Shark SM200QUK User manual

SM200QUK
OWNER’S GUIDE
SONIC STEAM POCKET™ MOP

TOLL FREE: 0800 51 41 31
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK OR INJURY:
1. Use the system only for its intended use.
2. DO NOT use outdoors.
3. DO NOT leave the appliance unattended
when plugged in. Always unplug the power
cord from the electrical outlet when not in use
and before servicing.
4. DO NOT allow the appliance to be used by
children. Close attention is necessary when
used by or near children, pets or plants.
5. Use only as described in this manual.
6. Use only manufacturer’s recommended
accessories.
7. DO NOT operate the appliance with a
damaged plug or cord, or if the unit has been
dropped or damaged. To avoid the risk of
electric shock, do not disassemble or attempt
to repair the appliance on your own. If the
supply cord is damaged, it must be replaced
by a qualified electrician in order to avoid a
hazard. Incorrect re-assembly or repair can
cause a risk of electrical shock or injury to
persons when the appliance is used. .
8. To protect against a risk of electric shock, DO
NOT immerse the steam mop into water or
any other liquids.
9. DO NOT handle plug or steam mop with wet
hands or operate appliance without shoes.
10. DO NOT pull or carry by cord, use cord as
a handle, close a door on cord, or pull cord
around sharp edges or corners. Do not run
appliance over cord. Keep cord away from
heated surfaces.
11. DO NOT unplug by pulling on power cord.
To unplug, grasp the plug not the power cord.
Do not use extension cords or outlets with
inadequate current carrying capacity.
IMPORTANT SAFETY INSTRUCTIONS
For Household Use Only
WHEN USING YOUR SHARK®
SONIC STEAM POCKET™MOP,
BASIC SAFETY PRECAUTIONS
SHOULD ALWAYS BE FOLLOWED,
INCLUDING THE FOLLOWING:
READ ALL INSTRUCTIONS BEFORE
USING YOUR SHARK® SONIC
STEAM POCKET™MOP.
DANGER OF SCALDING.
Please use caution when using the steam mop.
The steam emitted from the steam mop is very
hot.
IMPORTANT:
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities
or lack of experience and knowledge,
unless they have been given supervision
or instruction concerning the use of the
appliance by a person responsible for their
safety.
Children should be supervised to ensure
that they do not play with the appliance.

12. DO NOT use for space heating purposes.
13. DO NOT put any objects into openings. Do
not use with any opening that is blocked.
14. DO NOT put hands or feet under the steam
mop. Unit gets very hot.
15. Use ONLY on flat, horizontal surfaces. Do
not use on walls, counters or windows.
16. DO NOT use on leather, wax polished
furniture or floors, synthetic fabrics, velvet or
other delicate, steam sensitive materials.
17. DO NOT add cleaning solutions, scented
perfumes, oils or any other chemicals to
the water used in this appliance as this may
damage the unit or make it unsafe for use. If
you live in a hard water area, we recommend
using distilled water in your steam mop.
18. Liquid or steam must not be directed towards
equipment containing electrical components,
such as the interior of ovens.
19. When in use, NEVER turn the appliance over
or on its side. NEVER DIRECT STEAM
TOWARDS PEOPLE, ANIMALS OR
PLANTS.
20. NEVER LEAVE THE STEAM MOP
IN ONE SPOT ON ANY SURFACE
FOR ANY PERIOD OF TIME WHEN
THE CLEANING PAD IS ATTACHED
OR WITH THE SONIC FEATURE IF
TURNED ON AS THIS WILL DAMAGE
YOUR FLOORS.
21. Always unplug and allow the steam mop to
cool before removing the mop head.
22. Allow the steam mop to cool before carefully
removing the cleaning pad after you have
unplugged the steam mop.
23. When cleaning the steam mop, unplug the
power cord from the electrical outlet, allow
to cool and clean with a dry or damp cloth.
Do not pour water or use alcohol, benzene or
paint thinner on the unit.
24. Extreme caution should be exercised when
using this appliance to clean stairs.
25. Never use steam mop without the cleaning
pad attached.
26. Keep your work area well lit.
27. Store steam mop indoors in a cool, dry place.
28. To avoid circuit overload, do not operate
another appliance on the same socket (circuit)
as the steam cleaner.
29. If an extension cord is absolutely necessary,
an extension cord rated a minimum of 15
ampere, 14 gage cord should be used. Cords
rated for less amperage may overheat. Care
should be taken to arrange cord so that it
cannot be pulled or tripped over.
30. DO NOT store unit with damp/wet cleaning
pad attached. Never leave the Steam Mop in
one spot on any surface for any period of time
with a damp or wet cleaning pad attached as
this will damage your floors.
WARNING: Your steam mop is
designed to clean hard floor surfaces that will
withstand high heat. Do not use on unsealed
wood or unglazed ceramic floors. On surfaces
that have been treated with wax or some
no wax floors, the sheen may be removed
by the heat and steam action. It is always
recommended to test an isolated area of the
surface to be cleaned before proceeding. We
also recommend that you check the use and
care instructions from the floor manufacturer.
SAVE THESE
INSTRUCTIONS

TOLL FREE: 0800 51 41 31
This manual covers model number:
SM200QUK 11
TECHNICAL SPECIFICATIONS
Voltage: 220-240V~, 50/60Hz.
Power: 1550 Watts
Water Capacity: 400 ml (13.5 oz.)
This appliance complies with the WEEE-Directive 2002/96/EC on the disposal of electrical and electronic
equipment (WEEE).
This appliance complies with the European directives for electromagnetic compatibility (EMC) 2004/108/EC
and its revisions, as well as Low Voltage Directive (LVD) 2006/95/EC and its revisions.
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environment or human health
from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of
material sources. To return your used device, please use the return and collection systems
or contact the retailer where this product was purchased. They can take this product for
environmental safe recycling.
This product has no on/off switch and operates when plugged into the main supply source. Disconnect the
plug from mains after use.
Although the product is not provided with standby mode or off mode, it still fulfills the requirements of
1275/2008/EC - the directive for Eco-Design requirements since according to technical justification, it is
considered as inappropriate to provide standby and off modes when connecting to mains. To reduce energy
consumption be sure to unplug the unit after use.
Not to be disposed
of with o ther
household waste.
IPX4

1
Contents
Getting Started ................................................................................................... 2
Using Your Sonic Steam Pocket
™
Mop......................................................... 5
Care and Maintenance........................................................................................ 7
Troubleshooting Guide........................................................................................ 8
Thank you for
purchasing the
Shark®Sonic
Steam Pocket™Mop.

2TOLL FREE: 0800 51 41 31
When assembling your steam mop there may be a little water in or around the water tank. This is because we test
all our steam mops 100% before you buy them, so you get a quality Shark
®
Sonic Steam Pocket
™
Mop.
gFilling Flask
hCarpet Glider
aMop Handle
bWater Tank Cap (not shown)
cSonic Agitation On/Off Button
dWater Tank Viewing Window
eAll-Purpose Mop Head
fSonic Lift™Cleaning Pads (x4)
Getting Started
a
c
d
g
e
h
f
b

3
IMPORTANT: Always make sure the mop
is UNPLUGGED from the wall when not in
use. Never fill the mop, attach the mop head,
or change or remove the Sonic Lift™cleaning
pad when the mop is plugged into the wall. To
prolong the life of your Shark®Sonic Steam
Pocket™Mop, we recommend using distilled
water. Make sure you only add water to the
tank. The addition of chemicals or cleaning
solutions may damage the appliance and could
be unsafe for you and your family.
ASSEMBLE
1Insert the mop handle into the main body of the
steam mop (into the tube that leads to the tank).
Push the mop handle and main body of the
steam mop together until you hear it “click” into
place. (Fig. 1)
2Fit one side of the Sonic Lift™cleaning pad onto
the head first, making sure that the scrubbing
side is facing down, then using the lavender loop,
pull the pocket over the head. Attach the hook
and loop quick fasteners on the top of the pocket
to secure in place. (Fig. 2)
3Snap the mop head into the mop body by lining
up the groove on the back of the mop body with
the groove on the back of the mop head. Push
until you hear it “click” into place. (Fig. 3)
fig. 3
fig. 1
fig. 2
The Sonic Lift™cleaning pad has two different
cleaning sides. One side has nylon scrubbers to
break up tough stains and the other side is a shaggy
cleaning pad to lift up and lock away dirt and debris.

4TOLL FREE: 0800 51 41 31
IMPORTANT: Do not use on unsealed wood
or unglazed ceramic floors. On surfaces that
have been treated with wax or some no wax
floors, the sheen may be removed by the heat
and steam action. It is always recommended to
test an isolated area of the surface to be cleaned
before proceeding. We recommend that you
check the use and care instructions from the
floor manufacturer.
4Turn the water tank cap counter clockwise and
remove from the tank. (Fig. 4)
Use the filling flask to pour water into the tank.
Do not fill past the fill line on the water tank.
(Fig. 5)
5After filling the tank, replace the water tank
cap by placing back on the tank and turning it
clockwise until tight.
Getting Started - cont.
fig. 4 fig. 5
Calcium and mineral deposits can build up and
impact the performance of your steam mop
over time. To extend the life of your product we
recommend that you use distilled water.

5
Using Your Sonic Steam Pocket™Mop
IMPORTANT: Do not use the mop without
attaching a cleaning pad and adding water
to the tank first. When you are using the mop
for the first time, it might take longer than the
normal 30 seconds to start steaming. Just pump
the handle a few times in a downward motion to
prime the pump.
2Pump the handle a few times in a downward
motion. This pumping action will release steam
as you mop and allows you to customise the
amount of steam you want. Begin mopping with
a forward and backward motion. The natural
motion of mopping will produce steam. (Fig. 8)
NOTE: The steam mop is on when it is plugged
in. Unplug when you want to turn it off.
NOTE: The Sonic Agitation On/Off button is
only for activating the sonic agitation function of
the steam mop. It does not turn the appliance on
or off.
NOTE: Make sure the floors are swept or
vacuumed before using the Sonic Steam
Pocket™Mop.
1Pull and twist the quick release cord holder to
unwrap the power cord completely. (Fig. 6)
Plug into an electrical outlet. The Power “On”
Light around the Sonic Agitation button will turn
blue. (Fig. 7)
It takes approximately 30 seconds for the mop to
heat up and the steam to be ready.
fig. 6
fig. 8
fig. 7
Pump for
steam

6TOLL FREE: 0800 51 41 31
Using Sonic Agitation
Use the Sonic Agitation feature and the scrubbing
side of the Sonic Lift™cleaning pad to clean tough,
dried on stains faster and easier.
3Press the Sonic On/Off button to turn on the sonic
scrub. (Fig. 9)
4Use the scrubbing side of the Sonic Lift™cleaning
pad to break up the tough stains and then turn the
mop head around to use the shaggy side of the
Sonic Lift™cleaning pad to lift up and lock away all
of the dirt and debris. (Fig. 10)
NOTE: For deeper cleaning/sanitisation of
household bacteria such as e-coli, salmonella, or
StaphA., the area in question must be cleaned
continuously for 30 seconds (or 30 back and forth
strokes).
5When the water tank is empty, the Sonic Steam
Pocket™Mop will stop producing steam. You
can refill the water tank at any time as long as
the mop is unplugged from the outlet. Follow the
instructions from page 4.
IMPORTANT: Never leave the Sonic Steam
Pocket™Mop with a damp/wet Sonic Lift™
cleaning pad on any floor surface for any amount
of time as this may damage the floor.
Using Your Sonic Steam Pocket™Mop - cont.
fig. 9
fig. 10
Using the Carpet Glider
1The Carpet Glider can be used with the All-
Purpose Head to lightly steam your carpet and
area rugs. Just place the mop head with the
Sonic Lift™cleaning pad (shaggy side down)
attached into the glider. (Fig. 11)
2 Move the steam mop back and forth across a
section of the carpet. (Fig. 12)
fig. 11
fig. 12
The steam mop will not clean your carpeting
or area rugs. However, it is great for grooming
and freshening.
The Sonic Lift™cleaning pad has two different
cleaning sides. One side has nylon scrubbers to
break up tough stains and the other side is a shaggy
cleaning pad to lift up and lock away dirt and debris.

7
Care and Maintenance
2 Remove the Sonic Lift™cleaning pad by
releasing the hook and loop fasteners and
using the lavender loop on the side of the
pocket to pull off. Avoid contact with the hot
pad or dirt. Then empty the water tank.
(Fig. 13)
3To store the Shark®Sonic Steam Pocket™
Mop hanging up; first remove the head (after
it has cooled and the steam has been released)
then hang on a large hook. (Fig. 14)
NOTE: If you want to store it standing upright,
then make sure it’s leaning against a wall for
added support and safety. Always store your
Sonic Steam Pocket™Mop with the Sonic
Lift™cleaning pad removed and away from
children or high traffic areas.
AFTER USE AND STORAGE
1When you have finished using the Sonic
Steam Pocket™Mop, unplug the cord from
the outlet and let the unit cool 2-3 minutes.
Release the residual steam by pumping the
handle several times before removing the Sonic
Lift™cleaning pad from the mop head.
fig. 13
fig. 14
CARE OF YOUR CLEANING PAD
1We recommend washing your Sonic Lift™
cleaning pads separately from other fabrics
to avoid picking up lint. Only use liquid
detergent (no powder detergent). Do not
use any fabric softeners or bleach. Line dry.
Do not tumble dry. (Fig. 15)
2If there are loose threads on the cleaning pad
carefully cut the thread with scissors. Do not pull
on them or cut at the base. (Fig. 16)
IMPORTANT: The cleaning pad may be very
hot from the steam. Use caution when removing.
Let the unit cool for 2-3 minutes before removing
the cleaning pad.
fig. 16
fig. 15
AVOIDING DECALCIFICATION IN YOUR
STEAM MOP
Calcium and mineral deposits can build up and
impact the performance of your steam mop
over time. To extend the life of your product we
recommend that you use distilled water.
40°

8TOLL FREE: 0800 51 41 31
Troubleshooting Guide
PROBLEM POSSIBLE REASONS & SOLUTIONS
Sonic Steam Pocket™
Mop will not turn on.
Your Sonic Steam Pocket™Mop should be securely plugged into an electrical
outlet only.
Check your fuse or breaker.
Sonic Steam Pocket™
Mop will not make steam.
Prime the pump, see page 5 for more information.
Is there water in the water tank? If not, add water to your Sonic Steam Pocket™
Mop following instructions on page 4.
Sonic Steam Pocket™
Mop leaves water on the floor.
Check to see if the Sonic Lift™cleaning pad is too wet. We recommend you unplug
the Sonic Steam Pocket™Mop and change the Sonic Lift™cleaning pad.
Make sure the Sonic Lift™cleaning pad is attached correctly.
Do not leave your Sonic Steam Pocket™Mop on the floor with a damp or wet
cleaning pad.
Make sure the cap is securely on the water tank.
Sonic Steam Pocket™
Mop is hard to push.
Make sure the Sonic Lift™cleaning pad is attached correctly.
Check to see if the Sonic Lift™cleaning pad is excessively dirty.
Check to see if the Sonic Lift™cleaning pad is excessively wet. If it is, change to a
dry cleaning pad.
Floors are cloudy, streaky or
spotty after steaming.
The Sonic Lift™cleaning pad might be dirty. Change the cleaning pad .
If you washed the
Sonic Lift™ cleaning pad with powder detergent, then it may be
damaged and require replacement
.
You might have left the mop in the same spot for too long.
Do you have hard water? If you do, you might want to switch to distilled water.
This might be leftover from past cleaners used on the floor surface. Use the
Sonic
Steam Pocket™
Mop a few more times and see if the leftover cloudiness is
removed. If this does not work, we suggest rinsing the floor with water, letting it
dry, and then steam mopping again with a clean pad. One or more rinses generally
removes the residue. A more stubborn case may require you to rinse the floor with a
mix of one part vinegar and two parts water.

9
Notes

10 TOLL FREE: 0800 51 41 31
Notes

11
Notes

Not to be disposed
of with o ther
household waste.
IPX4
Technical Details
Model number: SM200QUK
Input: 1550 Watts
Main unit voltage: 220/240 V~, 50/60 Hz
For customer service please contact:
QVC
South Boundary Road
Knowsley, Liverpool
L70 2QA
Tel.: [phone]
COPYRIGHT© EURO-PRO OPERATING LLC 2012
PRINTED IN CHINA
Illustrations may differ with actual product.
SM200QUK.E.121005.1
