AIR PURIFIER
with Humidifying Function
OPERATION MANUAL
KC-C70E
KC-C100E
KC-C150E
KC-C70E
KC-C100E
KC-C150E
LUCHTREINIGER
met luchtbevochtiger
GEBRUIKSAANWIJZING
LUFTREINIGER
mit Befeuchtungsfunktion
BEDIENUNGSANLEITUNG
OSAKA, JAPAN
SHARP CORPORATION
Purificateur d’air avec
fonction d’humidification
MANUEL D’UTILISATION
Воздухоочиститель с
функцией увлажнения
РУКОВОДСТВО ПО
ЭКСПЛУАТАЦИИ
OCZYSZCZACZ POWIETRZA
z funkcjąnawilżania
INSTRUKCJA OBSŁUGI
Nemlendirme Fonksiyonlu
HAVA TEMİZLEYİCİ
KULLANMA KILAVUZU
Printed in China
TINS-A248KKRZ 08C- 2
KC-C100ETur.indd1KC-C100ETur.indd1 2008/03/0316:07:292008/03/0316:07:29

NOTE
Please read before operating your new Air Purier
HEPA Filter
Washable Deodorizing Filter
Pre-Filter
The air purier draws in room air from the air intake, passes the air through a Pre-Fil-
ter, a Washable Deodorizing Filter and a HEPA Filter inside of the unit, then discharg-
es the air through the air outlet. The HEPA Filter can remove 99.97% of dust particles
as small as 0.3 microns that pass through the lter and also helps absorb odours. The
Washable Deodorizing Filter gradually absorbs odours as they pass through the lter.
Some odours absorbed by the lters may break down over time, resulting in additional
odour. Depending on the usage environment, especially when the product is used in
extreme environments (significantly more severe than normal household use), this
odour may become strong in a shorter period than expected. If the odour persists, the
lters should be replaced.
• The air purier is designed to remove air-suspended dust and odour, but not harmful gases (for ex-
ample, carbon monoxide contained in cigarette smoke). If the source of the odour still exist, the air
purier may not completely remove the odor.
(Common illustration has used “KC-C100E”.)
KC-C100E_Eng.indd 2 07.11.13 1:24:34 PM

ENGLISH
DEUTSCH
NEDERLANDS
РУССКИЙ
POLSKI
FRANÇAIS
E-1
ENGLISH
Thank you for purchasing this SHARP Air Pu-
rier. Please read this manual carefully be-
fore using the air purier.
After reading, keep the manual in a conven-
ient location for future reference.
FEATURES CONTENTS
IMPORTANT SAFETY INSTRUCTIONS
...E-2
• WARNING ..................................................E-2
• CAUTIONS CONCERNING OPERATION .E-3
• INSTALLATION GUIDELINES....................E-3
• FILTER GUIDELINES ................................E-3
PART NAMES.............................................E-4
• ILLUSTRATIVE DIAGRAM.........................E-4
• BACK..........................................................E-4
• FRONT MONITOR .....................................E-5
PREPARATION FOR USE............................E-6
• FILTER INSTALLATION .............................E-6
• REFILLING WATER TANK .........................E-7
OPERATION ...............................................E-8
• MAIN UNIT DISPLAY .................................E-8
• CLEAN AIR & HUMIDIFY MODE ...............E-8
• CLEAN AIR MODE.....................................E-9
• CLEAN ION SHOWER MODE ...................E-9
• FAN SPEED BUTTON................................E-9
• Plasmacluster ON/OFF BUTTON.............E-10
• LIGHTS ON/OFF BUTTON ......................E-10
• WATER SUPPLY INDICATOR LIGHT......E-10
•
ADJUSTMENT OF SENSOR DETECTION SENSITIVITY
..E-10
CARE AND MAINTENANCE .................E-11
• FILTER INDICATOR LIGHT .....................E-11
• BACK PANEL AND SENSORS ................E-11
• UNIT ........................................................E-11
• WATER TANK...........................................E-12
• WASHABLE DEODORIZING
FILTER .....................................................E-12
• HUMIDIFYING TRAY ...............................E-13
• HUMIDIFYING FILTER.............................E-14
• FILTER REPLACEMENT GUIDELINES .....E-15
TROUBLESHOOTING ............................E-16
SPECIFICATIONS....................................E-18
INFORMATION ON PROPER DISPOSAL
..E-19
Unique Combination of Air Treatment
Technologies
Triple Filtration System + Plasmacluster
+ Humidication
(Common illustration has used “KC-C100E”.)
TRAPS DUST*
Washable pre-filter traps dust and other
large airborne particles.
DECREASES ODOURS
Washable deodorizing lter absorbs many
common household odours.
REDUCES POLLEN & MOLD*
HEPA filter traps 99.97% of particles as
small as 0.3 microns.
FRESHENS
Plasmacluster treats the air similar to the
way nature cleans the environment by
emitting a balance of positive and negative
ions.
HUMIDIFIES
Runs up to 10 hours per lling.**
*When air is drawn through the lter sys-
tem.
**Room size:
up to 48m2 (KC-C150E)
up to 38m2 (KC-C100E)
up to 26m2 (KC-C70E)
Sensor Technology continuously monitors
air quality, automatically adjusting opera-
tion based on detected air purity and hu-
midity.
KC-C100E_Eng.indd 3 07.11.13 1:24:34 PM

E-2
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions should be followed, including the
following:
WARNING - To reduce the risk of electrical shock, re or injury to persons:
NOTE - Radio or TV Interference
If this air purier should cause interference to radio or television reception, try to correct the interfer-
ence by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation distance between the unit and radio/TV receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is con-
nected.
• Consult the dealer or an experienced radio/TV technician for help.
• Read all instructions before using the unit.
• Use only a 220~240 volt outlet.
• Do not use the unit if the power cord or plug is damaged or the connection to the wall out-
let is loosened.
• Periodically remove dust from the plug.
• Do not insert ngers or foreign objects into the air intake or air outlet.
• When removing the power plug, always hold the plug and never pull on the cord.
Electrical shock and/or re from a short circuit may result.
• Do not remove the plug when your hands are wet.
• Do not use this unit near gas appliances or replaces.
• When relling the Water Tank, cleaning the unit, or when the unit is not in use, be sure to unplug
the unit. Electrical shock and/or re from a short circuit may result
• If the power cord is damaged, it must be replaced by the manufacturer, its service agent, a
Sharp authorized Service Centre or similarly qualied person in order to avoid a hazard.
• Do not operate when using aerosol insecticides or in rooms where there is oily residue, incense,
sparks from lit cigarettes, chemical fumes in the air, or in locations where the unit may get wet,
such as a bathroom.
• Be cautious when cleaning the unit. Strong corrosive cleansers may damage the exterior.
• Only a Sharp Authorized Service Centre should service this air purier. Contact the nearest Serv-
ice Centre for any problems, adjustments, or repairs.
• When carrying the unit, remove the Water Tank and Humidifying Tray rst and hold the unit by
handles on both sides.
• Do not drink the water in the Humidifying Tray or Water Tank.
• Change the water in the Water Tank daily with fresh tap water and regularly clean the Water Tank
and Humidifying Tray. (See E-12 and E-13). When unit is not in use, dispose of the water in the
Water Tank and Humidifying Tray. Leaving water in the Water Tank and/or Humidifying Tray may
result in mold, bacteria, and bad odours.
In rare cases, this bacteria may cause harmful physical effects.
KC-C100E_Eng.indd 4 07.11.13 1:24:34 PM

ENGLISH
DEUTSCH
NEDERLANDS
РУССКИЙ
POLSKI
FRANÇAIS
E-3
FILTER GUIDELINES
• Follow the instructions in this manual for correct care and maintenance of the lters.
CAUTIONS CONCERNING OPERATION
• Do not block the intake and/or air outlet.
• Do not use the unit near or on hot objects, such as stoves or heaters or where it may come into
contact with steam.
• Always operate the unit in an upright position.
• Hold the unit by using the handles on both sides when moving.
Do not move when the unit is operating.
• Do not operate the unit without the lters, Water Tank, and Humidifying Tray properly in-
stalled.
• Do not wash and reuse the HEPA lter.
Not only does it not improve lter performance, it may cause electric shock or malfunction.
• Clean the exterior with a soft cloth only.
The unit surface may be damaged or cracked.
In addition, the sensors may malfunction as a result.
• Frequency of maintenance required (descaling) will depend on the hardness or the impuri-
ties of the water that you use; the harder the water the more often descaling will be neces-
sary.
• Keep the unit away from water.
INSTALLATION GUIDELINES
• When using the unit, place at least 2m away from equipment utilizing electric waves such
as televisions or radios to avoid electrical interference.
• Avoid a location where the sensor is exposed to direct wind.
The unit may not operate properly.
• Avoid use in locations where furniture, fabrics or other items may come in contact with and
restrict the air intake and/or air outlet.
• Avoid use in locations where the unit is exposed to condensation or drastic temperature
changes. Appropriate conditions are when room temperature is between 5-35ºC.
• Place on a stable surface with sufcient air circulation.
When placing the unit on a heavily carpeted area, the unit may vibrate slightly.
Place the unit on an even surface to avoid water leakage from the Water Tank and/or Humidifying
Tray.
• Avoid locations where grease or oily smoke is generated.
The unit surface may crack or the sensor may malfunction as a result.
• Leave about 60cm of clearance when placing near a wall.
The wall directly behind the air outlet may become dirty over time. When using the unit for an ex-
tended period of time in the same location, periodically clean the wall and protect the wall with a
vinyl sheet, etc. to prevent the wall from becoming dirty.
KC-C100E_Eng.indd 5 07.11.13 1:24:35 PM

PART NAMES
E-4
ILLUSTRATIVE DIAGRAM - FRONT
Air Outlet
Main Unit
BACK
Handle(2 locations left and right)
Sensors
• Dust Sensor
• Temperature / Humidity Sensor
Tank Handle
Water Tank
(For humidifying)
Humidifying Filter
Tank Cap
Float
Humidifying Tray
Power Cord
Plug
Air Outlet
HEPA Filter (white)
Washable Deodorizing
Filter (black)
Tabs
Back Panel (Pre-Filter)
Air Inlet
Date Label
(Rating Label)
Filter Frame
KC-C150E, KC-C100E KC-C70E
Main Unit Display
Front Monitor
Odour Sensor
Air Outlet
Main Unit Display
Front Monitor
Main Unit
(Shape of plug depends on country.)
KC-C100E_Eng.indd 6 07.11.13 1:24:35 PM

ENGLISH
DEUTSCH
NEDERLANDS
РУССКИЙ
POLSKI
FRANÇAIS
E-5
FRONT MONITOR
Indicates condition and humidity of room air.
Plasmacluster Indicator
Light(blue)
Blue : Plasmacluster ON
Humidity Indicator Light
(green)
Displays the approximate hu-
midity level in the room. Only
displays when the Clean Air
& Humidify Mode is selected.
Humidity setting cannot be
adjusted.
This light will illuminate when the water
tank needs to be relled.
(Ex.) At 60% humidity
Water Supply Indicator Light(red)
DUST MONITOR
The dust sensor continuously monitors
the air and changes colour depending
on air purity.
Clean Very Impure
all redall green yellow
Light off : Plasmacluster OFF
Sensor Reading
Plasmacluster Indicator
Light(blue)
Blue : Plasmacluster ON
Humidity Indicator Light
(green)
Displays the approximate hu-
midity level in the room. Only
displays when the Clean Air
& Humidify Mode is selected.
Humidity setting cannot be
adjusted.
This light will illuminate when the water tank
needs to be relled.
Water Supply Indicator Light(red)
DUST MONITOR
The dust sensor continuously monitors
the air and changes colour depending
on air purity.
Sensor Reading
Clean Very Impure
all redall green yellow
Light off : Plasmacluster OFF
High - 65% or more
Med - 65% or less of 40% or more
Low - 40% or less
KC-C100E, KC-C150E
KC-C70E
ODOUR MONITOR
The odour sensor continuously monitors
the air and changes colour depending on
odour intensity.
green yellow red
storongfaint Odour in the room
KC-C100E_Eng.indd 7 07.11.13 1:24:46 PM

E-6
4
3
Fill in the usage
start date on the
Date Label.
Use the usage start date
as a guide for when the
lters should be replaced.
Date Label
Unplug the unit before installing
or adjusting the lters.
PREPARATION FOR USE
2
1
Remove the Back Panel.
Install the lters
Install the HEPA Filter.
To maintain the quality of the lters, they are packed in plastic bags and placed in the
unit. Be sure to remove the lters from the plastic bags and replace the lters in the
unit before initial use.
1
Gently push down on the
tabs, then tilt and remove the
back panel.
Remove the lters
2
Remove the Wash-
able Deodorizing Filter
(black) and HEPA Filter
(white) from the plastic
bags.
Back Panel
HEPA Filter
Washable
Deodorizing
Filter
HEPA Filter
Insert the Back Panel’s 2 bottom tabs
(left and right) into the small holes in the
unit, and slide the Washable Deodor-
izing Filter between the HEPA Filter and
the Back Panel.
Gently push in
the upper tabs
(left and right) to
lock in place.
FILTER INSTALLATION
1
2
Tabs on the top
Washable Deodorizing Filter
Back Panel
Bottom tabs
Upper tabs
Installing the filter backwards
will affect the performance of
the unit.
Please make sure that the HEPA Filter is
placed in proper orientation.
Tab
KC-C100E_Eng.indd 8 07.11.13 1:24:49 PM

ENGLISH
DEUTSCH
NEDERLANDS
РУССКИЙ
POLSKI
FRANÇAIS
REFILLING THE WATER TANK
The unit can be used in the Clean Air Mode with-
out putting water in the Water Tank. When using
the Clean Air & Humidify Mode, or the CLEAN ION
SHOWER Mode, the Water Tank should be lled with
water.
2
1
3
Remove the Water Tank by unlatching the
top.
Remove the Water Tank Cap and care-
fully ll the Water Tank with tap water.
• Change the water in the Water Tank every day with
fresh tap water.
After lling, securely tighten the Tank Cap.
• Check to see that there is no water leaking.
• Be sure to wipe off any excess water on the outside of
the Water Tank.
• When carrying the Water Tank, hold it with both hands
so that the Water Tank opening is facing up.
Replace the Water Tank in the unit.
• The top latch will “click” in place when the Water Tank
is properly installed.
4
CAUTION
Tank Handle
Water Tank
Tank Cap
Water Tank
E-7
Humidifying
Tray
tighten
• Do not expose the unit to water. Short circuit and/or electrical shock may occur as a result.
• Do not use hot water (40ºC), chemical agents, aromatic substances, dirty water, or other
damaging substances, deformation and/or malfunction may occur.
• Use only fresh tap water. Use of other water sources may promote the growth of mold, fun-
gus and/or bacteria.
KC-C100E_Eng.indd 9 07.11.13 1:24:50 PM

E-8
CLEAN AIR & HUMIDIFY MODE
OPERATION
Use the Clean Air & Humidify Mode to quickly clean the air, reduce odours and to humidify.
Fill Water Tank. (See E-7)
About Automatic Humidify Mode
1
2
3
Press the FAN SPEED Button to select the de-
sired fan speed.
Press the CLEAN AIR & HUMIDIFY MODE Button.
• If the power cord was not unplugged between uses, the
unit will automatically re-start at the previously selected
settings.
About the Temperature/Humidity Sensors. The Temperature/
Humidity sensors automatically detect and adjust humidity
according to changes in room temperature. Depending on
the size and humidity of the room, humidity may not reach
55~65%. In such cases, it is recommended that CLEAN AIR
& HUMIDIFY/MAX MODE be used.
Temperature
~18ºC
18ºC~24ºC
24ºC~
Humidity
65%
60%
55%
Power OFF Button
Power ON Button
Light ON/OFF Button
Fan Speed Button/
Indicator Light (green)
CLEAN ION SHOWER MODE Button/
Indicator Light (blue)
Press any of the buttons to se-
lect mode and start the unit.
Clean Air & Humidify MODE Button/
Indicator Light (green)
Clean Air MODE Button/
Indicator Light (green)
MAIN UNIT DISPLAY
• Indicator lights will show the fan speed
currently selected.
Press the Power OFF Button to turn the unit off.
Filter Reset Button/
Indicator Light (red)
Plasmacluster ON/OFF Button/
Indicator Light (green)
KC-C100E_Eng.indd 10 07.11.13 1:24:51 PM

ENGLISH
DEUTSCH
NEDERLANDS
РУССКИЙ
POLSKI
FRANÇAIS
Press the CLEAN AIR MODE Button on the display .
E-9
Use the Clean Air Mode when additional humidity is not required.
1
2
• If the power cord was not unplugged between uses, the unit
will automatically re-start at the previously selected settings.
Press the FAN SPEED BUTTON to select the
desired fan speed.
CLEAN ION SHOWER MODE
1
Press the CLEAN ION SHOWER MODE Button
on the display to select this mode.
When the operation nishes, the unit will return to the prior
operation.
CLEAN AIR MODE
CLEAN ION SHOWER Mode with humidication releases concentrated Plasmacluster ions.
By repeating strong and gentle airow cycles, the unit effectively removes airborne dust, pol-
len, mold and allergens from the air drawn through the lter system. Water must be in the Wa-
ter Tank when this mode is selected.
The unit humidies when there’s water in the Water Tank, and it operates without humidifying
when there’s no water in it.
• Indicator lights will show the fan speed
currently selected.
Press the Power OFF Button to turn the unit off.
Press the Power OFF Button to turn the unit off.
The Fan Speed
Please note the fan speed cannot be sdjusted during the CLEAN ION SHOWER MODE.
AUTO operation
MAX operation
MEDIUM operation
LOW operation
The fan speed is automatically switched (between HIGH and
LOW) depending on the amount of impurities in the air. The
sensors detect impurities for efcient air purcation.
The unit will operate at maximum fan speed.
The unit will operate at medium fan speed.
The unit will operate quietly using minimal air intake.
*HiGH fan speed is an intermediate speed between MEDIUM and MAX.
KC-C100E_Eng.indd 11 07.11.13 1:24:52 PM

E-10
OPERATION
WATER SUPPLY INDICATOR LIGHT
When the Water Tank is empty, the Water Supply Indicator
Light will ash to indicate that the Water Tank should be relled.
Please note the light will not flash even when the Water
Tank is empty during the Clean Air Mode and the Clean ION
SHOWER Mode.
Sound indicator setting for water supply.
In addition to the Indicator Light, the unit can be set to signal
with an audible beep when the Water Tank is empty. With the
unit OFF, press the Lights ON/OFF button for 3 seconds to turn
the audible signal ON.
Cancellation
To cancel the audible signal, with the unit OFF, press the Lights
ON/OFF button again more than 3 seconds.
ADJUSTMENT OF SENSOR DETECTION SENSITIVITY
Set to ‘low” if the DUST MONITOR and ODOUR MONITOR is constantly red to reduce
sensitivity, and set to ‘high’ if the DUST MONITOR and ODOUR MONITOR is constantly
green to increase sensitivity.
1
With the unit OFF, press the Fan Speed Button for 3 seconds.
The Fan Speed Indicator Lights will display the currently set sensor sensitivity level. The
factory setting is Standard, indicated by the MED light.
2
3
Press the Fan Speed Button to set
the desired sensor sensitivity.
Refer to the diagram on the right to select the
desired sensor sensitivity level.
Press the Power OFF Button.
Note that if the Power OFF Button is not pushed
within 8 seconds of adjusting sensor sensitiv-
ity, the setting will be saved automatically. The
sensor sensitivity setting will be saved even if
the unit is unplugged.
Sensor Detection
sensitivity
Fan Speed
Indicator Light
LIGHTS ON/OFF Button
Press this button to turn Front Panel monitor lights ON and
OFF.
High
Standard
Low
Plasmacluster ON/OFF Button
Press the Plasmacluster ON/OFF Button to turn Plasmaclus-
ter Ion Mode ON and OFF. A green light will indicate that the
Plasmacluster Ion Mode in ON.
KC-C100E_Eng.indd 12 07.11.13 1:24:53 PM

ENGLISH
DEUTSCH
NEDERLANDS
РУССКИЙ
POLSKI
FRANÇAIS
E-11
CARE AND MAINTENANCE
UNIT
To prevent dirt or stains on the unit, clean regularly. If stains are allowed to remain, they may
become difcult to remove.
Wipe with a dry, soft cloth
For stubborn stains or dirt, use a soft cloth dampened with warm water.
Do not use volatile uids
Benzene, paint thinner, polishing powder, may damage the surface.
Do not use detergents
Detergent ingredients may damage the unit.
FILTER INDICATOR LIGHT
The Filter Indicator Light will illuminate as a reminder to perform mainte-
nance of the Back Panel, Sensors, and Humidifying Filter. The Indicator
Light will turn on after approximately 720 hours of use.
After performing maintenance, reset the Filter Indicator. Plug the unit in,
turn power ON, and press the RESET button for 3 seconds. The Filter
Indicator Light will go off. Even if the lter indicator light is already off, the
RESET button should be pressed to reset the maintenance timer.
BACK PANEL and SENSORS
Gently remove dust from the sensor opening and
the back panel, using a vacuum cleaner attach-
ment or similar tool.
Remove the sensor lter and tap it lightly over a
sink or trashcan to dislodge dust. If it is very dirty,
wash it gently with lukewarm water. Do not use
any detergents or chemicals of any kind to
clean the lter. Dry lter completely before re-
placing in the unit. Do not operate unit without all
lters properly installed.
SENSOR FILTER CARE
Sensor
Back Panel
Sensor Filter
To maintain optimum performance of this air purier, please clean the unit including
the sensor and lters periodically.
When cleaning the unit, be sure to rst unplug the power cord, and never handle the
plug with wet hands. Electrical shock and/or bodily injury may occur as a result.
After 720 hours of use
(30days ×24hours = 720
Whenever dust accumulates
on the unit or every 2 months
Whenever dust accumulates on the unit or every 2 months
Care Cycle
Care Cycle
Care Cycle
KC-C100E_Eng.indd 13 07.11.13 1:24:54 PM

E-12
WATER TANK
1
3
Drip dry lter to remove excess water.
HAND WASH ONLY!
DO NOT DRY IN CLOTHES
DRYER!
• Avoid drying lter outdoors during inclement weather (e.g. rain or cold temperatures).
Do not allow lter to freeze.
• If lter is dried indoors, take precautions, such as placing towels, etc under the lter to prevent
water damage to the oor.
Rinse the inside of the tank by leaving a small amount
of lukewarm water inside, closing the tank cap firmly,
and shaking the tank. Mild household detergents may be
used to clean the inside of the tank, but detergent should
be diluted and the tank should be thoroughly rinsed to
remove all detergent residue.
Tank Cap
Water Tank
2
WASHABLE DEODORIZING FILTER CARE
Rinse dirt from the WASHABLE DEODORIZING
FILTER under lukewarm water.
Dry lter completely in a well ventilated
area. If possible, dry outdoors.
CAUTION
4
CARE AND MAINTENANCE
Replace the lter in unit. (See E-6).
CAUTION
(Note the Water Tank is not dishwasher safe.)
Dry lter completely before replacing to prevent odours.
Do not operate unit without all lters properly installed.
Dry lter in a sideways position to avoid warping of the lter.
• When washing the lter for the rst time, the rinse water may
be brown. This does not affect deodorization performance.
• Avoid bending or folding the lter when washing.
Every day when Humidifying
When an unpleasant odour is noticed
from the air outlet.
When performance of lter seems to be
reduced and odours persist.
Care Cycle
Care Cycle
KC-C100E_Eng.indd 14 07.11.13 1:24:55 PM

ENGLISH
DEUTSCH
NEDERLANDS
РУССКИЙ
POLSKI
FRANÇAIS
E-13
Frequency of maintenance cycle will depend on the hardness
of the water. Avoid spilling water when removing or cleaning
the tray.
Remove the Water Tank and Humidifying Tray.
1
2
3
Rinse the inside of the Humidifying
Tray with lukewarm water to remove
impurities.
• Do not remove the
Styrofoam oat .
• Clean difcult-to-
reach parts with a
cotton-tipped swab
or tooth brush.
Unlatch the Wa-
ter Tank rst, then
remove the tray.
Use both hands
when pulling out the
Humidifying Tray to
avoid spilling water.
1
Dilute detergent according to
instructions on the container.
Clean difcult-to-reach parts
with a cotton swab or tooth
brush.
2
CAUTION
Humidifying Filter
Water Tank
Tank Handle
Humidifying
Tray
Float
If the Styrofoam oat comes off,
replace by inserting the tabs of
the Float into the holes in the
Humidifying Tray as shown in the
diagram.
When Water Deposits are Difcult to Remove
• Use only mild kitchen detergents to
clean the Humidifying Tray. Use of
non-designated chemicals or deter-
gents can cause deformation, tarnish-
ing, cracking (water leakage).
Insert the oat below
this tab.
Insert the tab on
the other side of the
oat into the hole.
Insert the tab of the
oat into the hole.
Fill Humidifying Tray half-
way with lukewarm water,
add a small amount of mild
kitchen detergent, and leave
to soak for about 30 min-
utes.
Rinse the Humidifying
Tray with lukewarm water.
• Rinse until all detergent residue
is removed.
• Inadequate rinsing may
cause the detergent
odor or changes
in the shape/ color
of the main unit.
4
Replace the Humidifying Filter and re-
place the Humidifying Tray in the unit.
The Humidifying Filter will not
t if placed in backwards. Be
sure there is no gap between
the Humidifying tray and the
unit when the Humidifying Tray
is replaced in the unit. The unit
may not operate properly if the
Humidifying Tray is not properly
replaced in the unit.
D o n o t h o l d
this part.
Remove the Water Tank and Humidifying
Filter from the Humidifying Tray. Drain ac-
cumulated water by tilting the Humidify-
ing Tray slowly.
Color:Gray
HUMIDIFYING TRAY
1 month
Care Cycle
KC-C100E_Eng.indd 15 07.11.13 1:24:58 PM

E-14
CARE AND MAINTENANCE
HUMIDIFYING FILTER
Frequency of maintenance cycle will depend on the hardness or the impuri ties of the water
that you use; the harder the water the more often descaling will be necessary.
1
6
* Do not scrub the Humid-
ifying Filter, rinse gently
under lukewarm water
only.
5
Remove the Water Tank and
Humidifying Tray.
2
Remove the Humidifying Filter
from the Humidifying Tray.
Avoid spilling water from the Humidifying Tray.
3
Preparing the descaling solu-
tion.
Citric acid, available at some drugstores,
or 100% bottled lemon juice are used
for descaling. Choose either one to use,
and prepare the descaling solution.
Pre-soak the Humidifying Filter
in the solution for 30 minutes
before cleaning.
4
When using lemon juice,
it is recommended to pre-
soak longer than citric
acid.
Rinse the Humidifying Filter
repeatedly with lukewarm water
to remove all the solution resi-
due.
Inadequate rinsing may cause odour and
affect the performance and/or appear-
ance of the unit.
Attach the Humidifying Filter
to the Humidifying Tray, and
replace the Humidifying Tray in
the unit.
•The Humidifying Filter will not fit if
placed in backwards. Be sure there is
no gap between the Humidifying tray
and the unit when the Humidifying Tray
is replaced in the unit. The unit may not
operate properly if the Humidifying Tray
is not properly replaced in the unit.
7
Plug in the unit, turn power ON,
and press the Filter Reset But-
ton on the display more than 3
seconds to reset.
Water Tank
Humidifying
Tray
Humidifying lter
Humidifying
Tray
Pay attention not to spill water when cleaning the lter.
•When not using the
unit for a long pe-
riod of time, dry the
Humidifying Filter
completely before
replacing.
Care Cycle Once a month or when the Filter Indicator Light is on.
<For using citric acid>
Dissolve 3 teaspoons of citric acid and 2
1/2 cups of lukewarm water in a suitable
container, and stir well.
<For using lemon juice>
100% bottled lemon juice can be used
for descaling. Use only 100% bottled
lemon juice with no pulp (strain juice
if necessary). Combine 1/4 cup lemon
juice and 3 cups of lukewarm water in a
container large enough to hold the Hu-
midifying Filter and stir well. You may notice reddish-brown or white
deposits forming on the surface of the Hu-
midifying Filter. These impurities (calcium,
etc.) are due to the impurities contained
in tap water; this is not a defect. Replace
the Humidifying Filter when it is covered
completely in white deposits.
KC-C100E_Eng.indd 16 07.11.13 1:24:59 PM

ENGLISH
DEUTSCH
NEDERLANDS
РУССКИЙ
POLSKI
FRANÇAIS
E-15
Filter life will vary depending on the room environment, usage, and location of the unit.
If dust or odours persist, replace the lters.
(Refer to “Please read before operating your new Air Purier”)
Guide for lter replacement timing
Up to 5 years after opening
Filter life can be greatly reduced depending on the room environment. Cigarette smoke, pet dan-
der, and other airborne particles can reduce lter life. Check lters regularly and replace as neces-
sary.
• True HEPA Filter: 1unit
Model FZ-C150HFE(for KC-C150E)
FZ-C100HFE(for KC-C100E)
FZ-C70HFE (for KC-C70E)
• Washable Deodorizing Filter: 1unit
Model FZ-C150DFE(for KC-C150E)
FZ-C100DFE(for KC-C100E)
FZ-C70DFE (for KC-C70E)
• Humidifying Filter: 1unit
Model FZ-C100MFE
Humidifying Filter
Replacement Filters
HEPA Filter
Washable Deodorizing Filter
The lter can be repeatedly used after washing, or it can be replaced.
Up to 2 years after opening
• Mineral deposits (white, black, or red masses) which are not removed after cleaning or the Hu-
midifying Filter is still dirty.
• Filter is severely damaged or warped.
1. Replace lters according to the instructions provided with the replacement lters.
2. Use the date labels as a reminder for when the lters should be replaced.
Disposal of Filters
Replacing the Filters
Please dispose of used lters according to any local laws and regulations.
HEPA Filter materials:
• Filter: Polypropylene • Frame: Polyester
Washable Deodorizing Filter Materials:
• Polyester, Rayon, Activated charcoal
Humidifying Filter materials:
• Rayon, Polyester
Filter life can be greatly reduced depending on the room environment. Even if 2 years have not
passed, replace the Humidifying Filter if you notice the following:
(Gray)
Filter Frame(Gray)
(white)
Filter Frame(white)
FILTER REPLACEMENT GUIDELINES
Humidifying lter
KC-C100E_Eng.indd 17 07.11.13 1:24:59 PM

E-16
TROUBLESHOOTING
Before calling for service, please review the Troubleshooting chart below, since the problem may not
be a unit malfunctions.
SYMPTOM REMEDY(not a malfunction)
Odours and smoke are not
removed.
• Clean or replace the filters if they appear to be heavily
soiled. (See E-11,E-12,E-14)
The Front Monitor illuminates
green even when the air is im-
pure.
• The air could be impure at the time the unit was plugged in.
Unplug the unit, wait one minute, and plug the unit in again.
The Front Monitor illuminates or-
ange or red even when the air is
clean.
• Sensor operation is affected if the dust sensor openings are
dirty or clogged. Gently clean the dust sensors (See E-11).
A clicking or ticking sound is
heard from the unit.
• Clicking or ticking sounds may be audible when the unit is
generating ions.
The discharged air has an odour. • Check to see if the lters are heavily soiled.
• Clean or replace the lters.
• Plasmacluster Air Puriers emit small traces of ozone which
may produce an odour.
• Is the unit installed in a location that is difcult for the sen-
sor to detect cigarette smoke?
• Are the dust sensor openings blocked or clogged?
(In this case, clean the openings.) (See E-11)
The unit does not operate when
cigarette smoke is in the air.
Filter Indicator Light is illu-
minated. • After replacing lters, connect the power cord to an outlet
and press the Filter Reset Button. (See E-11)
The Front Monitor are turned
off.
• Check to see if the Lights OFF Mode selected. If so, then
press the Lights ON/OFF Button to activate the indicator
lights. (See E-10)
The Water Supply Indicator Light
does not illuminate when the
tank is empty.
• Check Styrofoam oat for impurities. Clean the Humidifying-
Tray. Ensure unit is located on a level surface.
Water lever in the tank does not
decrease or decreases slowly.
• Check to see if the Humidifying Tray and Water Tank are
correctly installed. Check the Humidifying Filter.
• Clean or replace the lter when it is heavily soiled
(See E-14 and E-15).
The Front Monitor lights change
colour frequently. • The Front Monitor lights automatically change colours as
impurities are detected by the dust sensor and odour sen-
sor.
KC-C100E_Eng.indd 18 07.11.13 1:24:59 PM

ENGLISH
DEUTSCH
NEDERLANDS
РУССКИЙ
POLSKI
FRANÇAIS
E-17
ERROR DISPLAY
LAMP INDICATION REMEDY
Flashing of the Fan Speed Indicator Light
'AUTO' or the 'CLEAN ION SHOWER' Light.
Flashing of the Humidity Indicator Light '30'.
Flashing of the Clean Air & Humidify
Indicator Light.
Abnormal temperature-
humidity sensor
If error occurs again, contact the Sharp Service Centre.
Flashing of the Fan Speed Indicator Light
'LOW'.
ERROR DETAILS
Problem in circuit board
Abnormal fan motor
Abnormal humidity lter
Unplug the unit, wait one minute,
and plug the unit in again.
Turn power OFF to cancel the
error display, wait one minute,
and then turn power ON.
Flashing of the Humidity Indicator Light '70'.
Verify if the Humidifying Filter,
Humidifying Tray and Water
Tank are properly installed and
then turn power ON again.
KC-C100E_Eng.indd 19 07.11.13 1:25:00 PM

SPECIFICATIONS
Standby Power In order to operate the electrical circuits while the power plug is inserted in the wall outlet, this product consumes about 0.7W of standby power. For energy conservation, unplug the power cord when the unit is not in use.
*1 •The Recommended Room Size is appropriate for operating the unit of maximum fan speed. •The Recommended Room Size area indicates the space where a certain amount of dust particles can be removed in 30 minutes.
*2 •Humidication Amount changes in accordance with indoor and outdoor temperature and humidity. Humidication Amount increases as temperatures rise or humidity decreases. Humidication Amount decreases as temperatures decrease or humidity rises. •Measurement Condition : 20ºC, 30% humidity (JEM1426)
*3 •The class of the HEPA lter by EN1822 is H10.
E-18
Dust collection Deodorization
Cord Lenght(m) Dimensions(mm) Weight(kg)
KC-C100E
220~240V 50/60Hz
CLEAN AIR
CLEAN AIR & HUMIDIFY
MAX MED LOW
398(W)×288(D)×627(H)
11.0
Model Power supply Fan Speed Adjustment
Fan Speed (m3/hour) Rated Power(W) Noise Level(dBA) Humidication(mL/hour)*2
Recommended Room Size(m2)*1 Water Tank Capacity(L) Sensors
Filter type
KC-C70EKC-C150E
Dust/odour/Temperature & Humidity Dust/Temperature & Humidity
HEPA with Microbial control *3
Washable Deodorizing
2.0
378(W)×265(D)×586(H)
9.0
360(W)×233(D)×550(H)
8.0
MAX MED LOW MAX MED LOW
396
56 51
390
54 50
730
234
18.5
39
234
20 39
500
84
5.5(4.9)
17
120
8.8(8.2)
25
300
306
41 47
288
40 47
600
168
11.6
35
168
13.5
35
400
60
3.8(3.3)
15 84
6.8(6.3)
22
230
210
26 45
186
21 42
450
132
9.5
34
132
11.5
34
330
48
3.7(3.4)
15 54
6.1(5.8)
20
170
Fan Speed (m3/hour) Rated Power(W) Noise Level(dBA)
4.3
~48 ~38 ~26
4.0 3.0
KC-C100E_Eng03.03.indd 20 08.3.3 3:44:33 PM
