1General information
Addendum to the Operating Instructions – CMP.. Servomotors with MOVILINK® DDI Interface
4
1 General information
INFORMATION
The differences between the motors with the MOVILINK®DDI interface and the stan-
dard CMP.. motors are described in this document.
This document applies as a supplement to the "Synchronous servomotors CMP40–
 CMP112, CMPZ71 – CMPZ100" operating instructions. The operating instructions
are still valid.
26877090/EN – 03/2022

2
Motor structure
Basic structure
Addendum to the Operating Instructions – CMP.. Servomotors with MOVILINK® DDI Interface 5
2 Motor structure
2.1 Basic structure
The following figure shows an example of a CMP.. servomotor with
MOVILINK® DDI interface:
[1]
29017423115
[1] Hybrid plug connector
26877090/EN – 03/2022

2Motor structure
Motor nameplates
Addendum to the Operating Instructions – CMP.. Servomotors with MOVILINK® DDI Interface
6
2.2 Motor nameplates
The following graphics show the nameplates of a CMP.. servomotor with the
MOVILINK® DDI interface as an example:
[1]
[2]
CMP50S/DI/PK/AZ4Z/SD1
01.123456789.0001.21
Mo 1.3 Nm
Mpk 5.2 Nm
Io 1.32 A
Imax 7 A
Usys 400 V
IM B5
IP 65
kg 2.213
Th.Kl. (F)
TENV
VTnC 0-4500 r/min
n max 4500 r/min
Up 281 V
Ta -20..40 °C
3~IEC60034 22935908 Made in Germany
DI0E00
Jahr2021
9007232620639243
[1] MOVILINK®DDI interface
[2] Type designation
CMP50S/DI/PK/AZ4Z/SD1
01.123456789.0001.21
nur Umrichterbetrieb 22936149
9007232620646411
26877090/EN – 03/2022

2
Motor structure
Type designation example
Addendum to the Operating Instructions – CMP.. Servomotors with MOVILINK® DDI Interface 7
2.3 Type designation example
The following table shows the example of a type designation:
Example: CMP50S/BK/DI/PK/AZ4Z/SD1
Synchronous servomotor CMP50 Flange-mounted motor size 50
Length S Short
Mechanical attachments /BK BK holding brake
Motor option digital interface /DI MOVILINK® DDI
Standard equipment temperature
sensor
/PK PK temperature sensor
Encoder motor option /AZ4Z Multi-turn absolute encoder
Connection motor option /SD1 SD1 hybrid connector
2.4 Type code for MOVILINK®DDI interface identification
Type code
for
MOVILINK®
DDI
interface
identificatio
n
The following diagram shows the structure of the MOVILINK®DDI interface identifica-
tion:
DI0C00
DI DI = MOVILINK®DDI
0 0 = No brake control via MOVILINK®DDI1)
1 = Brake control BS1Z via MOVILINK® DDI
2 = Brake control BG1Z via MOVILINK® DDI2)
C C = Extended electronic nameplate and temperature detection (mo-
tor, inverter)
E = Extended electronic nameplate, temperature detection of motor
and encoder data acquisition (motor, inverter)
00 Reserved
1) If a "0" (DI0..) has been selected in the 3rd digit of the DI type code, the motor may be combined with a
MOVIMOT® flexible decentralized inverter. In the case of a MOVIDRIVE® or MOVITRAC® control cabinet
inverter, an external brake rectifier must be used.
2) If a "2" (DI2..) has been selected in the 3rd digit of the DI type code, the motor may not be combined with
a MOVIMOT® flexible decentralized inverter. In the case of a MOVIDRIVE® or MOVITRAC® control cab-
inet inverter, an external brake rectifier may not be used.
26877090/EN – 03/2022

3Designs and options
Synchronous servomotors
Addendum to the Operating Instructions – CMP.. Servomotors with MOVILINK® DDI Interface
8
3 Designs and options
3.1 Synchronous servomotors
Designation
CMP.. Flange-mounted motor size 50 / 63 / 71 / 80 / 100
3.2 Mechanical attachments
Designation Option
/BK Permanent magnet brake for CMP50 – 63
/BP Holding brake for CMP71–100
3.3 Temperature sensor/temperature detection
Designation Option
/PK PT1000 temperature sensor
3.4 Encoders
Designation Option
– No encoder, (CMP50–100)
/EZ2Z Single-Turn encoder, MOVILINK® DDI, (CMP50–100)
/EZ4Z Single-Turn encoder, MOVILINK® DDI, high resolution,
(CMP50–63)
/AZ2Z Multi-Turn encoder, MOVILINK® DDI, (CMP50–100)
/AZ4Z Multi-Turn encoder, MOVILINK® DDI, high resolution,
(CMP50–63)
3.5 Connection options
Designation Description
/SD1 Motor connector, M23, only plug socket at the motor side, hy-
brid connector for motor, brake and communication
MOVILINK® DDI, (CMP50–100)
/SDB Motor connector, M40, only plug socket at the motor side, hy-
brid connector for motor, brake and communication
MOVILINK® DDI, (CMP50–100)
26877090/EN – 03/2022

3
Designs and options
Connection options
Addendum to the Operating Instructions – CMP.. Servomotors with MOVILINK® DDI Interface 9
Designation Description
/KD Terminal box for CMP50 –100, hybrid cable for motor, brake
and encoder MOVILINK® DDI clampable,
(CMP50–100)
/KDD Terminal box for CMP80 – 100 with AZ2Z/EZ2Z/without en-
coder, clampable power connection, encoder connector, M23,
MOVILINK® DDI pluggable
/SMCD Motor power connector, M58; encoder connector
MOVILINK® DDI, M23, (CMP100 with AZ2Z/EZ2Z/without en-
coder)
/SBCD Brakemotor power connector, M58; encoder connector
MOVILINK® DDI, M23, (CMP100 with AZ2Z/EZ2Z/without en-
coder)
26877090/EN – 03/2022

4Electrical installation
Information on connector connection
Addendum to the Operating Instructions – CMP.. Servomotors with MOVILINK® DDI Interface
10
4 Electrical installation
4.1 Information on connector connection
With SD1 and SDB, the cable is introduced via an adjustable right-angle connector.
SEW‑EURODRIVE recommends aligning the right-angle connector with the mating
connector plugged in.
NOTICE
Damage to the right-angle connector can occur in case of rotation without mating
connector.
Damage to the plug connector and the sealing surface can occur.
• Adjust the right-angle connector only while the mating connector is plugged in.
• If you do not have a mating connector at hand, do NOT use pliers to adjust the
right-angle connector.
NOTICE
Potential damage to the right-angle connector.
Possible damage to property.
• Do not align the right-angle connector frequently.
INFORMATION
• Comply with the permitted bending radii of the cables.
• When using low-capacity trailing cables, the bending radii are larger than for the
previously used standard cables.
• SEW‑EURODRIVE recommends the use of low-capacity cables.
• Use cables with a permitted continuous operating temperature of minimum 80°C.
INFORMATION
The connector should only be rotated to install and connect the motor. Do not turn
the plug connector regularly once it has been installed.
26877090/EN – 03/2022

4
Electrical installation
Information on connector connection
Addendum to the Operating Instructions – CMP.. Servomotors with MOVILINK® DDI Interface 11
INFORMATION
To protect the motor protection devices or the brake control from damage, you must
not route unshielded supply cables alongside switched-mode power cables.
Shielded supply cables may be routed together with switched-mode power lines in
one cable.
Switched-mode power cables are:
• Output cables from servo inverters, converters, and brake units
• Supply cables for braking resistors and similar options
4.1.1 SD1/SDB connector locations
The right-angle plug connector can be rotated horizontally to achieve the required po-
sition. The following figure illustrates an example of various plug connector align-
ments:
9007231550278027
26877090/EN – 03/2022

4Electrical installation
Connection with plug connectors
Addendum to the Operating Instructions – CMP.. Servomotors with MOVILINK® DDI Interface
12
4.2 Connection with plug connectors
The cable entry of the power and signal cables is installed using plug connectors.
Comply with the permitted bending radii of the cables.
Pay attention to the combinatorics of the brake control options in chapter "Technical
data"(→247).
4.2.1 Connecting SD1 hybrid plug connectors (M23)
The wiring diagram of the plug connector depicts the contact end of the connections.
Assignment for motor without brake
Function
Motor connection for motors with MOVILINK® DDI interface
Connection type
M23, male, male thread, TE Connectivity – Intercontec Products, series 723, SEW-
EURODRIVE insert, SpeedTec equipment, coding ring: without, protected against
contact
Connection diagram
V
D
WPE
C
U
DDI
A
B
Contact Signal Description
U U Motor connection phase U
V V Motor connection phase V
W W Motor connection phase W
A Reserved Do not connect
B Reserved Do not connect
C Reserved Do not connect
D Reserved Do not connect
PE PE PE connection
DDI DDI MOVILINK® DDI
Assignment for brakemotors with BK../BP.. brake
Function
Motor connection for motors with MOVILINK® DDI interface
26877090/EN – 03/2022

4
Electrical installation
Connection with plug connectors
Addendum to the Operating Instructions – CMP.. Servomotors with MOVILINK® DDI Interface 13
Connection type
M23, male, male thread, TE Connectivity – Intercontec Products, series 723, SEW-
EURODRIVE insert, SpeedTec equipment, coding ring: without, protected against
contact
Connection diagram
V
D
WPE
C
U
DDI
A
B
Contact Signal Description
U U Motor connection phase U
V V Motor connection phase V
W W Motor connection phase W
A Brake - Brake connection -
B Reserved Do not connect
C Reserved Do not connect
D Brake + Brake connection +
PE PE PE connection
DDI DDI MOVILINK® DDI
Assignment for CMP50/63 brakemotors with BK.. brake with BS1Z brake control
in the motor
Function
Motor connection for motors with MOVILINK® DDI interface
Connection type
M23, male, male thread, TE Connectivity – Intercontec Products, series 723, SEW-
EURODRIVE insert, SpeedTec equipment, coding ring: without, protected against
contact
26877090/EN – 03/2022

4Electrical installation
Connection with plug connectors
Addendum to the Operating Instructions – CMP.. Servomotors with MOVILINK® DDI Interface
14
Connection diagram
V
D
WPE
C
U
DDI
A
B
No. Name Function
U U Motor connection phase U
V V Motor connection phase V
W W Motor connection phase W
A GND GND connection
B 24V 24V DC connection
C Reserved Do not connect
D Reserved Do not connect
PE PE PE connection
1 DDI MOVILINK® DDI
26877090/EN – 03/2022

4
Electrical installation
Connection with plug connectors
Addendum to the Operating Instructions – CMP.. Servomotors with MOVILINK® DDI Interface 15
4.2.2 Connecting SDB hybrid plug connectors (M40)
The wiring diagram of the plug connector depicts the contact end of the connections.
Assignment for motor without brake
Function
Motor connection for motors with digital interface (MOVILINK® DDI)
Connection type
M40, male, male thread, TE Connectivity – Intercontec Products, series 740, SEW-
EURODRIVE insert, SpeedTec equipment, coding ring: without, protected against
contact
Connection diagram
2
U
PE
N
V
DDI
+
1-
W
Contact Signal Description
U U Motor connection phase U
V V Motor connection phase V
W W Motor connection phase W
1 Reserved Do not connect
+ Reserved Do not connect
- Reserved Do not connect
2 Reserved Do not connect
N Reserved Do not connect
PE PE PE connection
DDI DDI MOVILINK® DDI
Assignment for brakemotor with BK../BP.. brake
Function
Motor connection for motors with digital interface (MOVILINK® DDI)
Connection type
M40, male, male thread, TE Connectivity – Intercontec Products, series 740, SEW-
EURODRIVE insert, SpeedTec equipment, coding ring: without, protected against
contact
26877090/EN – 03/2022

4Electrical installation
Connection with plug connectors
Addendum to the Operating Instructions – CMP.. Servomotors with MOVILINK® DDI Interface
16
Connection diagram
2
U
PE
N
V
DDI
+
1-
W
Contact Signal Description
U U Motor connection phase U
V V Motor connection phase V
W W Motor connection phase W
1 Brake - Brake connection -
+ Reserved Do not connect
- Reserved Do not connect
2 Brake + Brake connection +
N Reserved Do not connect
PE PE PE connection
DDI DDI MOVILINK® DDI
26877090/EN – 03/2022

4
Electrical installation
Connection with plug connectors
Addendum to the Operating Instructions – CMP.. Servomotors with MOVILINK® DDI Interface 17
4.2.3 Connecting SMCD/SBCD/KDD hybrid plug connectors
The wiring diagram of the plug connector depicts the contact end of the connections.
Assignment for motor with/without brake
Function
Motor connection for motors with MOVILINK® DDI interface
Connection type
M23, male, male thread, TE Connectivity – Intercontec Products, series 723, SEW-
EURODRIVE insert, SpeedTec equipment, coding ring: without, protected against
contact
Connection diagram
DDI
Contact Signal Description
DDI DDI MOVILINK® DDI
26877090/EN – 03/2022

4Electrical installation
Connection with plug connectors
Addendum to the Operating Instructions – CMP.. Servomotors with MOVILINK® DDI Interface
18
4.2.4 Connecting SMCD/SBCD power plug connectors with/without brake
The following table shows information about this connection:
The wiring diagram of the plug connector depicts the contact end of the connections.
Function
Power connection
Connection type
M58, TE Connectivity – Intercontec Products, series 958, SEW-EURODRIVE insert,
coding ring: without, male
Connection diagram
+
1
-
2
PE
W
V
U
Assignment for motor without brake
Contact Signal Description
+ Reserved Do not connect
- Reserved Do not connect
1 Reserved Do not connect
2 Reserved Do not connect
PE PE PE connection
U U Motor connection phase U
V W Motor connection phase W
W V Motor connection phase V
Assignment for brakemotor with BK../BP.. brake
Contact Signal Description
+ Brake + Brake +
- Brake - Brake -
1 Reserved Do not connect
2 Reserved Do not connect
PE PE PE connection
U U Motor connection phase U
V W Motor connection phase W
W V Motor connection phase V
26877090/EN – 03/2022

4
Electrical installation
Connecting the plug connectors – single-cable technology with SD1/SDB with brake
Addendum to the Operating Instructions – CMP.. Servomotors with MOVILINK® DDI Interface 19
4.3 Connecting the plug connectors – single-cable technology with SD1/SDB
with brake
The wiring of the brake controls at the brake side is shown in the following wiring dia-
grams. The wiring at the motor side can be found in the operating instructions of the
motor.
4.3.1 Wiring diagrams of the brake control of the BK.. or BZ.D brake
BMV brake controller
13
14 15
BMV
D
B
A
C
VWU
SD1
13
14 15
BMV
SDB
W
1
+
-
2
U
N
V
YE/ A
VT/ D
VT/ D
YE/ A
35264128395
13
14 15
BMV
SBCD
BK/ 3
BK/1
V
WU
+
1 2
-
35478182283
26877090/EN – 03/2022

4Electrical installation
Connecting the plug connectors – single-cable technology with SD1/SDB with brake
Addendum to the Operating Instructions – CMP.. Servomotors with MOVILINK® DDI Interface
20
BS24 brake protection
D
B
A
C
V
WU
SD1
SDB
W
1
+
-
2
U
N
V
24 VDC
1 2 3 4 5
BS
24 VDC
1 2 3 4 5
BS
- +
+-
YE/ A
VT/ D
YE/ A
VT/ D
35473586955
SBCD
BK/ 3
BK/ 1
V
WU
+
1 2
-
24 VDC
12345
BS
- +
35534867339
26877090/EN – 03/2022
