Sentera Controls MCS-1-LCD Service manual

Mounting and operating instructions
MCS -1-LCD MULTIFUNCTIONAL LOGIC
CONTROLLER

www.sentera.eu
MIW-MCS-1-LCD-EN-000-20/07/2016 2 - 33
Table of contents
SAFETY AND PRECAUTIONS 4
PRODUCT DESCRIPTION 5
ARTICLE CODES 5
INTENDED AREA OF USE 5
TECHNICAL DATA 5
STANDARDS 6
WIRING AND CONNECTIONS 6
OPERATIONAL DIAGRAMS 7
MOUNTING INSTRUCTIONS IN STEPS 8
VERIFICATION OF THE CORRECT INSTALLATION . . . . . . . . . . . . . . . . .10
OPERATING INSTRUCTIONS 12
CONTROLLER OVERVIEW. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
CONTROL FUNCTIONS OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . .12
PARAMETERS AND DEFAULT SETTINGS . . . . . . . . . . . . . . . . . . . . . .14
MC S -1- L C D MULTIFUNCTIONAL LOGIC
CONTROLLER

www.sentera.eu
MIW-MCS-1-LCD-EN-000-20/07/2016 3 - 33
CONFIGURING THE PARAMETERS 15
USING PREDEFINED TEMPLATES . . . . . . . . . . . . . . . . . . . . . . . . . .16
CUSTOMISING THE SETTINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
3SMONITOR SOFTWARE. . . . . . . . . . . . . . . . . . . . . . . . .17
3SMODBUS SOFTWARE . . . . . . . . . . . . . . . . . . . . . . . . .18
4-BUTON KEYBOARD INTERFACE . . . . . . . . . . . . . . . . . . .19
MAIN MENU STRUCTURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
DEVICE FUNCTIONALITY SELECTION . . . . . . . . . . . . . . . . .21
ANALOGUE INPUTS SETUP . . . . . . . . . . . . . . . . . . . . . . .22
DIGITAL INPUTS SETUP . . . . . . . . . . . . . . . . . . . . . . . . .23
ANALOGUE OUTPUTS SETUP . . . . . . . . . . . . . . . . . . . . . .24
RELAY CONTACT SETUP . . . . . . . . . . . . . . . . . . . . . . . . .25
SCHEDULE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
RUN SETTINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
MODBUS REGISTER MAPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
TRANSPORT AND STOCK KEEPING INFORMATION 33
WARRANTY INFORMATION AND RESTRICTIONS 33
MAINTENANCE 33
MC S -1- L C D MULTIFUNCTIONAL LOGIC
CONTROLLER

www.sentera.eu
MIW-MCS-1-LCD-EN-000-20/07/2016 4 - 33
back to the table of contents
SAFETY AND PRECAUTIONS
Read all information, the datasheet, mounting instructions and wiring scheme
before working with the product. For personal and equipment safety, and for
optimum product performance, make sure you entirely understand the contents
before installing, using, or maintaining this product.
For safety and licensing (CE) reasons, unauthorised conversion and/ or modifications
to the product are not permitted.
e product must not be exposed to abnormal conditions, such as: extreme
temperatures, direct sunlight or vibrations. Chemical vapours with high concentration
in combination with long exposure times can affect the product performance. Make
sure the work environment is as dry as possible; check for condensation spots.
All installations shall comply with the local health and safety regulations and local
electrical codes. is product can only be installed by an engineer or a technician
who has an expert knowledge of the product and safety precautions.
Avoid contacts with energised electrical parts; always treat the product as if it
is life. Always disconnect the power source before connecting the power cables,
servicing or repairing the product.
Always verify that you apply appropriate power supply to the product and use wires
with appropriate size and characteristics. Make sure that all the screws and nuts are
well tightened and fuses (if any) are fitted well.
Recycling of equipment and packaging should be taken into consideration and
disposed in accordance with local and national legislation/regulations.
In case there are any questions that are not answered, please contact your technical
support or consult a professional.
MC S -1- L C D MULTIFUNCTIONAL LOGIC
CONTROLLER

www.sentera.eu
MIW-MCS-1-LCD-EN-000-20/07/2016 5 - 33
back to the table of contents
PRODUCT DESCRIPTION
e MCS-1-LCD multifunctional logic controller has integrated analogue, digital
and relay outputs which are free configurable. Its multiple analogue, digital and
temperature inputs ensure functionality in a large range of HVAC applications. All
functional parameters and settings are accessible either via a 4-button interface
with LCD display, via a user-friendly monitoring software application for Windows or
via 3SModbus. A bootloader makes firmware updates via USB possible.
ARTICLE CODES
Code Supply
MCS-1-LCD 85—264 VAC / 47—63 Hz
INTENDED AREA OF USE
■Fan speed control and monitoring
■Air curtain control
■Advanced HVAC systems for maintaining stable environment and improved
comfort
■For indoor use only
TECHNICAL DATA
Temperature inputs
■2 temperature inputs: PT500 & PT1000 compatible (automatic detection)
Analogue inputs
■2 analogue inputs Ai1 and Ai2: (0—10 VDC / 2—10 VDC / 0—20 mA / 4—20 mA / PWM)
►Input impedance (0—10 VDC mode): 136 kΩ
►Input impedance (0—20 mA mode): 505 Ω
►Input impedance (PWM mode): 131 kΩ
Digital inputs
■4 digital inputs
Analogue outputs
■2 analogue outputs: (0—10 VDC / 2—10 VDC / 0—20 mA / 4—20 mA / PWM)
►Load resistance in 0—10 VDC mode: ≥ 50 kΩ
►Load resistance in 0—20 mA mode: ≤ 500 Ω
►Load resistance in PWM mode: ≥ 50 kΩ
Relay outputs
■2 relay outputs: C/O, 250 VAC / 16 A (resistive load)
PWM outputs
■Internally supplied (Fig. 3a) or
■Open collector (Fig. 3b)
Supply outputs
■1 supply output: 24 VDC / 200 mA
Other specifications
■Leakage current: < 0,25 mA
■Power consumption:
►no load: max. 2 W
►full load: max. 11 W
■USB 2.0 interface
■Modbus RTU (RS485) communication
MC S -1- L C D MULTIFUNCTIONAL LOGIC
CONTROLLER

www.sentera.eu
MIW-MCS-1-LCD-EN-000-20/07/2016 6 - 33
back to the table of contents
■Enclosure:
►ABS plastic, grey (RAL7035)
►IP54 (according to EN 60529)
■Operating ambient conditions:
►temperature: 0—40 °C
►rel. humidity: 0—80 % rH (non-condensing)
■Storage temperature: -10—50 °C
STANDARDS
■Low Voltage Directive 2014/35/EC
■EMC Directive 2014/30/EC: EN 61326
■WEEE Direc tive 2012/19/EU
■RoHs Directive 2011/65/EU
WIRING AND CONNECTIONS
LPower supply, Line
NPower supply, Neutral
NC1 Normally closed contact, relay 1
COM1 Common contact, relay 1
NO1 Normally open contact, relay 1
NC2 Normally closed contact, relay 2
COM2 Common contact, relay 2
NO2 Normally open contact, relay 2
T1 Temperature input 1 (PT500 or PT1000)
GND Ground, common ground reference for T1 and T2
T2 Temperature input 2 (PT500 or PT1000)
Ai1 Analogue input 1 (0—10 VDC / 2—10 VDC / 0—20 mA / 4—20 mA / PWM)
GND Ground, common ground reference for Ai1 and Ai2
Ai2 Analogue input 2 (0—10 VDC / 2—10 VDC / 0—20 mA / 4—20 mA / PWM)
Di1 Digital input 1 (GND reference)
Di2 Digital input 2 (GND reference)
Di3 Digital input 3 (GND reference)
Di4 Digital input 4 (GND reference)
Ao1 Analogue output 1 (0—10 VDC / 2—10 VDC / 0—20 mA / 4—20 mA / PWM)
GND Ground, common ground reference for Ao1 and Ao2
Ao2 Analogue output 2 (0—10 VDC / 2—10 VDC / 0—20 mA / 4—20 mA / PWM)
GND Ground reference for supply output
+24 VDC Supply output (24 VDC / 200 mA)
/B Modbus RTU (RS485) signal /B
A Modbus RTU (RS485) signal /A
Connections
Cable cross section: max. 1,5 / 2,5 mm2
Cable gland clamping range: 3—6 mm
2 USB sockets, type Mini B
MC S -1- L C D MULTIFUNCTIONAL LOGIC
CONTROLLER

www.sentera.eu
MIW-MCS-1-LCD-EN-000-20/07/2016 7 - 33
back to the table of contents
OPERATIONAL DIAGRAMS
LINEAR FUNCTION
Tix/Aix,
[x]
A
ox, [%]
5 %
Linear
(Cool, Dry, Drain
0–100 %)
Max
Min
Off
level
Min
control
range
Max
control
range
A
ox, [%]
5 %
Tix/Aix,
[x]
Linear (Heat, Humidify, Obtain, 100–0 %)
Max
Min
Off
level
Min
control
range
Max
control
range
CONTROL FUNCTION
Tix/Aix,
[x]
A
ox, [%]
5 %
Controlled output Output (normal)
Output (high priority)
Max
Min
Off
level Min
control
range
Max
control
range
SP-
Hysteresis SP
PID CONTROL
t,[s]
SP
Tix/Aix,
[X]
PID control
(Cool, Dry, Drain 0–100 %)
t,[s]
Tix/Aix,
SP
[X]
PID control
(Heat, Humidify, Obtain, 100–0 %)
UNBALANCED LINEAR MODE UNBALANCED PID MODE
Tix/Aix,
[x]
A
ox, [%]
Ao2 output
with negative
unbalanced
coefficient
Ao2 output
with positive
unbalanced
coefficient
Ao1 output
Max
Min
Off
level Min control
range
Max
control
range
t, [s]
Ti
x/Aix,
SP
[X]
Negative unbalanced
coefficient
Positive unbalanced
coefficient
ANALOGUE OUTPUTS IN FUNCTION OF DIGITAL INPUTS
t, [s]
A
ox, [%]
0
Related value
Maximum
Active state
event
Inactive state
event
DIX remote Off
t,[s]
A
ox, [%]
0
Related value
Maximum
Active state
event
Inactive state
event
DIX maximum speed
MC S -1- L C D MULTIFUNCTIONAL LOGIC
CONTROLLER

www.sentera.eu
MIW-MCS-1-LCD-EN-000-20/07/2016 8 - 33
back to the table of contents
RELAY CONTACT FUNCTION ACTIVE STATE COM - > NO
Tix/Aix,
[x]
COMNO
Rcx,
[state]
COMNC
SP-
Hysteresis SP
TIX/AIX function
Active state
event
Inactive state
event
t, [s]
Rcx,
[state]
COMNO
COMNC
DIX function
RELAY CONTACT FUNCTION ACTIVE STATE COM -> NC
Tix/Ai
x,
[x]
COMNO
Rcx,
[state]
COMNC
SP-
Hysteresis
SP
TIX/AIX function
t,[s]
Active state
event
Inactive state
event
Rcx,
[state]
COMNO
COMNC
DIX function
MOUNTING INSTRUCTIONS IN STEPS
Before you start mounting your controller read carefully “Safety and
Precautions”. Choose a smooth surface for an installation location (a wall,
panel and etc.). Then proceed with the following mounting steps:
1. Switch off the power supply.
2. Unscrew the four screws on the front cover and open it carefully.
ATTENTION Make sure the flat cable, connecting the motherboard with the LCD printed circuit
board remains in place!
3. Insert the connecting cables through the cable glands of the unit.
4. Do the wiring according to the wiring diagram (see Fig. 1) using the information
from section “Wiring and connections”. Connect the controlled equipment and
the sensors (if necessary). Use cables with recommended length and type with
respect to your application. Mind the following recommendations:
►Use shielded cables for the analogue inputs / outputs in case the cable length
is between 4 and 12 m and voltage (VDC) mode is used.
►When the cable length exceeds 12 m, use the analogue inputs / outputs in
current (mA) mode.
Fig. 1 Wiring and connections
Power supply
Line
Neutral
Relay contact 1
Normally closed
Common
Normally open
Relay contact 2
Normally open
Common
Normally closed
PT 500 / PT1000 PT 500 / PT1000
Analogue inputs Digital inputs
Analogue outputs
Supply
output
Modbus
RTU
ATTENTION When you first use the unit make sure that the load corresponds to the default
output values. If the default values do not fit the load used, configure the unit
first, then connect the load. Improper load may cause damage to the controller.
MC S -1- L C D MULTIFUNCTIONAL LOGIC
CONTROLLER

www.sentera.eu
MIW-MCS-1-LCD-EN-000-20/07/2016 9 - 33
back to the table of contents
ATTENTION Do not mix the temperature ground (GND) with other ground (GND) terminals!
5. Customise the factory settings for the PWM outputs to the desired ones if you
are going to use a PWM output. By default the IPWM1 and IPWM2 jumpers (Fig.
2) are closed and the PWM outputs 1 and 2 are connected to an internal voltage
source of +12 VDC. See Fig. 3a Internally supplied PWM schematic. Remove
the jumpers (Fig. 2) if you need PWM open collector outputs. See Fig. 3b Open
collector schematics.
Fig. 2 PWM jumpers Fig. 3 PWM schematics
3a Internally supplied PWM schematic 3b Open collector schematic
PWM out
Control
100 Ω
4,7 kΩ
2,2 kΩ
+12 VDC
GND
BC 817
PWM out
Control
100 Ω
5 VDC ≤ +Vcc ≤ 24 VDC
REXT
REXT=Vcc
5 mA
4,7 kΩ
BC 817
GND
6. Check if your unit starts or terminates the network (see Example 1 and
Example2). If it does, connect the NBT resistor. Place the NBT jumper (Fig.4)
onto the pins. Otherwise leave it disconnected (default setting).
Example 1 Example 2 Fig. 4 Network bus
resistor jumper
Slave 1
RX
ТX
NBT
NBT
NBT
Slave 2
Master
Slave n
Slave 2
Slave 1
RX
ТX
NBT
NBT
Master
Slave n
7. Fix the rear lid of the enclosure on the wall/panel by the delivered dowels and
screws. Mind the correct mounting position and unit mounting dimensions.
(SeeFig. 5 Mounting dimensions and Fig.6Mounting position.)
MC S -1- L C D MULTIFUNCTIONAL LOGIC
CONTROLLER

www.sentera.eu
MIW-MCS-1-LCD-EN-000-20/07/2016 10 - 33
back to the table of contents
Fig. 5 Mounting dimensions Fig.6Mounting position
115
201
63
140
102
4x
4,50
Acceptable Not acceptable
8. Close the enclosure and fix the cover.
9. Switch on the power supply.
ATTENTION If an AC power supply is used with any of the units in a Modbus network the
GND terminal should NOT BE CONNECTED to other units on the network or
via the CNVT‑USB‑RS485 converter. is may cause permanent damage to the
communication semiconductors and / or the computer!
10. If necessary, customize the other factory settings to the desired ones. Use
3SModbus software, 3SMonitor software or the 4-button menu and LCD display
VERIFICATION OF THE CORRECT INSTALLATION
When you first switch on the power supply, the display will illuminate and show the
time and date, Temp. °C (the default operational mode) and the active working mode
(Run or Stand-by). If this is not the case, open the enclosure and check the status of
the power on green LED. See Fig. 7 Operating indication.
■If the LED is off, your unit is not supplied. Check the connections again.
■If the LED is on, but the LCD display is off, check the connection of the ribbon
(flat)cable.
Fig. 7 Operation indication
ATTENTION Be careful when you are handling with the ribbon cable. It must not touch the
power supply block. is will damage your unit. See Fig. 8.
MC S -1- L C D MULTIFUNCTIONAL LOGIC
CONTROLLER

www.sentera.eu
MIW-MCS-1-LCD-EN-000-20/07/2016 11 - 33
back to the table of contents
Fig. 8 MCS-1-LCD PCB
Ribbon cable
e ribbon cable must not touch
the power supply module.
Power supply module
Check the status of the both LEDs (LEDRX and LEDTX). See Fig. 9 Modbus
communication indication. If they blink your unit has detected a Modbus network. If
they do not, check the connections again.
Fig. 9 Modbus communication indication
MC S -1- L C D MULTIFUNCTIONAL LOGIC
CONTROLLER

www.sentera.eu
MIW-MCS-1-LCD-EN-000-20/07/2016 12 - 33
back to the table of contents
OPERATING INSTRUCTIONS
CONTROLLER OVERVIEW
T1
Ai1
T2
Ai2
Di1
Di3
Di2
Di4
REFERENCE:
CO2
Rel.humidity
Temp
AIR quality
Diff. pressure
TYPE :
0–10 VDC
2–10 VDC
0–20 mA
4–20 mA
PWM
SETPOINT
FIXED or
TIMESCHEDULE
RANGE
FIXED or
TIMESCHEDULE
ACTIVE STATE :
H IGH
L OW
Ao1 to
MAX
Ao1 to
OFF
Ao2 to
MAX
Ao2 to
OFF
RELAY
Control
PROBE TYPE:
PT500
PT1000
LINEAR
HEATING COOLING
HUMIDIFY DRY
OBTAIN DRAIN
CONTROL
PID
HUMIDIFY COOL
OBTAIN DRAIN
Ao1
0–10 VDC, 2-10 VDC
0–20 mA, 4-20 mA
PWM
Relay 1
Relay 2
Ao2
0–10 VDC, 2-10 VDC
0–20 mA, 4-20 mA
PWM
Free
(Independent to Ao1)
Unbalanced to Ao1
Balanced to Ao1
DIGITAL OVER RULE
FUNCTION
DI - FUNCTION
CONTROL FUNCTIONS OVERVIEW
e MCS-1-LCD controller features integrated analogue and relay outputs which can
be controlled either in one of the pre-configured modes or they can be personalised.
Its numerous different analogue, digital and temperature inputs ensure a large range
of functional control. You can choose the control function between:
LINEAR FUNCTION
Analogue outputs in linear function of the inputs
In cool mode the value of the analogue output rises linear in function of a higher
measured input value (according to the sensor(s) selected). is linear function goes
from the minimum to the maximum range of the assigned input and drops to 0 VDC
when off level is reached. e off level can be selected over the full sensor range.
In heat mode the value of the analogue output drops linear in function of a higher
measured input value.
MC S -1- L C D MULTIFUNCTIONAL LOGIC
CONTROLLER

www.sentera.eu
MIW-MCS-1-LCD-EN-000-20/07/2016 13 - 33
back to the table of contents
CONTROL FUNCTION
Analogue outputs in function of the normal priority and high priority inputs
e value of an analogue output in control mode follows a linear function of the
input with normal priority until the high priority assigned input reaches its setpoint.
e value then rises to the maximum value in the selected “time to maximum”
timespan. e output stays at maximum until the high priority input value reaches
SP – hysteresis, and then it drops following the linear function of the input with
normal priority.
PID CONTROL
During the PID control the analogue output changes to keep the assigned normal
input value at its selected setpoint level. e proportional gain (Kp), integration
period (Ti) and derivation period (Td) of the PID control are free configurable to set
the required slope, gain or magnitude.
e implemented autotune function calculates the parameters automatically
according to the system.
ANALOGUE OUTPUTS IN FUNCTION OF THE DIGITAL INPUTS
e analogue outputs can individually correspond to the state of the digital input.
When a digital input with remote off function becomes ‘active’, the related analogue
output drops to 0 and goes back to the current function value (Linear, Control or PID)
when it becomes ‘inactive’. When a digital input with ‘maximum output’ function
becomes ‘active’, the related analogue output rises to maximum and goes back to
the current function value (Linear, Control or PID) when it becomes ‘inactive’. All the
digital inputs have priority to all the other inputs (Ai1, Ai2, T1 and T2).
FREE
e second analogue output Ao2 is independent from the first analogue output Ao1.
BALANCED
e value of the second analogue output Ao2 follows the value of the first output Ao1.
UNBALANCED
In unbalanced mode the value of the second analogue output Ao2 follows the function
of the first output Ao1 according to the set offset values. See the operational
diagrams with positive and negative unbalanced (offset) coefficient.
RELAY CONTACT FUNCTION
Depending on the pre-selected active state of a relay, the relay contact switches
open or closed at the previously set setpoint of the assigned analogue or temperature
input, and switches back (closed or open) at the SP - hysteresis value.
In case there is an assigned digital input for relay switching, the relay contact
switches open or closed at the event of active state and switches back (closed or
open) when the state changes to inactive.
MC S -1- L C D MULTIFUNCTIONAL LOGIC
CONTROLLER

www.sentera.eu
MIW-MCS-1-LCD-EN-000-20/07/2016 14 - 33
back to the table of contents
PARAMETERS AND DEFAULT SETTINGS
GENERAL
Parameter Default value
Temperature input 1 and 2 (T1 & T2)Input state In use
Sensor range -30—70 °C
Control range 0—40 °C
Off level -10 °C
Setpoint 20 °C
Hysteresis 2 °C
Units Celsius
Calibration Stand-by
Analogue input 1 and 2 (Ai1 & Ai2)Input type Not in use
Sensor range 0—10,0 VDC
Measured quantity Relative humidity
Reference sensor range 20—80 % rH
Control range 20—80 % rH
Off level 20 % rH
Setpoint 50 % rH
Hysteresis 6 % rH
Free units Empty
Digital input 1, 2, 3 and 4 (Di1, Di2, Di3 & Di4)Function Not in use
Active state Low
Analogue output 1 and 2 (Ao1 & Ao2)Output type 0—10,0 VDC
Output function Linear
Output mode Cool
Minimum value 0 %
Maximum value 100 %
Time to maximum 60 s
Kp value 1,0 gain
Ti value 10 s
Td value 1 s
Autotune PID control Stand-by
Analogue output 1 (Ao1)Assigned normal input Temperature input 1 (T1)
Assigned high priority input Analogue input 2 (Ai2)
Analogue output 2 (Ao2)Assigned normal input Temperature input 2 (T2)
Assigned high priority input Analogue input 1 (Ai1)
Analogue output relation Free
Unbalance coefficient 0 %
Relay contacts 1 and 2 (Rc1 & Rc2)Assigned input(s) Not in use
Functionality Device functionality Temperature Cool
Passwords Installer password 0000
User password 0000
MC S -1- L C D MULTIFUNCTIONAL LOGIC
CONTROLLER

www.sentera.eu
MIW-MCS-1-LCD-EN-000-20/07/2016 15 - 33
back to the table of contents
Parameter Default value
Scheduling Scheduled number of run periods 1
Scheduled run period 1 duration 8:30 - 17:00
Scheduled run period 2 duration --:-- - --:--
Scheduled run period 3 duration --:-- - --:--
Scheduled run period 4 duration --:-- - --:--
Scheduled run period 1 days of week Monday, Tuesday, Wednesday, ursday, Friday
Scheduled standby period 1 duration dd mmm yyyy - dd mmm yyyy
Scheduled standby period 2 duration dd mmm yyyy - dd mmm yyyy
Scheduled standby period 3 duration dd mmm yyyy - dd mmm yyyy
Scheduled standby period 4 duration dd mmm yyyy - dd mmm yyyy
CONFIGURING THE PARAMETERS
e default parameters can be modified by using either one of predefined user-
friendly templates or by customising them freely.
ATTENTION e mode selector (Fig. 10)should always be in run mode except for firmware
updates.
Fig. 10 Mode selector
IPWM1IPWM2
LEDRX
LEDTX
NBT
LNNC1COM1NO1
NO2
T1
GND
T2
Ai1
GND
Ai2
Di1 Di2 Di3 Di4
Ao1
GND
Ao2
GND
+24 VDC
/B
A
COM2 NC2
BOOT
MODE J4
RUN
NOTE e USB interface allows LCD display and control board firmware updates. To
update contact the technical support.
MC S -1- L C D MULTIFUNCTIONAL LOGIC
CONTROLLER

www.sentera.eu
MIW-MCS-1-LCD-EN-000-20/07/2016 16 - 33
back to the table of contents
USING PREDEFINED TEMPLATES
See table Table below to know about the available templates that pre-define the
device functionality.
Device functionality
Parameters
Predefined templates
Free
Temperature
cool
Temperature
heat
Relative
humidity
CO2Air quality Differential
pressure
Temperature
and CO2
Differential
pressure and
temperature
Control range (T1) 0—40°C 0—40°C N/A N/A N/A N/A 0—40°C 0—40°C 0—40°C
Off level (T1) -10°C 40°C N/A N/A N/A N/A -10°C -10°C -10°C
Setpoint (T1) N/A N/A N/A N/A N/A N/A N/A 20°C N/A
Control range (T2) 0—40°C 0—40°C N/A N/A N/A N/A N/A N/A 0—40°C
Off level (T2) 0°C 40°C N/A N/A N/A N/A N/A N/A -10°C
Setpoint (T2) N/A N/A N/A N/A N/A N/A N/A N/A N/A
Control range (Ail) N/A N/A 20—80 % rH 0—2.000 ppm 0—2.000 ppm 0—2.000 Pa 0—2.000 ppm 0—2.000 Pa 0—10.000
units
Off level (Ail) N/A N/A 20 % rH 0 ppm 0 ppm 0 Pa 0 ppm 0 Pa N/A
Setpoint (Ail) N/A N/A N/A N/A N/A N/A 1000 ppm N/A 5.000 units
Control range
(Ai2)
N/A N/A N/A N/A N/A N/A N/A N/A 0—10.000
units
Off level (Ai2) N/A N/A N/A N/A N/A N/A N/A N/A N/A
Setpoint (Ai2) N/A N/A N/A N/A N/A N/A N/A N/A 5.000 units
Analog output
function (Aol)
Linear Linear Linear Linear Linear Linear Controlled Controlled Controlled
Analog output
mode (Aol)
Cool Heat 0—10 VDC 0—10 VDC 0—10 VDC 10—0 VDC N/A N/A N/A
Assigned normal
input (Aol)
T1 T1 Ai1 Ai1 Ai1 Ai1 T1 Ai1 T1
Assigned high
priority input (Aol)
N/A N/A N/A N/A N/A N/A Ai1 T1 Ai1
Analog output
function (Ao2)
Linear Linear N/A N/A N/A N/A Linear Linear Controlled
Analog output
mode (Ao2)
Cool Heat N/A N/A N/A N/A 0—10 VDC Cool N/A
Assigned normal
input (Ao2)
T2 T2 N/A N/A N/A N/A Ai1 T1 T2
Assigned high
priority input
(Ao2)
N/A N/A N/A N/A N/A N/A N/A N/A Ai2
MC S -1- L C D MULTIFUNCTIONAL LOGIC
CONTROLLER

www.sentera.eu
MIW-MCS-1-LCD-EN-000-20/07/2016 17 - 33
back to the table of contents
CUSTOMISING THE SETTINGS
ere are 3 possible ways to customize the default parameters:
■using 3SMonitor software
■using 3SModbus software, and
■with the help of the 4-buton interface
3SMONITOR SOFTWARE
3SMonitor application is a free Sentera software. You can download it from our
website at http://www.senteracontrols.com/3smodbus/Setup3SM.msi
Before you download it, make the connections carefully. Connect a USB cable
between connector J1 (Fig. 11) and the computer USB port.
Fig. 11 USB connector J1
ATTENTION e USB connector J4 shown in Fig. 12 is for firmware updates only.
Fig. 12 USB connector J4
MC S -1- L C D MULTIFUNCTIONAL LOGIC
CONTROLLER

www.sentera.eu
MIW-MCS-1-LCD-EN-000-20/07/2016 18 - 33
back to the table of contents
When you run the 3SMonitor application, the home screen shown in Fig. 13 will
appear on your screen. Installer access level provides full control over the device
inputs and outputs configuration, time schedule and firmware update. e user
access level provides only monitoring, scheduling and setting time and date. If you
log in as Installer, you can choose between setup wizard and monitoring (Fig. 14).
Fig. 13 3SMonitor home screen
NOTE e password box is not available when password is removed.
Fig. 14 Wizard / Monitoring screen
For further information about parameter configuring refer to the chapter “Main
menu structure”.
3SMODBUS SOFTWARE
3SModbus is a free application for Windows. You can download it from our website
at http://www.senteracontrols.com/3smodbus/3smodbus.exe
MC S -1- L C D MULTIFUNCTIONAL LOGIC
CONTROLLER

www.sentera.eu
MIW-MCS-1-LCD-EN-000-20/07/2016 19 - 33
back to the table of contents
Before you download it, make the connections carefully. Connect A and /B terminals
with A and /B of a CNVT-USB-RS485 converter (Fig. 15).
Fig. 15 CNVT-USB-RS485 converter
ATTENTION Do NOT connect the GND signal of the CNVT‑USB‑RS485 converter! (See section
“Wiring and Connections”.) is may damage the computer’s USB port.
When you run the 3SModbus application, the home screen shown in Fig. 16 will
appear on your screen.
Fig. 16 3SMоdbus home screen
For parameter settings refer to Chapter “Modbus register maps”.
4-BUTON KEYBOARD INTERFACE
Fig. 17 LCD display home screen
To configure the MCS-1-LCD, use the 4-button interface and LCD display following
the menu structure. (See chapter “Main menu structure”.). For the parameter
default values, please refer to “Modbus register maps” chapter.
MC S -1- L C D MULTIFUNCTIONAL LOGIC
CONTROLLER

www.sentera.eu
MIW-MCS-1-LCD-EN-000-20/07/2016 20 - 33
back to the table of contents
MAIN MENU STRUCTURE
NOTE To configure the MCS‑1‑LCD using the 4‑button interface and LCD display, you can
follow the next menu structure. e possible parameter values and their default
values can be found in the table “Modbus register maps”.
e framed menu is only available
if logged in as installer
6
7
8
9
User
1
Home screen
Schedule
installer settings
Temperature
inputs screen
Output screen
Reset installer
password
Remove installer
password
Device
functionality
Analogue inputs
Digital inputs
Analogue outputs
Relay contacts
Change installer
password
Analogue inputs
screen
Digital inputs
screen
installer password
options
Bootloader
Time and date
setup
Reset user
password
Remove user
password
Run periods
Run days
Standby periods
Run periods
parameters
Clear schedule
User password
options
Change user
password
User or installer
password prompt
Installer command
prompt
User or installer
password prompt
Reset to default
2
1
3
4
5
MC S -1- L C D MULTIFUNCTIONAL LOGIC
CONTROLLER
