SERVICE MANUAL
Page
SPECIFICATIONS ............................................................................................................................. 1-1-1
LASER BEAM SAFETY PRECAUTIONS .......................................................................................... 1-2-1
IMPORTANT SAFEGUARDS AND PRECAUTIONS......................................................................... 1-3-1
STANDARD NOTES FOR SERVICING............................................................................................. 1-4-1
OPERATING CONTROLS AND FUNCTIONS .................................................................................. 1-5-1
CABINET DISASSEMBLY INSTRUCTIONS ..................................................................................... 1-6-1
FIRMWARE RENEWAL MODE ......................................................................................................... 1-7-1
TROUBLESHOOTING ....................................................................................................................... 1-8-1
BLOCK DIAGRAMS........................................................................................................................... 1-9-1
SCHEMATIC DIAGRAMS/ CBA’S AND TEST POINTS .................................................................. 1-10-1
WAVEFORMS.................................................................................................................................. 1-11-1
WIRING DIAGRAM .......................................................................................................................... 1-12-1
SYSTEM CONTROL TIMING CHARTS .......................................................................................... 1-13-1
IC PIN FUNCTION DESCRIPTIONS ............................................................................................... 1-14-1
LEAD IDENTIFICATIONS................................................................................................................ 1-15-1
EXPLODED VIEWS ......................................................................................................................... 1-16-1
MECHANICAL PARTS LIST ............................................................................................................ 1-17-1
ELECTRICAL PARTS LIST ............................................................................................................. 1-18-1
CONTENTS
In the interests of user-safety (Required by safety regula-
tions in some countries) the set should be restored to its
original condition and only parts identical to those specified
be used.
MODELS DV-SL80
DV-SL80X
SERVICE MANUAL DVD VIDEO PLAYER MODELS DV-SL80/DV-SL80X
DVD VIDEO PLAYER
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
SHARP CORPORATION
OPERATE
3 4
NTSC/PAL
---DV-SL80 ---DV-SL80
X

1-1-1 E5943SP
SPECIFICATIONS
NOTES:
1. All Items are measured without pre-emphasis unless otherwise specified.
2. Power supply : AC110 - 240 V ~ 50/60Hz --- [ DV-SL80 ]
AC220 - 240 V ~ 50/60Hz --- [ DV-SL80X ]
3. Load imp. : 100 k ohm
4. Room ambient : 5 °C ~ 40 °C
ITEM CONDITIONS UNIT NOMINAL LIMIT
1 Video Output 75 ΩVpp 1.0 ±0.1
2-1 Coaxial Digital Out mVpp 500
2-2 Optical Digital Out dBm -18
(DV-SL80X only)
3 Audio (PCM)
3-1. Output Level 1 kHz 0 dB Vrm 2.0
3-2. S/N dB 120
3-3. Freq. Response
DVD fs=48 kHz 20 ~ 22 kHz dB ±0.5
CD fs=44.1 kHz 20 ~ 22 kHz dB ±0.5
3-4. THD +N
DVD 1k Hz 0 dB % 0.0025
CD 1k Hz 0 dB % 0.003
4 Power consumption 14 W (Standby: 2.0 W) --- [ DV-SL80 ]
12 W (Standby: 1.5 W) --- [ DV-SL80X ]
5 Weight 1.3kg
6 Dimension 435 mm X 51 mm X 211 mm

1-2-1 DVD_LASER
LASER BEAM SAFETY PRECAUTIONS
This DVD player uses a pickup that emits a laser beam.
Do not look directly at the laser beam coming
from the pickup or allow it to strike against
your skin.
The laser beam is emitted from the location shown in the figure. When checking the laser diode, be sure to keep your
eyes at least 30cm away from the pickup lens when the diode is turned on. Do not look directly at the laser beam.
Caution: Use of controls and adjustments, or doing procedures other than those specified herein, may result in
hazardous radiation exposure.
D
rive Mecha Assembly
Laser Beam Radiation
Laser Pickup
Turntable

1-3-1 E5943IMP
1. IMPORTANT SERVICE NOTES
BEFORE RETURNING THE DVD VIDEO PLAYER
Before returning the DVD video player to the user,
perform the following safety checks.
1. Inspect all lead dress to make certain that leads are
not pinched or that hardware is not lodged between
the chassis and other metal parts in the DVD video
player.
2. Inspect all protective devices such as non-metallic
control knobs, insulation materials, cabinet backs,
adjustment and compartment covers or shields, isola-
tion resistor/capacitor networks, mechanical insula-
tors etc.
3. To be sure that no shock hazard exists, check for
current in the following manner.
Plug the AC line cord directly into a 230 volt AC outlet
(Do not use an isolation transformer for this test).
Using two clip leads, connect a 1.5k ohm, 10 watt
resistor paralleled by a 0.15µF capacitor in series with
all exposed metal cabinet parts and a known earth
ground, such as a water pipe or conduit.
UseanDVM or VOMwith1000 ohmper volt, or higher,
sensitivity or measure the AC voltage drop across the
resistor (See Diagram).
Move the resistor connection to earth exposed metal
part having a return path to the chassis (metal cabinet,
screw heads, knobs and control shafts, etc.) and
measure the AC voltage drop across the resistor.
Reverse the AC plug on the set and repeat AC voltage
measurements for each exposed part. Any reading of
1.4Vrms (thiscorresponds to 0.7mArms AC.)or more
is excessive and indicates a potential shock hazard
which must be corrected before returning the DVD
video player to the owner.
1. NOTES DE SERVICE IMPORTANTES
AVANT DE RENDRE LE REPRODUCTOR DE VíDEO
DVD
AvantderendrelereproductordevídeoDVDàl’utilisateur,
effectuer les vérifications de sécurité suivantes.
1. Vérifier toutes les gaines de fil pour être sûr que les fils
ne sont pas pincés ou que le matériel n’est pas coincé
entre le châssis et les autres pièces métalliques dans le
reproductor de vídeo DVD.
2. Vérifier tous les dispositifs de protection tels que les
boutons de commande non métalliques, les matériaux
d’isolement, le dos du coffret, les couvercles de
compartiment et ajustement ou les boucliers, les
réseaux de résistance / condensateur d’isolement, Ies
isolateurs mécaniques, etc.
3. Pourêtresûrqu’iln’yaaucunrisquedechocélectrique,
vérifier le courant de fuite de la maniére suivante.
Brancher le cordon d’alimentation secteur directement
dans une prise de courant de 230 volts. (Ne pas utiliser
de transformateur d’isolement pour cet essai).
Utiliser deux fils à pinces et connecter une résistance
de10watts1,5kohmenparallèleavecuncondensateur
de0,15µFensérieavecdespiècesducoffretmétallique
exposées et une masse de terre connue telle qu’un
tuyau ou un conduit d’eau.
Utiliser un DVM ou VOM avec une sensibilité de 1000
ohms par volt ou plus ou mesurer la chute de tension
CA entre la résistance (voir diagramme).
Déposer la connexion de la résistance à toutes les
pièces métalliques exposées ayant un parcours de
retour au châssis (coffret métallique, tétes de vis, bou-
tons et arbres de commande, etc.) et mesurer la chute
de tension CA entre la résistance. Inverser la fiche CA
(une fiche intermédiaire non polarisée doit être utilisée
à seule fin de faire ces vérifications.) sur l’appareil et
répéter les mesures de tension CA pour chaque piéce
métallique exposée. Toute lecture de 1,4 V rms (ceci
correspond à 0,7 mA rms CA) ou plus est excessive et
signale un danger de choc qui doit être corrigé avant de
rendre le reproductor de vídeo DVD à son utilisateur.
IMPORTANT SAFEGUARDS AND PRECAUTIONS
SSVM
AC SCALE
1.5k ohms.
10W
0.15
TEST PROBE
T
O EXPOSED
M
ETAL PARTS
CONNECT TO
KNOWN EARTH
GROUNG
F
VTVM
AC SCALE
1.5k ohms
10W
CONNECT TO
KNOWN EARTH
GROUND
TO EXPOSED
METAL PARTS
TEST PROBE
0.15 F

1-4-1 DVD_NOTE2
Circuit Board Indications
a. The output pin of the 3 pin Regulator ICs is indicated
as shown.
Top View
Out In
Bottom View
Input
b. For other ICs, pin 1 and every fifth pin are indicated
as shown.
5
10
Pin 1
< Bottom View >
c. The 1st pin of every male connector is indicated as
shown.
Pin 1
< Bottom View >
Instructions for Connectors
1. When you connect or disconnect the FFC (Flexible
Foil Connector) cable, be sure to first disconnect the
AC cord.
2. FFC (Flexible Foil Connector) cable should be in-
serted parallel into the connector, not at an angle.
FFC Cable
Connector
CBA
* Be careful to avoid a short circuit.
Using lead-free wire solder
When fixing the PWB soldered with the lead-free solder,
apply lead-free wire solder. Repairing with conventional
lead wire solder may cause damage or accident due to
cracks.
As the melting point of lead-free solder (Sn-Ag-Cu) is
higherthanthe lead wire solderby40°C,we recommend
you to use a dedicated soldering bit, if you are not
familiar with how to obtain lead-free wire solder or
soldening bit, contact our service station or service
ranch in your area.
Soldering
As the melting point of lead-free solder (Sn-Ag-Cu) is
about 220°C which is higher than the conventional lead
solder by 40°C, and as it has poor solder wettabillty, you
may be apt to keep the soldering bit in contact with the
PWB for extended period of time. However, Since the
land may be peeled off or the maximum heat-resistance
temperature of parts may be excoeded, remove the bit
from the PWB as soon as you conurm the steady
soldering condition.
Lead-free solder contains more tin, and the end of the
soldering bit may be easily corroded. Make sure to tum
on and off the power of the bit as required. if a different
type of solder stays on the tip of the soldering bit, it is
alloyed with lead-free solder. Clean the bit after every
use of it.
When the tip of the soldering bit is blackened during
use, file it with steel wool or fine sandpaper.
Becareful when replacing parts with polarity indication
on the PWB silk.
Lead-free wire solder for servicing
STANDARD NOTES FOR SERVICING
Part No. Description Code
ZHNDAi123250E J 0.3mm 250g(1roll) BL
ZHNDAi126500E J 0.6mm 500g(1roll) BK
ZHNDAi12801KE J 1.0mm 1kg(1roll) BM

1-4-2 DVD_NOTE2
How to Remove / Install Flat Pack-IC
1. Removal
With Hot-Air Flat Pack-IC Desoldering Machine:
(1)Prepare the hot-air flat pack-IC desoldering ma-
chine, then apply hot air to the Flat Pack-IC (about 5
to 6 seconds). (Fig. S-1-1)
Fig. S-1-1
(2)Remove the flat pack-IC with tweezers while apply-
ing the hot air.
(3)Bottom of the flat pack-IC is fixed with glue to the
CBA; when removing entire flat pack-IC, first apply
soldering iron to center of the flat pack-IC and heat
up. Then remove (glue will be melted). (Fig. S-1-6)
(4)Release the flat pack-IC from the CBA using twee-
zers. (Fig. S-1-6)
Caution:
1. Do not supply hot air to the chip parts around the flat
pack-IC for over 6 seconds because damage to the
chip parts may occur. Put masking tape around the
flat pack-IC to protect other parts from damage.
(Fig. S-1-2)
2. The flat pack-IC on the CBA is affixed with glue, so
be careful not to break or damage the foil of each pin
or the solder lands under the IC when removing it.
Hot-air
Flat Pack-IC
Desoldering
Machine
CBA
Flat Pack-IC
Tweezers
Masking
Tape
Fig. S-1-2
With Soldering Iron:
(1)Using desoldering braid, remove the solder from all
pins of the flat pack-IC. When you use solder flux
which is applied to all pins of the flat pack-IC, you can
remove it easily. (Fig. S-1-3)
Flat Pack-IC Desoldering Braid
Soldering Iron
Fig. S-1-3
(2)Lift each lead of the flat pack-IC upward one by one,
using a sharp pin or wire to which solder will not
adhere (iron wire). When heating the pins, use a fine
tip soldering iron or a hot air desoldering machine.
(Fig. S-1-4)
Fine Tip
Soldering Iron
Sharp
Pin
Fig. S-1-4
(3)Bottom of the flat pack-IC is fixed with glue to the
CBA; when removing entire flat pack-IC, first apply
soldering iron to center of the flat pack-IC and heat
up. Then remove (glue will be melted). (Fig. S-1-6)
(4)Release the flat pack-IC from the CBA using twee-
zers. (Fig. S-1-6)
With Iron Wire:
(1)Using desoldering braid, remove the solder from all
pins of the flat pack-IC. When you use solder flux
which is applied to all pins of the flat pack-IC, you can
remove it easily. (Fig. S-1-3)
(2) Affix the wire to a workbench or solid mounting point,
as shown in Fig. S-1-5.
(3)While heating the pins using a fine tip soldering iron
or hot air blower, pull up the wire as the solder melts
so as to lift the IC leads from the CBA contact pads
as shown in Fig. S-1-5.

1-4-3 DVD_NOTE2
(4)Bottom of the flat pack-IC is fixed with glue to the
CBA; when removing entire flat pack-IC, first apply
soldering iron to center of the flat pack-IC and heat
up. Then remove (glue will be melted). (Fig. S-1-6)
(5)Release the flat pack-IC from the CBA using twee-
zers. (Fig. S-1-6)
Note:
When using a soldering iron, care must be taken to
ensure that the flat pack-IC is not being held by glue.
When the flat pack-IC is removed from the CBA,
handle it gently because it may be damaged if force
is applied.
To Solid
Mounting Point
Soldering Iron
Iron Wire
or
Hot Air Blower
Fig. S-1-5
Fine Tip
Soldeing Iron
CBA
Flat Pack-IC
Tweezers
Fig. S-1-6
2. Installation
(1)Using desoldering braid, remove the solder from the
foil of each pin of the flat pack-IC on the CBA so you
can install a replacement flat pack-IC more easily.
(2)The “ ” mark on the flat pack-IC indicates pin 1. (See
Fig. S-1-7.) Be sure this mark matches the 1 on the
PCB when positioning for installation. Then presol-
der the four corners of the flat pack-IC. (See Fig. S-
1-8.)
(3)Solder all pins of the flat pack-IC. Be sure that none
of the pins have solder bridges.
Example :
Pin 1 of the Flat Pack-IC
is indicated by a " " mark. Fig. S-1-7
Presolder
CBA
Flat Pack-IC
Fig. S-1-8

1-4-4 DVD_NOTE2
Instructions for Handling
Semi-conductors
Electrostatic breakdown of the semi-conductors may
occurduetoapotentialdifferencecausedbyelectrostatic
charge during unpacking or repair work.
1. Ground for Human Body
Be sure to wear a grounding band (1MΩ) that is properly
grounded to remove any static electricity that may be
charged on the body.
2. Ground for Workbench
Be sure to place a conductive sheet or copper plate with
proper grounding (1MΩ) on the workbench or other
surface, where the semi-conductors are to be placed.
Because the static electricity charge on clothing will not
escape through the body grounding band, be careful to
avoid contacting semi-conductors with your clothing.
CBA
< Incorrect >
CBA
Grounding Band
Conductive Sheet or
Copper Plate
< Correct >

1-5-1 E5943IB
OPERATING CONTROLS AND FUNCTIONS
AUDIO OUT
DIGITAL AUDIO OUT
COAXIALOPTICAL
LY
VIDEO
OUT C
B
/ P
B
S-VIDEO
OUT
C
R
/ P
R
COMPONENT
VIDEO OUT
R
11 13 14 161512
10
4
REAR VIEW
OPERATE
243519
8
7
6
FRONT PANEL
REMOTE CONTROL
STILL/PAUSEDIRECT SKIP
RETURN
ZOOM
MODE
SUBTITLE
MARKER
MENU
SKIP
REPEAT
A-B REPEAT
ANGLE AUDIO
CLEAR
TITLE
STOP
PLAY
FWD
REV
SETUP
DIMMER
ENTER
OPEN/
CLOSE
GAMMA
ON
SCREEN
OPERATE
1 2 3
6
54
7
0
+10
8 9
1
2
3
5
7
9
10
11
12
13
8
4
6
14 29
28
26
27
25
24
23
22
21
19
17
16
15
18
20
C
PLAY Button
Starts playback of the disc contents.
DIRECT SKIP Button
Press to locate a desired point.
STOP Button
Stops operation of the disc.
OPEN/CLOSE Button
Press to insert discs into or remove them from the tray.
SETUP Button
Press to enter the setup mode or to change setup items.
MARKER Button
Press to call back the Marker display.
MODE Button
Activates programme playback or random playback mode.
(CD/MP3/JPEG)
Activates the 3D sound or Rapid Play. (DVD)
AUDIO Button
Press to select a desired audio language or sound mode.
ANGLE Button
Press to change the camera angle to see the sequence
being played back from a different angle.
MENU Button
Displays the DVD menus and MP3 file lists.
Arrow Buttons ( )
(left/right/up/down) Select an item in the menu.
ENTER Button
Press to accept a setting.
REPEAT Button
Repeats playback of the current disc, title, chapter or track.
A-B REPEAT Button
Repeats playback of a selected section.
SKIP Button
Plays back from the beginning of the next chapter or track.
SKIP Button
Plays back from the beginning of the current chapter or
track.
FWD Button
Fast forwards playback to a desired point.
STILL/PAUSE Button
Pause playback temporarily/frame-by-frame playback.
OPERATE Button
Press to turn the power on and off.
ON SCREEN Button
Displays the current status on the TV screen for checking
purposes.
DIMMER Button
Press to change the Panel Display settings.
GAMMA Button
Press to adjust the black parts of the picture brighter.
ZOOM Button
Enlarges part of a DVD-reproduced image.
SUBTITLE Button
Press to select a desired subtitle language.
TITLE Button
Displays the title menu.
RETURN Button
Returns to the previous operation.
Numerical Buttons
CLEAR Button
Resets a setting.
REV Button
Fast reverse playback to a desired point.
1. OPERATE
to switch the player to ON or OFF
2. PLAY
to start or resume disc playback
3. STOP
to stop playback
4. SKIP / REV
goes to previous chapter or track during playback; press
and hold for 1.5 seconds for a reverse search
5. SKIP / FWD
goes to next chapter or track during playback; press and
hold for 1.5 seconds for a forward search
6. OPEN/CLOSE
to open/close the disc tray
7. Disc tray
8. Remote sensor window
9. Display
1
0. MAINS (AC Power Cord)
connect to a standard AC outlet
11. OPTICAL (Digital audio out)
connect to digital (optical) audio equipment
(DV-SL80X only)
12. COAXIAL (Digital audio out)
connect to AUDIO inputs of a digital (coaxial) audio
equipment
13. AUDIO OUT (Left/Right)
connect to AUDIO inputs of an amplifier, receiver or
stereo system
14. VIDEO OUT
connect to the Video Input of a TV
15. COMPONENT VIDEO OUT
connect to a TV with Component video in jacks
16. S-VIDEO OUT
connect to a TV with S-Video inputs
CAUTION:
Do not touch the inner pins of the jacks on the rea
r
panel. Electrostatic discharge may cause perma-
nent damage to the player.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.

1-6-1 E5943DC
CABINET DISASSEMBLY INSTRUCTIONS
1. Disassembly Flowchart
This flowchart indicates the disassembly steps to gain
access to item(s) to be serviced. When reassembling,
follow the steps in reverse order. Bend, route, and dress
the cables as they were originally.
1: Identification (location) No. of parts in the figures
2: Name of the part
3: Figure Number for reference
4: Identification of parts to be removed, unhooked,
unlocked, released, unplugged, unclamped, or de-
soldered.
P=Spring, L=Locking Tab, S=Screw,
CN=Connector,
*=Unhook, Unlock, Release, Unplug, or Desolder
e.g.5(S-1) = five Screws (S-1),
2(L-2) = two Locking Tabs (L-2)
5: Refer to "Reference Notes."
About tightening screws
When tightening screws, tighten them with the following
torque.
Screws Torque
(S-1), (S-2), (S-3A), (S-4), 0.45 ±0.05 N•m
(S-5), (S-6)
(S-3B) 0.38 ±0.04 N•m
Reference Notes
CAUTION 1: Locking Tabs (L-1), (L-2) and (L-3) are
fragile. Be careful not to break them.
1-1. Release four Locking Tabs (L-1). Then, release
three Locking Tabs (L-2) .
1-2. Release three Locking Tabs (L-3). Then remove
the Front Assembly.
CAUTION 2: Electrostatic breakdown of the laser diode
in the optical system block may occur as a potential
difference caused by electrostatic charge accumulated
on cloth, human body etc., during unpacking or repair
work.
To avoid damage of pickup follow next procedures.
2-1. Short the three short lands (either of two places) of
FPC cable with solder before removing the FFC
cable (CN201) from it as shown in “View for A” in
Fig. 4. If you disconnect the FFC cable (CN201),
the laser diode of pickup will be destroyed. (Fig. 4)
2-2. Disconnect Connectors (CN301), (CN401) and
(CN601). Remove two Screws (S-3A) and (S-3B)
and lift the DVD Main CBA Unit. (Fig. 4)
CAUTION 3: When reassembling, confirm the FFC
cable (CN201) is connected completely. Then remove
the solder from the three short lands of FPC cable.
(Fig. 4)
2. Disassembly Method
REMOVAL
ID/
LOC.
No.
Fig.
No.
REMOVE/
*UNHOOK/UNLOCK/
RELEASE/UNPLUG/
DESOLDER
Note
PART
[1] Top Case 1 3(S-1) -
[2] Front 2 *4(L-1), *3(L-2), 1
Assembly *3(L-3), 1-1
1-2
[3]
Reinforce
3 3(S-2) -
Plate
[4]
DVD
Main 4 (S-3A), (S-3B), 2
CBA Unit *CN201, *CN301, 2-1
*CN401, *CN601 2-2
3
[5] DVD 5 4(S-4) -
Mecha
[6] AV CBA 6 (S-5), -
4(S-6)---[DV-SL80]
5(S-6)---[DV-SL80X],
*2(L-5)
[7]
Function
6 *CN2001 -
CBA
↑↑↑ ↑ ↑
123 4 5
[2] Front Assembly
[3] Reinforce Plate
[4] DVD Main CBA Unit
[5] DVD Mecha [6] AV CBA
[7] Function CBA
[1] Top Case

1-6-2 E5943DC
(S-1)
[1]Top Case
Fig. 1
(L-2)
(L-3)
(L-1)
(L-1)
Fig. 2
[2] Front Assembly
(S-2)
Fig. 3
[3] Reinforce Plate
(S-3B) (S-3A)
CN201
CN301
CN401
CN601
A
Fig. 4
[4] DVD Main
CBA Unit
View for A
Short the three short lands
by soldering.
(Either of two places.)
Short
lands
Short lands
FPC Cable
OR
Solder
Solder
(S-4) (S-4)
(S-4)
[5] DVD Mecha
Fig. 5

1-6-3 E5943DC
HOW TO EJECT MANUALLY (Method 1)
1 Remove the Top Case.
2 Remove the Reinforce Plate.
3 Rotate the roulette in the direction of the arrow as shown below.
A
View for A
Rotate this roulette in
the direction of the arrow
DV-DL80X
only
(S-5)
(S-6)
(S-6)
CN2001
(L-5)
[6] AV CBA
[7] Function CBA
Fig. 6

1-6-4 E5943DC
HOW TO EJECT MANUALLY (Method 2)
1 Turn the unit over.
2 Insert the shaft less than a diameter of 3 mm (e.g. screwdriver) straightly into the opening
as shown.
3 Turn the shaft along with the opening clockwise.
4 Repeat steps 2 and 3 until the tray will open.
5 Pull the tray slowly with a hand.
B
View for B
Turn the shaft along with
the opening clockwise.
Rear
Front
Opening
Shaft
(e.g. screwdriver)

1-7-1 E5945TEST
FIRMWARE is built-in program to operate DVD player.
To get rid of error when playing new software (disc) in
the market, FIRMWARE version is updated. Perform
the following to update the FIRMWARE version.
1. Turn the power on and remove the disc on the tray.
2. To put the DVD player into version up mode, press
[9], [8], [7], [6], and [DIRECT SKIP] buttons on the
remote control unit in that order. The tray will open
automatically.
Fig. a appears on the screen and Fig. b appears on
the VFD.
F/W Version Up Mode Model No : *******
VERSION : *.**
Please insert a DISC
for F/WVersion Up.
EXIT: POWER
"*******" differ depending on the model
s.
Fig. a Version Up Mode Screen
F
ig. b VFD in Version Up Mod
e
The DVD player can also enter the version up mode
with the tray open. In this case, Fig. a will be shown
on the screen while the tray is open.
3. Load the disc for version up.
4. The DVD player enters the F/W version up mode
automatically. Fig. c appears on the screen and Fig.
d appears on the VFD. If you enter the F/W for
different models, "Disc Error" will appear on the
screen, then the tray will open automatically.
VERSION : E5****_****.ab5
Reading...(*2)
F/W Version Up Mode Model No : *******
VERSION : *.**
Fig. c Programming Mode Screen
"*******" differ depending on the model
s.
F
ig. d VFD in Programming Mode (Exampl
e)
FIRMWARE RENEWAL MODE
The appearance shown in (*2) of Fig. c is described
as follows:
AppearanceNo. State
Reading... Sending files into the memory
Erasing... Erasing previous version data
Programming...
1
2
3 Writing new version data
5. After programming is finished, the tray opens auto-
matically. Fig. e appears on the screen and the
checksum in (*3) of Fig. e appears on the VFD.
(Fig. f)
VERSION : E5****_****.ab5
Completed
SUM : 7ABC (*3)
F/W Version Up Mode Model No : *******
VERSION : *.**
"*******" differ depending on the model
s.
Fig. e Completed Program Mode Screen
F
ig. f VFD upon Finishing the Programming Mode (Exampl
e)
At this time, no buttons are available.
6. Remove the disc on the tray.
7. Unplug the AC cord from the AC outlet. Then plug it
again.
8. Turn the power on by pressing the [OPERATE]
button and the tray will close.
9. Press [1], [2], [3], [4], and [ON SCREEN] buttons on
the remote control unit in that order.
Fig. g appears on the screen.
MODEL : *******
Version
: *.**
Region
: *
EXIT: POWEREEPROM CLEAR : CLEAR
Fig. g
"*******" differ depending on the model
s.
10.Press [CLEAR] button on the remote control unit.
Fig. h appears on the screen.

1-7-2 E5945TEST
MODEL : *******
Version
: *.**
Region
: *
EEPROM CLEAR : OK
EXIT: POWEREEPROM CLEAR : CLEAR
"*******" differ depending on the model
s.
Fig. h
When "OK" appears on the screen, the factory
default will be set. Then the firmware renewal mode
is complete.
11.To exit this mode, press [OPERATE] button.

1-8-1 E5943TS
TROUBLESHOOTING
FLOW CHART NO.2
The fuse blows out.
After servicing, replace the fuse.
Check the presence that the primary component
is leaking or shorted and service it if defective. Check the presence that the rectifying diode or
circuit is shorted in each rectifying circuit of
secondary side, and service it if defective.
FLOW CHART NO.3
When the output voltage fluctuates.
Yes
No
FLOW CHART NO.4
When buzz sound can be heard in the vicinity of power circuit.
Check if there is any short-circuit on the rectifying diode and the circuit in each rectifying circuit of the secondary
side
, and service it if defective.
(D1003, D1006, D1008, D1016, D1030, IC1002, Q1002, Q1004, Q1005, Q1011)
Does the photo coupler circuit on the secondary
side operate normally?
Check IC1001, D1012, D1024 and their periphery,
and service it if defective.
Check IC1001, IC1006, D1048 and their
periphery, and service it if defective.
FLOW CHART NO.5
-FL is not outputted.
Is approximately -23V voltage supplied to the
anode of D1003? Check D1003 and periphery circuit, and service it
if defective.
Check if there is any leak or short-circuit
on the loaded circuit, and service it if defective.
Yes
No
FLOW CHART NO.1
The power cannot be turned on.
Is the fuse normal?
Is normal state restored when once unplugged
power cord is plugged again after several seconds?
Is the EV +3.3V line voltage normal?
See FLOW CHART No.2 <The fuse blows out.>
Check if there is any leak or short-circuiting on the
primary circuit component, and service it if defective
.
(Q1001, Q1003, Q1008, T1001, D1001, D1002,
D1004, D1005, D1011, C1003, C1005)
Check each rectifying circuit of the secondary circuit
and service it if defective.
Yes
Yes
Yes
No
No
No

1-8-2 E5943TS
FLOW CHART NO.7
P-ON+5V is not outputted. (EV+11V is outputted normally.)
Is the "H" signal inputted into the base of Q1004?
Replace Q1004.
Check R1068 and D1046, and service it if defective
.
Yes
No
FLOW CHART NO.8
P-ON+3.3V is not outputted. (P-ON+10V is outputted normally.)
Is 3.3V voltage supplied to the collector of Q1011?
Replace Q1011 or R1067.
Check D1008, C1007, C1038, L1007 and the
periphery circuit, and service it if defective.
Yes
No
FLOW CHART NO.9
EV+5V is not outputted.
Is EV+11V outputted normally?
Check D1047 and the periphery circuit,
and service it if defective.
Refer to "FLOW CHART NO.6"
<P-ON+10V (EV+11V) is not outputted.>
Yes
No
FLOW CHART NO.10
EV+1.2V is not outputted.
Is 2.5V voltage supplied to Pin(1) of IC1002?
Replace IC1002.
Check D1006, C1014, L1008 and the periphery
circuit, and service it if defective.
Yes
No
FLOW CHART NO.6
P-ON+10V (EV+11V) is not outputted.
Is 11V voltage supplied to the emitter of Q1002?
Is the voltage of base on Q1002 lower than the
voltage of emitter on Q1002 when turning the power on?
Replace Q1002.
Check D1030, D1048, C1035, C1048, L1009 and
the periphery circuit, and service it if defective.
Check Q1016 and PWRCON line and service it if
defective.
Yes
Yes
No
No

1-8-3 E5943TS
Yes No
FLOW CHART NO.12
The key operation is not functioning.
Are the contact point and the installation state of the
key switches (SW2101, SW2104-2108) normal?
When pressing each switches (SW
2101,
SW
2104-
2108
), do the voltage of each pin of IC2001
(shown below) increase?
SW2104, 2106, 2107: IC2001 3PIN
SW2101, 2105, 2108: IC2001 4PIN
Check the switches (
SW2101, SW2104-2108
) and
their periphery, and service it if detective.
No Re-install the switches (
SW2101, SW2104-2108
)
correctly or replace the poor switch.
Replace IC2001. Yes
FLOW CHART NO.13
No operation is possible from the remote control unit.
Operation is possible from the DVD, but no
operation is possible from the remote control unit.
Replace the infrared remote control receiver (RM2001)
.
Or replace the remote control unit.
Check the line between Pin(1) terminal of receiver
(RM2001) and Pin(22) of CN1001, and service it if
defective.
Is the "L" pulse sent out Pin(1) terminal of receiver
(RM2001) when the infrared remote control is activated?
Is the "L" pulse supplied to the Pin(22) of CN1001?
Replace DVD Main CBA.
Is 5V voltage supplied to Pin(3) terminal of
the infrared remote control receiver (RM2001)?
Yes No
Check EV+5V line and service it if defective.
No
No
Yes
Yes
Yes
Yes
Yes
Yes
No
No
No
No
FLOW CHART NO.11
The fluorescent display tube does not light up.
Is 3.3V voltage supplied to Pins(6,24) of IC2001?
Is the voltage of approximately -20V supplied to
Pin(15) of IC2001?
Is there 500kHz oscillation at Pin(26) of IC2001?
Are the filament voltage supplied between
Pins(1, 2) and Pins(29, 30) of the fluorescent
display tube? And the negative voltage applied
between these pins and GND?
Replace the fluorescent display tube.
Check the EV+3.3V line and service it if defective.
Check the -FL (-20V) line and service it if defective
.
Check R2002, IC2001 and their periphery, and
service it if defective.
Check PWRCON
line, and service
it if defective.
Is the "H" signal inputted
to base of Q1016?
Check D1016, D1017,T1001, and their periphery,
and service it if defective.
Is -15V voltage supplied to collector of Q1005?
No
Yes
YesNo
Check Q1015, Q1016, D1055, and
their periphery, and service it if defective.

1-8-4 E5943TS
FLOW CHART NO.17
[No Disc] indicated. (When the focus servo is not functioning.)
FLOW CHART NO.18
[No Disc] indicated. (When the laser beam does not light up.)
Replace the DVD Main CBA.
Replace the DVD Mecha.
No
Yes
Replace the DVD Main CBA.
Replace the DVD Mecha.
No
Yes
No improvement can be found. Original DVD Main CBA is poor.
No improvement can be found. Original DVD Main CBA is poor.
FLOW CHART NO.16
[No Disc] indicated. (When the focus error occurs.)
Replace the DVD Main CBA.
No improvement can be found. Original DVD Main CBA is poor.
Replace the DVD Mecha.
No
Yes
Yes
FLOW CHART NO.15
The disc tray cannot be opened and closed.
Replace the DVD Main CBA.
Original DVD Main CBA is poor.
Replace the DVD Mecha.
No improvement can be found. No
Yes
FLOW CHART NO.14
The disc tray cannot be opened and closed. (It can be done using the remote control unit.)
Is the normal control voltage inputted to Pin(4) of
IC2001?
Refer to "FLOW CHART NO.12" <The key
operation is not functioning.>
Refer to "FLOW CHART NO.15" <The disc tray
cannot be opened and closed.>
Replace the "OPEN/CLOSE" button (SW2108).
No

1-8-5 E5943TS
Is 5V voltage applied to the pin(4, 12) of IC1402?
Replace IC1402. Check P-ON+5V line and
service it if detective.
Are the video signals outputted to each pin
of IC1402?
Yes No
Yes
Yes
No
IC1402 13PIN S-Y
IC1402 11PIN Cb/Pb
IC1402 10PIN Cr/Pr
IC1402 14PIN CVBS
IC1402 15PIN S-C
Check the periphery of JK1404 from Pins (10, 11,
13) of IC1402 and service it if detective.
Check
the periphery of
JK1404 from Pin(14) of
IC1402
and service it if detective.
Check the periphery of JK1401 from
Pin (13) of IC1402 and service it if detective.
Check the periphery of JK1401 from
Pin (15) of IC1402 and service it if detective.
Are the video signals outputted to the specific
output terminal?
Are the component video signals outputted to the
VIDEO OUT terminal (JK1404)?
Are the luminance signals outputted to the
S-OUT terminal (JK1401)?
Are the chroma signals outputted to the
S-OUT terminal (JK1401)?
No
No
No
No
Are the composite video signals outputted to
the VIDEO OUT terminal (JK1404)?
FLOW CHART NO.20
Picture does not appear normally.
Set the disc on the disc tray, and playback.
Are the video signals outputted to each pin of
CN1601 on the AV CBA? Replace the DVD Main CBA or DVD Mecha.
Check the line between each pin of CN1601 and
each pin of IC1402 on the AV CBA, and service
it if detective.
CN1601 10PIN →IC1402 1PIN S-C
CN1601 8PIN →IC1402 3PIN S-Y
CN1601 6PIN →IC1402 6PIN Cb/Pb
CN1601 4PIN →IC1402 8PIN Cr/Pr
Are the video signals shown above inputted into
each pin of IC1402?
Yes
No
No
CN1601 4PIN Cr/Pr
CN1601 6PIN Cb/Pb
CN1601 8PIN S-Y
CN1601 10PIN S-C
IC1402 1PIN S-C
IC1402 3PIN S-Y
IC1402 6PIN Cb/Pb
IC1402 8PIN Cr/Pr
FLOW CHART NO.19
Both functions of picture and sound do not operate normally.
Replace the DVD Main CBA.
Replace the DVD Mecha.
No
Yes
No improvement can be found. Original DVD Main CBA is poor.
This manual suits for next models
1
Table of contents
Other Sharp DVD Player manuals

Sharp
Sharp DV-SL1200W User manual

Sharp
Sharp DV-S1S(G) User manual

Sharp
Sharp DV-SL80X User manual

Sharp
Sharp DV-720S User manual

Sharp
Sharp DV-SV80S(G) User manual

Sharp
Sharp DV-740S User manual

Sharp
Sharp DV-SV90S(B) User manual

Sharp
Sharp DV-SV80S(B) User manual

Sharp
Sharp DV-600S User manual

Sharp
Sharp DV-S1U User manual

Sharp
Sharp DV-SL90UA User manual

Sharp
Sharp DV-SV80S User manual

Sharp
Sharp DV-SV 80 H User manual

Sharp
Sharp XL-E171DVH User manual

Sharp
Sharp DV-SL80U User manual

Sharp
Sharp DV-NC65H User manual

Sharp
Sharp DV-SV97S(RU) User manual

Sharp
Sharp DV-500D User manual

Sharp
Sharp DV-SL10S(Y) User manual

Sharp
Sharp DV-SV92S(RU) User manual
