Sharp JW Series Instruction manual

1
Sharp Manufacturing Systems Corporation
JW Series Computer Link
SIO Driver
1 System Configuration.......................................................................................................3
2 Selection of External Device............................................................................................8
3 Example of Communication Setting.................................................................................9
4 Setup Items....................................................................................................................45
5 Cable Diagram...............................................................................................................50
6 Supported Device...........................................................................................................79
7 Device Code and Address Code....................................................................................83
8 Error Messages..............................................................................................................87

JW Series Computer Link SIO Driver
GP-Pro EX Device/PLC Connection Manual 2
Introduction
This manual describes how to connect the Display and the External Device.
In this manual, the connection procedure will be described by following the below sections:
1System Configuration
This section shows the types of External
Devices which can be connected and SIO
type.
)"1 System Configuration" (page 3)
2Selection of External Device
Select a model (series) of the External
Device to be connected and connection
method.
)"2 Selection of External Device" (page 8)
3Example of Communication Settings
This section shows setting examples for
communicating between the Display and
the External Device.
)"3 Example of Communication Setting" (page
9)
4Setup Items
This section describes communication
setup items on the Display.
Set communication settings of the Display
with GP-Pro EX or in off-line mode.
)"4 Setup Items" (page 45)
5Cable Diagram
This section shows cables and adapters
for connecting the Display and the
External Device.
)"5 Cable Diagram" (page 50)
Operation

JW Series Computer Link SIO Driver
GP-Pro EX Device/PLC Connection Manual 3
1 System Configuration
The system configuration in the case when the External Device of Sharp Manufacturing Systems Corporation and the
Display are connected is shown.
Series CPU Link I/F SIO Type Setting
Example Cable Diagram
JW20H
JW-21CU JW-21CM*1
RS422/485
(4wire)
Setting
Example 1
(page 9)
Cable
Diagram 1
(page 50)
RS422/485
(2wire)
Setting
Example 2
(page 11)
Cable
Diagram 2
(page 54)
JW-22CU
Communication
port on the CPU
unit
RS232C Setting
Example 3
(page 13)
Cable Dia-
gram 3 (page
59)
RS422/485
(4wire)
Setting
Example 4
(page 15)
Cable Dia-
gram 4 (page
60)
JW-21CM*1
RS422/485
(4wire)
Setting
Example 1
(page 9)
Cable
Diagram 1
(page 50)
RS422/485
(2wire)
Setting
Example 2
(page 11)
Cable
Diagram 2
(page 54)
JW30H
JW-31CUH1 JW-21CM*1
RS422/485
(4wire)
Setting
Example 1
(page 9)
Cable Dia-
gram 1 (page
50)
RS422/485
(2wire)
Setting
Example 2
(page 11)
Cable
Diagram 2
(page 54)
JW-32CUH1
JW-32CUM1
JW-32CUM2
JW-33CUH1
JW-33CUH2
JW-33CUH3
PG/COMM1 on
the CPU unit RS422/485 (4wire)
Setting
Example 5
(page 17)
Cable
Diagram 5
(page 64)
PG/COMM2 on
the CPU unit
RS232C Setting
Example 6
(page 19)
Cable
Diagram 6
(page 68)
RS422/485
(4wire)
Setting
Example 7
(page 21)
Cable
Diagram 5
(page 64)
JW-21CM*1
RS422/485
(4wire)
Setting
Example 1
(page 9)
Cable
Diagram 1
(page 50)
RS422/485
(2wire)
Setting
Example 2
(page 11)
Cable
Diagram 2
(page 54)

JW Series Computer Link SIO Driver
GP-Pro EX Device/PLC Connection Manual 4
JW50H
JW70H
JW100H
JW-50CUH JW-10CM
RS422/485
(4wire)
Setting
Example 8
(page 23)
Cable
Diagram 1
(page 50)
RS422/485
(2wire)
Setting
Example 9
(page 25)
Cable
Diagram 2
(page 54)
JW-70CUH
JW-100CUH
Communication
port on the CPU
unit
RS232C Setting
Example 10
(page 27)
Cable
Diagram 3
(page 59)
RS422/485
(4wire)
Setting
Example 11
(page 29)
Cable
Diagram 7
(page 69)
JW-10CM
RS422/485
(4wire)
Setting
Example 8
(page 23)
Cable
Diagram 1
(page 50)
RS422/485
(2wire)
Setting
Example 9
(page 25)
Cable
Diagram 2
(page 54)
JW10
JW-1324K
JW-1424K
JW-1624K
JW-1342K
JW-1442K
JW-1642K
Communication
port on the base
module
RS422/485
(2wire)
Setting
Example 12
(page 31)
Cable Dia-
gram 8 (page
73)
Series CPU Link I/F SIO Type Setting
Example Cable Diagram

JW Series Computer Link SIO Driver
GP-Pro EX Device/PLC Connection Manual 5
*2 Available with the Ethernet units compatible with JW300. "300" is labeled on the front of JW300-
compatible units. For more information, contact the manufacturer of the External Device.
JW300
JW-311CU
JW-312CU
PG/COMM1 on
the CPU unit
RS232C Setting
Example 13
(page 33)
Cable
Diagram 9
(page 78)
RS422/485
(4wire)
Setting
Example 14
(page 35)
Cable
Diagram 5
(page 64)
JW-21CM*2
RS422/485
(4wire)
Setting
Example 17
(page 41)
Cable
Diagram 1
(page 50)
RS422/485
(2wire)
Setting
Example 18
(page 43)
Cable
Diagram 2
(page 54)
JW-321CU
JW-322CU
JW-331CU
JW-332CU
JW-341CU
JW-342CU
JW-352CU
JW-362CU
PG/COMM1 on
the CPU unit
RS232C Setting
Example 13
(page 33)
Cable
Diagram 9
(page 78)
RS422/485
(4wire)
Setting
Example 14
(page 35)
Cable
Diagram 5
(page 64)
PG/COMM2 on
the CPU unit
RS232C Setting
Example 15
(page 37)
Cable
Diagram 6
(page 68)
RS422/485
(4wire)
Setting
Example 16
(page 39)
Cable
Diagram 5
(page 64)
JW-21CM*2
RS422/485
(4wire)
Setting
Example 17
(page 41)
Cable
Diagram 1
(page 50)
RS422/485
(2wire)
Setting
Example 18
(page 43)
Cable
Diagram 2
(page 54)
*1 Note that some of them cannot be used or the range of use is restricted depending on the version of the link unit
JW-21CM.
Version sticker on
the front of the unit Restriction of use
30Hn Available to use without restriction
30H Unable to read or write the file register 10 to 2C
Unable to read or write the file register address 100000 to 176777
Without sticker Unable to use in the JW30H Series
Series CPU Link I/F SIO Type Setting
Example Cable Diagram

JW Series Computer Link SIO Driver
GP-Pro EX Device/PLC Connection Manual 6
COM Port of IPC
When connecting IPC with External Device, the COM port which can be used changes with series and SIO type.
Please refer to the manual of IPC for details.
Usable port
Dip switch setting: RS-232C
Series Usable port
RS-232C RS-422/485(4 wire) RS-422/485(2 wire)
PS-2000B COM1*1 , COM2,
COM3*1, COM4
*1 The RI/5V can be switched. Please switch with the change switch of IPC.
--
PS-3650A, PS-3651A COM1*1 --
PS-3700A (Pentium®4-M)
PS-3710A COM1*1, COM2*1,
COM3*2 , COM4
*2 It is necessary to set up the SIO type with the Dip switch. Please set up as follows according to SIO
type to be used.
COM3*2 COM3*2
PS-3711A COM1*1, COM2*2 COM2*2 COM2*2
Dip switch Setting Description
1 OFF Reserve (always OFF)
2OFF
SIO type: RS-232C
3OFF
4 OFF Output mode of SD (TXD) data: Always output
5 OFF Terminal resistance (220Ω) insertion to SD (TXD): None
6 OFF Terminal resistance (220Ω) insertion to RD (RXD): None
7 OFF Short-circuit of SDA (TXA) and RDA (RXA): Does not Exist
8 OFF Short-circuit of SDB (TXB) and RDB (RXB): Does not Exist
9OFF
RS (RTS) Auto control mode: Disable
10 OFF

JW Series Computer Link SIO Driver
GP-Pro EX Device/PLC Connection Manual 7
Dip switch setting: RS-422/485 (4 wire)
Dip switch setting: RS-422/485 (2 wire)
Dip switch Setting Description
1 OFF Reserve (always OFF)
2ON
SIO type: RS-422/485
3ON
4 OFF Output mode of SD (TXD) data: Always output
5 OFF Terminal resistance (220Ω) insertion to SD (TXD): None
6 OFF Terminal resistance (220Ω) insertion to RD (RXD): None
7 OFF Short-circuit of SDA (TXA) and RDA (RXA): Does not Exist
8 OFF Short-circuit of SDB (TXB) and RDB (RXB): Does not Exist
9OFF
RS (RTS) Auto control mode: Disable
10 OFF
Dip switch Setting Description
1 OFF Reserve (always OFF)
2ON
SIO type: RS-422/485
3ON
4 OFF Output mode of SD (TXD) data: Always output
5 OFF Terminal resistance (220Ω) insertion to SD (TXD): None
6 OFF Terminal resistance (220Ω) insertion to RD (RXD): None
7 ON Short-circuit of SDA (TXA) and RDA (RXA): Exist
8 ON Short-circuit of SDB (TXB) and RDB (RXB): Exist
9ON
RS (RTS) Auto control mode: Enable
10 ON

JW Series Computer Link SIO Driver
GP-Pro EX Device/PLC Connection Manual 8
2 Selection of External Device
Select the External Device to be connected to the Display.
Setup Items Setup Description
Maker Select the maker of the External Device to be connected. Select "Sharp MS Corporation".
Driver
Select a model (series) of the External Device to be connected and connection method.
Select "JW Series Computer Link SIO".
Check the External Device which can be connected in "JW Series Computer Link SIO" in
system configuration.
)"1 System Configuration" (page 3)
Use System Area
Check this option when you synchronize the system data area of the Display and the device
(memory) of the External Device. When synchronized, you can use the ladder program of
the External Device to switch the display or display the window on the Display.
Cf. GP-Pro EXReference Manual "Appendix 1.4 LS Area (only for direct
access method)"
This can be also set with GP-Pro EX or in off-line mode of the Display.
Cf. GP-Pro EX Reference Manual "5.14.6[ Setting Guide of [System Setting
Window], Setting Guide of [Main Unit Settings], System Area Setting"
Cf. Maintenance/Troubleshooting "2.14.1 Settings common to all Display
models System Area Settings"
Port Select the Display port to be connected to the External Device.

JW Series Computer Link SIO Driver
GP-Pro EX Device/PLC Connection Manual 9
3 Example of Communication Setting
Examples of communication settings of the Display and the External Device, recommended by Digital
Electronics Corp., are shown.
3.1 Setting Example 1
Settings of GP-Pro EX
Communication Settings
To display the setting screen, select [Device/PLC Settings ] from [System setting window] in workspace.
Device Setting
To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific
Settings] of [Device/PLC Settings].

JW Series Computer Link SIO Driver
GP-Pro EX Device/PLC Connection Manual 10
Settings of External Device
Use the rotary switch on Link I/F for setting. Please refer to the manual of the External Device for more details.
Restart the power of the External Device after setting the switch to enable the setting.
Function Setting Switch
Station Setting Switch
Operation ModeSetting Switch
Transfer Speed Setting Switch
Termination Resistance Switch
Unit No. Switch
Rotary Switch Setting
Value Setup Description
SW0 4 SIO Type: Computer link
Rotary Switch Setting
Value Setup Description
SW2 (x10) 0 Station No. setting: Set the upper station number.
SW1 (x1) 1 Station No. setting: Set the lower station number.
• Set the station No. between 01 and 37 (o) with SW2 and SW1.
DIP Switch Setting
Value Setup Description
SW3-1 OFF Reserved
SW3-2 ON Number of communication wire: 4 wire
SW3-3 OFF Reserved
SW3-4 ON Parity: Even
Rotary Switch Setting
Value Setup Description
SW4 0 Transmission speed: 19200bps
DIP Switch Setting
Value Setup Description
SW7 ON Insert the termination resistance: Set it to ON to insert the termination resistance.
Set only the External Device which terminates the connection to ON.
Rotary Switch Setting
Value Setup Description
SW8 0 Set the data memory address for sub station 01 to 04.

JW Series Computer Link SIO Driver
GP-Pro EX Device/PLC Connection Manual 11
3.2 Setting Example 2
Settings of GP-Pro EX
Communication Settings
To display the setting screen, select [Device/PLC Settings ] from [System setting window] in workspace.
Device Setting
To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific
Settings] of [Device/PLC Settings].

JW Series Computer Link SIO Driver
GP-Pro EX Device/PLC Connection Manual 12
Settings of External Device
Use the rotary switch on Link I/F for setting. Please refer to the manual of the External Device for more details.
Restart the power of the External Device after setting the switch to enable the setting.
Function Setting Switch
Station Setting Switch
Operation ModeSetting Switch
Transfer Speed Setting Switch
Termination Resistance Switch
Unit No. Switch
Rotary Switch Setting
Value Setup Description
SW0 4 SIO Type: Computer link
Rotary Switch Setting
Value Setup Description
SW2 (x10) 0 Station No. setting: Set the upper station number.
SW1 (x1) 1 Station No. setting: Set the lower station number.
• Set the station No. between 01 and 37 (o) with SW2 and SW1.
DIP Switch Setting
Value Setup Description
SW3-1 OFF Reserved
SW3-2 OFF Number of communication wire: 2 wire
SW3-3 OFF Reserved
SW3-4 ON Parity: Even
Rotary Switch Setting
Value Setup Description
SW4 0 Transfer Speed: 19200 bps
DIP Switch Setting
Value Setup Description
SW7 ON Insert the termination resistance: Set it to ON to insert the termination resistance.
Set only the External Device which terminates the connection to ON.
Rotary Switch Setting
Value Setup Description
SW8 0 Set the data memory address for sub station 01 to 04.

JW Series Computer Link SIO Driver
GP-Pro EX Device/PLC Connection Manual 13
3.3 Setting Example 3
Settings of GP-Pro EX
Communication Settings
To display the setting screen, select [Device/PLC Settings ] from [System setting window] in workspace.
Device Setting
To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific
Settings] of [Device/PLC Settings].

JW Series Computer Link SIO Driver
GP-Pro EX Device/PLC Connection Manual 14
Settings of External Device
Set the bit of system memory in the External Device to ON or OFF. Please refer to the manual of the External
Device for more details.
Restart the power of the External Device after setting to enable the setting.
Setting for #236
• Description for Bit
Setting for #237
Setting Area Setting
Value Setup Description
#236 30(H) Communication setting. Enter in hex number.
Description for each bit is shown below.
Bit in System Area Setting
Value Setup Description
D0 OFF
Transfer Speed: 19200 bpsD1 OFF
D2 OFF
D3 OFF Parity: Even
D4 ON
D5 ON Stop bit: 2 bits
D6 OFF Always OFF
D7 OFF Always OFF
Setting Area Setting
Value Setup Description
#237 1(o) Station No. setting. Enter in octal number.

JW Series Computer Link SIO Driver
GP-Pro EX Device/PLC Connection Manual 15
3.4 Setting Example 4
Settings of GP-Pro EX
Communication Settings
To display the setting screen, select [Device/PLC Settings ] from [System setting window] in workspace.
Device Setting
To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific
Settings] of [Device/PLC Settings].

JW Series Computer Link SIO Driver
GP-Pro EX Device/PLC Connection Manual 16
Settings of External Device
Set the bit of system memory in the External Device to ON or OFF. Please refer to the manual of the External
Device for more details.
Restart the power of the External Device after setting to enable the setting.
Setting for #236
• Description for Bit
Setting for #237
Termination Resistance Switch
Setting Area Setting
Value Setup Description
#236 30(H) Communication setting. Enter in hex number.
Description for each bit is shown below.
Bit in System Area Setting
Value Setup Description
D0 OFF
Transfer Speed: 19200 bpsD1 OFF
D2 OFF
D3 OFF Parity: Even
D4 ON
D5 ON Stop bit: 2 bits
D6 OFF Always OFF
D7 OFF Always OFF
Setting Area Setting
Value Setup Description
#237 1(o) Station No. setting. Enter in octal number.
DIP Switch Setting
Value Setup Description
SW1 ON Insert the termination resistance: Set it to ON to insert the termination resistance.
Set only the External Device which terminates the connection to ON.

JW Series Computer Link SIO Driver
GP-Pro EX Device/PLC Connection Manual 17
3.5 Setting Example 5
Settings of GP-Pro EX
Communication Settings
To display the setting screen, select [Device/PLC Settings ] from [System setting window] in workspace.
Device Setting
To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific
Settings] of [Device/PLC Settings].

JW Series Computer Link SIO Driver
GP-Pro EX Device/PLC Connection Manual 18
Settings of External Device
Set the bit of system memory in the External Device to ON or OFF. Please refer to the manual of the External
Device for more details.
Restart the power of the External Device after setting to enable the setting.
Setting for #234
• Description for Bit
Setting for #235
Setting Area Setting
Value Setup Description
#234 30(H) Communication setting. Enter in hex number.
Description for each bit is shown below.
Bit in System Area Setting
Value Setup Description
D0 OFF
Transfer Speed: 19200 bpsD1 OFF
D2 OFF
D3 OFF Parity: Even
D4 ON
D5 ON Stop Bit: 2 bits
D6 OFF Always OFF
D7 OFF Always OFF
Setting Area Setting
Value Setup Description
#235 1(o) Station No. setting. Enter in octal number.

JW Series Computer Link SIO Driver
GP-Pro EX Device/PLC Connection Manual 19
3.6 Setting Example 6
Settings of GP-Pro EX
Communication Settings
To display the setting screen, select [Device/PLC Settings ] from [System setting window] in workspace.
Device Setting
To display the setting screen, click ([Setting]) of the External Device you want to set from [Device-Specific
Settings] of [Device/PLC Settings].

JW Series Computer Link SIO Driver
GP-Pro EX Device/PLC Connection Manual 20
Settings of External Device
Set the bit of system memory in the External Device to ON or OFF. Please refer to the manual of the External
Device for more details.
Restart the power of the External Device after setting to enable the setting.
Setting for #236
• Description for Bit
Setting for #237
Setting Area Setting
Value Setup Description
#236 30(H) Communication setting. Enter in hex number.
Description for each bit is shown below.
Bit in System Area Setting
Value Setup Description
D0 OFF
Transfer Speed: 19200 bpsD1 OFF
D2 OFF
D3 OFF Parity: Even
D4 ON
D5 ON Stop Bit: 2 bits
D6 OFF Always OFF
D7 OFF Always OFF
Setting Area Setting
Value Setup Description
#237 1(o) Station No. setting. Enter in octal number.
