Sharp Aquos U SHV37 Service manual

Setting Guide
Please read this manual first
Thank you for buying the “AQUOS U SHV37” (simply called the
“product” from here on).
This manual describes the settings and precautions for using the
product. For detailed descriptions of various functions, refer to the
“Instruction Manual application” (Japanese version) that can be
used on the product.
* For illustrations and descriptions in this manual, refer to “Basic
Manual” available on the au homepage and on the product.
* The company names and product names appearing in this manual
are trademarks or registered trademarks of their respective holders.
* Phone illustrations and screen shots are for descriptive purposes only,
and may differ from the actual product.
October 2016, 1st Edition
Sold by: KDDI CORPORATION,
OKINAWA CELLULAR TELEPHONE COMPANY
Manufactured by: SHARP CORPORATION
Basic Operations
Describes names of parts and basic operations.
Initial Settings
■STEP1: Language Setting
Set the language to use on the product.
■STEP2: Wi-Fi®Connection/Got another device? Settings
You can connect to an Internet service via a household wireless LAN
(Wi-Fi®) environment or a public wireless LAN environment when out
and about. Continue your Google™ accounts, etc. from another Tap
& Go-compatible device.
■STEP3: Google Account Settings
Set up a Google account for using applications provided by Google
Inc.
■STEP4: auかんたん設定 (au Easy Setting)
Set an au ID etc. to use various services provided by au.
E-mail Settings and Changing E-mail Address
Set for using E-mail (@ezweb.ne.jp). An e-mail address is set
automatically in the initial settings. You can change the e-mail
address set in the initial settings.
Making/Receiving Calls
You can make/receive a call.
How to Transfer Data with the au Settings Menu
Return/Store data with the au Settings Menu.
Reducing Battery Consumption
You can switch the setting of functions using “function buttons” to
reduce the battery consumption.
濡れた状態での充電は、
異 常 な 発 熱・焼 損 など の
原 因となり大 変 危 険 で す。
For detailed operations, refer to the “Instruction Manual application” (Japanese version) that can be used on the product.
●When the display language is Japanese, on the home screen, “Apps Sheet” [[取扱説明書] (Instruction Manual).
You can switch the display language for function names and other items to English.
●On the home screen, “Apps Sheet” [[設定] (Settings) [[言語と入力] (Language & input) [[言語] (Language) [[English].
■Character Input Method
You can enter characters by flick input or tapping keys repeatedly. Tap “ ” to switch the input
modes.
Flick input
By touching a key, the candidates that can be entered by flick input are displayed as shown on the
right. By flicking the key in the direction of a desired character being displayed, the character is
entered in the character entry area.
■App Permissions Settings
When you activate applications/functions to access to the function or information of the product for the first time, the confirmation screen for
requesting the permission of access authority is displayed. When the confirmation screen is displayed, check the displayed contents
carefully and follow the one-screen instructions.
●The explanation screen for permissions may be displayed depending on the applications/functions. Also, multiple confirmation screens
may be displayed or the displayed contents may differ. Check the displayed contents carefully and follow the on-screen instructions.
If you deny the permission, the application/function may not be activated or the use of function may be restricted.
●In this manual, some description of the confirmation screens may be omitted.
■Using “Basic Manual”
●To use the application for the first time, you need to download and install it by following on-screen instructions.
The Google initial settings screen is displayed automatically when you turn the power on for the first time. Follow the on-screen instructions
to set each function.
■STEP1: Language Setting
●Alternatively, on the home screen, “Apps Sheet” [[Settings] [[Language & input] [[Language].
■STEP2: Wi-Fi®Connection/Got another device? Settings
You may skip the steps here for making Wi-Fi®connection and Got another device? settings. By using Got another device? setting, you can
copy your Google accounts, data, etc. from an Android™device compatible with Tap & Go function to the product. For detailed Wi-Fi®
settings, refer to the “Instruction Manual application” (Japanese version) that can be used on the product.
●Alternatively, on the home screen, “Apps Sheet” [[Settings] [[Wi-Fi] [Tap “Off” to set “On” to set Wi-Fi®connection.
* To use Tap & Go, select “Copy your Google Accounts, apps, and data from your other device” and follow the on-screen instructions.
When using the product
●The battery is built into the product, and cannot be removed by the customer.
●To force the power off, hold fdown for 8 or more seconds (Release your finger after the product vibrates to turn the power off).
Basic Operations
ADisplay
Touch it directly with your fingers to operate.
Tap/Double tap
Tap: Gently touch the
screen and then
immediately release
your finger.
Double tap: Tap the
same position twice.
Long touch
Keep touching an
item etc. with your
finger.
Slide/Swipe/Drag
While your finger is
gently touching the
screen, an item, etc.,
trace it to the desired
direction or position.
Flick
Touch the screen and
then quickly move
(flick) your finger up,
down, right or left.
Pinch
Touch the screen with
two fingers and widen
(pinch-out) or narrow
(pinch-in) the fingers'
distance.
Turning the Screen On
Lift the product and keep it stationary to turn the
screen on when the screen is turned off (Turn screen
on by holding).
* This function is enabled when you purchase the
product.
In the following cases etc., the screen may not be
turned on.
• When you are moving with the product held (while
walking, driving a car, etc.)
• When you keep the product moving before or after
lifting it
• When you lift the product vertically or horizontally
B^ (Back key): Tap it to return to the previous screen.
C# (Home key): Tap it to display the home screen.
D$(Recent Apps key): Tap it to display Recent Apps screen. Long touch it to
display the status panel.
Ef(Power key): Hold it down to turn the power on. Hold it down while the power is
turned on [[Power off] to turn it off.
Unlocking the screen
Unlock the screen by sliding “ ” up.
●If a password, etc. is set for the screen lock,
it is displayed as .
The installation is not
completed
The installation is
completed
1 2
z
On the home screen, “Apps
Sheet” [[Basic Manual].
[Install] [On the Google Play
screen, [UPDATE] [Install by
following on-screen instructions.
Use Basic Manual
For detailed operations of Instruction Manual application, in “取扱説明書” (Instruction Manual), [ ] [[ヘルプ] (help) to refer to help
when the display language is Japanese.
Initial Settings
1
Select the language [[].
123
z z
[SKIP]. [SKIP ANYWAY]. [No thanks]* [[NEXT].
《Character entry screen (12 Key)》
■STEP3: Google Account Settings
You can use applications provided by Google Inc. such as “Play Store” and “Hangouts™” by setting up a Google account. You can use the
product without a Google account set, but in such case some applications are not available.
The main setting items are as follows.
●The Google account setup screen is also displayed when you activate an application for which a Google account is required for the first
time.
●Depending on how you operate, screens other than those below may be displayed.
*1 If you already have a Google account, enter the e-mail address.
*2 To specify payment information for use with Google Play™, follow the on-screen instructions.
*3 To use an e-mail address other than the e-mail address of Google account or E-mail (@ezweb.ne.jp), follow the on-screen instructions.
*4 To set the screen lock, enable the check box and follow the on-screen instructions.
*5 To use Google Now™, select “Yes, I'm in”.
■STEP4: auかんたん設定 (au Easy Setting)
You can use various services provided by au such as au Smart Pass and “au Simple Payment Service” in which you can purchase
applications displayed on Google Play by setting an au ID.
●Alternatively, on the home screen, “Apps Sheet” [[Settings] [[au Settings Menu] [[au Easy Setting].
*1 The default value is the four-digit security code you wrote on the application form.
*2 au ID registration is complete.
*3 To use the “Data Storage” application and automatically store photos and address book entries to the au server, select “Turn Auto Backup on”.
*4 Preliminary settings for Lookout for au are finished by permitting each authority.
*5 If a confirmation screen is displayed for Wi-Fi®connection or au Market, follow the on-screen instructions.
*6 Applications to be displayed and their number may be updated.
*7 If a screen for recovery of an application appears, follow the on-screen instructions to recover the application.
Username Register your Google account (user ID) and any characters which you want to use as a mail address. You can register any
user name but you cannot set the same user name as another user's.
Password Register the password for using your Google account.
1 2 3 4
z z z z
[Or create a new account].*1 Enter your “First name” and
“Last name” [[NEXT].
Enter basic information
[[NEXT].
Enter your “Username”
[[NEXT].
5 6 7 8
z z z z
Enter the password
[[NEXT].
Confirm phone number for reset
[[NEXT].
Confirm phone number
[[VERIFY].
Confirm the contents
[[I AGREE].
910 11 12
z z z z
[NEXT]. Confirm the contents of Google
services [[NEXT].
Select “No thanks”*2
[[CONTINUE].
Select “Not now”*3
[[NEXT].
13 14 15
z z
Disable the check box*4
[[SKIP].
[SKIP ANYWAY]. Select “Skip”*5 [[NEXT].
au ID Register your au phone number or any other characters as an au ID. The same “au ID” as another user's cannot be
registered.
au ID password Register the password for using your au ID.
1 2 3 4
z z z z
[Next]. [Register “au ID”] [[Next]. [au IDの 設 定・保 存 ]
(Set/Save au ID).
Enter the security code
[[OK].*1
5 6 7 8
z z z z
Enter the password
[[設定] (Settings).
[終了] (Finish).*2 Confirm the contents and
follow the on-screen
instructions [[Next].
Confirm the contents and
follow the on-screen
instructions [[Agree]
[[Next].
910 11 12
z z z z
Confirm the contents
[[Agree].
Confirm the contents and
follow the on-screen
instructions [[Next].*3
Confirm the contents and
follow the on-screen
instructions [[Next].
Confirm the contents and
follow the on-screen
instructions [[Next].
13 14 15 16
z z z
Confirm the contents and
follow the on-screen
instructions [[Next].*4
Select data you want to return
from au Smart Pass
[[次へ] (Next).*5
Mark the applications to
install*6 [[次へ] (Next).*7
[Finish].
AL55_e_設定ガイド.fm 1 ページ ２０１６年１１月２２日 火曜日 午後６時４８分

E-mail (@ezweb.ne.jp) is a service which enables you to exchange e-mails with other cell phones which support e-mail and with PCs. An
e-mail address is set automatically in the initial settings. You can change the e-mail address set in the initial settings.
■Initial Settings
■Changing E-mail Address
■Restoring Backed Up E-mail
You can restore mails an old product has backed up to this product.
●Save the mail data from the old au phone to the microSD™memory card beforehand.
●
Screens displayed when receiving a call or during a call may differ depending on the settings of a call, screen for receiving a call, operations
during an incoming call/a call etc. For details, refer to the “Instruction Manual application” (Japanese version) that can be used on the product.
■Entering a Phone Number and Making a Call
■Making a Call Using Incoming History/Outgoing History
■Making a Call Using Address Book
■Answering a Call (When a call arrives while the backlight is off or the lock screen is displayed)
■Answering a Call (When a call arrives while the backlight is on (except when the lock screen is
displayed))
* When you answer a call by “Speaker”, operate after tapping “ ”/“ ”.
■Putting a Current Call on Hold
While the call is on hold, guidance is played for the other party.
You can return/store data from an old au phone to this product using a microSD™memory card or au Smart Pass server.
●To return/store data using an au Smart Pass server, you must set an au ID.
●To return data using a microSD™memory card, save the data from the old au phone to the microSD™ memory card beforehand.
■Returning Data with the au Settings Menu
*1 If a confirmation screen is displayed for terms of use/privacy policy, follow the on-screen instructions.
*2 To return data from “auスマートパスのサーバから戻す (Return from au Smart Pass server)” (data stored on an au Smart Pass server), you must set
an au ID.
*3 Not displayed if you selected “auスマートパスのサーバから戻す (Return from au Smart Pass server)” at step 4.
*4 This screen is displayed when “スマートフォンのデータを戻す (Return smartphone data)” is selected.
*5 If a confirmation screen is displayed for restoring data, follow the on-screen instructions.
*6 If a confirmation screen is displayed for Wi-Fi®connection, follow the on-screen instructions.
■How to Save Data from au Settings Menu
To protect important data, be sure to save (back up) data periodically to a microSD™ memory card or au Smart Pass server.
*1 If a confirmation screen is displayed for terms of use/privacy policy, follow the on-screen instructions.
*2 If you save data from “auスマートパスのサーバに預ける (Store to au Smart Pass server)” (store data to an au Smart Pass server), you must set an
au ID.
*3 If a confirmation screen is displayed for saving data, follow the on-screen instructions.
*4 If a confirmation screen is displayed for Wi-Fi®connection, follow the on-screen instructions.
You can access “function buttons” from the status panel to enable/disable functions and modify their settings. You can reduce the battery
consumption by switching their setting frequently, such as when not using the functions. Enabled functions are displayed in white.
●You can also reduce the battery consumption using “Energy saving”. For details, refer to the “Instruction Manual application” (Japanese
version) that can be used on the product.
E-mail Settings and ChangingE-mail Address
1234
zzz
Home screen [[]. Confirm the contents
[[閉じる] (Close).
Confirm the contents
[[Close].
Confirm the contents [
[同意する] (Agree)/[同意しない]
(Disagree) [[完了] (Done).
1234
zzzz
Home screen [[]. [MENU] [
[Change Address/Setting Filter].
[Eメールアドレスの変更へ]
(To change e-mail address).
Enter the security code
[[送信] (Send).
567
z z
Confirm the contents
[[承諾する] (Accept).
Enter an e-mail address
[[送信] (Send).
[OK] [[閉じる] (Close).
1234
zzzz
Home screen [[]. [MENU] [[E-mail settings]. [Backup/Restore] [
[Restore mails].
Select the mail type to restore
[[OK].
5 6
z
Select the backed up data to
restore [[OK].
[Add]/[Overwrite] [[OK].
Making/ReceivingCalls
1 2
z
Home screen [[]. Enter a phone number
[[CALL].
123
z z
Home screen [[]. [Incoming]/[Outgoing]. Tap “ ” of the other party you
want to make a call to.
1234
zzz
Home screen [[]. []. Select the other party you want
to make a call to.
[].
123
z z
Slide “Answer” down while an
incoming call is arriving.
The call starts. Tap “End call” to end the call.
1 2 3
z z
Tap “Accept”/“Speaker” while an
incoming call is arriving.
The call starts. Tap “End” to end the call.*
1 2 3
z z
Tap “Hold” during
a call.
The call is put on hold and the
guidance is played for
the other party.
Tap “Unhold” to return to
the call.
How to Transfer Data with the au Settings Menu
1 2 3 4
z z z z
On the home screen,
“Apps Sheet” [[Settings].
[au Settings Menu]. [Data Transfer].*1 [au スマートパスのサーバから戻
す
] (Return from au Smart Pass
server)
*2
/[SD カードから復元する ]
(Restore from SD card).
“SDカードから復元する
(Restore from SD card)”
selected
“auスマートパスのサーバか
ら戻す (Return from au
Smart Pass server)” selected
5 6
z
If you selected “SDカードから復
元する(Restore from SD card)”,
select your old au phone type.*3
Checkmark the data to return,
[戻す] (Return)*4*5
[[完了] (Done).
Checkmark the data to return,
[戻す] (Return)*6
[[完了] (Done).
When the product is kept at an au shop or another shop for repairs, the memory will be deleted. Back up data in advance.
1 2 3 4
z z z z
On the home screen,
“Apps Sheet” [[Settings].
[au Settings Menu]. [Data Transfer].*1 [auスマートパスのサーバに預け
る](Store to au Smart Pass
server)*2/[SDカードに保存する]
(Save to SD card).
“SDカードに保存する
(Save to SD card)”
selected
“auスマートパスのサーバに
預ける(Store to au Smart
Pass server)” selected
5
Checkmark the data to save,
[保存する] (Save)
[[完了] (Done).
Checkmark the data to store,
[預ける] (Store)*3*4
[[完了] (Done).
Automatically Storing Photos and Address Book
Use the following steps to set automatic backup of photos and address book entries to the au Smart Pass server using the “Data
Storage” application. Photos can only be automatically stored with a Wi-Fi®connection.
●On the home screen, “Apps Sheet” [[Settings] [[au Settings Menu] [[Backup Setting] [Select the type of data to store
automatically.
Viewing/Playing data
You can view/play data on the product by the following operations.
●On the home screen, “Apps Sheet” [[Contents Manager] [Tap the data to display.
ReducingBattery Consumption
1 2
z
Slide the status bar down with
your two fingers.
Tap the functions whose setting
you want to switch by using
“function buttons”.
AL55_e_設定ガイド.fm 2 ページ ２０１６年１１月２２日 火曜日 午後６時４８分
