Shark PRO SONIC STEAM POCKET User manual

S3701CO
OWNER’S GUIDE
PRO SONIC STEAM
POCKET®MOP
WWW.SHARKCLEAN.COM
S3701CO_11_IB_E_130115_1.indd 1 13-01-15 2:41 PM

TOLL FREE: 1-800-798-7398
WHEN USING YOUR SHARK®
STEAM MOP, BASIC SAFETY
PRECAUTIONS SHOULD ALWAYS
BE FOLLOWED, INCLUDING THE
FOLLOWING:
READ ALL INSTRUCTIONS BEFORE
USING YOUR STEAM MOP.
DANGER OF SCALDING.
Please use caution when using the
Steam Mop. The steam emitted from
the Steam Mop is very hot.
POLARIZED PLUG:
This appliance has a polarized plug
(one blade is wider than the other). As
a safety feature, this plug will fit into
a polarized outlet only one way. If the
plug does not fit fully into the outlet,
reverse the plug. If it still does not fit,
contact a qualified electrician. Do
not attempt to defeat this safety
feature.
WARNING:
TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK OR INJURY:
1. Use the system only for its intended
use.
2. DO NOT use outdoors.
3. DO NOT leave the appliance
unattended when plugged in. Always
unplug the power cord from the
electrical outlet when not in use and
before servicing.
4. DO NOT allow to be used as a toy. DO
NOT allow the appliance to be used by
children. Close attention is necessary
when used by or near children, pets or
plants.
5. Use only as described in this manual.
6. Use only manufacturer’s recommended
accessories.
7. DO NOT operate the appliance with
a damaged plug or cord, or if the unit
has been dropped or damaged. To
avoid the risk of electric shock, do not
disassemble or attempt to repair the
appliance on your own. Return the
appliance to EURO-PRO Operating LLC
for examination and repair. Incorrect
re-assembly or repair can cause a risk
of electrical shock or injury to persons
when the appliance is used.
8. To protect against a risk of electric
shock, DO NOT immerse the Steam
Mop into water or any other liquids.
9. DO NOT handle plug or Steam Mop
with wet hands or operate appliance
without shoes.
10. DO NOT pull or carry by power cord,
use power cord as handle, close a door
on the power cord, or pull the power
cord around sharp edges or corners.
Keep power cord away from heated
surfaces.
IMPORTANT SAFETY INSTRUCTIONS
For Household Use Only
S3701CO_11_IB_E_130115_1.indd 2 13-01-15 2:41 PM

www.sharkclean.com
11. DO NOT unplug by pulling on power
cord. To unplug, grasp the plug not
the power cord. Do not use extension
cords or outlets with inadequate
current carrying capacity.
12. DO NOT put any objects into
openings. Do not use with any opening
that is blocked.
13. DO NOT put hands or feet under the
Steam Mop. Unit gets very hot.
14. DO NOT use for space heating
purposes.
15. Use ONLY on flat, horizontal surfaces.
Do not use on walls, counters or
windows.
16. DO NOT use on leather, wax polished
furniture or floors, synthetic fabrics,
velvet or other delicate, steam sensitive
materials.
17. DO NOT add cleaning solutions,
scented perfumes, oils or any other
chemicals to the water used in this
appliance as this may damage the unit
or make it unsafe for use. If you live
in a hard water area, we recommend
using distilled water in your Steam
Mop.
18. When in use, NEVER turn the appliance
over or on its side. NEVER DIRECT
STEAM TOWARDS PEOPLE,
ANIMALS OR PLANTS.
19. NEVER LEAVE THE STEAM MOP
IN ONE SPOT ON ANY SURFACE
FOR ANY PERIOD OF TIME WHEN
MICRO-FIBER PAD IS ATTACHED AS
THIS WILL DAMAGE YOUR FLOORS.
20. Carefully remove the micro-fiber
cleaning pad immediately after you
have unplugged and allowed the
Steam Mop to cool.
21. When cleaning the Steam Mop, unplug
the power cord from the electrical
outlet and clean with a dry or damp
cloth. Do not pour water or use
alcohol, benzene or paint thinner on
the unit.
22. Extreme caution should be exercised
when using this appliance to clean
stairs.
23. Never use the Steam Mop without
micro-fiber cleaning pad attached.
24. Keep your work area well lit.
25. Store the Steam Mop indoors in a cool,
dry place.
26. To avoid circuit overload, do not
operate another appliance on the same
socket (circuit) as the steam cleaner.
27. If an extension cord is absolutely
necessary, an extension cord rated a
minimum of 15 ampere, 14 gage cord
should be used. Cords rated for less
amperage may overheat. Care should
be taken to arrange cord so that it
cannot be pulled or tripped over.
28. Always unplug and allow the Steam
Mop to cool before removing or
changing mop heads.
WARNING: Your Steam Mop is
designed to clean hard floor surfaces
that will withstand high heat. Do not
use on unsealed wood or unglazed
ceramic floors. On surfaces that have
been treated with wax or some no wax
floors, the sheen may be removed by
the heat and steam action. It is always
recommended to test an isolated area
of the surface to be cleaned before
proceeding. We also recommend that
you check the use and care instructions
from the floor manufacturer.
SAVE THESE
INSTRUCTIONS
S3701CO_11_IB_E_130115_1.indd 3 13-01-15 2:41 PM

TOLL FREE: 1-800-798-7398
This manual covers model number:
S3701CO 11
TECHNICAL SPECIFICATIONS
Voltage: 120V., 60Hz.
Power: 1550 Watts
Water Capacity: 450 ml (15.2 oz.)
S3701CO_11_IB_E_130115_1.indd 4 13-01-15 2:41 PM

1
www.sharkclean.com
Contents
Getting Started..................................................................2
Using Your Steam Mop ......................................................5
Care of Your Steam Mop ...................................................9
Troubleshooting Guide.......................................................11
Warranty ...........................................................................15
Thank you for
purchasing the
Shark®Pro Sonic
Steam Pocket®
Mop.
S3701CO_11_IB_E_130115_1.indd 1 13-01-15 2:41 PM

2
TOLL FREE: 1-800-798-7398
Getting Started
When assembling your Steam Mop there may be a little water in or around the water tank. This is
because we test all our Steam Mops 100% before you buy them, so you get a quality Shark®Pro
Sonic Steam Pocket®Mop.
Dust
steam
Mop
Scrub
S
O
N
I
C
S
C
R
U
B
a
d
f
g
i
b c
e
hFilling Flask
i(1) 6mm x 54mm Large Screw*
*Phillips or flat head screwdriver can be used.
Screwdriver not included.
aMop Handle
bWater Tank Cap (not shown)
cSteam Selector Button
dSonic Scrub On/Off Button
eSteam Mop Body
fAll-Purpose Mop Head
gSonic Lift™Cleaning Pads (x2)
h
S3701CO_11_IB_E_130115_1.indd 2 13-01-15 2:41 PM

3
www.sharkclean.com
Dust
steam
Mop
Scrub
S
O
N
I
C
S
C
R
U
B
IMPORTANT: Always make sure the
Steam Mop is UNPLUGGED from the wall
when not in use. Never fill the Steam Mop,
attach the mop head, change or remove
the cleaning pad when the Steam Mop is
plugged into the wall. To prolong the life
of your Shark®Pro Sonic Steam Pocket®
Mop, we recommend using distilled water.
Make sure you only add water to the tank.
Chemicals or cleaning solution may damage
the appliance and could be unsafe for you
and your family.
ASSEMBLE
1Insert the Mop handle end labeled “Front”
into the Steam Mop body. Make sure it is
inserted past the line printed on the pole.
Secure the assembled handle and pole by
using the large screw and a Phillips or a flat
head screwdriver (screwdriver not included).
(fig. 1)
fig. 1
Dus t
steam
Mop
Scrub
S
O
N
I
C
S
C
R
U
B
S3701CO_11_IB_E_130115_1.indd 3 13-01-15 2:41 PM

4
TOLL FREE: 1-800-798-7398
Getting Started - cont’d
IMPORTANT: Do not use on unsealed
wood or unglazed ceramic floors. On
surfaces that have been treated with wax
or some no wax floors, the sheen may be
removed by the heat and steam action. It
is always recommended to test an isolated
area of the surface to be cleaned before
proceeding. We recommend that you check
the use and care instructions from the floor
manufacturer.
NOTE: To prolong the life of your Steam
Mop, we recommend using distilled water.
2Fit one side of the Sonic Lift™cleaning
pad onto the head first, making sure that
the scrub side is facing down, then using
the lavender loop, pull the pocket over
the head. Attach the hook and loop quick
fasteners on the top of the pocket to secure
in place. (fig. 2)
3Snap the mop head into the mop body by
lining up the groove on the back of the
mop body with the groove on the back of
the mop head. Push until you hear it “click”
into place. (fig. 3)
4Turn the water tank cap counter clockwise
and remove from the tank. (fig. 4)
Use the filling flask and pour water into the
tank. Do not overfill. Replace the cap on
the water tank. (fig. 5)
fig. 4
fig. 5
fig. 2
fig. 3
Dust
steam
Mop
Scrub
S
O
N
I
C
S
C
R
U
B
S3701CO_11_IB_E_130115_1.indd 4 13-01-15 2:41 PM

5
www.sharkclean.com
IMPORTANT: Your Steam Mop needs water
to make steam! Never use your Steam Mop
without water in the tank.
Sweep or vacuum your floors prior to
cleaning with your Steam Mop.
Visit www.sharkclean.com for other great
quick cleaning products to complement
your Steam Mop, such as the Shark®
Navigator™ Lift Away®(model NV350).
1Pull and twist the quick release cord holder
to unwrap the power cord completely. Plug
into an electrical outlet. (fig. 6)
2The power “On” light around the Sonic
Scrub button will turn blue. If the light does
not turn on, reference the troubleshooting
section on page 11. (fig. 7)
NOTE: The Steam Mop is on when it is
plugged in. Unplug when you want to turn
it off.
NOTE: The Sonic Scrub On/Off button
is only for activating the “Sonic Scrub”
function of the Steam Mop. It does not turn
the appliance on or off.
IMPORTANT: Make sure you do not use
the mop without attaching a cleaning pad
and adding water to the tank first. When
you are using the mop for the first time,
it might take longer than the normal 30
seconds to start steaming.
Using Your Steam Mop
fig. 6
fig. 7
S
C
R
U
B
S
O
N
I
C
S3701CO_11_IB_E_130115_1.indd 5 13-01-15 2:41 PM

6
TOLL FREE: 1-800-798-7398
Using Your Steam Mop - cont’d
fig. 8
fig. 9
SELECTING YOUR STEAM SETTING
3Press the STEAM button once for DUST
setting (DUST lighted setting indicator will
illuminate). DUST setting is a light steam for
a quick dusting and the best dry time.
(fig. 8)
Press the STEAM button a second time to
activate the MOP setting. MOP setting is for
normal, everyday steam cleaning. (fig. 9)
Press the STEAM button a third time to
activate the SCRUB setting. SCRUB setting
is for heavy cleaning and will leave floors
damp.
To better understand which steam setting to
use for your cleaning task, turn to page 7.
Press the STEAM button until the light
flashes to stop the steam.
Dust
steam
Mop
Scrub
S
O
N
I
C
S
C
R
U
B
S
C
R
U
B
S
O
N
I
C
Dust
Mop
Scrub
steam
S3701CO_11_IB_E_130115_1.indd 6 13-01-15 2:41 PM

7
www.sharkclean.com
Setting Ideal for These Surfaces Recommended Usage
Laminate
Bamboo
Hardwood
Marble
Light cleaning and dusting
Loosen and lift light dirt
Sanitize floors
Hardwood
Marble
Tile
Stone
Tile
Stone
Linoleum
Carpet
(with Carpet Glider)
Basic, everyday cleaning
Remove spots and smaller messes
Clean moderate and heavily-trafficked
areas
Sanitize floors
Tough cleaning and removal of stuck-on
messes and stains
Deep clean heavily-trafficked areas
Cut through heavy dirt and grime
Sanitize floors
Freshen area rugs and carpets
The Shark®Pro Sonic Steam Pocket®Mop has three unique steam settings so you
can use the perfect amount of steam for the cleaning task at hand. See below for
tips on when to use each setting.
DUST
MOP
SCRUB
S3701CO_11_IB_E_130115_1.indd 7 13-01-15 2:41 PM

8
TOLL FREE: 1-800-798-7398
Using Your Steam Mop - cont’d
IMPORTANT: Never leave the Pro Sonic
Steam Pocket®Mop with a damp/wet
Sonic Lift™cleaning pad on any floor
surface for any amount of time as this may
damage the floor.
NOTE: Please wait 2-3 minutes for the
Steam Mop to cool off before removing the
cleaning pad. Never leave the Steam Mop
with a damp/wet micro-fiber cleaning pad
on any floor.
fig. 11
fig. 10
Dust
stream
Mop
Scrub
S
O
N
I
C
S
C
R
U
B
Using Sonic Scrub
Use the “Sonic Scrub” feature and the
scrub side of the Sonic Lift™cleaning pad
to clean tough, dried on stains faster and
easier.
4Press the Sonic On/Off button to turn on
the “Sonic Scrub”. (fig. 10)
5Use the scrub side of the Sonic Lift™
cleaning pad to break up the tough stains.
Then flip the mop head over to use the
shaggy side of the Sonic Lift™cleaning pad
to lift up and lock away all of the dirt and
debris. (fig. 11)
6When the water tank is empty, the Pro
Sonic Steam Pocket®Mop will stop
producing steam. You can refill the water
tank at any time as long as the mop is
unplugged from the outlet. Follow the
instructions from page 4.
The Sonic Lift™cleaning pad has two different
cleaning sides. One side has nylon scrubbers to
break up tough stains and the other side is a shaggy
cleaning pad to lift up and lock away dirt and debris.
Dust
steam
Mop
Scrub
S
O
N
I
C
S
C
R
U
B
S3701CO_11_IB_E_130115_1.indd 8 13-01-15 2:41 PM

9
www.sharkclean.com
2Empty the water tank before storage.
Remove the water tank cap and empty the
tank over a sink. Replace the water cap.
(fig. 13)
3To store the Shark®Pro Sonic Steam
Pocket®Mop hanging up, first remove the
head (after it has cooled and the steam has
been released) then hang on a large hook.
(fig. 14)
AFTER USE AND STORAGE
1When you have finished using the Steam
Mop, press the STEAM button until the LED
light turns flashing BLUE. This stops the unit
from steaming. Unplug the cord from the
outlet and place the mop into the upright
position. Let the unit cool for 2-3 minutes.
Remove the micro-fiber cleaning pad by
releasing the quick fasteners and using the
lavender loop on the side of the pocket,
avoiding contact with the hot pad or dirt.
(fig. 12)
Care of Your Steam Mop
fig. 12
fig. 13 fig. 14
Dust
steam
Mop
Scrub
S
O
N
I
C
S
C
R
U
B
S3701CO_11_IB_E_130115_1.indd 9 13-01-15 2:41 PM

10
TOLL FREE: 1-800-798-7398
fig. 15
fig. 16
To order additional parts and
accessories, feel free to contact
us at www.sharkclean.com or
call 1-800-798-7398.
Care of Your Steam Mop - cont’d
CARE OF YOUR CLEANING PAD
1We recommend washing your Sonic Lift™
cleaning pads separately from other fabrics
to avoid picking up lint. Only use liquid
detergent (no powder detergent). Do
not use any fabric softeners or bleach.
Line dry or dry on a low dryer setting.
(fig. 15)
2If there are loose threads on the cleaning
pad carefully cut the thread with scissors.
Do not pull on them or cut at the base.
(fig. 16)
IMPORTANT: The cleaning pad may be
very hot from the steam. Use caution when
removing. Let the unit cool for 2-3 minutes
before removing the cleaning pad.
AVOIDING DECALCIFICATION IN YOUR
STEAM MOP
Calcium and mineral deposits can build up
and impact the performance of your Steam
Mop over time. To extend the life of your
product we recommend that you use distilled
water.
S3701CO_11_IB_E_130115_1.indd 10 13-01-15 2:41 PM

11
www.sharkclean.com
Troubleshooting Guide
PROBLEM POSSIBLE REASONS & SOLUTIONS
The Pro Sonic Steam
Pocket
®
Mop will not
turn-on.
Your Steam Mop should be securely plugged into an electrical outlet only.
Check your fuse or breaker.
If your unit still does not work, call Customer Care at 1-800-798-7398.
The unit will not
make steam.
Is there water in the water tank? If not, add water to your Steam Mop following
instructions on page 4.
If the unit still doesn’t make steam, follow the decalcification instructions on page 10.
Cannot select steam
setting/flashing blue light
remains on.
If you have already plugged in your unit, unplug and try a different outlet. This may
reset the standby mode.
Add water to the tank and press the STEAM button to select a steam setting.
If your unit still does not work, call Customer Care at 1-800-798-7398.
The Pro Sonic Steam
Pocket
®
Mop leaves
water on the floor.
Check to see if your Sonic Lift™cleaning pad is soaked through. We recommend
you unplug the Steam Mop and change the Sonic Lift™ cleaning pad.
Make sure the Sonic Lift™cleaning pad is attached correctly.
The Pro Sonic Steam
Pocket
®
Mop left a white
spot on the floor.
Do not leave your Steam Mop on the floor with a damp or wet cleaning pad.
If you’re using tap water we recommend switching to distilled water.
Make sure the cap is securely on the water tank.
Floors are cloudy, streaky
or spotty after steaming.
The Sonic Lift™cleaning pad might be dirty. Change the cleaning pad .
If you washed the Sonic Lift™ cleaning pad with powder detergent, then it
may be damaged and require replacement .
Replacement pads are available at www.sharkclean.com.
You might have left the mop in the same spot for too long.
Do you have hard water? If you do, you might want to switch to distilled
water.
This might be leftover from past cleaners used on the floor surface. Use the
Pro Sonic Steam Pocket® Mop a few more times and see if the leftover
cloudiness is removed. If this does not work, we suggest rinsing the floor with
water, letting it dry, and then steam mopping again with a clean pad. One or
more rinses generally removes the residue. A more stubborn case may require
you to rinse the floor with a mix of one part vinegar and two parts water.
The Pro Sonic Steam
Pocket
®
Mop is hard to
push.
Make sure the Sonic Lift™cleaning pad is attached correctly.
Check to see if the Sonic Lift™cleaning pad is excessively dirty.
Check to see if the Sonic Lift™cleaning pad is excessively wet. If it is, change
to a dry cleaning pad.
S3701CO_11_IB_E_130115_1.indd 11 13-01-15 2:41 PM

12
TOLL FREE: 1-800-798-7398
Notes
S3701CO_11_IB_E_130115_1.indd 12 13-01-15 2:41 PM

13
www.sharkclean.com
Notes
S3701CO_11_IB_E_130115_1.indd 13 13-01-15 2:41 PM

14
TOLL FREE: 1-800-798-7398
Notes
S3701CO_11_IB_E_130115_1.indd 14 13-01-15 2:41 PM

15
www.sharkclean.com
ONE (1) YEAR LIMITED WARRANTY
EURO-PRO Operating LLC warrants this product to be free from defects in material and
workmanship for a period of one (1) year from the date of the original purchase, when utilized for
normal household use, subject to the following conditions, exclusions and exceptions.
If your appliance fails to operate properly while in use under normal household conditions within
the warranty period, return the complete appliance and accessories, freight prepaid. For assistance
with warranty service options or customer support, please call our customer care and product
specialists at , call 1 [phone] or visit our website www.sharkclean.com.
If the appliance is found to be defective in material or workmanship, EURO-PRO Operating
LLC will repair or replace it free of charge. Proof of purchase is required and a fee of $19.95 will
apply to cover the cost of return freight. *
The liability of EURO-PRO Operating LLC is limited solely to the cost of the repair or
replacement of the unit at our option. This warranty does not cover normal wear of parts and does
not apply to any unit that has been tampered with or used for commercial purposes. This limited
warranty does not cover damage caused by misuse, abuse, negligent handling or damage due
to faulty packaging or mishandling in transit. This warranty does not cover damage or defects
caused by or resulting from damages from shipping or repairs, service or alterations to the product
or any of its parts, which have been performed by a repair person not authorized by EURO-PRO
Operating LLC.
This warranty is extended to the original purchaser of the unit and excludes all other legal and/or
conventional warranties. The responsibility of EURO-PRO Operating LLC warranty if any, is
limited to the specific obligations expressly assumed by it under the terms of the limited warranty.
In no event is EURO-PRO Operating LLC liable for incidental or consequential damages
of any nature whatsoever. Some states/provinces do not permit the exclusion or limitation of
incidental or consequential damages, so the above may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which vary from
state to state or province to province.
*Important: Carefully pack item to avoid damage in shipping. Be sure to
include proof of purchase date and to attach tag to item before packing with
your name, complete address and phone number with a note giving purchase
information, model number and what you believe is the problem with the item.
We recommend you insure the package (as damage in shipping is not covered
by your warranty). Mark the outside of your package “ATTENTION CUSTOMER
SERVICE”. We are constantly striving to improve our products, therefore the
specifications contained herein are subject to change without notice.
Product Registration
Please visit www.sharkclean.com or call 1-800-798-7398 to register your new Shark®product within
ten (10) days of purchase. You will be asked to provide the store name, date of purchase and model number
along with your name and address.
The registration will enable us to contact you in the unlikely event of a product safety notification. By
registering you acknowledge to have read and understood the instructions for use, and warnings set forth in the
accompanying instructions.
S3701CO_11_IB_E_130115_1.indd 15 13-01-15 2:41 PM

EURO-PRO Operating LLC
U.S.: Newton, MA 02459
Canada: Ville St. Laurent, Québec H4S 1A7
1-800-798-7398
www.sharkclean.com
COPYRIGHT © 2013 EURO-PRO OPERATING LLC
PRINTED IN CHINA
S3701CO.E.130115.1
Illustrations may differ from actual product.
S3701CO_11_IB_E_130115_1.indd 16 13-01-15 2:41 PM
