Sharp FU-P40S User manual

中文
FU-P40S
R
ENGLISH
AIR PURIFIER
OPERATION MANUAL
Free Standing
*Plasmacluster is a trademark of
Sharp Corporation.
空氣清新機
使用說明書
直立式
*Plasmacluster“離子簇”是聲寶
公司的商標。
ＦＵ－Ｐ４０Ｓ＿ＣＨ 2004.4.13, 14:521

ENGLISH
FEATURES
Plasmacluster Ion Control
Theunitcontrolstheratioofnegativeions
and positive ions depending on the con-
dition of the room.
•Clean Mode
Approximatelythesamenumbersofposi-
tive and negative ions are discharged.
This mode is effective for reducing some
airborne mold.
•Ion Control Mode
Plenty of negative ions exist in natural
surroundingssuchaswaterfallsorforests.
In this mode, negative ions will be re-
leased in an increased rate, in order to
bring the room air close to this natural
environment.
•AUTO Plasmacluster Ion Mode
The unit will switch between Clean Mode
and Ion Control Mode automatically de-
pendingontheamountof impurities in the
airdetectedbythe dust and odorsensors.
•Filters
1) Pre-Filter
It collects large particles.
2) Washable Active Carbon Filter
Its deodorizing performance can be
maintained by washing.
3) HEPA (High Efficiency
Particulate Air) Filter with
Microbial Control Filter
High-efficiency particle collection in-
cluding pollen and dust.
CONTENTS
IMPORTANT SAFETY INSTRUCTIONS .... E-2
•WARNING....................................................E-2
•CAUTIONS CONCERNING OPERATION ...E-2
•REMOTE CONTROL LIMITATIONS ............E-2
•INSTALLATION GUIDELINES .....................E-3
•FILTER GUIDELINES ..................................E-3
•HOW SHARPAIR PURIFIER WORKS........E-3
PART NAMES.......................................... E-4
•MAIN UNIT DISPLAY...................................E-4
• INCLUDED...................................................E-4
• BACK ...........................................................E-4
PREPARATION........................................ E-5
•INSERTING BATTERIES
IN THE REMOTE CONTROL ......................E-5
•REMOTE CONTROL USE...........................E-5
•FILTER INSTALLATION...............................E-6
OPERATION ............................................ E-8
•MAIN UNIT OPERATION.............................E-8
•REMOTE CONTROL OPERATION .......... E-10
CARE AND MAINTENANCE................. E-11
•MAIN UNIT.................................................E-11
•ODOR SENSOR / DUST SENSOR ...........E-11
• PRE-FILTER ..............................................E-11
•WASHABLE ACTIVE CARBON
FILTER CARE ........................................... E-12
•FILTER REPLACEMENT
GUIDELINES ............................................ E-13
TROUBLE SHOOTING..........................E-14
SPECIFICATIONS ................................. E-15
E-1
ENGLISH
Thankyou forpurchasingthe SHARPAir Purifier.Pleaseread this manualcarefullyfor thecorrect
usage information. Before using this product, be sure to read the section: “Important Safety In-
structions.”
After reading this manual, retain it in a convenient location for future reference.

IMPORTANT SAFETY INSTRUCTIONS
E-2
When using electrical appliances, basic safety precautions should be followed, including the
following:
WARNING - To reduce the risk of electrical shock, fire or injury to persons:
•Read all instructions before using the air purifier.
•Use only a 220-240 volt outlet.
•Do not use the air purifier if the power cord or plug is damaged or the connection to the wall
outlet is loose.
•Periodically remove dust from the power plug.
•Do not insert fingers or foreign objects into the intake or air outlet.
•When removing the power plug, always hold the plug and never pull the cord.
Electrical shock and/or fire from short circuit may occur as result.
•Do not use this air purifier near gas appliances or fireplaces.
•Remove the power plug from the wall outlet before cleaning the unit and when not using the
unit.
Electrical shock from bad insulation and / or fire from short circuit may occur as a result.
•If the power cord is damaged, it must be replaced by the manufacturer, its service agent,
Sharp authorized service or similarly qualified person in order to avoid a hazard.
•Do not operate when using aerosol insecticides or in rooms where there is oily residue, incense,
sparks from lit cigarettes, chemical fumes in the air or a humidity condition.
•Use care when cleaning the air purifier. Strong corrosive cleansers may damage the exterior.
•Only SharpAuthorized Servicers should service this air purifier. Contact the nearest Servicer for any
problems, adjustments, or repairs.
•The batteries must be removed from the remote control before disposal, and the batteries must be
disposed of safely.
CAUTIONS CONCERNING OPERATION
•Do not block the intake and air outlet.
•Do not use the unit near or on hot objects, such as range or where it may come into contact with
steam.
•Always hold the handle on the back of the main unit when moving it.
•Holding the front panel when carrying may cause it to detach, thus dropping the unit and resulting in
bodily injury.
•Do not operate the unit without the filter.
Not only it does not improve filter performance, it may cause electric shock or malfunction.
•Clean the exterior with a soft cloth only.
The unit surface may be damaged or cracked.
In addition, the sensor may malfunction as a result.
REMOTE CONTROL LIMITATIONS
DO NOT USE THE REMOTE CONTROL IN THE FOLLOWING LOCATIONS:
•Any location where there is inverter lighting equipment or electronic spontaneous lighting
equipment
The remote control may become inoperative. In this case, move away from such lighting equipment
or change direction.
•Location exposed to direct sunlight or fluorescent.
The unit may not receive signals from the remote control.

ENGLISH
INSTALLATION GUIDELINES
•During the operation of the product, please place the unit at least 2m away from equipments
which involve electric wave such as televisions, radios or wave clocks, in case electrical
interference occurs to such equipments.
•Leave at least 60cm of space from the wall.
The motor may overheat, causing a malfunction.
•Avoid a location where the sensor is exposed to direct wind.
The unit may not operate properly.
•Avoid locations where curtains, etc., come into contact with the intake or air outlet.
Curtains, etc., may become dirty or a malfunction may occur.
•Avoidlocations where the unitis exposed to condensation, dueto drastic temperature changes.
•Place on a stable surface with sufficient air circulation.
• Do not install when there is generation of lampblack, such as in a kitchen, etc.
The unit surface may crack or the sensor may malfunction as a result.
•The wall behind the air outlet may become dirty as time passes. When using the unit for extensive
period in the same location, use a vinyl sheet, etc., to prevent the wall from becoming dirty. In addi-
tion, periodically clean the wall, etc.
FILTER GUIDELINES
•Follow the instructions in this manual for correct care and maintenance of the filters.
HOW SHARP AIR PURIFIER WORKS
An air purifier draws in room air from its air intake, lets the air pass through an Active Carbon Filter
(Deodorizing Filter) and a HEPA Filter (dust collection filter) inside of the unit, then discharges the air
from its air outlet. The air purifier repeats this process by moving its internal fan.
As air passes through, the HEPA Filter can remove dust particles. The Active Carbon Filter gradually
absorbs odor elements as they repeatedly pass through the filter.
(Odor elements are absorbed by HEPA Filter as well.)
Some odor ingredients absorbed by the filters may become separated and may be discharged through
theair outlet andresult in additional odor. Depending on theusage environment, thisodor may become
strong in a shorter period than expected.
In this case, purchase the optional replacement filter kit FZ-P40SF.
NOTE
•The air purifier is designed to remove
air-suspended dust and odor, but not
harmful gases (for example, carbon
monoxide contained in cigarette
smoke). If the odor sources still exist,
it cannot completely remove the odor.
(for example, odors from construction
materials and pet odors).
•It is suggested to open the window a
bit when you are smoking in order to
facilitate ventilation.
E-3
HEPA Filter
Active Carbon Filter

15min. HIGH operation Indicator Light
PART NAMES
MAIN UNIT DISPLAY
Filter Indicator Light
AUTO Operation Indicator Light
Pollen Mode Indicator Light
OFF Timer Display Indicator Lights
Odor Sensor
Remote Control Receiver
CLEAN-SIGN Light
Odor Sensor
Dust Sensor
POWER ON/OFF Button See Page E-8
MODE Button See Page E-8
Sensor Sensitivity Select Switch
Sensorsensitivity canbeadjusted to“Normal ( )”
or “Sensitive ( )” by this switch.
Main Unit
Band See Page E-7
Filter Frame
HEPA Filter (white) See Page E-7,13
(with Microbial Control Filter (blue))
Washable Active Carbon Filter (black)
See Page E-7,12,13
Pre-Filter
Front Panel
Remote Control See Page E-10
Tab
E-4
Fan Speed Indicator Lights
Plasmacluster
Indicator Light
BACK
INCLUDED
Remote Control (1 unit)
Battery (AA battery x 2 )
•Operation manual
Handle
Air Outlet
Date Label
Power Cord
Power Plug
(shape of plug depends on country)

ENGLISH
E-5
Battery Information
•The battery life is about 1 year.
•The batteries for this remote control are for initial use only . Change the batteries
when necessary.
•Incorrect usage of the batteries may cause battery fluid leakage and/or damage.
Take care of the following when handling:
•Whenreplacing the batteries, replace bothbatterieswith new ones ofthesame
type. (Use 2 AA manganese batteries.)
•When not using the unit or remote control for an extended period, remove the
batteries.
• The batteries are for initial use only and may be depleted within 1 year.
INSERTING BATTERIES IN THE REMOTE CONTROL
1
Remove the back cover
Press and slide the back cover to
remove.
2
Insert batteries
Insert batteries with and as
shown below.
3
Close the back cover
REMOTE CONTROL USE
•Operatewith theremotecontrolfacingthemain
unit receiver.
•The signal range is about 7m.
•Make sure there are no objects blocking the
path of the signal.
•Abeep sound will be heard from the main unit
when a signal is received.
NOTE
•Avoid dropping or damaging the remote
control, using in a high humidity condition, in
direct sunlight or near a heat source.
Receiver
Transmitter
PREPARATION

PREPARATION
To maintain the quality of the filters, they are installed in the main unit within plastic bags.
Be sure to remove the filters from the plastic bags before using the unit.
1
Remove the filters
1
Remove the Front Panel.
Pull the bottom of the Front Panel.
3
Remove the Active Carbon Filter
(black) and HEPA Filter (white) from
the plastic bags.
E-6
Be sure to remove the power plug from the wall outlet.
FILTER INSTALLATION
2
Pull out the Filter Frame and remove
the Pre-Filter,Active Carbon Filter and
HEPA Filter.
Front Panel
Filter Frame
Pre-Filter
Pre-Filter
Active Carbon Filter
HEPA Filter
Filter Frame
Active Carbon Filter HEPA Filter

ENGLISH
E-7
outlet.
2
Install the filters
1
Place the HEPA Filter
within the Filter Frame with
the tabs facing up.
Do not install the filter backwards or
the unit will not operate properly.
2
PlacetheActiveCarbonFilter
on top of the HEPA Filter
with the bands (2 places)
facing up.
3
Place the Pre-filter through
the bands (2 places) located
in the corners of the Active
Carbon Filter.
Insert the tabs of the pre-filter into
the associated holes of the Filter
Frame.
5
Fill in the usage start date
on the Date Label.
Use the date as a guide for the
Filter Replacement schedule.
4
Mount the Filter Frame to
the main unit.
Tabs
HEPA Filter
Filter Frame
Band
Active Carbon Filter
HEPAFilter
Filter Frame
Tabs (4 places)
Band
Holes
Main unit
Filter Frame
Band
Date Label

OPERATION
MAIN UNIT OPERATION
Plasmacluster Indicator Light
MODE Button
E-8
Power ON/OFF Button
AUTO operation
Thefanspeedisautomaticallyswitched
(HIGH*,NORMAL,SILENT) depending
ontheamountofpollution in the air.The
sensors detect the pollution for efficient
air purification.
15 min. HIGH*operation
TheunitwilloperateatHIGH*fanspeed
for 15 minutes, then will operate atAuto
operation.
The operation mode is effective when
quick removal of impurities in the air is
desired.
POLLEN mode operation
Theunitwilloperate at HIGH* fan speed
for 10 minutes, then will alternate
between NORMAL and HIGH for 20
minutes.
10 minutes: HIGH fan speed
20 minutes: NORMAL fan speed
20 minutes: HIGH fan speed
Main Unit Controls
• AUTO
•15 min. HIGH
•POLLEN
•SILENT
•NORMAL
•MAX
Clean-Sign Light
Power ON/OFF Button
• Used to start operation (short beep) and stop operation (long beep)
•Plasmacluster Indicator Light and Fan Speed Indicator Light turn on/off.
•Unless unplug the power cord, the operation starts in the previous mode the unit
was operated in.
MODE Button
•The operation mode can be switched.
*HIGH fan speed is an
intermediate speed
between NORMAL
and MAX.
1
2
NORMAL operation
The unit will operate at a fan
speed of NORMAL.
MAX operation
The unit will operate at a fan
speed of MAX.
SILENT operation
The unit will operate quietly
using minimal air intake.
Filter Indicator Light
1
2

ENGLISH
DETERMINING THE BASE IMPURITY RATE
For the first 30 seconds after the power plug is inserted into the wall outlet,
the unit will check the conditions of the air. If operation is set to ON during this
time, the CLEAN-SIGN LIGHT will alternately flash in green, orange and red.
PLASMACLUSTER INDICATOR LIGHT
Plasmacluster ion operation is selected using the remote control.
Blue light
When the Plasmacluster ion operation is in Clean Mode, or in AUTO
Plasmacluster Ion Mode and the air in the room is impure, the light will
activate and the unit will operate in Clean Mode.
Green light
When the Plasmacluster ion operation is in the Ion Control Mode, or in
AUTO Plasmacluster Ion Mode and the air in the room is clean, this light will
activate and the unit will operate in Ion Control Mode.
Light off
There are no Plasmacluster ions being generated.
•The light can be turned off by using the ‘Display ON/OFF Button’ on the
Remote Control. In this case, Plasmacluster ions are generated.
(Please turn off the light when not required.)
CLEAN-SIGN LIGHT
The color changes according to the air condition.
Clean (Green) Slightly Impure (Orange) Very Impure (Red)
ABOUT THE CLEAN-SIGN
•The condition of the CLEAN-SIGN depends on the room air condition
detected by the Dust and Odor Sensor when the plug is inserted into the wall
outlet.
•It is possible to have a green CLEAN-SIGN with impurities in the air at the
time that the air purifier was just introduced to the room environment.After
a while, however, the base impurity rate will be adjusted to detect room air
condition correctly.
•Use the Display ON/OFF Button on the remote control to turn off the
Indicator light.
E-9
FILTER INDICATOR LIGHT
Clean the Active Carbon Filter when the Filter Indicator Light activates.
(The indicator light will activate in about 2 months, when using the unit or 24
hours daily.) (See Page E-12)

Plasmacluster
Plasmacluster Ion Mode Selections
AUTO
Whenpressed,theunitwillswitchbetweenClean
ModeandtheIonControlModeautomaticallyde-
pending on the amount of impurities in the air as
detected by the dust and odor sensors. Clean
Mode will operate for 1 minute when the Auto
function is selected.
(ION CONTROL)
When pressed, the unit will constantly operate in
Ion Control Mode.
The Plasmacluster Ion Indicator Light is green.
(CLEAN)
Whenpressed,theunit will constantly
operate in the Clean Mode, in which
the same numbers of positive and
negative ions are discharged. The
Plasmacluster Indicator Light is blue.
OFF
Thegenerationof ions will cease and
the Plasmacluster Indicator Light will
go out.
E-10
REMOTE CONTROL OPERATION
OPERATION
Operations available with
the Remote Control
• AUTO
•MANUAL
•POLLEN
•OFF TIMER
•15 min. HIGH
•DISPLAY ON/OFF
Plasmacluster Ion mode
selections
• AUTO
•CLEAN
•ION CONTROL
•OFF
Transmitter
Filter Reset Button
When the Washable Active Car-
bon Filter is cleaned and
reinserted into the main unit,
press the Filter Reset Button.
Pollen Mode Operation
Button
See Page E-8
Off Timer Button
The set time switches every time
the button is pressed as shown
below.
1 hour 4 hours
Cancel 8 hours
•The indicator light shows the
remaining time.
•The unit will stop operation
when the timer is up.
POWER ON/OFF Button
•When you press the
POWERON/OFFButton, a
short beep will sound and
operation will start inAUTO
Mode.
•Unless unplug the power
cord,the operation startsin
the previous mode the unit
was operated in.
•To stop, press the POWER
ON/OFF Button again.
A long beep will sound and
operation will stop.
Auto (Fan Speed) Button
The fan speed switches au-
tomatically depending on the
amountofimpuritiesintheair.
Manual (Fan Speed) Button
The fan speed can be
switched among Silent,
NORMALandMAX settings.
15 min. HIGH Button
See page E-8
Display ON/OFF Button
Switches the Plasmacluster
Indicator Light and CLEAN-
SIGNLighteither ONorOFF.

ENGLISH
FILTER CLEANING
Remove the Front Panel, Clean the surface of the Pre-Filter lightly with a vacuum cleaner.
If it is contaminated heavily, remove it from the Filter Frame to wash it.
NOTE
•In case of washing, use a soft brush etc. and cold/warm
water.
•Metal brushes or scrub brushes may cause damage.
•After washing, leave it in the shade until it gets dried.
Then place it back to the frame.
•Never wash or clean the HEPA Filter using the nozzle of
a vacuum cleaner directly.
This will greatly decrease the performance of the filters.
CARE AND MAINTENANCE
To maintain optimum performance of this air purifier, please clean the unit including
the sensors and filters periodically.
When cleaning the unit, be sure to unplug the power cord, and never handle the plug
with wet hands. Electrical shock and/or bodily injury may occur as a result.
MAIN UNIT
To prevent dirt or stains on the main unit, clean as often as necessary. If stains are allowed to
remain, they may become hard to clean.
Wipe with a dry, soft cloth
For stubborn stains or dirt, use a soft cloth dampened with warm water.
Do not use volatile fluids
Benzene, paint thinner, polishing powder, etc., may damage the surface.
Do not use detergents
Detergent ingredients may damage the unit.
Keep the unit away from water
ODOR SENSOR / DUST SENSOR
The sensitivity of the sensor will become
unstable if the odor/dust sensor is dirty or
blocked. Remove dust from the surfaces
of the sensor openings using a vacuum
cleaner.
Hole of odor sensor
E-11
Hole of dust sensor

E-12
CARE AND MAINTENANCE
WASHABLE ACTIVE CARBON FILTER CARE
Care Cycle
When the Filter Indicator Light lights up,
this indicates that the filter needs to be
cleaned. If the unit is kept on 24 hours a
day then the Filter Indicator Light will acti-
vate in about 2 months.
The Filter Indicator Light is for reference.
Clean the filter as often as necessary
when odor persists.
1
Remove
visible dirt
with a
vacuum
cleaner.
2
Fill a large container with
warm water, add a mild
kitchen detergent and stir.
Diluteas indicated
on the detergent
container.
3
Allow the filter to soak ap-
proximately 30 minutes be-
fore washing.
If the filter surface
is very dirty, scrub
with an old tooth-
brush.
CAUTION
Handle with care to
prevent damage to
theactivatedcarbon
particles.
4
Rinse thoroughly with clean
water
CAUTION
If rinsing in a con-
tainer, be sure to
rinse 3 to 4 times so
that the odor is
rinsed thoroughly
from the filter.
5
Remove excess water
Thefilter will be saturated withwaterafter rins-
ing. To decrease drying time, wrap the filter in
an old thick towel so that excess water can be
removed.
CAUTION
Some carbon may adhere to
the towel, but it is harmless.
HAND WASH ONLY!
DO NOT TUMBLE DRY!
6
Dry the filter outdoors
if possible in a well
ventilated area.
CAUTION
•The wet filter is heavy. Fix it securely for drying to
make sure it does not fall down.
•Thefiltertakeslonger to dryinwinter,on rainy days.
Wash it on a day when the weather is good and
dry it in the sun.
Move it indoors at night to prevent freezing.
•Dry the filter outdoors in a well ventilated area. If
dried indoors, the water dripping off the filter may
soil your floor.
•Makesure that theactivatedcarbon hasnotshifted
to one side inside the filter. If it has, distribute it
evenly with your fingers.
•Let the filter dry thoroughly.
If used while the filter is still moist, then the air that
is exhausted from the main unit will have an odor.
It may take 1 or 2 days to dry.
7
Reinstalling the Filter.
Reinstall the filter as shown on Page E-6,7
8
Once the Active Carbon Filter has
been cleaned, connect the power
cord to the outlet and press the Filter
ResetButton on the Remote Control.
•Once the Filter Reset
Button has been acti-
vated, you will hear a
beep sound that
means the unit has
been reset.
•The Filter indicator
light will then go out
automatically.
Filter Reset Button

ENGLISH
FILTER REPLACEMENT GUIDELINES
Depending on the usage environment, air outlet odor may become strong
after several months.
If dust or odors cannot be removed easily, replace the filters.
(Refer to HOW SHARPAIR PURIFIER WORKS E-3)
Guide for filter replacement timing
•The following filter life and replacement period is based on the condition of smoking 10
cigarettes per day and the dust collection/deodorization power is reduced by half compared
with that of new filters.
We recommend to replace the filters more frequently if the product is used in a condition
significantly severer than normal household use.
• HEPA Filter (with Microbial Control Filter) About 5 years after opening
•Active Carbon Filter About 5 years after opening
REPLACING THE FILTERS
1
See page E-6,7 for directions on how
to install the filters when replacing.
2
After replacing the filters:
Be sure to press the Filter Reset Button on the
Remote Control with the power cord connected to the
outlet.
A short beep will be heard and the operation hours
stored in the memory will be reset.
The Filter Indicator Light will then go out automati-
cally.
3
Fill in the usage start date of the filters
on the Date Label.
Replacement Filters
Model: FZ-P40SF
•HEPA Filter (with Microbial Control Filter) : 1 unit
•Active Carbon Filter: 1 unit
Please consult your dealer for purchase of
replacement filters.
Disposal of Filters
Please dispose of replaced filters according to the local disposal laws and regulations.
HEPA Filter (with Microbial Control Filter) materials:
•Filter: Polypropylene
•Frame: Polyester
•Microbial Control Filter: Polypropylene, Polyethylene
Active Carbon Filter Materials:
•Deodorizer: Activated charcoal
•Net: Polypropylene 60%, Polyester 40%
E-13
Date Label

TROUBLESHOOTING
E-14
Before calling for repair, please review the list below, since the problem may not be a unit malfunction.
SYMPTOM REMEDY (not a malfunction)
The Remote Control does not
work • Have the batteries been depleted?
•Are the batteries inserted correctly?
•Is a fluorescent lighting in the room flickering due to service
life?
Odors and smoke are not
removed •Clean or Replace the filters if they appear to be heavily soiled.
(Refer to E-12,E-13)
The CLEAN-SIGN Light lights
green even when the air is
impure
•The air could be impure at the time the unit was plugged in.
(Refer to E-9)
The CLEAN-SIGN Light lights
orange or red even when the air
is clean
•The sensitivity of the sensor becomes unstable when the
opening of the odor sensor is dirty or is clogged.
Clean the dust around the sensor opening using a vacuum
cleaner. (Refer to E-11)
•When in Clean Mode ( or Ion Control Mode), the Plasmacluster
Indicator Light color will not change.
A clicking or ticking sound is
heard from the unit •Clicking sound is emitted when the unit is in the Ion Control
Mode,and ticking sound is emittedwhen theunit is generating
ions.
If the sound is irritating, set the unit away from you.
The discharged air has an
aroma or odor. •Check to see if the filters are heavily soiled.
Replace the filters.
•Plasmacluster Air Purifiers emit small traces of ozone which
may produce an odor. The amount of ozone emitted by the ion
generator is very little which is below the saety levels set by
the IEC 60335-2-65, and it is harmless to the human body.
The Plasmacluster Indicator
Light remains green (or blue)
and does not change
The unit does not operate when
cigarette smoke is in the air. •Is the unit installed in a location that is difficult for the sensor to detect cigarette smoke?
•Are the odor sensor openings blocked or clogged?
(In this case, clean the openings.) (Refer to E-11)
The Filter Indicator Light
remains activated even after
replacing filter.
•After replacing filters, connect the power cord to an outlet and
press the Filter Reset Button on the remote control. (Refer to
E-12)
The Plasmacluster Indicator
Light or the CLEAN-SIGN Light
will not activate.
•Check to see if the Display OFF Mode on the Remote Control
is selected. If so, then press the Display ON/OFF Button on
the Remote Control to activate the indicator light.
(Refer to E-10)
ERROR DISPLAY
LAMP INDICATION REMEDY
The “Silent” Fan Speed Indica-
tor Light blinks. Fan motor disconnected or abnormal.
Operation stops.
•Pressing the ON/OFF button will reset the error display, but if
error occurs again, contact the shop where you purchased the
unit.

ENGLISH
SPECIFICATIONS
E-15
Model
Power supply
Fan speed level
Rated power
Air Flow Volume
Applicable floor surface
Cord Length
Dimensions
Weight
Fan
Speed
Operation
220-240V 50/60Hz
~31m2*
2.5m
415mm(W)x200mm(D)x570mm(H)
6.7kg
MAX
34 W
240 m3/hour
NORMAL
8.1 W
120 m3/hour
SILENT
3.3 W
30 m3/hour
* The applicable floor surface area is the surface area for operating the unit in MAX fan level.
•Applicable floor surface area indicates the space where a certain amount of dust particle can be
removed in 30 minutes.
Standby Power
In order to operate the electrical circuits while the power plug is inserted in the wall outlet, this
product consumes about 0.7W of standby power.
For energy conservation, unplug the power cord when the unit is not in use.
FU-P40S

ＦＵ－Ｐ４０Ｓ＿ＣＨ 2004.4.13, 14:522

中文
C-1
中文
多謝您購買聲寶空氣清新機。請仔細閱讀此說明書﹐以了解正確的使用信息。在使用本產品之
前﹐請務必閱讀“重要安全事項”這一節。
閱讀後請妥善保管此說明書﹐以便日後翻閱。
特性
離子簇控制
本機將根據室內空氣狀況控制正負離子的
比率。
•淨化模式
釋放出大約相等數量的正負離子。
此模式有助減少空氣中的霉菌。
•離子控制模式
大量的負離子存在於大自然環境（如﹕瀑
布、森林）中。 在此模式下﹐負離子被釋
放的比率會增加﹐從而使室內空氣接近大
自然環境。
•自動離子簇模式
本機將會根據灰塵和異味感應器所感測的
空氣污濁程度﹐從而自動轉換為淨化模式
或離子控制模式。
•過濾網
1) 前過濾網
用於吸附較大的灰塵粒子。
2) 可清洗活性碳過濾網
可通過清洗保持其除臭功能。
3) 備有微生物控制過濾網的HEPA過
濾網（高效能微粒空氣過濾網）
可以高效吸附微粒﹐包括花粉和灰
塵。
目錄
重要安全事項 .............................................. C-2
•警告 ............................................................. C-2
•操作本機的注意事項 .................................... C-2
•遙控器限制 .................................................. C-2
•安裝指南 ...................................................... C-3
•過濾網指南 .................................................. C-3
•聲寶空氣清新機操作原理............................. C-3
部件名稱 .................................................. C-4
•主機部件 ...................................................... C-4
•附件 ............................................................. C-4
•背部 ............................................................. C-4
準備工作 .................................................. C-5
•安裝遙控器電池 ........................................... C-5
•使用遙控器 .................................................. C-5
•安裝過濾網 .................................................. C-6
操作 ......................................................... C-8
•主機操作 ...................................................... C-8
•遙控器操作 ................................................ C-10
保養和清潔 ............................................ C-11
•主機 ........................................................... C-11
•異味感應器/灰塵感應器 ............................. C-11
•前過濾網 .................................................... C-11
•可清洗活性碳過濾網保養........................... C-12
•過濾網更換指南 ......................................... C-13
維修前的檢查事項 .................................. C-14
規格 ....................................................... C-15
ＦＵ－Ｐ４０Ｓ＿ＣＨ 2004.4.13, 14:523

重要安全事項
C-2
當使用電器時﹐必須遵守基本的安全預防措施﹐包括以下各方面﹕
警告 — 為了減少電擊、火災或受傷等危險﹕
•在使用空氣清新機之前請閱讀所有注意事項。
•只能使用220-240V的插座。
•如果電線或插頭已經損壞﹐或者壁裝電源插座已經鬆脫﹐請勿使用空氣清新機。
•定期清除電源插頭上的灰塵。
•請勿將手指或異物插入進氣口或排氣口。
•當拔掉電源插頭時﹐必須緊握插頭而不要拉扯電線。
否則可能導致電擊和/或因短路引起火災。
•請勿在靠近氣體設備或壁爐的地方使用空氣清新機。
•當清潔本機或不使用本機時﹐請從壁裝電源插座上拔掉插頭。
否則可能導致因絕緣不良引起的電擊和/或因短路引起的火災。
•如果電源線損壞﹐必須由生產商或其代理、聲寶公司的特約維修中心或具有相同資格的人員來更換﹐
以免發生危險。
•當使用噴霧殺蟲劑時請勿使用本機﹐或若房間內有油渣、焚香時的煙、點燃香煙的火苗、空氣中的化
學氣體或濕氣重時也不要使用本機。
•清潔空氣清新機時請加以小心。腐蝕性強的清潔劑會損壞本機的表面。
•只有聲寶特約維修人員才能維修本空氣清新機。當需要調整、修理或有任何問題時﹐請聯絡就近的維
修人員。
•電池處理前必須從遙控器中取出﹐並且必須安全處理。
操作本機的注意事項
•請勿堵塞進氣口和排氣口。
•不要靠近或在熱源體上（如可能接觸到蒸汽的場所）使用本機。
•移動本機時﹐要一直緊握主機後面的手柄。
•移動時若握前面板﹐會導致前面板脫落﹐從而摔落主機﹐造成傷害。
•請勿在沒有過濾網的情況下操作本機。
這不僅不能增強過濾網的性能﹐反而會導致電擊或故障。
•只能使用一塊軟布清潔表面。
否則本機表面可能會損壞或破裂。
此外﹐還可能導致感應器故障。
遙控器限制
請勿在下列情況下使用遙控器﹕
•任何有變頻器的照明設備或電子燈光設備的地方。
遙控器可能會失靈。在這種情況下﹐使本機遠離這些燈光設備或改變其方向。
•陽光或螢光直接照射的地方。
本機可能接收不到來自遙控器的信號。
ＦＵ－Ｐ４０Ｓ＿ＣＨ 2004.4.13, 14:524
