Sentiotec KASKI 220 PANORAMA User manual

EN
DE
FR
IT
NL
KASKI-220-P
Version 01/23 item no. 1-053-432
ASSEMBLY INSTRUCTIONS
English
Barrel sauna
KASKI 220
PANORAMA
Ø 220 ×220 cm

Table of Contents
1. Preparing for installation 3
1.1. Important note 3
1.2. Foundation 4
1.3. Anchoring the outdoor sauna 4
1.4. Tools required 4
1.5. Maintenance and cleaning 6
1.6. Disposal 6
2. Assembling the cabin 7
2.1. Mounting the feet 7
2.2. Assembling the barrel staves 7
2.3. Assembling the front and rear wall 7
2.4. Completing the barrel 7
2.5. Mounting the door 8
2.6. Installinginteriorttings 8
2.7. Installing accessories 8
2.8. Covering the roof 8
Dimensional drawing (following the last language of the instructions) 9
Floor plan (following the last language of the instructions) 10
Parts list (following the last language of the instructions) 11
Assembly illustrations (following the last language of the instructions) 12

EN
Assembly instructions p. 3/8
1. Preparing for installation
Read these assembly instructions carefully and keep them within reach. so that
you can look up product information at any time.
1.1. Important note
●Checkwithyourlocalplanningauthority(municipalo󰀩ce,magistrate)with
respect to the building regulations and load standards.
●A solid foundation is important for the durability as well as the safety of your
outdoor sauna. We recommend having the foundation laid by a specialist.
●The anchoring of the outdoor sauna is the responsibility of the customer. No
warranty in the event of damage.
●The outdoor sauna is delivered by lorry (also possible by semi-trailer truck).
Access to the unloading area must be ensured.
●Beforeyoubeginwork,checkthepartslisttoensurethatalltheindividual
partshavebeendelivered.Ifyoudiscoveranymissingparts,notifyyour
dealer within 14 days of receiving the sauna cabin.
● Keepthedeliverynote,theinvoiceandtheassemblyinstructionsinasafe
place in case of any questions.
●You need manual skills and an assistant for the installation.
● Allscrewttingsmustbepre-drilled.
Attention!
Theelectricalconnectionmayonlybeperformedbyaqualied
electricianorsimilarlyqualiedperson.
●We recommend installing the bitumen shingles included in the scope of
delivery promptly after completion of the barrel sauna.
● Woodisanaturalproductthatcanswell,shrinkorwarp,despitegoodstor-
age.Forthisreason,someforcemaybenecessaryduringtheinstallation.
●Thewoodoftheoutdoorsaunaisuntreated.Toincreasethelifeexpectancy,
we recommend painting the outside with a suitable paint to protect the wood.
●The inside of the wooden parts used must not be treated with any paint.
These assembly instructions can also be found in the downloads section
of our website: www.sentiotec.com/downloads.

Assembly instructions p. 4/8
1.2. Foundation
The following foundation elements have proven themselves in practice:
• Foundation slab (base plate)
• Strip foundation
Forbothtypes,afoundationthatisabsolutelyatandload-bearingmustbe
ensured. Only then can the assembly of the outdoor sauna be ensured without
anydi󰀩cultiesandwithapreciset.
1.3. Anchoring the outdoor sauna
Theoutdoorsaunamustbermlyanchoredonthebaseplateorthestrip
foundation. Strong winds can exert a powerful force on the garden sauna. To
preventdamagetoyour,orthirdparty,propertyproperanchoringisessential.
We point out that anchoring the garden sauna is the responsibility of the
customer and we do not accept any liability for accidental damage.
1.4. Tools required
●Hammer with a wooden block and a mallet
●Cordless screwdriver with bits for cross-head screws and Torx
●Roller tape measure
● Drillbitswithadiameterof4mm,5mm,6mm,20–30mm
(for sauna heater power cable)
●Spirit level
●Open-ended spanner
●Utility knife
●Ladder
●Saw

EN
Assembly instructions p. 5/8
60 cm
80 cm
100 cm
This symbol indicates tips and useful information
Pre-drill
Cut to correct size
Nailing
Carry out wiring
Check the right angle:
Handle glass with care: Special care must be taken with the edges of
the glass—hardened glass can shatter into small pieces in the event of
impact. Insert protective cushioning (e.g: cardboard box) under the edge
of the glass.
