Sentera Controls SPVL8-010-EP Service manual

Mounting and operating instructions
SPVL8-010-EP EC FAN CONTROLLER WITH
MODBUS/DCI OUTPUT

www.sentera.eu
MIW-SPVL8-010-EP-EN-000-23/06/2023 2 - 9
back to the table of contents
SPVL8-010-EP EC FAN CONTROLLER WITH
MODBUS/DCI OUTPUT
Table of contents
SAFETY AND PRECAUTIONS 3
PRODUCT DESCRIPTION 4
ARTICLE CODES 4
INTENDED AREA OF USE 4
TECHNICAL DATA 4
STANDARDS 4
OPERATIONAL DIAGRAMS 5
WIRING AND CONNECTIONS 5
MOUNTING INSTRUCTIONS IN STEPS 5
VERIFICATION OF INSTALLATION 8
OPERATING INSTRUCTIONS 8
TRANSPORT AND STORAGE 9
WARRANTY AND RESTRICTIONS 9
MAINTENANCE 9

www.sentera.eu
MIW-SPVL8-010-EP-EN-000-23/06/2023 3 - 9
back to the table of contents
SPVL8-010-EP EC FAN CONTROLLER WITH
MODBUS/DCI OUTPUT
SAFETY AND PRECAUTIONS
Read all the information, the datasheet, Modbus map, mounting and operating
instructions and study the wiring and connection diagram before working with the
product. For personal and equipment safety, and for optimum product performance,
make sure you entirely understand the contents before installing, using or maintaining
this product.
For safety and licensing (CE) reasons, unauthorised conversion and/ or modifications
of the product are inadmissible.
e product should not be exposed to abnormal conditions, such as extreme
temperatures, direct sunlight or vibrations. Long-term exposure to chemical
vapours in high concentration can affect the product performance. Make sure the
work environment is as dry as possible; avoid condensation.
All installations shall comply with local health and safety regulations and local
electrical standards and approved codes. is product can only be installed by
an engineer or a technician who has expert knowledge of the product and safety
precautions.
Avoid contacts with energised electrical parts. Always disconnect the power
supply before connecting, servicing or repairing the product.
Always verify that you apply appropriate power supply to the product and use
appropriate wire size and characteristics. Make sure that all the screws and nuts
are well tightened and fuses (if any) are fitted well.
Recycling of equipment and packaging should be taken into consideration and these
should be disposed of in accordance with local and national legislation/regulations.
In case there are any questions that are not answered, please contact your
technical support or consult a professional.

www.sentera.eu
MIW-SPVL8-010-EP-EN-000-23/06/2023 4 - 9
back to the table of contents
SPVL8-010-EP EC FAN CONTROLLER WITH
MODBUS/DCI OUTPUT
PRODUCT DESCRIPTION
e SPVL8-010-EP is a speed controller and monitoring device for Modbus RTU
fans with DCI interface (EBM-Papst protocol). e Modbus RTU/DCI interface (DCI
Gen. 1) is used to configure, control and monitor up to 20 fans. Fans featuring the
EBM-Papst Modbus/DCI interface will be addressed automatically by the SPVL8-EP
controller. is results in much faster commissioning.
ARTICLE CODES
Code Supply voltage
SPVL8-010-EP 85—305 VAC / 50—60 Hz
INTENDED AREA OF USE
■Speed control, monitoring and commissioning of EBM-Papst filter fan units (FFUs)
with EC motor
TECHNICAL DATA
■Modbus RTU/DCI interface (daisy chain interface)
■Linear digital output signal according to the position of the potentiometer
■Automatic initial configuration of each fan
■Automatic assignment of network ID of each fan
■Control from low to high or from high to low speed, selectable via Modbus RTU
holding registers
■Fan status monitoring via RGB LED and Modbus input registers
■OFF position
■Bootloader for updating the firmware via Modbus RTU
■Adjustable minimum (Vmin) and maximum (Vmax) output value via Modbus RTU
holding registers
■Flush or surface mounting
■Push in terminal block
■Compatible with EBM-Papst K3G-series FFU with Modbus RTU/DCI interface
■Enclosure:
►External: ASA, white colour (28049P ), IP54 (according to EN 60529)
►Internal: polyamide, natural colour, IP44 (according to EN 60529)
■Operating ambient conditions:
►temperature: 0—40 °C
►rel. humidity: 5—95 % rH (non-condensing)
STANDARDS
■Low Voltage Directive 2014/35/EU
►60529:1991 Degrees of protection provided by enclosures (IP Code)
Amendments AC:1993, A1:2000, A2:2013, AC:2016-12 and AC:2019-12 to EN
60529
►EN 60730-1:2011 Automatic electrical controls for household and similar use.
Part 1: General requirements
►EN 60730-2-8:2002 Automatic electrical controls for household and similar
use. Part 2-8: Particular requirements for electrically operated water valves,
including mechanical requirements Amendment A1:2003 to EN 60730-2-8
►EN 60730-2-9:2010 Automatic electrical controls for household and similar use.
Part 2-9: Particular requirements for temperature sensing controls
■EMC directive 2014/30/EU:
►EN 60730-1:2011 Automatic electrical controls for household and similar use -

www.sentera.eu
MIW-SPVL8-010-EP-EN-000-23/06/2023 5 - 9
back to the table of contents
SPVL8-010-EP EC FAN CONTROLLER WITH
MODBUS/DCI OUTPUT
Part 1: General requirements
►EN 60730-2-8:2002 Automatic electrical controls for household and similar
use - Part 2-8: Particular requirements for electrically operated water valves,
including mechanical requirements Amendment A1:2003 to EN 60730-2-8
►EN 60730-2-9:2010 Automatic electrical controls for household and similar use
- Part 2-9: Particular requirements for temperature sensing controls
■RoHs Directive 2011/65/EU – Restriction of use of certain hazardous substances
in electrical and electronic equipment
►EN IEC 63000:2018 Technical documentation for the assessment of electrical
and electronic products with respect to the restriction of hazardous substances
OPERATIONAL DIAGRAMS
From low to high speed From high to low speed
Output [%]
Min range
Max range
100 %
10 %
Max
Off
Switch
On
0
0 %
Potentiometer position
Min
Output [%]
Min range
Max range
10 %
100 %
Max
Off
Switch
On
0
0 % Potentiometer position
Min
WIRING AND CONNECTIONS
LPower supply, line (85—305 VAC / 50—60 Hz)
NPower supply, neutral (85—305 VAC / 50—60 Hz)
8 - DCI Modbus DCI output
7 - GND Ground
6 and 2 - /B Modbus RTU (RS485), signal /B
5 and 4 Do not connect
3 and 1 - A Modbus RTU (RS485), signal A
Connections
Supply cables Cable cross section: 0,5—1,5 mm2
Modbus DCI communication /
RS485 + DCI Cat5 cable / UTP
DCI
GND
/B
A
/B
A
RJ45
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
3
4
5
6
3
4
MOUNTING INSTRUCTIONS IN STEPS
Before you start mounting the unit, read carefully “Safety and Precautions” and
follow the steps:

www.sentera.eu
MIW-SPVL8-010-EP-EN-000-23/06/2023 6 - 9
back to the table of contents
SPVL8-010-EP EC FAN CONTROLLER WITH
MODBUS/DCI OUTPUT
Flush mounting
1. Disconnect the mains supply.
2. Remove the knob by pulling it out.
3. Unscrew the washer to remove the cover of the external enclosure.
4. Do the wiring according to the wiring diagram (see Fig. 1 Wiring and connections).
5. Mount the internal enclosure into the wall according to the mounting dimensions
shown in Fig. 2 Mounting dimensions - flush mounting.
Fig. 1 Wiring and connections
Modbus RTU (RS485)
Power supply:
230 VAC / 50—60 Hz
DCI
GND
Modbus DCI
DCI
GND
/B
A
/B
A
RJ45
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
3
4
5
6
3
4
Fig. 2 Mounting dimensions - flush mounting
54
50
76
54
54
50
76
54
20 38
52
Correct Incorrect

www.sentera.eu
MIW-SPVL8-010-EP-EN-000-23/06/2023 7 - 9
back to the table of contents
SPVL8-010-EP EC FAN CONTROLLER WITH
MODBUS/DCI OUTPUT
6. Mount back the cover and secure it with the washer.
7. Put back the knob and turn it to off position.
8. Install all Modbus/DCI controlled motors and carry out electrical wiring according
to their datasheet.
9. Connect the controller to the motors using appropriate cables. See Fig. 4
Connection.
Fig. 4 Connection
SPVL8-010-EP
controller
EBM-papst FFU 1 EBM-papst FFU 2 EBM-papst FFU X
10. Turn on the power supply.
11. Turn on the controller.
12. All motors connected to the controller will be configured automatically.
13. Check the connection status via the LED indication. Turn the knob of the controller
to control the speed of the FFUs.
14. Customise the factory settings to the desired ones via the 3SModbus software
or SenteraWeb. For the default factory settings, see the Modbus register map.
Surface mounting
1. Disconnect the mains supply.
2. Remove the knob by pulling it out and open the cover.
3. Unscrew the washer to remove the cover of the external enclosure.
4. Mount the external enclosure onto the surface by means of the screws and dowels
adhering to the mounting dimensions shown in Fig. 3 Mounting dimensions -
surface mounting.

www.sentera.eu
MIW-SPVL8-010-EP-EN-000-23/06/2023 8 - 9
back to the table of contents
SPVL8-010-EP EC FAN CONTROLLER WITH
MODBUS/DCI OUTPUT
Fig. 3 Mounting dimensions - surface mounting
82
89
64
82
20 38
52
64
64
Correct Incorrect
5. Insert the cables through the grommets.
6. Do the wiring according to the wiring diagram (see Fig. 1 Wiring and connections).
7. Insert the internal enclosure into the external one and fix it using the screws.
Mount back the cover and secure it with the washer.
8. Put back the knob and turn it to off position.
9. Install all Modbus DCI controlled motors and carry out electrical wiring according
to their datasheet.
10. Connect the controller to the motors using appropriate cables. See Fig. 4
Connection.
11. Turn on the power supply.
12. Turn on the controller.
13. All motors connected to the controller will be configured automatically.
14. Check the connection status via the LED indication. Turn the knob of the controller
to control the speed of the FFUs.
15. Customise the factory settings to the desired ones via the 3SModbus software
or SenteraWeb. For the default factory settings, see the Modbus register map.
For the complete Modbus register data, refer to the product Modbus Register
Map, which is a separate document attached to the article code on the website
and contains the registers list. Products with earlier firmware versions may not be
compatible with this list.
NOTE
Optional settings
To assure correct communication, the NBT needs to be activated. See the Modbus
Register Map of the product.
NOTE Mount the unit so that the terminal block and connections are at the lower side.

www.sentera.eu
MIW-SPVL8-010-EP-EN-000-23/06/2023 9 - 9
back to the table of contents
SPVL8-010-EP EC FAN CONTROLLER WITH
MODBUS/DCI OUTPUT
VERIFICATION OF INSTALLATION
ATTENTION Use only tools and equipment with non-conducting handles when working on
electrical devices.
As soon as the unit has detected at least one FFU, addressing and configuration will
be completed automatically.
For installation status, please check the LED indications in the product datasheet.
OPERATING INSTRUCTIONS
ATTENTION Use only tools and equipment with non-conducting handles when working on
electrical devices.
e unit is intended for use with EC fans / motors. It restarts after power failure.
In case of faulty operation, please check if:
■the right voltage is applied
■all connections are correct
■Modbus communication is working and all settings are accessible via Modbus RTU
TRANSPORT AND STORAGE
Avoid shocks and extreme conditions; stock in original packing.
WARRANTY AND RESTRICTIONS
Two years from the delivery date against defects in manufacturing. Any modifications
or alterations to the product after the date of publication relieve the manufacturer
of any responsibilities. e manufacturer bears no responsibility for any misprints or
mistakes in this data.
MAINTENANCE
In normal conditions this product is maintenance-free. If soiled, clean with a dry or
damp cloth. In case of heavy pollution, clean with a non-aggressive product. In these
circumstances the unit should be disconnected from the supply. Pay attention that
no fluids enter the unit. Only reconnect it to the supply when it is completelydry.
