Long-term exposure to chemical
vapours in high concentration can affect the product performance. Make sure the
work environment is as dry as possible; avoid condensation.
All installations shall comply with local health and safety regulations and local
electrical standards and approved codes. is product can only be installed by an
engineer or a technician who has expert knowledge of the product and safety
precautions.
Avoid contacts with energised electrical parts; always treat the product as if it is
live. Always disconnect the power supply before connecting, servicing or repairing
the product.
Always verify that you apply appropriate power supply to the product and use
appropriate wire size and characteristics. Make sure that all the screws and nuts
are well tightened and fuses (if any) are fitted well.
Recycling of equipment and packaging should be taken into consideration and these
should be disposed of in accordance with local and national legislation/regulations.
In case there are any questions that are not answered, please contact your
technical support or consult a professional.
RDCZ RESIDENTIAL FAN SPEED
CONTROLLER

www.sentera.eu
MIW-RDCZ-EN-003 - 29 / 10 / 2020 4 - 12
back to the table of contents
PRODUCT DESCRIPTION
e RDCZ series are residential HVAC controllers used to control AC fans or voltage
controllable motors in HVAC applications. ey feature a wide supply voltage
range 110—230 VAC / 50—60 Hz and a variable control output signal between
an adjustable minimum and maximum level. e controller can work in 2 modes.
In Automatic mode it is a demand-based controller with adjustable setpoint that
can be connected to a broad range of Sentera sensors. In Manual mode, the RDCZ
works as a full-featured triac controller. e settings are easily adjustable either via
the 3-button interface equipped with a 7-Segment LED display, via our 3SModbus
software application or via the Sensistant configurator.
ARTICLE CODES
Code Supply Enclosure
RDC Z9-15-WH 110—230 VAC ±10 % /
50—60 Hz
white-ivory (ASA LURAN 757, RAL 9010)
RDC Z9-15-BK anthracite (ABS- copolymer, RAL 7021)
INTENDED AREA OF USE
■Manual control for HVAC applications
■HVAC applications for improved comfort and energy saving
■For indoor use only
TECHNICAL DATA
■Supply voltage, Us: 110—230 VAC ±10 % / 50—60 Hz
■Inrush current:
►Max. 15 A (110 VAC)
►Max. 25 A (230 VAC)
■No-load power:
►110 VAC / 60 Hz < 0,9 W
►230 VAC -/ 50 Hz < 2,3 W
■Regulated output: 30—100 % Us
■Minimum load: 100 mA
■Maximum load: Imax. 1,5 A
■Minimum output voltage, Umin: 30—65 % Us
■Maximum output voltage, Umax: 75—100 % Us
■Start-up value: 30—100% Us
■Start-up duration: 2—10 seconds
■7-segment LED display and 3-button keyboard interface
■Enclosure:
►External: IP54 (according to EN 60529)
►Internal: IP44 (according to EN 60529)
■Operating ambient conditions:
►temperature: -10—40 °C
►rel. humidity: 5—80 % rH (non-condensing)
■Storage temperature: -20—50 °C
RDCZ RESIDENTIAL FAN SPEED
CONTROLLER

www.sentera.eu
MIW-RDCZ-EN-003 - 29 / 10 / 2020 5 - 12
back to the table of contents
STANDARDS
■Low Voltage Directive 2014/35/EC
■EMC Directive 2014/30/EC: EN 61000-6-2: 2005/AC:2005,
EN 61000-6-3:2007/A1:2011/AC:2012, EN 61326-2-3:2013
■WEEE Direc tive 2012/19/EC
■RoHs Directive 2011/65/EC
OPERATIONAL DIAGRAMS
Automatic mode
PI control (Cool, Dry, Drain)
SP
t, (s)
Input
(°C, ppm,
%)
PI control (Heat, Humidify, Obtain)
* PI control can require adjustment of parameters, depending on the local circumstances.
Out
[%]
Max
Min
SP - Hyst SP + HystSP In
(°C, ppm, %)
Direct control (Cool / Dry /Drain)
Direct control (Heat / Humidify / Obtain)
Manual mode
Stepless operational diagram 4 steps operational diagram
.
40 100
100
80
60
40
20
0
Out
[%]
LED
indication
(Stand-by)
Min
range
Max range
Min
range
Max range
LED
indication
(Stand-by)
Out
[%]
100
80
60
40
20
040
-0- 80 -2-
60
-1- 100 -3-
.
WIRING AND CONNECTIONS
L Power supply, line (110—230 VAC ±10 % / 50—60 Hz)
NPower supply, neutral (110—230 VAC ±10 % / 50—60 Hz)
Regulated output to motor, Imax 1,5 A
Regulated output to a single-phase AC motor
A Modbus RTU (RS485) signal A
/B Modbus RTU (RS485) signal /B
Connections Cable cross section: max. 2,5 mm2
Start-up
(soft start) duration
RDCZ RESIDENTIAL FAN SPEED
CONTROLLER

www.sentera.eu
MIW-RDCZ-EN-003 - 29 / 10 / 2020 6 - 12
back to the table of contents
MOUNTING INSTRUCTIONS IN STEPS
Before you start mounting the unit read carefully “Safety and Precautions”.
Then proceed with the following steps:
For inset mounting
1. Disconnect the power supply.
2. Remove the frame cover of the enclosure and take the RDCZ controller out, so
that it can be easily connected.
3. Do the wiring according to the wiring diagram (see Fig. 1).
Fig. 1 Wiring and connections
L NA/B
Power supply
110—230 VAC ±10%
50—60 Hz
Modbus
RTU
/B
A
Single phase AC Motor
Max 1,5 A
4. Mount the internal enclosure into the wall by inserting suitable connecting
elements into the openings. Mind the correct position and mounting dimensions
shown in Fig. 2 and Fig. 3.
Fig. 2 Mounting dimensions - inset mounting Fig. 3 Mounting position
10 58
58
76
38
52
Correct Incorrect
5. Put back the frame cover of the enclosure.
6. Switch on the power supply.
7. Customise the factory settings to the desired ones via the 3-button interface,
the 3SModbus software or via the Sensistant.
For surface mounting
1. Disconnect the power supply.
2. Remove the frame cover of the enclosure.
3. Take out the internal enclosure.
4. Mount the external enclosure to the wall using the delivered dowels and screws.
Mind the correct position and mounting dimensions shown in Fig. 4 and Fig. 4.
RDCZ RESIDENTIAL FAN SPEED
CONTROLLER

www.sentera.eu
MIW-RDCZ-EN-003 - 29 / 10 / 2020 7 - 12
back to the table of contents
5. Insert the connecting cables through the grommets of the unit.
Fig. 4 Mounting dimensions - surface mounting Fig. 5 Mounting position
64
64
2X
ø4,3
fix
fix
82
91
10 38
52
Correct Incorrect
6. Do the wiring according to the wiring diagram (see Fig. 1) using the information
from section “Wiring and connections”.
7. Put the internal enclosure into the external one and fix it using the delivered
screws and washers. (Fig. 4).
8. Put back the frame cover of the enclosure.
9. Switch on the power supply.
10.Customise the factory settings to the desired ones via the 3-button interface,
the 3SModbus software or Sensistant.
Optional settings
If your unit is the first or the last unit on the Mdbus RTU network (see Example 1 and
Example2), enable the NBT resistor via 3SModbus or the menu of the controller. If
your device is not an end device, leave the NBT disabled (default Modbus setting).
Example 1 Example 2
RX
ТX
NBT
NBT
Slave 2
Master
Slave n
Slave 1
Slave 2
Slave 1
RX
ТX
NBT
NBT
Master
Slave n
OPERATING INSTRUCTIONS
Choosing the operating mode
To choose the desired operating mode, press the up and down buttons
simultaneously in order to access the Setup mode. e decimal point after the values
indicates that the unit is in Setup Mode.
e display shows “RUN”. To change the run mode, press the button. Use the up
and down buttons to select “1” for automatic mode or “0” - for manual mode.
RDCZ RESIDENTIAL FAN SPEED
CONTROLLER

www.sentera.eu
MIW-RDCZ-EN-003 - 29 / 10 / 2020 8 - 12
back to the table of contents
To save the selected mode press for 4 seconds. The display will show "888" for a
few second to indicate that the value is stored in the memory. Press the up and
down buttons simultaneously again in order to exit the Setup mode.
■AUTOMATIC MODE:
In Automatic mode the RDCZ is a “master” device, i.e. it needs to be connected to
a sensor via Modbus RTU in order to operate and control the environment based
on the information received by the sensor. If no sensor is connected, the display
will show “...” and the RDCZ will not work. e sensor needs a few seconds in order
to take samples from the environment.
Automatic mode
Modbus RTU max. 1,5 A
RSMFF-2R
Room sensor
RDCZ
Residential fan speed controller AC fan
►Adjustment of parameters:
If necessary, some parameters, such as setpoints, can be adjusted. To do so,
you can either use the 3-button interface to enter the menu mode (see MENU
STRUCTURE below), use the free downloadable 3SModbus software to enter
the Modbus registers from a computer (see Modbus registers maps), or use the
Sensistant configurator.
►Operating the RDCZ in automatic mode:
e RDCZ can be switched on and off by pressing and holding the button for 4
seconds. The decimal point on the display indicates that the unit is in Stand-by mode.
When the RDCZZ is operational , you can toggle the display between the value
measured by the sensor and the output value (percentage) by pressing the button.
e automatic output for RDCZ (to obtain the installed setpoint), can be temporarily
overruled by pressing and holding the up button for 4 seconds (See Fig. 6 Overrule
mode below). You can now manually adjust the output to the desired level. After a
predefined period of time (from 10 to 120 minutes), the RDCZ returns to automatic
mode. e setting of this duration is only accessible via Modbus RTU. e I-O
adjustable parameter should be set to “Output”.
Fig. 6 Overrule mode
RDCZ RESIDENTIAL FAN SPEED
CONTROLLER

www.sentera.eu
MIW-RDCZ-EN-003 - 29 / 10 / 2020 9 - 12
back to the table of contents
■MANUAL MODE:
In Manual mode, the RDCZ operates as a full-featured manual controller for AC
fans.. e output value increases / decreases in the range between the min. and
max. settings (or 0). See the operational diagram. e output can be stepless or
divided into 2—10 equal steps.
Manual mode
max. 1,5 A
RDCZ
Residential fan speed controller AC fan
►Adjustment of parameters:
If necessary, some paramaters, such as the number of steps, can be adjusted.
To do so, you can either use the 3-button interface to enter the menu mode (see
MENU STRUCTURE below), use the free downloadable 3SModbus software to
enter the Modbus registers from a computer (see Modbus registers maps) or use
the Sensistant configurator.
►Operating the RDCZ in manual mode:
e RDCZ can be switched on and off by pressing and holding the button for 4
seconds. The decimal point on the display indicates that the unit is in Stand-by mode.
To increase the output value or step, use the up button. To decrease the output
value or step, press the down button.
When the number of steps is > 0, you can toggle the display between the number of
steps and the output value (percentage) by pressing the button.
NOTE In manual mode, the RDCZ is a “slave” device. is means that eventually, the
output value can be overridden by a Building Management System.
RDCZ RESIDENTIAL FAN SPEED
CONTROLLER

www.sentera.eu
MIW-RDCZ-EN-003 - 29 / 10 / 2020 10 - 12
back to the table of contents
MENU STRUCTURE
run 0. – 1.
output–input
0. – 2.00.
50. – 500.
30. – 65.
75. – 100.
0. – 1.
0. – 100.
0. – 100.
0. – 1.
2. – 10.
10. – 120.
baudrate
i - o
SP
rAngE
Lo
Hi
Pi
Pro
int
FAn START - uP
START-uP duration
OVerruLe timer
Net Settings
go To bootLoader
RESET To DEFAuLT
PRESS to return PRESS for 8 s
55 Err . . . 23.5 42.5 642 999 0.52
Master
Controller
Output Value %
0 – Slave mode
1 – Stand-alone
(Master) mode
Show input / output
value
Range depends from
connected sensor
Sensor range for
min. to max. output
Low Output Voltage
30 – 65 % Us
High Output Voltage
75 – 100 % Us
0 - Disable PI control
1 – Enable PI control
Kp – Proportional
Ki – Integral
0 - Softstart
1 - Kickstart
Start-up duration (s)
Overrule timer
10 – 120 (min)
baudrate – parity – NBT
In percentage In °C In % rH In ppm In ppmIn ppb
Error in CRC
checking
(Wrong data)
Slave not
connected or
nothing to read Temperature Humidity CO2TVOC
Decrement
value
Increment
value
RDCZ RESIDENTIAL FAN SPEED
CONTROLLER

www.sentera.eu
MIW-RDCZ-EN-003 - 29 / 10 / 2020 11 - 12
back to the table of contents
run 0. – 1.
30. – 65.
75. – 100.
30. – 100.
0. – 1.
2. – 10.
0. – 9.
0. – 9.
Id
Lo
Hi
Start Speed
Fan Start–uP
FS duration
Steps
Start Step
Net Settings
RESET To DEFAuLT
PRESS to return PRESS for 8 s
55 -4-
Slave
Controller
Output Value
0 – Slave mode
1 – Stand-alone
(Master) mode
Low Output Voltage
30 – 65 % VAC
High Output Voltage
75 – 100 % VAC
0 - Disable PI control
1 – Enable PI control
0 - Softstart
1 - Kickstart
Start-up duration (s)
Number of output steps
Start step
Id – baudrate – parity – NBT
In percentage
Step mode
(step)
Decrement
value
Increment
value
Step number
7-SEGMENT DISPLAY INDICATION
Indication Description
Digits Output value, menu items and settings
A decimal point Stand-by mode
Blinking digits Parameter saving or unit reset
1—100 Output value in working mode
Digits with a point Parameter value in setting mode
Indication of output steps Toggled with output value by pressing
RDCZ RESIDENTIAL FAN SPEED
CONTROLLER

www.sentera.eu
MIW-RDCZ-EN-003 - 29 / 10 / 2020 12 - 12
back to the table of contents
VERIFICATION OF INSTALLATION INSTRUCTIONS
When you first switch on the mains supply, the display will show “888” for 2 seconds.
en, ”20” will appear and the connected AC motor will run at minimum speed.
If this is not the case, check the connections.
Press and hold the up button until you reach the maximum output value ‘100’.
e AC motor will run at maximum speed. Press the button for 4 seconds until
the display shows a decimal point ‘.’. e RDCZ is now in Stand-by mode, the output
is 0, and the motor will stop.
If this is not the case, check the connections.
Fig. 7 Start-up indication
TRANSPORT AND STORAGE
Avoid shocks and extreme conditions; stock in original packing.
WARRANTY AND RESTRICTIONS
Two years from the delivery date against defects in manufacturing. Any modifications
or alterations to the product after the date of publication relieve the manufacturer
of any responsibilities. e manufacturer bears no responsibility for any misprints or
mistakes in this data.
MAINTENANCE
In normal conditions this product is maintenance-free. If soiled, clean with a dry or
damp cloth. In case of heavy pollution, clean with a non-aggressive product. In these
circumstances the unit should be disconnected from the supply. Pay attention that
no fluids enter the unit. Only reconnect it to the supply when it is completelydry.
RDCZ RESIDENTIAL FAN SPEED
CONTROLLER
