R
KI-A60E
Jenis berdiri sendiri
AIR PURIFIER
with Humidifying Function
OPERATION MANUAL
ENGLISH
PEMBERSIH UDARA
dengan Fungsi Melembap
BUKU PANDUAN OPERASI
MALAYSIA
Free standing type
Device of this mark is a trademark
of Sharp Corporation.
"Plasmacluster" and "Device of a cluster of
grapes" are registered trademarks of Sharp
Corporation in Japan, USA and elsewhere.
"High-Density 25000 is a trademark of
Sharp Corporation.
* The number in this technology mark indicates an
approximate number of ions supplied into air of
1 cm3, which is measure around the centre of a
room with the “high-density plasmacluser 25000”
applicable floor area (at 1.2 m height above the
floor) at the medium wind volume in humidifying &
air purifying mode, or in air purifying mode, when
a humidifier/air purifier or an air purifier using the
high-density plasmacluster ion evolving device is
placed close to a wall.
This product is equipped with a device corresponding
to this capacity.
直立式
空气净化器
使用说明书
中文
KI-A60E-CH-2.indd 1 12.3.2 11:37:57 AM

NOTE
The air purifier draws in room air through the air intake, circulates it through a
Pre-Filter, a Deodorizing Filter and a HEPA Filter inside the unit, and then discharges
it through the air outlet. The HEPA Filter can remove 99.97% of dust particles as small
as 0.3 microns that pass through the filter and also helps absorb odours.
The Deodorizing Filter gradually absorbs odours as they pass through the filter.
Some odours absorbed by the filters will break down over time, causing additional
odours. Depending on usage conditions, and especially if the product is used in
environments significantly more severe than a normal household, these odours may
become noticeable sooner than expected. If these odours persist replace the filters.
• The air purifier is designed to remove air-suspended dust and the odours they cause. The air
purifier is not designed to remove harmful gases such as carbon monoxide contained in cigarette
smoke. The air purifier may not completely remove an odour if the source of the odour is still
present.
Please read before operating your new Air Purifier
Pre-Filter
Deodorizing Filter
HEPA FilterHEPA FilterHEPA Filter
Front Pre-Filter
OM_KI-A60E_EN.indd 2 12.3.1 10:54:58 AM

E-1
ENGLISH
ENGLISH
FEATURES CONTENTS
IMPORTANT SAFETY INSTRUCTIONS
... E-2
• WARNING
• CAUTIONS CONCERNING OPERATION
• INSTALLATION GUIDELINES
• FILTER GUIDELINES
PART NAMES............................................. E-4
• FRONT / BACK
• MAIN UNIT DISPLAY
• FRONT MONITOR
PREPARATION.............................................E-6
• FILTER INSTALLATION
• REFILLING THE WATER TANK
OPERATION ...............................................E-8
• CLEAN AIR & HUMIDIFY
• CLEAN AIR
• CLEAN ION SHOWER
• FAN SPEED
• PLASMACLUSTER ION ON/OFF
USEFUL FUNCTION ...............................E-10
• LIGHTS CONTROL
• CHILD LOCK
• SOUND INDICATOR SETTING
• ADJUSTING SENSOR SENSITIVITY
• DISPLAY
• OFF TIMER
• AUTO RESTART
CARE AND MAINTENANCE .................E-12
• FILTER INDICATOR
• CARE INDEX
• REMOVING THE HUMIDIFIER
• WATER TANK
• HUMIDIFYING FILTER
• HUMIDIFYING TRAY AND COVER
• BACK PANEL
• FRONT PRE-FILTER
• DEODORIZING FILTER
• UNIT
• PLASMACLUSTER ION GENERATING UNIT
• UNIT REPLACING LIGHT
• REPLACING THE PLASMACLUSTER ION
GENERATING UNIT
• FILTER REPLACEMENT
TROUBLESHOOTING ............................E-19
SPECIFICATIONS....................................E-22
A Unique Combination of Air Treatment
Technologies
Triple Filtration System + Plasmacluster
+ Humidification
TRAPS DUST*
Washable Pre-Filter traps dust and other
large airborne particles.
DECREASES ODOURS
Deodorizing filter absorbs many common
household odours.
REDUCES POLLEN & MOLD*
HEPA filter traps 99.97% of particles as
small as 0.3 microns.
FRESHENS
By emitting a balance of positive and neg-
ative ions, Plasmacluster air treatment is a
natural process.
HUMIDIFIES
Can operate up to 10 hours per filling.**
*When air is circulated through the filter
system.
**Room size:
up to 50 m2
Plasmacluster's sensor technology contin-
uously monitors air quality and automati-
cally adjusts operation based on air purity
and humidity level.
Thank you for purchasing this SHARP Air
Purifier. Please read this manual carefully
before using the air purifier.
After reading, keep the manual in a conven-
ient location for future reference.
OM_KI-A60E_EN.indd 1 12.3.1 10:54:58 AM

E-2
IMPORTANT SAFETY INSTRUCTIONS
Always follow basic safety precautions when using electrical appliances, including the
following:
WARNING – Always observe the following to reduce the risk of electrical shock, fire, or injury:
•Read all instructions before using the unit.
•Use only a 220~240 volt outlet.
• Do not use the unit if the power cord or plug is damaged or if the connection to the wall
outlet is loose.
• Periodically remove dust from the plug.
• Do not insert fingers or foreign objects into the air intake or air outlet.
• When removing the power plug, always hold the plug and never pull on the cord.
Failure to do so can cause a short circuit resulting in electrical shock or fire.
• When removing the unit, do not damage the power cord with the casters.
Failure to do so can cause electric shock, heat generation, or fire.
• Do not remove the plug when your hands are wet.
• Do not place the unit near gas appliances or fireplaces.
•
Always unplug the unit when refilling the water tank, cleaning the unit, or when the unit is not in
use. Failure to do so can cause a short circuit resulting in electrical shock or fire.
•
In order to avoid safety hazards, if the power cord is damaged, it must be replaced by either
the manufacturer, a service agent, a Sharp authorized Service Center or a similarly qualified
service provider.
•Only a Sharp Authorized Service Centre should service this air purifier. Contact the nearest Service
Centre for any problems, adjustments, or repairs.
•Do not operate the unit in rooms where aerosol insecticides are present. Do not operate the unit in
rooms where there is oily residue, incense, sparks from lit cigarettes, or chemical fumes in the air.
Do not operate the unit in places where it may get wet, such as a bathroom.
•Be cautious when cleaning the unit. Strong corrosive cleansers can damage the exterior.
•When carrying the unit, first remove the Water Tank and Humidifying Tray, and then hold the unit by
the handles on both sides.
•Do not drink the water in the Humidifying Tray or Water Tank.
•Replace the water in the Water Tank daily with fresh tap water, and regularly clean the Water Tank
and Humidifying Tray (Ref. E-12 and E-13). When the unit is not in use, dispose of the water in the
Water Tank and Humidifying Tray. Leaving water in the Water Tank or Humidifying Tray can cause
mold, bacteria, and bad odours.
In rare cases, such bacteria can be a health hazard.
•This appliance is not intended for use by persons (including children) with reduced physical,
sensory, or mental capabilities, nor by persons with insufficient experience and knowledge of how
to operate the unit, unless they are given proper supervision and instruction on how to use the unit
by a person responsible for their safety.
Do not allow children to play with the unit.
NOTE – What to do if the unit interferes with radio or TV reception
If the air purifier interferes with radio or television reception, try one or more of the following
measures:
•Adjust or reposition the receiving antenna.
•Increase the distance between the unit and the radio or TV.
•Connect the equipment into an outlet on a circuit different from that of the radio or TV receiver.
•Consult the dealer or a qualified radio or TV technician.
OM_KI-A60E_EN.indd 2 12.3.1 10:54:58 AM

E-3
ENGLISH
CAUTIONS CONCERNING OPERATION
•Do not block the air intake or air outlet.
•Do not place the unit near or on hot objects, such as stoves or heaters, or where it may come into
contact with steam.
•Always operate the unit in an upright position.
• When moving the unit, use the handles on both sides.
Do not move the unit when it is in operation.
• Do not move or change the direction of the main unit when pulling it along by the casters.
• If the unit is on tatami mat, easily damaged flooring, an uneven surface, or thick-piled carpet, lift it
up when moving.
• When moving the unit by its casters, move it slowly and in a horizontal direction.
• Before moving the unit, make sure it is not operating, and remove the Water Tank and Humidifying
Tray while holding the side handle of the unit.
• When removing the Water Tank, be careful to not to get your fingers caught inside the unit.
• Do not operate the unit without the filters, the Water Tank, and the Humidifying Tray
properly installed.
• Do not wash and reuse the HEPA filter.
Doing so will not improve filter performance and can also cause electric shock or operating
malfunctions.
• Clean the exterior with a soft cloth only.
Do not use volatile fluids or detergents.
Doing so can damage or crack the exterior of the unit.
In addition, doing so can cause sensor malfunctions.
• The frequency of descaling maintenance will depend on the hardness of and the impurities
in the water that you use; the harder the water the more often descaling will be necessary.
• Keep the unit away from water.
INSTALLATION GUIDELINES
• When using the unit, place it at least 2-meters away from equipment that emits electric
waves, such as televisions or radios, to avoid electrical interference.
• Avoid locations where the sensors are exposed to direct wind.
Doing so can cause the unit to malfunction.
• Avoid locations where furniture, fabrics, or other objects can come in contact with the unit
and interfere with the intake and outtake of air.
• Avoid locations where the unit is exposed to condensation or drastic changes in
temperature. Appropriate room temperature is between 5 – 35 ºC.
• Place the unit on a level and stable surface with sufficient air circulation.
When placed on heavy carpet, the unit may vibrate slightly.
Place the unit on a level surface to avoid water leakage from the Water Tank and Humidifying Tray.
• Avoid locations that generate grease or oily smoke.
Doing so can cause the unit exterior to crack and the sensors to malfunction.
• To ensure proper airflow, place the unit about 30 cm (1 ft) away from the wall.
The wall directly behind the air outlet may become dirty over time. When using the unit for an
extended period of time at the same location, periodically clean the walls adjacent to it. You can
also prevent walls from becoming dirty by covering them with a vinyl sheet or other protective
covering.
FILTER GUIDELINES
•Follow the instructions in this manual for proper filter care and maintenance.
OM_KI-A60E_EN.indd 3 12.3.1 10:54:58 AM

E-4
PART NAMES
FRONT / BACK
5
1 Air Outlet (Back) 6 Float
2 Handle (2 Locations) 7 Humidifying Tray
3 Sensor (Internal)
•Dust Sensor
•Temperature / Humidity Sensor
•Odour Sensor
8 Caster (4 Locations)
9 HEPA Filter
10 Deodorizing Filter
11 Back Panel (Pre-Filter)
4 Humidifying Filter 12 Air Inlet
5 Water Tank 13 Power Cord / Plug
1
2
4
5
9
3
13
(Plug shape varies by country.)
12
4
1
3
6
2
1 Main Unit Display (Ref.E-5)
2 Air Outlet (Front)
3 Front Pre-Filter (Right & Left)
4 Front Monitor
5 Main Unit
6 Caster Stopper
To lock a caster stopper (Right & Left)
Locked Unlocked
7
8
11
10
Unit Cleaning Brush
Hook
Ion Generating Unit
6
FRONT
BACK
OM_KI-A60E_EN.indd 4 12.3.1 10:54:59 AM

E-5
ENGLISH
Humidity ON
1
POWER ON Button
a CLEAN AIR MODE Button /INDICATOR LIGHT (green)
b CLEAN AIR & HUMIDIFY MODE Button / INDICATOR LIGHT (green)
c CLEAN ION SHOWER MODE Button / INDICATOR LIGHT (green)
2
FAN SPEED Button / INDICATOR LIGHT (green) 6 LIGHT CONTROL Button
(Press 3 sec.)
Plasmacluster Ion ON / OFF Button
3
OFF Timer / INDICATOR LIGHT (green)
(Press 3 sec.) FILTER RESET Button
4
CHILD-LOCK Button / INDICATOR LIGHT (green) 7 POWER OFF Button
5
Plasmacluster Sign / INDICATOR LIGHT (blue) 8 DISPLAY Button
MAIN UNIT DISPLAY
2
4
5
FRONT MONITOR
green
off
red
(Flash ing)
Humidity OFF
Unit needs water
green
red
Clean
Impure
a
Humidify Light Odour Monitor*
Indicates odour intensity of the room
according to 3 color-coded levels
.
green red
Faint Strong
Dust Monitor
Indicates air purity according to 5
colour-coded levels.
67 1
bc
3
8
Wattage Monitor
Indicates how much power a particular
fan speed setting consumes.
Humidity Monitor
Indicates the approximate
humidity level in the room.
The humidity setting
cannot be adjusted.
Unit Replacing Light
OM_KI-A60E_EN.indd 5 12.3.1 10:55:00 AM

E-6
1
Remove the Back Panel.
PREPARATION
FILTER INSTALLATION
2
Remove the Filters from the plas-
tic bag.
3
Install the Filters in the correct
order as shown.
4
Install the Back Panel.
HEPA filter
Deodorizing filter
Always be sure to remove the
power plug from the wall outlet.
Click
HEPA filter Deodorizing filter
Back Panel
OM_KI-A60E_EN.indd 6 12.3.1 10:55:01 AM

1
3
1
2
2
MAX
E-7
ENGLISH
3
Install the Water Tank.
CAUTION
REFILLING THE WATER TANK
1
Remove the Water Tank.
2
Fill the Water Tank with tap water.
• Check to see that there is no water leaking.
• Be sure to wipe off any excess water on
the outside of the Water Tank.
• When carrying the Water Tank, hold it
with both hands and with the Water Tank
opening facing up.
How to refill the Water Tank when using the Clean Air & Humidify Mode or the Clean ION Shower Mode.
• Do not expose the unit to water. Doing so can cause a short circuit or electrical shock.
• Do not use hot water (40 ºC), chemical agents, aromatic substances, Doing so can deform the unit
or cause it to malfunction.
• Use only fresh tap water. Using other water sources risks the growth of molds, fungi, or bacteria.
Tighten
CAUTION
Click
Water Tank
OM_KI-A60E_EN.indd 7 12.3.1 10:55:02 AM

E-8
OPERATION
STOP
About the Automatic Humidify Mode
The temperature and humidity sensors automatically detect
and adjust humidity according to changes in room temperature.
Depending on the size and humidity level of a room, humidity
may only reach a level of about 55~65 %. If this occurs, using the
CLEAN AIR & HUMIDIFY/MAX MODE is recommended.
CLEAN AIR & HUMIDIFY
Temperature Humidity
~18 ºC 65 %
18 ºC~24 ºC 60 %
24 ºC~ 55 %
How to use the unit to quickly clean and humidify the air and reduce odours.
• Select the fan speed you want.
(Ref. E-9)
• Unless the power cord has been
unplugged, the unit will start operation
with the most previous settings.
NOTE
• Fill the Water Tank. (Ref. E-7)
• When the Water Tank is empty, the unit operates in CLEAN AIR MODE and the light flashes
red.
START
STOP
CLEAN AIR
How to use the unit when additional humidity is not required.
• Select the fan speed you want.
(Ref. E-9)
• Unless the power cord has been
unplugged, the unit will start operation
with the most previous settings.
START
OM_KI-A60E_EN.indd 8 12.3.1 10:55:02 AM

E-9
ENGLISH
CLEAN ION SHOWER
START
• If the “Plasmacluster Ion is OFF,
the plasmacluster ion will be not released.
• When the operation finishes, the unit will return to
its prior operation mode.
When using this mode, you can change to another
mode or to .
PLASMACLUSTER ION ON/OFF
FAN SPEED
Select the fan speed you want.
How to use the unit to purify air in an indoor space that has suddenly become dirty.
Discharges slightly stronger air for 60 minutes
.
NOTE
OFF
When the Plasmacluster function is ON, the Plasmacluster light is on.
NOTE
AUTO The fan speed is automatically switched between HIGH and LOW depending
on the amount of impurities in the air. The sensors detect impurities for efficient
operation.
POLLEN The unit operates at High Level
for 10 minutes and then alternates
between MEDIUM and HIGH.
10 minutes: High fan level
20 minutes: Medium fan level
20 minutes: High fan level
ON
ECONOMY AUTO
The fan speed is automatically adjusted depending on the amount of impurities
in the air. The sensors detect impurities for efficient operation.
more 3 sec. more 3 sec.
AUTO
POLLEN
MAX MED LOW
ECONOMY AUTO
OM_KI-A60E_EN.indd 9 12.3.1 10:55:03 AM

brighter
darker
turn off
E-10
USEFUL FUNCTION
High
Standard
Low
LIGHT CONTROL
Use the Light Control to select the brightness you want.
CHILD LOCK
This locks the settings. It uses the same method as the starting operation.
ON CANCELLATION
SOUND INDICATOR SETTING
You can set the unit to make a beeping sound when the Water Tank is empty.
(with the unit OFF)
ON
ADJUSTING SENSOR SENSITIVITY
1
If the DUST MONITOR and ODOUR MONITOR are constantly red, the unit reduces sensor sensitivity. It the unit is set
to HIGH, the DUST MONITOR and ODOUR MONITOR are constantly green and the unit increases sensitivity.
How to adjust the sensitivity.
RED••••••••SET to “LOW” GREEN•••SET to “HIGH”
2
3
CAUTION • If you do not press the power OFF button within 8 seconds of adjusting sensor
sensitivity, the setting is saved automatically.
• The sensor sensitivity setting is saved even after the unit is unplugged.
more 3 sec.
(with the unit OFF)
more 3 sec.
(with the unit OFF)
more 3 sec.
more 3 sec. more 3 sec.
CANCELLATION
brighter
darker
turn off
OM_KI-A60E_EN.indd 10 12.3.1 10:55:04 AM

E-11
ENGLISH
CARE AND MAINTENANCE
Changing the Humidity and Wattage indicators.
DISPLAY
Always be sure to remove
the power plug from the wall
outlet.
Humidity Wattage
Select the length of time you want. The unit automatically stops once the selected time is reached.
OFF TIMER
1hour 2hour 4hour 8hour
CANCELLATION
NOTE
• Pressing with the OFF TIMER setting displays the remaining time for 3 seconds.
• To reset the operating time, press while the remaining is being displayed.
If the unit is unplugged or if there is a power failure, the unit will resume operation with the previous
settings after power is restored.
AUTO RESTART
(with the unit OFF)
ON
(with the unit OFF)
CANCELLATION
(in 3 sec.)
When the , , lamps light up for 10 seconds, settings are
complete.
(in 3 sec.)
more 3 sec.
OM_KI-A60E_EN.indd 11 12.3.1 10:55:04 AM

1
3
2
1
2
1
2
E-12
CARE AND MAINTENANCE
CARE INDEX
The filter Indicator Light will turn on after approximately 720 hours. (30 days × 24 hours =720 hours)
This is a reminder to perform the maintenance described below.
After performing maintenance, reset the Filter Indicator. (Ref. E-12)
Front Pre-filter (Ref. E-15)
Unit (Ref.E-15)
HEPA filter
Not washable
REMOVING THE HUMIDIFIER
After maintenance, correctly reattach the parts.
FILTER INDICATOR
more 3 sec.
• Filter Indicator Light turns on.
Humidifying Tray Cover
(Ref. E-14)
Plasmacluster Ion Generating Unit
(Ref. E-16)
Back Panel
(Ref. E-14)
Humidifying Filter (Ref. E-13)
Water Tank (Ref. E-13)
Humidifying Tray (Ref. E-14) Deodorizing filter (Ref. E-15)
OM_KI-A60E_EN.indd 12 12.3.1 10:55:06 AM

E-13
ENGLISH
WATER TANK
Rinse the inside with a small amount of water.
•Hold the Water Tank steady when holding it by the handles.
Always be sure to remove the power plug
from the wall outlet.
CAUTION
NOTE How to clean hard to remove dirt.
Toothbrush
Tank Cap
Clean the inside of the Water
Tank with a soft sponge and
the Tank Cap with a cotton
swab or toothbrush.
HUMIDIFYING FILTER
Rinse with plenty of water.
CAUTION
• Do not remove the Humidifying Filter from the filter frame.
• Avoid spilling water in the Humidifying Tray.
NOTE How to clean hard to remove dirt
1.
Soak in water with a descaling solution for about 30 minutes.
Recommended descaling solutions
• Citric acid (available at some drugstores)
• 100% bottled lemon juice with no pulp.
<When descaling with citric acid>
<When descaling with lemon juice>
stir well!
2 1/2 cups of water
3 teaspoons
3 cups of water
1/4 cup
stir well!
When using lemon juice as your descaling solu-
tion, allow for more soak time.
CAUTION
2.
Rinse off the descaling solution with plenty of water.
OM_KI-A60E_EN.indd 13 12.3.1 10:55:06 AM

E-14
CARE AND MAINTENANCECARE AND MAINTENANCE
Back Panel
HUMIDIFYING TRAY AND COVER
CAUTION
1. Remove the Humidifying Tray Cover.
2.
Rinse the inside of the Humidifying Tray and then
scrub the Humidifying Tray Cover with a toothbrush.
• Do not remove the Float and the Roller.
• If the Float or the Roller comes off, refer to E-20.
NOTE How to clean hard to remove dirt
TRAY
1.
Fill the tray half-way with water.
2.
Add a small amount of kitchen
detergent.
3.
Soak for 30 minutes.
4.
Rinse off the kitchen detergent
with clean water.
COVER
1.
Add a small amount of kitchen
detergent to water and soak for
about 30 minutes.
2.
Rinse off the kitchen detergent
with clean water.
Clean the parts which are difficult
to reach with a cotton swab or
toothbrush.
DO NOT use the detergents
shown on E-15.
They can deform, tarnish, or crack
(thus causing water to leak) the
unit.
BACK PANEL
NOTE How to clean hard to remove dirt
Gently remove dust with an appropriate cleaning tool,
such as a vacuum cleaner with a proper attachment.
Roller
Humidifying Tray Cover
Float
1.
Add a small amount of kitchen
detergent to water and soak for
about 10 minutes.
DO NOT apply excessive pressure
when scrubbing the back panel.
2.
Rinse off the kitchen detergent
with clean water.
3.
Completely dry the filter in a well-
ventilated area.
CAUTION
CAUTION
OM_KI-A60E_EN.indd 14 12.3.1 10:55:07 AM

E-15
ENGLISH
FRONT PRE-FILTER
UNIT
Wipe with a dry, soft cloth.
• Do not use volatile fluids
Benzene paint thinner or polishing powder can damage
the surface.
• Do not use detergents
Detergent ingredients can damage the unit.
CAUTION
Gently remove dust with an appropriate
cleaning tool, such as a vacuum cleaner
with a proper attachment.
NOTE
After pulling the Front Pre-Filter to the front, detach it by
pulling downward.
DEODORIZING FILTER
Gently remove dust with an appropriate clean-
ing tool, such as a vacuum cleaner with a
proper attachment.
Left Right
Always be sure to remove the power plug
from the wall outlet.
OM_KI-A60E_EN.indd 15 12.3.1 10:55:08 AM

E-16
Flashing slowly
(red)
Elapsed Time Display Message
Begin use
Approx. 17,500 hours Replace the Plasmacluster
Ion Generating Unit
Approx. 19,000 hours Stop operating the front
outlet Fan
CARE AND MAINTENANCECARE AND MAINTENANCE
PLASMACLUSTER ION GENERATING UNIT (electrode section)
Clean every 6 months or more often if necessary
(When operated the unit around-the-clock.)
Remove dust attached to the electrode section of the unit with the cleaning
brush included with the unit or a commercially-available cotton applicator.
(Ref. E-17 removing the unit)
CAUTION
Connection Terminals
Unit Cleaning Brush
Electrode Section
(4 parts)
Electrode
Root of the
electrode
[ Before cleaning ] [ After cleaning ]
UNIT REPLACING LIGHT
The Unit Replacing light will turn on after approximately 17,500 hours.
( 2 years × 24 hours = 17,500)
<REPLACEMENT Plasmacluster Ion Generating Unit>
Please consult your dealer to purchase the following model.
Model : IZ-C75SE
<Disposal>
Dispose of the old Plasmacluster ion generating unit according to local laws and regulations.
-materials-
• Unit : Polystyrene terephthalate, electronic parts.
Flashing fast
(red)
• Do not touch the electrode section. Doing so can cause injury.
• Do not transform the electrode section. Doing so can damage it.
• Do not touch the connection terminals. Doing so can damage them.
•If dust has hardened, lightly water a commercially-available cotton applicator and then
wipe off the part.
OM_KI-A60E_EN.indd 16 12.3.1 10:55:08 AM

1
3
2
1
2
1
2
E-17
ENGLISH
[ After cleaning ]
REPLACING THE PLASMACLUSTER ION GENERATING UNIT
1
Remove the Unit Cover.
2
Slide the hook.
3
Remove the Unit.
4
Replace with a new or restored
Unit.
5
Attach the Unit Cover.
6
Press the Operation Button.
Make sure that the Unit Replacing
Light is OFF.
new or restored unit
Always be sure to remove the power plug
from the wall outlet.
OM_KI-A60E_EN.indd 17 12.3.1 10:55:09 AM

E-18
CARE AND MAINTENANCECARE AND MAINTENANCE
•HEPA Filter About 10 years after first use
•Deodorizing Filter About 10 years after first use
•Humidifying Filter About 10 years after first use
Replacement Filter Model
Consult your dealer when purchasing a replacement filter.
AIR PURIFIER MODEL
REPLACEMENT FILTER MODEL
HEPA Filter :
1 unit
Deodorizing
Filter : 1 unit
Humidifying
Filter : 1unit
KI-A60E FZ-AX6HFE FZ-AX6DFE FZ-AX6MFE
When to replace the filter
Filter life varies depending on the room environment, usage conditions, and location of the unit.
If dust or odour persists, replace the filter.
(Refer to “Please read before operating your new Air Purifier”)
The following filter life and replacement timing is based on purifying a room in which 5 cigarettes per
day are smoked and the unit's dust collection and deodorizing performance has declined to half the
level of a new filter.
We recommend replacing the filter more frequently if the unit is used in conditions significantly more
severe than a normal household.
Humidifying Filter
Filter Frame (white)
Filter Frame (gray)
FILTER REPLACEMENT
NOTE
HEPA Filter
Deodorizing Filter
Use the date label to remind you when to replace the filter.
Disposing of filters
Dispose of used filters according to local laws and regulations.
HEPA Filter material :
• Filter : Polypropylene
• Frame: Polyester
Deodorizing Filter material :
• Filter : Paper
Humidifying Filter material :
• Filter : Rayon, polyester
OM_KI-A60E_EN.indd 18 12.3.1 10:55:10 AM
