INSTALLATION MANUAL
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with
specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
SHARP CORPORATION
CHAPTER 1. Configuration
CHAPTER 2. Installation in MX-3500/4500 series
CHAPTER 3. Installation in MX-5500N/6200N/7000N
CONTENTS
CODE: 00ZMXPEX2/I1E
DIGITAL FULL COLOR
MULTIFUNCTIONAL SYSTEM OPTION
PRINT CONTROLLER UNIT
MODEL
MX-PEX1
MX-PEX2

MX-PEX2 Configuration 1 – 1
MX-PEX2 Service Manual
[1] Configuration
1. Combination list
2. Unpacking
1) Remove the print controller unit.
3. Packed items
1) Check that all the items are included in the package.
4. NOTE FOR INSTALLATION
The MFP model is detected when the power is turned on for the first time after the shipment from the factory, and the system that matches the
MFP (MX-5500N/6200N/7000N or MX-3500/4500 series) is started.
After the system is started, the initial setup screen is displayed.
After the completion of the setup, the detection of MFP model at the boot-up will not be executed.
It is necessary to return the controller to the default state if you want to re-connect it to another MFP after the setup.
System setting →Printer Setting (administrator area) →Fiery Setting →Run Setup
Password: Fiery.1 (Default) →Factory Default
NOTE: Please make sure to reset to the default state if you connect the controller to another model, because the controller starts
even when it is connected to another MFP (e.g., the controller set for MX-3500/4500 series to the MFP for MX-5500N/6200N/
7000N) even after completion of the setup.
NOTE: MX-PEX1 was shipped after setting the basic setting (the information of MFP) by default, but MX-PEX2 is shipped in the fac-
tory shipment setting (without setting of the information of MFP), because it is necessary to detect MFP when turning on the
power.
MX-PEX1 MX-PEX2
MX-3500/4500 series YES YES
MX-5500N/6200N/7000N NO YES
No. Names of bundles Quantity
1 I/F unit 1
2 Step screw 2
3 LAN cable (cross cable) 1
4 AC power cable 1
5 Caution label 1
6 CD-ROM 7
7 Quick guide 1
8 Release notes 1
9 KODAK chart 1
1
4
23
6
78
5
9
CAUTION:MX-PEX2 is compatible with both MX-5500N/6200N/7000N and MX-3500/4500 series.

MX-PEX2 Installation in MX-3500/4500 series 2 – 1
MX-PEX2 Service Manual
[2] Installation in MX-3500/4500
series
<Note before installation>
* Start installation after checking that the LINE indicator and the
DATA indicator below it on the operation panel are neither lit nor
blinking.
1. Turn off the power of the main unit
1) Turn the power switch located on the operation panel to the
"OFF" position.
2) After checking that the operation panel has gone out, open the
front cabinet and turn the main power switch to the “OFF” opsi-
tion.
3) Remove the power plug of the main unit from the outlet.
2. Install of the I/F unit
1) Remove the ozone filter cover. Remove the screws, and
remove the right rear cabinet cover.
2) Remove the screws, and pull out the MFP cnt PWB unit.
3) Remove the three screws of the MFP cnt PWB. Install the I/F
unit (package part No. 1) with the three screws that was
detached from MFP cnt PWB.
* When installing the I/F unit, use an extreme care to make
the sheet metal not come in contact with the MFP cnt PWB.
OFF
OFF
OFF
3
2
1
1
2
3

MX-PEX2 Installation in MX-3500/4500 series 2 – 2
4) Restore the MFP cnt PWB unit to the main unit, and fix with the
screws.
5) Cut out the cut-out portion of the right rear cabinet cover for
cable along the perforated line. Attach the right rear cabinet
cover, and fix with the screw. Attach the ozone filter cover.
3. Installation of the printer controller
1) Remove the four screws from the rear cabinet. Attach two step
screws (package part No. 2) to the two positions in four posi-
tions where the fixing screws have been removed.
2) Engage the printer controller unit with the step screws, and
slide it to the right door side.
3) Fix the print controller unit using the two screws of the four
screws removed in step 1.
4. Connector connection
1) Connect the cable (A) of the I/F unit, the LAN cable (package
part No. 3), and the AC power cord (C) (package part No. 4).
4
3
2
1
1
1
1
1
2
1
2
A
B
C

MX-PEX2 Installation in MX-3500/4500 series 2 – 3
5. Caution label attachment
1) Attach the caution label (package part No. 5) near a AC power
cord inlet of the main unit.
6. Turn on the power switch of the print
controller unit and the main unit
1) Insert the power plug of the print controller unit into the power
outlet.
2) Insert the power plug of the main unit to the outlet.
3) Turn on the power switch of the print controller unit.
4) Open the front cabinet. Turn ON the power switch in the front
cabinet of the main unit.
5) Turn ON the power switch on the operation panel.
7. Note for network setting and
calibration resetting
CAUTION: After the MX-PEX1/PEX2 is installed, be sure the
setting of items as follows again.
(Reconfiguration in setting is required, because the
information that had been keeping before installa-
tion is initialized.)
1) System setting →Printer Setting (administrator area) →Fiery
Setting →Carry out the initial setting from Fiery menu.
2) After the initial setting and automatic reboot →Printer Setting
(administrator area) →Fiery Setting →Carry out the calibra-
tion from Fiery menu again.
A. About the Fiery Setting
Refer to the configuration manual "SETTING UP THE FIERY
X3ETY2 FROM THE COPIER TOUCH PANEL".
B. About the calibration
Refer to the color printing manual "Calibration".
1) To execute the calibration from the touch panel of Copier, refer
to the "Calibrating from the Fiery X3eTY2 copier touch panel".
2) To execute the calibration with a color measurement meter,
refer to the "Calibrating with ColorWise Pro Tools Calibrator".
ON
ON
ON
ON
CAUTION:

MX-PEX2 Installation in MX-5500N/6200N/7000N 3 – 1
MX-PEX2 Service Manual
[3] Installation in MX-5500N/
6200N/7000N
<Note before installation>
* Start installation after checking that the LINE indicator and the
DATA indicator below it on the operation panel are neither lit nor
blinking.
1. Turn OFF the power of the main unit
1) Turn the power switch located on the operation panel to the
"OFF" position.
2) After checking that the operation panel has gone out, open the
front cabinet and turn the main power switch to the “OFF” posi-
tion.
3) Disconnect the power plug of the main unit from the power out-
let.
2. Removal of the control box
1) Remove the screw of right rear cabinet, push down the right
rear cabinet. Disengage the pawls, and remove the right rear
cabinet so that slide to the front side.
2) Remove the screws of control box. Raise the finger handle,
and pull out the control box slowly.
3) Pull out the control box until the position in which the clamp is
seen. Remove the HDD-IDE cable from the clamp.
4) Pull out the control box until the position in which the connector
of the HDD-IDE cable is seen. Pull the sheet, and remove the
HDD-IDE cable.
"OFF"
"OFF"
"OFF"
3
4
1
2
1
1
2
2
3
1
2
1
2

MX-PEX2 Installation in MX-5500N/6200N/7000N 3 – 2
3. Install of the I/F unit
1) Remove the three screws of the MFP cnt PWB. Install the I/F
unit (package part No.1) with the three screws that was
detached from MFP cnt PWB.
* When installing the I/F unit, use an extreme care to make
the sheet metal not come in contact with the MFP cnt PWB.
4. Installation of the control box
1) Insert the control box until the connectable position for HDD-
IDE cable, connect the HDD-IDE cable.
2) Insert the control box until the position that fix the HDD-IDE
cable to the clamp, put the HDD-IDE cable to the sheet (A),
and fix it to the clamp.
* Check that the HDD-IDE cable is not twisting, hanging
down, etc.
3) Push the control box into the main unit. Lay the finger handle.
Fix with the screws.
4) Cut out the cut-out portion of the right rear cabinet.
5) Push into the cable to the right cabinet rear cover, and attach
it. At this time, check that the pawls are properly fitted to the
main unit.
1
2
3
1
2
1
A
2
3
12
2
3
3
2
4
5
2
3
1

MX-PEX2 Installation in MX-5500N/6200N/7000N 3 – 3
5. Installation of the printer controller
1) Remove the four screws from the rear cabinet. Attach two step
screws (package part No. 2) to the two positions in four posi-
tions where the fixing screws have been removed.
2) Engage the printer controller unit with the step screws, and
slide it to the right door side.
3) Fix the print controller unit using the two screws of the four
screws removed in step 1.
4) Connect the cable (A) of the I/F unit, the LAN cable (package
part No. 3), and the AC power cord (C) (package part No. 4).
6. Caution label attachment
1) Attach the caution label (package part No. 5) near a AC power
cord inlet of the main unit.
7. Turn ON the power switch of the print
controller unit and main unit
1) Insert the power plug of the print controller unit into the power
outlet.
1
1
1
1
2
1
2
2
A
B
C

MX-PEX2 Installation in MX-5500N/6200N/7000N 3 – 4
2) Insert the power plug of the main unit into the power outlet.
3) Turn ON the power switch of the print controller unit.
4) Open the front cabinet. Turn ON the power switch in the front
cabinet of the main unit.
5) Turn ON the power switch on the operation panel.
8. Note for network setting and
calibration resetting
CAUTION: After the MX-PEX2 is installed, be sure the setting
of items as follows again.
(Reconfiguration in setting is required, because the
information that had been keeping before installa-
tion is initialized.)
1) System setting →Printer Setting (administrator area) →Fiery
Setting →Carry out the initial setting from Fiery menu.
2) After the initial setting and automatic reboot →Printer Setting
(administrator area) →Fiery Setting →Carry out the calibra-
tion from Fiery menu again.
A. About the Fiery Setting
Refer to the configuration manual "SETTING UP THE FIERY
X3ETY2 FROM THE COPIER TOUCH PANEL".
B. About the calibration
Refer to the color printing manual "Calibration".
1) To execute the calibration from the touch panel of Copier, refer
to the "Calibrating from the Fiery X3eTY2 copier touch panel".
2) To execute the calibration with a color measurement meter,
refer to the "Calibrating with ColorWise Pro Tools Calibrator".
ON
"ON"
ON
ON
CAUTION:

No part of this publication may be reproduced,
stored in a retrieval system, or transmitted in
any form or by any means, electronic, mechanical,
photocopying, recording, or otherwise, without
prior written permission of the publisher.
COPYRIGHT ©XXXX BYSHARP CORPORATION
ALL RIGHTS RESERVED.
The PWB’s of this model employs lead-free solder. The “LF” marks indicated on the PWB’s and the Service Manual mean “Lead-Free” solder.
The alphabet following the LF mark shows the kind of lead-free solder.
(1) NOTE FOR THE USE OF LEAD-FREE SOLDER THREAD
When repairing a lead-free solder PWB, use lead-free solder thread.
Never use conventional lead solder thread, which may cause a breakdown or an accident.
Since the melting point of lead-free solder thread is about 40°C higher than that of conventional lead solder thread, the use of the
exclusive-use soldering iron is recommendable.
(2) NOTE FOR SOLDERING WORK
Since the melting point of lead-free solder is about 220°C, which is about 40°C higher than that of conventional lead solder, and its soldering
capacity is inferior to conventional one, it is apt to keep the soldering iron in contact with the PWB for longer time. This may cause land
separation or may exceed the heat-resistive temperature of components. Use enough care to separate the soldering iron from the PWB when
completion of soldering is confirmed.
Since lead-free solder includes a greater quantity of tin, the iron tip may corrode easily. Turn ON/OFF the soldering iron power frequently.
If different-kind solder remains on the soldering iron tip, it is melted together with lead-free solder. To avoid this, clean the soldering iron
tip after completion of soldering work.
If the soldering iron tip is discolored black during soldering work, clean and file the tip with steel wool or a fine filer.
Example:
5mm
Lead-Free
Solder composition
code (Refer to the
table at the right.)
<Solder composition code of lead-free solder>
Solder composition
Sn-Ag-Cu
Sn-Ag-Bi
Sn-Ag-Bi-Cu
Sn-Zn-Bi
Sn-In-Ag-Bi
Sn-Cu-Ni
Sn-Ag-Sb
Bi-Sn-Ag-P
Bi-Sn-Ag
a
b
z
i
n
s
p
Solder composition code
a
LEAD-FREE SOLDER

(Danish) ADVARSEL !
Lithiumbatteri – Eksplosionsfare ved fejlagtig håndtering.
Udskiftning må kun ske med batteri
af samme fabrikat og type.
Levér det brugte batteri tilbage til leverandoren.
(English) Caution !
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type
recommended by the manufacturer.
Dispose of used batteries according to manufacturer’s instructions.
(Finnish) VAROITUS
Paristo voi räjähtää, jos se on virheellisesti asennettu.
Vaihda paristo ainoastaan laitevalmistajan suosittelemaan
tyyppiin. Hävitä käytetty paristo valmistajan ohjeiden
mukaisesti.
(French) ATTENTION
Il y a danger d’explosion s’ il y a remplacement incorrect
de la batterie. Remplacer uniquement avec une batterie du
même type ou d’un type équivalent recommandé par
le constructeur.
Mettre au rebut les batteries usagées conformément aux
instructions du fabricant.
(Swedish) VARNING
Explosionsfara vid felaktigt batteribyte.
Använd samma batterityp eller en ekvivalent
typ som rekommenderas av apparattillverkaren.
Kassera använt batteri enligt fabrikantens
instruktion.
(German) Achtung
Explosionsgefahr bei Verwendung inkorrekter Batterien.
Als Ersatzbatterien dürfen nur Batterien vom gleichen Typ oder
vom Hersteller empfohlene Batterien verwendet werden.
Entsorgung der gebrauchten Batterien nur nach den vom
Hersteller angegebenen Anweisungen.
(For USA, CANADA)
“BATTERY DISPOSAL”
THIS PRODUCT CONTAINS A LITHIUM PRIMARY
(MANGANESS DIOXIDE) MEMORY BACK-UP BATTERY
THAT MUST BE DISPOSED OF PROPERLY. REMOVE THE
BATTERY FROM THE PRODUCT AND CONTACT YOUR
LOCAL ENVIRONMENTAL AGENCIES FOR INFORMATION
ON RECYCLING AND DISPOSAL OPTIONS.
“TRAITEMENT DES PILES USAGÉES”
CE PRODUIT CONTIENT UNE PILE DE SAUVEGARDE DE
MÉMOIRE LITHIUM PRIMAIRE (DIOXYDE DE MANGANÈSE)
QUI DOIT ÊTRE TRAITÉE CORRECTEMENT. ENLEVEZ LA
PILE DU PRODUIT ET PRENEZ CONTACT AVEC VOTRE
AGENCE ENVIRONNEMENTALE LOCALE POUR DES
INFORMATIONS SUR LES MÉTHODES DE RECYCLAGE ET
DE TRAITEMENT.
CAUTION FOR BATTERY REPLACEMENT
CAUTION FOR BATTERY DISPOSAL
* Applicable for model that uses battery.

SHARP CORPORATION
Digital Document System Group
CS Promotion Center
Yamatokoriyama, Nara 639-1186,
Japan
COPYRIGHT ©2006 BY SHARP CORPORATION
Trademark acknowledgements
Microsoft
®
Windows
®
operating system is a trademark or copyright of Microsoft
Corporation in the U.S.A. and other countries.
• Windows
®
95, Windows
®
98, Windows
®
Me, Windows NT
®
4.0, Windows
®
2000,
Windows
®
XP, Windows
®
2000 Server, Windows
®
Server 2003 and Internet
Explorer
®
are trademarks or copyrights of Microsoft Corporation in the U.S.A. and
other countries.
• IBM and PC/AT are trademarks of International Business Machines Corporation.
• Acrobat
®
Reader Copyright
®
1987- 2002 Adobe Systems Incorporated. All rights
reserved. Adobe, the Adobe logo, Acrobat, and the Acrobat logo are trademarks of
Adobe Systems Incorporated.
re
• All other trademarks and copyrights are the property of their respective owners.
All rights reserved.
Printed in Japan.
No part of this publication may be reproduced,
stored in a retrieval system, or transmitted,
in any form or by any means,
electronic; mechanical; photocopying; recording or otherwise
without prior written permission of the publisher.
