Sentiotec Concept R CP-RC-AF User manual

Version 05/15 ID no. M100-000-219
EN
INSTRUCTIONS FOR INSTALLATION AND USE
English
Concept R
AUTO REFILL SET
CP-RC-AF

WORLD OF WELLNESS
Table of Contents
1. About this instruction manual 3
2. Important information for your safety 4
2.1. Intended use 4
2.2. Safetyinformationfortheinstaller 4
3. Product description 5
3.1. Scopeofdelivery 5
3.2. Product functions 5
4. Installation and connection to sauna heater
Concept R combi 6
4.1. Preparing the sauna heater 6
4.2. Installingtheauto-rellunit 7
5. Installation and connection to auxiliary evaporator
Concept R 8
5.1. Preparationoftheauxiliaryevaporator 8
5.2. Installingtheauto-rellunit 9
6. Connecting the water inlet pipe 10
7. Function test 10
8. Troubleshooting 10
9. Cleaning and maintenance 11
10. Disposal 11
11. Technical data 12

WORLD OF WELLNESS
EN
Instructionsforinstallationanduse p.3/12
1. About this instruction manual
Carefullyreadtheseinstructionsforinstallationanduse,andkeepthemnear
the sauna. This ensures that you can refer to information regarding the function
andinstallationatanytime.
Symbols used for warnings
Theseinstallationandoperatinginstructionsfeaturewarningsymbolsnextto
activitiespresentingahazardtotheuser.Warningsymbolsmustbeobserved
atalltimes.Thispreventsdamagetopropertyandinjuries,whichintheworst
casemaybefatal.
Thewarningsymbolscontainkeywordswiththefollowingmeanings:
DANGER!
Seriousorfatalinjurywilloccurifthiswarningsymbolisnotobserved.
WARNING!
Seriousorfatalinjurymayoccurifthiswarningsymbolisnotobserved.
CAUTION!
Minorinjuriesmayoccurifthiswarningsymbolisnotobserved.
ATTENTION!
This keyword is a warning that damage to property may occur.
Other symbols
Thissymbolindicatestipsandusefulinformation.
Theseinstallationandoperatinginstructionscanalsobefoundinthe
downloadssectionofourwebsite:www.sentiotec.com.

WORLD OF WELLNESS
Instructionsforinstallationanduse p.4/12
2. Important information for your safety
TheCP-RC-AFauto-rellsethasbeenmanufacturedinaccordance
withtheapplicablesafetyregulationsfortechnicalunits.However,
hazardsmayoccurduringuse.Youshouldthereforeadhereto
thefollowingsafetyinformationandthespecicwarningsinthe
individualchapters.
2.1. Intended use
TheCP-RC-AFauto-rellsetenablestheevaporatortankinthe
ConceptRcombisaunaheaterortheConceptRauxiliaryevapo-
ratortobeautomaticallyrelled.TheCP-RC-AFauto-rellsetis
suitableforthefollowingmodels:
● CP-RC-090
● CP-RC-105
● CP-25-STP
Anyuseexceedingthisscopeisconsideredimproper.Improper
usecanresultindamagetotheproduct,severeinjuriesordeath.
2.2. Safety information for the installer
●Thexedwaterconnectionshouldbeinstalledonlybyaqualied
installeroracomparablyqualiedpersonaccordingtothelocal
provisionsoftheresponsiblewatercompany.
●The provisions of EN 61770 and EN 1717 must be observed.
Appropriate measures must be taken to ensure that water cannot
owbackintothedrinkingwatersystem.
● Ashut-offvalvemustbettedbetweenthexednetworkandthe
auto-rellset.Incaseofextendedperiodsofnon-useofthexed
waterconnection,theshut-offvalveshouldbeclosed.

WORLD OF WELLNESS
EN
Instructionsforinstallationanduse p.5/12
3. Product description
3.1. Scope of delivery
● Auto-rellunitwithwaterconnectionpipes
●Mounting screws
● Sealingring
● Instructionsforinstallationanduse
3.2. Product functions
Theauto-rellsetworksbasedontheprincipleofllinglevelmeas-
urement.Ifthelevelofthewaterintheevaporatortankdrops,the
oatlosesbuoyancyandthereforeopensthewatervalveonthe
auto-rellunit.Thisvalveensuresthatfreshwaterowsintothe
evaporatortankuntiltheoatrisesandmakesthewatervalve
closeagain.
●Observetheminimumandmaximumsupplywaterpressurespeci-
edinthetechnicaldata(see11. Technical data on page 12).
● Adrainmustbelocatedatthebottomofthesaunaroomincase
thewaterlineisdamagedorbeginstoleak.
●Fortheconnection,onlyusethehosesetincludedoroneobtained
fromcustomerservice.Undernocircumstancesshouldyouuse
existingorpreviouslyusedhosesets.
● Foryourownsafety,consultyoursupplierintheeventofprob-
lemsthatarenotexplainedinsufcientdetailintheinstallation
instructions.

WORLD OF WELLNESS
Installationinstructions,onlyforexperts p.6/12
4. Installation and connection to sauna heater
Concept R combi
Pleasetakethefollowingpointsintoaccountwheninstallingandconnectingthe
auto-rellunit:
●Workshouldonlybeperformedonthesaunaheateronceithascooleddown.
4.1. Preparing the sauna heater
●Makesurethatthesaunaheaterhascompletelycooleddownandremove
theceramicbowlforherbsandaromas
1.
● Removethesteamfunnel2 locatedundertheevaporatortank.
●Remove the strut 3withasuitablescrewdriver.
WARNING!
Risk of electric shock
●Thesaunaheatermayonlybeinstalledandconnectedwhenthe
powersupplyisdisconnected.
1
2
3

WORLD OF WELLNESS
EN
Installationinstructions,onlyforexperts p.7/12
4.2. Installing the auto-rell unit
1. Feedthewaterinletpipe3 throughtheinstallationopeningnexttothe
evaporatoruntiltheballvalveisvisibleatthebottom.
2. Removethesealingcapoftheevaporatortankconnection6.
3. Placetheatseal4 intotheunionnutontheevaporatortankinletpipe5.
4. Connecttheevaporatortankinletpipe5 to the evaporator tank connec-
tion 6.
5. Placetheauto-rellunit7intotheinstallationpositionintended.
6. Screwontheauto-rellunitinfourplacesusingthescrewsprovided.
3
4
5
7
6

WORLD OF WELLNESS
Installationinstructions,onlyforexperts p.8/12
5. Installation and connection to auxiliary evaporator
Concept R
Pleasetakethefollowingpointsintoaccountwheninstallingandconnectingthe
auto-rellunit:
●Workshouldonlybeperformedontheauxiliaryevaporatoronceithascooled
down.
5.1. Preparation of the auxiliary evaporator
●Makesurethattheauxiliaryevaporatorhascompletelycooleddownand
removetheceramicbowlforherbsandaromas
1.
● Removethesteamfunnel2 locatedundertheevaporatortank.
●Remove the strut 3withasuitablescrewdriver.
1
2
WARNING!
Risk of electric shock
●Theauxiliaryevaporatormayonlybeinstalledandconnectedwhen
thepowersupplyisdisconnected.
3

WORLD OF WELLNESS
EN
Installationinstructions,onlyforexperts p.9/12
5.2. Installing the auto-rell unit
1. Feedthewaterinletpipe3 throughtheinstallationopeningnexttothe
evaporatoruntiltheballvalveisvisibleatthebottom.
2. Removethesealingcapoftheevaporatortankconnection6.
3. Placetheatseal4 intotheunionnutontheevaporatortankinletpipe5.
4. Connecttheevaporatortankinletpipe5 to the evaporator tank connec-
tion 6.
5. Placetheauto-rellunit7intotheinstallationpositionintended.
6. Screwontheauto-rellunitinfourplacesusingthescrewsprovided.
7
5
4
6
3

WORLD OF WELLNESS
Installationinstructions,onlyforexperts p.10/12
6. Connecting the water inlet pipe
●Connecttheon-sitexedwaterconnectiontotheballvalveonthewater
inletpipe3.
►Observe the information regarding water pressure when doing so
(see11. Technical data on page 12)
► Ashut-offvalvemustbemountedbetweenthexednetworkandthexed
waterconnection,anditshouldbeclosedwhennotinuse.
7. Function test
1. Turnontheon-sitewaterinletpipefully.
2. Opentheballvalveofthewaterinletpipefully.
► Theevaporatortankllsupwithwater.
►Oncethemaximummarkisreached,theevaporatortankstopslling
upautomatically.
3. Start the evaporator.
►Whenthewaterlevelintheevaporatortankdrops,theauto-rellunitlls
itupwithwaterautomatically.
8. Troubleshooting
Iftheevaporatortankdoesnotllupautomatically,checkthewaterpressureofthe
on-sitexedwaterconnectionandthattheoatmovesfreelyintheauto-rellunit.
► Iftheoatdoesnotmovefreely,checkforanyobstructionsordirt.
► Iftheproblempersists,consultyourcustomerservicespecialist.

WORLD OF WELLNESS
EN
Instructionsforinstallationanduse p.11/12
10. Disposal
●Disposeofpackagingmaterialsinaccordancewiththeapplicable
disposalregulations.
●Useddevicescontainreusablematerials,aswellashazardous
substances.Donotdisposeofyouruseddevicewithhousehold
waste,butdosoinaccordancewiththelocallyapplicableregula-
tions.
9. Cleaning and maintenance
Theauto-rellsetismaintenance-free.

WORLD OF WELLNESS
Instructionsforinstallationanduse p.12/12
11. Technical data
General information
Capacity:     Approx.1.5litres
Material:     Stainlesssteelsheet
Water connection
Minimumwatersupplypressure:  30kPa(0.3bar)
Maximumwatersupplypressure:  600kPa(6bar)
Ifpressureisover600kPa(6bar):
► Pressurelimiter(standardregulator)mountedbetweenthexed
waterconnectionandtheauto-rellunit.
Fixedwaterconnection:   1/2"(1.27cm)  
Tank dimensions
Length: 135 mm
Width: 135 mm
Depth: 255 mm
Length of connection lines
Waterinletpipe:    1000mm
Evaporatorcable:    500mm

sentiotec GmbH world of wellness Oberregauer Straße 48 4844 Regau, Austria
T+43(0)7672/27720-800F+43(0)7672/27720-801
E[email protected]www.sentiotec.com
