Sharp SD-AT50H User manual

SD-AT50H
MANUALE DI ISTRUZIONI
GEBRUIKSAANWIJZING
MANUAL DE OPERAÇÃO
OPERATION MANUAL
BEDIENUNGSANLEITUNG
MODE D’EMPLOI
MANUAL DE MANEJO
BRUKSANVISNING
1-BIT DIGITAL HEIMKINO
ENSEMBLE HOME CINEMA 1-BIT
SISTEMA 1-BIT PARA HOME CINEMA
1-BIT DIGITAL HEMBIOGRAF
SISTEMA DIGITALE HOME CINEMA A 1 BIT
1-BIT DIGITALE HUISBIOSCOOP
CINEMA FAMILIAR DIGITAL DE 1-BIT
1-BIT DIGITAL
HOME CINEMA
DVD-SPIELER
LECTEUR DVD
REPRODUCTOR DE DVD
DVD SPELARE
LETTORE DVD
DVD-SPELER
APARELHO DE DVD
DVD PLAYER
Siehe Seiten i
bis vi und D-1
bis D-56.
DEUTSCH
Se reporter aux
pages i à vi et
F-1 à F-56.
FRANÇAIS
Consulte las
páginas i a vi
y S-1 a S-56.
ESPAÑOL
Hänvisa till
sidorna i till vi
och V-1 till V-56.
SVENSKA
Leggere le
pagine i a vi e
I-1 a I-56.
ITALIANO
Raadpleeg de
bladzijden i t/m
vi en N-1 t/m N-56.
NEDERLANDS
Favor consultar
as páginas i a vi e
P-1 a P-56.
PORTUGUÊS
Please refer to
pages i to vi and
E-1 to E-56.
ENGLISH
MODELL MODELLO
MODÈLE MODEL
MODELO MODELO
MODELL MODEL DX-AT50H
MODELL MODELLO
MODÈLE MODEL
MODELO MODELO
MODELL MODEL
SDAT50H(H)_FRONT 02.8.28, 5:36 PM1
Downloaded from: http://www.usersmanualguide.com/

i
SD-AT50H(H)_common.fm02/8/8
BESONDERE ANMERKUNGEN NOTE PARTICOLARI
REMARQUES SPÉCIALES BIJZONDERE OPMERKINGEN
NOTAS ESPECIALES NOTAS ESPECIAIS
SÄRSKILDA ANMÄRKNINGAR SPECIAL NOTES
●Bei Einstellung der ON/STAND-BY-Taste auf STAND-BY ist die
Netzspannung immer noch im Gerät vorhanden.
Wenn die ON/STAND-BY-Taste auf STAND-BY eingestellt wird, kann das
Gerät unter Verwendung der Timer-Betriebsart oder Fernbedienung in
Betrieb gesetzt werden.
Warnung:
In diesem Gerät sind keine vom Benutzer wartbaren Teile vorhanden.
Niemals Abdeckungen entfernen, außer wenn Sie dafür qualifiziert sind. In
diesem Gerät sind gefährliche Spannungen vorhanden. Vor Ausführung
von irgendwelchen Kundendienstarbeiten oder bei längerer Nicht-
verwendung des Gerätes stets den Netzstecker aus der Netzsteckdose
ziehen.
●Lorsque la touche ON/STAND-BY est mise en STAND-BY, l’appareil est
toujours sous tension.
Lorsque la touche ON/STAND-BY se trouve sur la position STAND-BY,
l’appareil est prêt à fonctionner par la minuterie ou la télécommande.
Avertissement:
Cet appareil contient des pièces non réparables par l’utilisateur. Personne
non qualifiée n’enlèvera jamais les couvercles. L’appareil contenant des
organes portés à haute tension, débrancher l’appareil avant toute réparation
ou en période de non-utilisation.
●Cuando el botón ON/STAND-BY está puesto en la posición STAND-BY,
todavía hay tensión dentro del aparato.
Cuando el botón ON/STAND-BY está puesto en la posición STAND-BY, el
aparato puede ponerse en funcionamiento utilizando el modo del
temporizador o el controlador remoto.
Advertencia:
Tenga en cuenta que dentro de este aparato no hay piezas que pueda
reparar. No quite nunca las tapas a menos que se esté cualificado para
hacerlo. Este aparato tiene en su interior tensiones peligrosas.
Desenchufe siempre la clavija de la red del tomacorriente antes de realizar
cualquier servicio de mantenimiento y cuando no se use el aparato
durante un largo período de tiempo.
●När ON/STAND-BY knappen är i läge STAND-BY, finns nätspänning i
apparaten.
Med ON/STAND-BY knappen i läge STAND-BY kan apparaten startas med
timerfunktion eller fjärrkontrollen.
Varning:
Apparaten innehåller inga delar som kan åtgärdas av kunden. Höljet får
endast öppnas av kvalificerad personal. Apparaten innehåller farliga
spänningar.
Stickkontakten ska därför dras ut från nätuttaget före reparationsarbeten
och bör dras ut om apparaten inte ska användas på mycket länge.
0110
●Dieses Gerät entspricht den Anforderungen der EG-Richtlinien 89/336/
EWG und 73/23/EWG mit Änderung 93/68/EWG.
●Ce matériel répond aux exigences contenues dans les directives 89/336/
CEE et 73/23/CEE modifiées par la directive 93/68/CEE.
●Este aparato satisface las exigencias de las Directivas 89/336/CEE y
73/23/CEE, modificadas por medio de la 93/68/CEE.
●Denna utrustning uppfyller kraven enligt riktlinjerna 89/336/EEC och 73/23/
EEC så som kompletteras av 93/68/EEC.
●Quest’apparecchio è conforme ai requisiti delle direttive 89/336/EEC e 73/
23/EEC, come emendata dalla direttiva 93/68/EEC.
●Dichiarazione di conformità
La società SHARP ELECTRONICS EUROPE GmbH dichiara che il prodotto
SHARP SISTEMA DIGITALE HOME CINEMA A 1BIT CON DVD è costruito
in conformità alle prescrizioni del D.M.n˚548 del 28/8/95, pubblicato sulla
G.U.n˚301 del 28/12/95 ed in particolare è conforme a quanto indicato
nell’art. 2, comma 1 dello stesso decreto.
●Dit apparaat voldoet aan de eisen van de richtlijnen 89/336/EEG en 73/23/
EEG, gewijzigd door 93/68/EEG.
●Este equipamento obedece às exigências das directivas 89/336/CEE e
73/23/CEE, na sua versão corrigida pela directiva 93/68/CEE.
●This equipment complies with the requirements of Directives 89/336/
EEC and 73/23/EEC as amended by 93/68/EEC.
●Dette udstyr overholder kravene i direktiv nr. 89/336/EEC og 73/23/EEC
med tillaeg nr. 93/68/EEC.
●Este equipamento obedece às exigências das directivas 89/336/CEE e 73/
23/CEE, na sua versão corrigida pela directiva 93/68/CEE.
●Dette produktet oppfyller betingelsene i direktivene 89/336/EEC og 73/23/
EEC i endringen 93/68/EEC.
●Tämä laite täyttää direktiivien 89/336/EEC ja 73/23/EEC vaatimukset, joita
on muutettu direktiivillä 93/68/EEC.
●
SISTEMA DIGITALE HOME CINEMA A 1BIT SD-AT50H
Downloaded from: http://www.usersmanualguide.com/

ii
SD-AT50H(H)_common.fm02/8/8
●Quando il tasto ON/STAND-BY si trova in posizione STAND-BY, all’interno
dell’apparecchio c’è ancora la corrente.
Se il tasto ON/STAND-BY si trova nella posizione STAND-BY, l’unitàpuò
essere accesa con il modo timer o con il telecomando.
Avvertenza:
L’apparecchio non contiene parti riparabili dall’utente.
Non togliere mai i coperchi, a meno di non essere qualificati per farlo.
All’interno dell’apparecchio ci sono tensioni pericolose, per cui si deve
sempre staccare la spina del cavo d’alimentazione dalla presa di corrente
prima di qualsiasi intervento di manutenzione e quando non si usa
l’apparecchio per un lungo periodo di tempo.
●Wanneer de ON/STAND-BY toets in de STAND-BY stand staat, loopt er
nog steeds stroom (netspanning) in het toestel.
Wanneer de ON/STAND-BY toets in de STAND-BY stand staat, kan het
toestel ingeschakeld worden via de timerfunctie of de afstandsbediening.
Waarschuwing:
Dit toestel bevat geen door de gebruiker te repareren onderdelen. Verwijder
de behuizing nooit tenzij u deskundig bent op dit gebied. In het toestel
loopt een gevaarlijke spanning; haal de stekker altijd uit het stopcontact
alvorens onderhoud uit te voeren of wanneer het toestel voor langere tijd
niet gebruikt wordt.
●Quando o botão ON/STAND-BY estiver ajustado na posição STAND-BY, a
voltagem de alimentação ainda se encontra presente dentro do aparelho.
Quando o botão ON/STAND-BY estiver ajustado na posição STAND-BY, o
aparelho pode ser colocado em operação através do modo de programação
horária ou pelo controle remoto.
Advertência:
Neste aparelho não hápartes que podem ser consertadas pelo usuário. Nunca
retire a tampa, a menos que vocêtenha qualificação para tal. Este aparelho
contém voltagens perigosas. Remova sempre o cabo de alimentação da
tomada antes de efetuar qualquer conserto ou quando deixar o aparelho muito
tempo fora de uso.
●When the ON/STAND-BY button is set at STAND-BY position, mains volt-
age is still present inside the unit.
When the ON/STAND-BY button is set at STAND-BY position, the unit may
be brought into operation by the timer mode or remote control.
Warning:
This unit contains no user serviceable parts. Never remove covers unless
qualified to do so. This unit contains dangerous voltages, always remove
mains plug from the socket before any service operation and when not
in use for a long period.
●Når ON/STAND-BY-knappen er sat i STAND-BY positionen, er der stadig
netspaending til stede i apparatet.
Når ON/STAND-BY-knappen er sat i STAND-BY position, kan apparatet
startes v.hj.a. timer-funksionen eller fjernbetjeningen.
Advarsel:
Apparatet indeholder ingen dele, der kan repareres af brugeren selv. Fjern
aldrig kabinettet med mindre De er kvalificeret hertil. Apparatet indeholder
farlig strømspaending. Traek altid stikket ud af stikkontakten før der
foretages reparationer, eller hvis apparatet ikke er i brug i laengere tid.
0111
DENNA APPARAT ÄR ANSLUTEN TILL 230 V VÄXELSTRÖM NÄR
STICKPROPPEN ÄR INSKJUTEN I VÄGGUTTAGET. FÖR ATT
FULLSTÄNDIGT KOPPLA IFRÅN APPARATEN, V.G. DRAG UT
STICKPROPPEN.
Downloaded from: http://www.usersmanualguide.com/

iii
SD-AT50H(H)_common.fm02/8/8
●Vorsicht:
Das Gerät weder Tropf- noch Spritzwasser aussetzen. Ansonsten besteht
die Gefahr eines Brandes oder elektrischen Schlages. Es sollten keine mit
Flüssigkeiten gefüllten Gegenstände wie Vasen auf dem Gerät abgestellt
werden.
●Attention:
Pour éviter un incendie ou une secousse électrique, mettre l’appareil à l’abri
d’eau (éclaboussure, goutte). Ne pas poser sur l’appareil un récipient contenant
du liquide.
●Advertencia:
Para evitar incendios y descargas eléctricas, no exponga el aparato a goteo
o salpicadura de líquidos. No deberán ponerse encima del aparato objetos
que estén llenos de líquido, como por ejemplo un florero.
●Varning:
Utsätt inte enheten för dropp eller stänk för att förhindra brand eller
elektriska stötar. Inga vätskefyllda föremål såsom vaser bör placeras
på enheten.
●Attenzione:
Per prevenire incendi o scosse elettriche, non fare gocciolare nessun liquido
sull’apparecchio e non bagnarlo. Non collocarvi sopra nessun oggetto
riempito d’acqua, come per esempio vasi.
●Waarschuwing:
Stel het toestel niet bloot aan druipend of spattend water om brand en
elektrische schokken te voorkomen. Met vloeistoffen gevulde voorwerpen,
zoals vazen, mogen niet op het toestel geplaatst worden.
●Cuidado:
Para evitar incêndio ou choque eléctrico, não exponha este aparelho a
gotejamento ou salpicamento de água. Não coloque objetos com água como,
por exemplo, um vaso de flores, em cima do aparelho.
●Warning:
To prevent fire or shock hazard, do not expose this appliance to dripping or
splashing. No objects filled with liquids, such as vases, should be placed
on the apparatus.
●Advarsel:
Til at forbygge ild og stød risiko, lad vaere med at undsaette denne indretning
for drypning eller overstaenkning. Der måikke anbringes nogen genstande
fyldt med vand, som for eksempel vaser, pådette apparat.
●Advarsel:
For åunngåbrann eller kortslutning, utsett ikke produktet for vann eller
fuktighet. Gjenstander som inneholder vaeske, feks. en blomstervase, må
ikke plasseres oppåapparatet.
●Varoitus:
Älä vie laitetta sateeseen tai kosteisiin tiloihin. Jos laite on kostunut,
anna sen kuivua ennen kuin käytät sitäverkkovirralla. Nestettäsisältäviä
astioita kuten esim. kukkamaljakoita ei saa asettaa laitteen päälle.
0110
Downloaded from: http://www.usersmanualguide.com/

iv
SD-AT50H(H)_common.fm02/8/8
Dieses Produkt ist ein Laserprodukt der Klasse 1.
Ce produit est classifié comme étant un LASER DE CLASSE 1.
Este producto está clasificado como un PRODUCTO LÁSER DE CLASE 1.
Denna produkt klassificeras som KLASS 1 LASERPRODUKT.
Questo prodotto è classificato come CLASS 1 LASER PRODUCT.
Dit product is geclassificeerd als een KLASSE 1 LASER PRODUCT.
This product is classified as a CLASS 1 LASER PRODUCT.
Este produto é classificado como PRODUTO LASER DE CLASSE 1.
Dette produktet er klassifisert som et KLASSE 1 LASERPRODUKT.
Dette produkt er klassificeret som et KLASSE 1 LASERPRODUKT.
Tämä laite on luokiteltu LUOKAN 1 LASERLAITTEEKSI.
Denna produkt klassificeras som KLASS 1 LASERAPPARAT.
●VORSICHT
Verwendung von Regelungen oder Einstellungen bzw. Durchführung von
anderen Verfahren als die hierin angegebenen kann zum Aussetzen
gefährlicher Strahlung führen.
Da der in diesem DVD-Spieler verwendete Laserstrahl für die Augen schädlich
ist, ist das Gehäuse unter keinen Umständen zu zerlegen.
Wenden Sie sich für Wartungsarbeiten nur an berechtigten Fachhändler.
●ATTENTION
Respecter les indications données relatives àla manipulation, au réglage et
au fonctionnement. En cas de non-respect, on s’exposera àune radiation
dangereuse.
Éviter absolument de démonter le lecteur DVD, qui utilise un rayon laser
nuisible aux yeux. Pour toute réparation, s’adresser àune personne qualifiée.
●PRECAUCIÓN
El uso de los controles, ajustes o ejecución de procedimientos distintos de los
especificados podría causar la exposición a radiación peligrosa.
No intente desmontar la caja ya que el haz de láser usado en este reproductor
de DVD es perjudicial para los ojos. Para el servicio de reparación, consulte a
una persona cualificada.
●OBSERVERA
Användning av reglage eller justeringar eller handhavande påannat sätt än
som anges kan leda till farlig bestrålning.
Försök inte ta isär höljet eftersom DVD spelarens laserstråle är skadlig för
ögonen. Överlåt service endast till kvalificerad personal.
●ATTENZIONE
L’uso dei comandi e l’effettuazione di regolazioni e procedimenti diversi da
quelli specificati nel manuale possono provocare una pericolosa esposizione
alle radiazioni.
Poichéil raggio laser usato in questo giradischi puòdanneggiare gli occhi,
non smontare il lettore DVD. Per le riparazioni rivolgersi a personale
specializzato.
●LET OP
Gebruik van regelaars, het maken van instellingen, gebruik of handelingen
anders dan in deze gebruiksaanwijzing vermeld, kan gevaarlijke straling
blootleggen.
De laserstraal in deze DVD-speler kan de ogen beschadigen, Probeer derhalve
de ombouw niet te verwijderen. Laat reparaties alleen over aan erkend
onderhoudspersoneel.
●CUIDADO
O uso de controles, ajustes ou a execução de procedimentos além daqueles
especificados aqui pode resultar em perigosa exposição àradiação.
Como os raios laser usados neste aparelho de DVD são perigosos para os
olhos, não tente desmontar o aparelho. Solicite o conserto somente para
pessoas especializadas.
●CAUTION
Use of controls, adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
As the laser beam used in this DVD player is harmful to the eyes, do not
attempt to disassemble the cabinet. Refer servicing to qualified personnel
only.
0110
Downloaded from: http://www.usersmanualguide.com/

v
SD-AT50H(H)_common.fm02/8/8
Eigenschaften der Laserdiode
Material: AIGaAs/InGaAIP
Wellenlänge: 780 nm/650 nm
Emissionsdauer: kontinuierlich
Laser-Ausgang: max. 0,69 mW
Caractéristiques de la diode laser
Matière: AIGaAs/InGaAIP
Longueur d’onde: 780 nm/650 nm
Durée d’émission: ininterrompue
Puissance de sortie
laser maximale: 0,69 mW
Características del diodo láser
Material: AIGaAs/InGaAIP
Longitud de onda: 780 nm/650 nm
Duración de emisión : continua
Salida de láser: máx. 0,69 mW
Laserdiodens egenskaper
Material: AIGaAs/InGaAIP
Våglängd: 780 nm/650 nm
Utstrålningsvaraktighet: kontinuerlig
Lasereffekt: max. 0,69 mW
Proprietà del diodo laser
Materiale: AIGaAs/InGaAIP
Lunghezza d’onda: 780 nm/650 nm
Durata di emissione: continua
Uscita massima del laser: 0,69 mW
Laser diode specificaties
Materiaal: AIGaAs/InGaAIP
Golflengte: 780 nm/650 nm
Stralingsduur: doorlopend
Laseruitgang: max. 0,69 mW
Propriedades do diodo de laser
Material: AlGaAs/InGaAIP
Comprimento de onda: 780 nm/650 nm
Duração da emissão: contínua
Saída de laser: máx. 0,69 mW
Laser Diode Properties
Material: AIGaAs/InGaAIP
Wavelength: 780 nm/650 nm
Emission Duration: continuous
Laser Output: max. 0.69 mW 0110
ADVERSEL-SYNLIG OG USYNLIG LASERSTRÅLING VED ÅBNING. SE IKKE IND I
STRÅLEN-HELLER IKKE MED OPTISKE INSTRUMENTER.
VARO! AVATTAESSA OLET ALTTIINA NÄKYVÄLLE JA NÄKYMÄTTÖMÄLLE
LASERSÄTEILYLLE ÄLÄ TUIJOTA SÄTEESEEN ÄLÄKÄ KATSO SITÄ OPTISEN
LAITTEEN LÄPI.
VARNING-SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR
ÖPPNAD. STIRRA EJ IN I STRÅLEN OCH BETRAKTA EJ STRÅLEN GENOM
OPTISKT INSTRUMENT.
0110
VAROITUS! LAITTEEN KÄYTTÄMINEN MUULLA KUIN TÄSSÄ
KÄYTTÖOHJEESSA MAINITULLA TAVALLA SAATTAA ALTISTAA
KÄYTTÄJÄN TURVALLISUUSLUOKAN 1 YLITTÄVÄLLE NÄKYVÄLLE JA
NÄKYMÄTTÖMÄLLE
LASERSÄTEILYLLE.
VARNING - OM APPARATEN ANVÄNDS PÅANNAT SÄTT ÄN I DENNA
BRUKSANVISNING SPECIFICERAS. KAN ANVÄNDAREN UTSÄTTAS FÖR
SYNLIG OCH OSYNLIG LASERSTRÅLNING, SOM ÖVERSKRIDER GRÄNSEN
FÖR LASERKLASS 1.
Downloaded from: http://www.usersmanualguide.com/

vi
SD-AT50H(H)_common.fm02/8/8
● In Lizenz von Digital Theater Systems, Inc. hergestellt. US Pat. Nr. 5,451,942,
5,956,674, 5,974,380, 5,978,762 und andere, ausgegebene und
schwebende, weltweite Patente. “DTS”und “DTS Digital Surround”sind
eingetragene Warenzeichen der Digital Theater Systems, Inc. Copyright
1996, 2000 Digital Theater Systems, Inc. Alle Rechte vorbehalten.
●Fabriqué, sous licence de Digital Theater Systems, Inc. Les brevets US
Pat. No. 5,451,942, 5,956,674, 5,974,380, 5,978,762 et autres internationaux
délivrés et demandés. “DTS”et “DTS Digital Surround”sont des marques
déposées de Digital Theater Systems, Inc. Copyright 1996, 2000 Digital
Theater Systems. Tous droits réservés.
●Fabricado con licencia de Digital Theater Systems, Inc. Patentes de
EE.UU.N.o5,451,942, 5,956,674, 5,974,380, 5,978,762 y otras patentes
mundiales emitidas y pendientes. “DTS”y “DTS Digital Surround”son
marcas registradas de Digital Theater Systems, Inc. Copyright 1996, 2000
Digital Theater Systems, Inc. Todos los derechos reservados.
●Tillverkad under licens från Digital Theater Systems, Inc. US Pat. No.
5,451,942, 5,956,674, 5,974,380, 5,978,762 och andra världspatent utgivna
och oavgjorda. “DTS”och “DTS Digtal Surround” är registrerade varumärken
för Digital Theater Systems, Inc. Copyright 1996, 2000 Digital Theater Sys-
tems, Inc. Alla rättigheter förbehållna.
●Costruito su licenza della Digital Theater Systems, lnc. US Pat. No.
5,451,942, 5,956,674, 5,974,380, 5,978,762 e brevetti giàconcessi o in
attesa di esserlo di altri Paesi. “DTS”e “DTS Digital Surround”sono marchi
di fabbrica registrati della Digital Theater Systems, Inc. Copyright 1996,
2000 Digital Theater Systems, Inc. Tutti i diritti riservati.
●Gefabriceerd onder licentie van Digital Theater Systems, lnc. US
patentnummer 5,451,942, 5,956,674, 5,974,380, 5,978,762 en andere
wereldwijde patenten verstrekt en aangevraagd. “DTS”en ”DTS Digital
Surround”zijn geregistreerde handelsmerken van Digital Theater Systems,
lnc. Copyright 1996, 2000 Digital Theater Systems, lnc. Alle rechten
voorbehouden.
●Produzido sob licença da Digital Theater Systems, Inc. Patente nos Estados
Unidos Nº5,451,942, 5,956,674, 5,974,380, 5,978,762 e outras patentes
ao redor do mundo emitidas e pendentes. “DTS”e “DTS”Digital Surround”
são marcas comerciais registradas da Digital Theater Systems, Inc. Direitos
autorais 1996, 2000 Digital Theater Systems, Inc. Todos os direitos
reservados.
●Manufactured under license from Digital Theater Systems, Inc. US Pat. No.
5,451,942, 5,956,674, 5,974,380, 5,978,762 and other world-wide patents
issued and pending. “DTS”and “DTS Digital Surround”are registered trade-
marks of Digital Theater Systems, Inc. Copyright 1996, 2000 Digital The-
ater Systems, Inc. All Rights Reserved.
●ln Lizenz von Dolby Laboratories hergestellt. “Dolby”, “Pro Logic”und
das Doppel-D-Symbol sind Warenzeichen der Dolby Laboratories.
Vertrauliche, unveröffentlichte Schriften. © 1992-1999 Dolby Laborato-
ries. Alle Rechte vorbehalten.
●Fabriquésous licence de Dolby Laboratories. «Dolby», «Pro Logic»et le symbole
double D sont des marques de commerce de Dolby Laboratories. Œuvres
confidentielles non publiées. © 1992-1999 Dolby Laboratories. Tous droits
réservés.
●Fabricado bajo licencia de Dolby Laboratories. “Dolby”, “Pro Logic”y el
símbolo con una doble D son marcas registradas de Dolby Laboratories.
Trabajos confidenciales no publicados. © 1992-1999 por Dolby Laborato-
ries. Todos los derechos queden reservados.
●Tillverkad påDolby Laboratories licens. “Dolby”, “Pro Logic”och dubbel-
D-symbol är varumärken som tillhör Dolby Laboratories. Konfidentiella
opublicerade arbeten. © 1992-1999 Dolby Laboratories. Alla rättigheter
förbehålls.
●Prodotto sotto licenza dalla Dolby Laboratories. “Dolby”, “Pro Logic”ed il
simbolo doppia D sono marchi registrati della Dolby Laboratories. Lavori
non pubblicati riservati. © 1992-1999 Dolby Laboratories. Tutti i diritti sono
riservati.
●Vervaardigd in licentie van Dolby Laboratories. “Dolby”, “Pro Logic”en het
dubbel D-symbool zijn handelsmerken van Dolby Laboratories. Vertrouwelijk
ongepubliceerd materiaal. © 1992-1999 Dolby Laboratories. Alle rechten
voorbehouden.
●Fabricado sob licença da Dolby Laboratories. “Dolby,” “Pro Logic”e o
símbolo do “D” duplo são marcas registradas da Dolby Laboratories.
Trabalhos inéditos confidenciais. © 1992-1999 Dolby Laboratories. Todos
os direitos reservados.
●Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic”
and the double-D symbol are trademarks of Dolby Laboratories. Confiden-
tial unpublished works. © 1992-1999 Dolby Laboratories. All rights reserved.
0208
Downloaded from: http://www.usersmanualguide.com/

E-1
02/8/28 SD-AT50H(H)E1.fm
SD-AT50H
ENGLISH
DX-AT50H
ENGLISH
General Information
- Introduction / Contents -
Introduction
Contents
Page
!General Information
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Description of discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5, 6
Controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 10
!Preparation for Use
System connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11, 12
Aerial connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
TV connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 - 15
System installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 16
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
General control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Changing the initial setting of DVD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 - 22
Language code list for disc language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
!Basic Operation
Listening to the radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Listening to the memorised station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Playing a disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27, 28
Page
!Advanced Disc Features
Basic operation
To locate the beginning of a chapter (track) (skip) . . . . . . . . . . . . . . . . . . . . . . 29
Fast forward/Fast reverse (search) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
To start playback from the desired point (direct play) . . . . . . . . . . . . . . . . . . . 30
Still picture/Frame advance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Slow-motion play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Useful features
To play in random order (random play) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
To play in the desired order (programmed playback) . . . . . . . . . . . . . . . . . . . . 31
To play repeatedly (repeat play) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
To play the contents between the specified points repeatedly (A-B repeat) . 32
To select a title from the top menu of the disc . . . . . . . . . . . . . . . . . . . . . . . . . 32
MP3 disc operation
MP3 disc playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Various settings
To change the subtitle language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
To change the audio language (audio output) . . . . . . . . . . . . . . . . . . . . . . . . . . 34
To select a subtitle or audio language from the disc menu . . . . . . . . . . . . . . . 34
To brighten an image (black level setting) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
To change the angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
To zoom in on an image (zoom) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
To change the display on TV screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
DVD mode operation indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Thank you for purchasing this SHARP product. To obtain the best performance from
this product, please read this manual carefully. It will guide you in operating your
SHARP product.
"SD-AT50H 1-Bit Digital Home Cinema and DX-AT50H DVD Player should be com-
bined for use.
"The SD-AT50H system includes an AV control unit, a subwoofer/amplifier unit, two
front speakers, two surround speakers and a centre speaker.
"DX-AT50H should be used exclusively with SD-AT50H. All accessories are pack-
aged in SD-AT50H.
The remote control works for both products.
Refer to this operation manual for DX-AT50H operations.
Downloaded from: http://www.usersmanualguide.com/

E-2
SD-AT50H(H)E1.fm02/8/28
SD-AT50H
ENGLISH
8
DX-AT50H
General Information
- Contents -
Page
!Advanced Features
Enjoying surround sound (sound mode) . . . . . . . . . . . . . . . . . . . . . . . . . . 37 - 39
Changing the registration in the remote control . . . . . . . . . . . . . . . . . . . . . . . .40
Speaker settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41, 42
Using the Radio Data System (RDS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 - 46
Timer and sleep operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 - 49
Audio connection of other equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Operating the connected TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
!References
Error indicators and warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Troubleshooting chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53, 54
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55, 56
Copyright Information:
"Unauthorised copying, broadcast, public display, transmission, public perfor-
mance and rental (regardless of whether or not such activities are for profit) of disc
contents are prohibited by law.
"This system is equipped with copy protection technology that causes substantial
degradation of images when the contents of a disc are copied to a videotape.
"This system is protected by U. S. patents and other intellectual property rights, the
copyright for which belongs to Macrovision Corporation. The use of Macrovision's
copy protection technology in the system is authorised by Macrovision and is
intended for home use only, unless otherwise authorised in writing by Macrovision.
Reverse engineering or disassembly is prohibited.
!Types of playable discs
The DVD player can play back discs bearing any of the following marks:
"For unplayable discs, see page 5.
Icons used in this operation manual
Some functions may not be available depending on discs. The following icons indicate
the discs that can be used in the section.
... Indicates DVDs.
... Indicates audio CDs.
... Indicates CD-R/RW with MP3 recording.
"Some operations may not be performed depending on discs even if they are de-
scribed in this manual.
"During operation, " " may be displayed on the screen. This means that the opera-
tions described in this manual are prohibited by the disc.
Disc type Disc contents Disc size
DVD Video Disc (*1) Audio and video (movies) 12 cm (5")
8 cm (3")
Or DVD-R/DVD-RW record-
ed in video mode (*2)
Audio CD Audio 12 cm (5")
8 cm (3")
Or CDV (*3)
Audio CD-R/CD-RW (*4) Audio 12 cm (5")
8 cm (3")
Or CD-R/CD-RW recorded
in MP3 format (*5)
(*1): This DVD player adopts the PAL system. However, it can also play back
NTSC discs as DVD-region 2 using the modified PAL system.
(*2): The DVD-R/DVD-RW may not be played back due to properties and scratch-
es of the disc, dirty optical pickup lens, etc.
(*3): Only the audio on the CDV can be played.
(*4): The CD-R/CD-RW may not be played back properly depending on the record-
ing equipment or the disc.
(*5): If the sampling frequency is 44.1 or 48.1 kHz and the fixed bit rate is 128 kbps
or higher, MPEG 1 Audio Layer3 (MP3) files can be played. However, some
of them may not be played depending on their conditions or formats.
Downloaded from: http://www.usersmanualguide.com/

E-3
SD-AT50H(H)E1_2.fm02/9/9
SD-AT50H
ENGLISH
DX-AT50H
General Information
- Accessories -
Accessories
Please confirm that the following accessories are included.
Note:
Only the above accessories are included.
Remote control 1 "AA" size battery (UM/SUM-3,
R6, HP-7 or similar) 2
AC power lead 1 Video cable 1 Digital audio cable 1
FM aerial 1 AM loop aerial 1 Stand 2 Antislip speaker cushion sheet
(20 pcs.) 1
SCART adaptor 2 (IN/OUT)
System connection cable 3 Speaker connection lead 5
Yellow Orange
IN
OUT
(For signal/power)
(For DVD player)
(For sound)
Blue
Black
White
approx. 15 m (45 feet) approx. 15 m (45 feet)
approx. 5 m
(15 feet)
approx. 5 m
(15 feet)
approx. 5 m
(15 feet)
Red
Green
Blue Grey
Downloaded from: http://www.usersmanualguide.com/

E-4
SD-AT50H(H)E1.fm02/8/28
SD-AT50H
ENGLISH
8
DX-AT50H
General Information
- Precautions -
Precautions
!General
"Please ensure that the subwoofer/amplifier unit is positioned in a well-ventilated
area and that there is at least 10 cm (4") of free space along the sides and back.
There must also be a minimum of 15 cm (6") of free space on the top of the sub-
woofer/amplifier unit.
"Use the system on a firm, level surface free from vibration.
"Keep the system away from direct sunlight, strong magnetic fields, excessive dust,
humidity and electronic/electrical equipment (home computers, facsimiles, etc.)
which generate electrical noise.
"Do not place anything on top of the components.
"Do not expose the system to moisture, to temperatures higher than 60°C (140°F)
or to extremely low temperatures.
"If the system does not work properly, unplug and plug it in again. Then turn on the
system.
"In case of an electrical storm, unplug the DVD player and the subwoofer/amplifier
unit for safety.
"Hold the AC power plug by the head when removing it from the wall socket, as
pulling the lead can damage internal wires.
"Do not remove the outer cover, as this may result in electric shock. Refer
internal service to your local SHARP service facility.
"The ventilation should not be impeded by covering the ventilation openings with
items, such as newspapers, tablecloths, curtains, etc.
"Attention should be drawn to the environmental aspects of battery disposal.
"The system is designed for use in moderate climate.
"This system should only be used within the range of 5°C - 35°C (41°F - 95°F).
Warning:
The voltage used must be the same as that specified by this system. Using this prod-
uct with a higher voltage other than that specified is dangerous and may result in a
fire or other types of accident, causing damage. SHARP will not be held responsible
for any damage resulting from the use of this system with a voltage other than that
specified.
Caution:
"The DVD player and the subwoofer/amplifier unit will get warm whilst being used.
Do not touch warm areas of the DVD player and the subwoofer/amplifier unit for
prolonged periods to avoid damage to you.
"This system is equipped with a special function which protects the amplifier circuit
from damages. When it is activated, the sound switch is turned off. In this case,
set the DVD player and the AV control unit to the stand-by mode and turn them on
again.
!Volume control
The sound level at a given volume setting depends on speaker efficiency, location
and various other factors. It is advisable to avoid exposure to high volume levels,
which occur whilst turning the system on with the volume control setting up high, or
whilst continually listening at high volumes.
!Care of DVD/CD discs
DVD/CD discs are fairly resistant to damage, however mistracking can occur due to
an accumulation of dirt on the disc surface. Follow the guidelines below for maximum
enjoyment from your DVD/CD collection and player.
"Do not write on either side of the disc, particularly the non-label side from which
signals are read. Do not mark this surface.
"Keep your discs away from direct sunlight, heat, and excessive moisture.
"Always hold the DVD/CDs by the edges. Fingerprints, dirt, or water on the DVD/
CDs can cause noise or mistracking. If a DVD/CD is dirty or does not play prop-
erly, clean it with a soft, dry cloth, wiping straight out from the centre, along the
radius.
10 cm (4") 10 cm (4")
15 cm (6")
10 cm (4")
"This subwoofer/amplifier unit is fitted with a cooling
fan at the rear for improved cooling. Do not cover the
opening in this section with any obstacles.
Cooling fan
NO YES
Correct
Downloaded from: http://www.usersmanualguide.com/

E-5
SD-AT50H(H)E1.fm02/8/28
SD-AT50H
ENGLISH
DX-AT50H
General Information
- Description of discs -
Description of discs
!Discs that cannot be played
"The discs above cannot be played at all, or no sound is heard although images
appear on the screen or vice versa.
"Faulty playback may damage the speakers and can have an adverse effect on
your hearing when played at high volume settings.
"This DVD player adopts the PAL system. Check the recording system before
purchasing discs.
"You cannot play illegally produced discs.
Notes:
"A disc that has scratches or fingerprints on it may not play properly. Refer to "Care
of DVD/CD discs (page 4)" and clean the disc.
"Do not play the discs of special shapes (heart or octagon shaped) as they can be
ejected whilst rotating and cause injury.
!Title, chapter and track
DVDs are divided into "titles" and "chapters". If the disc has more than one movie on
it, each movie is a separate "title". "Chapters" are subdivisions of titles.
The audio CDs consist of "tracks".
A "track" is each tune on an audio CD.
Note:
Title, chapter, or track numbers may not be recorded on some discs.
!Icons used on DVD discs
Check the icons of the DVD case before playing your discs.
"DVDswithouttheregionnumber"2" or
"ALL". "CDG
"Video CD
"DVDs with SECAM system "Photo CD
"DVD-ROM "CD-ROM
"DVD-RAM "SACD
"DVD-Audio "Discs recorded in special formats, etc.
Chapter 1
Title 1 Title 2
Chapter 2 Chapter 3 Chapter 1 Chapter 2
Track 1 Track 2 Track 3 Track 4 Track 5
Display Description
Region number (playable area number) DVD discs are programmed with region
numbers indicating countries in which
they can be played.This system can play
discs with region number "2" or "ALL".
Format recorded on the DVD To adopt the video format to the connect-
ed TVs ("wide-screen TV" or "4:3 size
TV").
Recorded in 4:3.
You can enjoy wide images on a wide-screen TV, and letterbox size
images on the 4:3 size TV.
You can enjoy wide images on a wide-screen TV, and sides-cut 4:3
images on the 4:3 size TV.
Type of subtitles recorded Recorded subtitle languages.
Example: A desired language can be selected with
the SUB TITLE button.
1: English
2: Japanese
Number of camera angles Number of angles recorded on the DVD.
A desired angle can be selected with the
ANGLE button.
Number of audio track and audio
recording system The number of audio tracks and audio re-
cording system are indicated.
Example:
1: Original <English>
(DTS 5.1 Surround)
"The audio recorded on the DVD can
be switched by using the AUDIO but-
ton.
"Audio and recording system vary de-
pending on the DVD. Check them in
the DVD's manual.
2: Japanese (Dolby Digi-
tal 5.1 Surround)
226
1
ALL
2
2
Downloaded from: http://www.usersmanualguide.com/

E-6
SD-AT50H(H)E1.fm02/8/28
SD-AT50H
ENGLISH
8
DX-AT50H
General Information
- Description of discs -
The list below shows the countries covered by region number 2.
* represents area name.
Common names Names of nations and areas
Albania Republic of Albania
Andorra Principality of Andorra
Austria Republic of Austria
Bahrain State of Bahrain
Belgium Kingdom of Belgium
Bosnia and Herzegovina Bosnia and Herzegovina
Bulgaria Republic of Bulgaria
Channel Islands *Channel Islands
Croatia Republic of Croatia
Cyprus Republic of Cyprus
Czech The Czech Republic
Denmark Kingdom of Denmark
Egypt Arab Republic of Egypt
Faeroe Islands *Faeroe Islands
Finland Republic of Finland
France French Republic
Germany Federal Republic of Germany
Gibraltar *Gibraltar
Greece Hellenic Republic
Greenland *Greenland
Hungary Republic of Hungary
Iceland Republic of Iceland
Iran Islamic Republic of Iran
Iraq Republic of Iraq
Ireland Ireland
Isle of Man *Isle of Man
Israel State of Israel
Italy Italian Republic
Japan Japan
Jordan Hashemite Kingdom of Jordan
Kuwait State of Kuwait
Common names Names of nations and areas
Lebanon Republic of Lebanon
Lesotho Kingdom of Lesotho
Liechtenstein Principality of Liechtenstein
Luxembourg Grand Duchy of Luxembourg
Macedonia Republic of Macedonia
Malta Republic of Malta
Monaco Principality of Monaco
Netherlands Kingdom of the Netherlands
Norway Kingdom of Norway
Oman Sultanate of Oman
Poland Republic of Poland
Portugal Portuguese Republic
Qatar State of Qatar
Romania Romania
San Marino Republic of San Marino
Saudi Arabia Kingdom of Saudi Arabia
Slovakia The Slovak Republic
Slovenia Republic of Slovenia
South Africa Republic of South Africa
Spain Kingdom of Spain
Svalbard and Jan Mayen Islands *Svalbard and Jan Mayen Islands
Swaziland Kingdom of Swaziland
Sweden Kingdom of Sweden
Switzerland Swiss Confederation
Syrian Arab Republic Syrian Arab Republic
Turkey Republic of Turkey
United Arab Emirates United Arab Emirates
United Kingdom United Kingdom of Great Britain and North-
em Ireland
Vatican City State State of the City of Vatican
Yemen Republic of Yemen
Yugoslavia Federal Republic of Yugoslavia
Downloaded from: http://www.usersmanualguide.com/

E-7
SD-AT50H(H)E1.fm02/8/28
SD-AT50H
ENGLISH
DX-AT50H
General Information
- Controls and indicators -
Controls and indicators
!AV control unit
1. RDS Indicator
2. Radio Text Indicator
3. Traffic Programme Indicator
4. Traffic Announcement Indicator
5. Dynamic PTY Indicator
6. Audio Signal Indicators/Speaker Indicators
7. Timer Play Indicator
8. Sleep Indicator
9. FM stereo mode indicator
10.FM Stereo Receiving Indicator
Reference page
11.On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18, 54
12.Timer Set Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
13.Function Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25, 27, 51
14.Digital/Analog Input Select or Tuner Band Select Button . . . .25, 51
15.Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
16.Remote Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
17.Power Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
18.Sound Mode Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38, 39
19.Headphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
20.System Connection Socket (to DVD player) . . . . . . . . . . . . . . . . . .11
21.Audio Digital Input Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
22.Coaxial Digital Audio Input Socket . . . . . . . . . . . . . . . . . . . . . . . . .11
23.Audio Input Sockets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11, 15, 50
24.System Connection Sockets (to subwoofer/amplifier unit) . . . . . .11
25.AM Loop Aerial Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
26.Aerial Earth Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
27.FM 75 Ohms Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Display
Front
Back
12 13 14 15
16 18 19
1
7
8
9
32 4 5 6
(1)
(7) (8)
(2) (3) (4) (5) (6)
(9) (
10 )( 11 )( 12 )( 13 )
20 21 22 23 25 26 27
24
17
11
10
MODEL NO. SD-AT50H
(AV CONTROL UNIT)
1-BIT DIGITAL HOME CINEMA
SHARP CORPORATION
MADE IN MALAYSIA
<The bottom of the unit>
(1) Left Front Speaker Indicator (8) Subwoofer Indicator
(2) Front Left Signal Indicator (9) Left Surround Speaker Indicator
(3) Centre Speaker Indicator (10) Surround Left Signal Indicator
(4) Centre Signal Indicator (11) Surround Monaural Signal
Indicator
(5) Front Right Signal Indicator (12) Surround Right Signal Indicator
(6) Right Front Speaker Indicator (13) Right Surround Speaker Indicator
(7) Low Frequency Effect Indicator
Downloaded from: http://www.usersmanualguide.com/

E-8
SD-AT50H(H)E1.fm02/8/28
SD-AT50H
ENGLISH
8
DX-AT50H
General Information
- Controls and indicators -
!Subwoofer/amplifier unit
Reference page
1. Subwoofer
2. Bass Reflex Duct
3. System Connection Socket (to AV control unit) . . . . . . . . . . . . . . 11
4. Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5. System Connection Socket (to AV control unit) . . . . . . . . . . . . . . 11
6. AC Power Input Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
7. Lead Holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
!Satellite speaker 5
Front speaker 2: magnetically shielded
Centre speaker 1: magnetically shielded
Surround speaker 2: magnetically shielded
Reference page
1. Speaker
2. Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3. Mounting Holes for Stand or Bracket (Optionally available) . . . . 16
Using antislip speaker cushions:
You can install satellite speakers either vertically or horizontally.
Affix the cushions (supplied) to the bottom of the speakers to prevent them from slid-
ing or falling due to vibration.
A sheet of speaker cushions (20 pcs.) is supplied with this product. Use 4 cushions
per speaker.
3
4
5
6
7
21
12
3
Front Back Bottom
Side
(Vertical position) (Horizontal position)
Downloaded from: http://www.usersmanualguide.com/

E-9
SD-AT50H(H)E1.fm02/8/28
SD-AT50H
ENGLISH
DX-AT50H
General Information
- Controls and indicators -
Controls and indicators (continued)
!DVD player
1.CD Indicator
2.DVD Indicator
3.CD/MP3 Disc Random Play Indicator
4.Disc Repeat or Disc A - B Repeat Indicator
5.DVD Title Indicator
6.Disc Play Indicator
7.Disc Pause Indicator
8.CD/MP3 Disc Track Indicator
9.DVD Chapter Indicator Reference page
10.On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
11.DVD Chapter Skip or CD/MP3 Disc Track Down Button . . . . .29, 33
12.DVD Chapter Skip or CD/MP3 Disc Track Up Button . . . . . . . .29, 33
13.Disc Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
14.Disc Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27, 28
15.Disc Tray Open/Close Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
16.Disc Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
17.System Connection Socket (to AV control unit) . . . . . . . . . . . . . . .11
18.Audio Output Sockets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
19.Coaxial Digital Audio Output Socket . . . . . . . . . . . . . . . . . . . . . . . .11
20.Video Output Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
21.S-video Output Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
22.Component Video Output Sockets . . . . . . . . . . . . . . . . . . . . . . . . .14
23.AC Power Lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
1110 12 13 14 15
16
17 18 19 20 2221
123 4
5
6
7
8
9
MODEL NO. DX-AT50H
DVD PLAYER
230 V ~ 50 Hz 15 W
SERIAL NO.
SHARP CORPORATION
MADE IN CHINA
23
Display
Front
<The bottom of the unit>
Back
Downloaded from: http://www.usersmanualguide.com/

E-10
SD-AT50H(H)E1.fm02/8/28
SD-AT50H
ENGLISH
8
DX-AT50H
General Information
- Controls and indicators -
!Remote control Reference page
1.Remote Control Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
2.Display Brightness Select or Clock Display Button . . . . . . . . . . . . . . . .18, 24
3.TV Display Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
4.Direct Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
5.Direct Number Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26, 30, 40
6.Disc Repeat Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
7.Disc A - B Repeat Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
8.DVD Menu Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
9.Cursor Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24, 33, 47
10.Disc Fast Reverse, Tuner Preset Down Button . . . . . . . . . . . . . . . . . . . .26, 29
11.Disc Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
12.DVD Chapter Skip, CD/MP3 Disc Track Down or
Tuning Down Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25, 29, 33
13.DVD Top Menu Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
14.Digital/Analog Input Select or Tuner Band Select Button . . . . . . . . . . . . . .25, 51
15.Timer Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
16.Sound Mode Select Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
17.Dynamic Sound Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
18.TV Input Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
19.Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
20.On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
21.RDS Display Mode Select or DVD Audio Language Select or
CD Audio Output Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34, 43
22.RDS Programme Type/Traffic Information Search or
DVD Angle Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35, 46
23.RDS ASPM (Auto Station Programme Memory) or
DVD Subtitle Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34, 45
24.Clear Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26, 30
25.DVD Initial Setting Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
26.Amplifier Initial Setting Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
27.CD/MP3 Disc Play Mode Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
28.Return Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19, 31, 42
29.Enter Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24, 33, 47
30.Disc Fast Forward, Tuner Preset Up Button . . . . . . . . . . . . . . . . . . . . . .26, 29
31.DVD Chapter Skip, CD/MP3 Disc Track Up or Tuning Up Button . .25, 29, 33
32.Disc Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27, 28
33.Function Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25, 27, 51
34.DVD Frame Advance, Disc Pause Button . . . . . . . . . . . . . . . . . . . . . . . .28, 30
35.TV On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
36.DVD Zoom Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
37.Black Level Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
38.TV Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
39.TV Channel Select Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
13
12
1
2
3
4
5
6
8
7
9
10
14
15
16
17
18
19
20
22
21
23
24
25
27
28
29
30
31
32
33
34
35
36
37
38
39
26
11
Buttons with " " mark in the illustration can be operated on the remote control only.
Downloaded from: http://www.usersmanualguide.com/

E-11
SD-AT50H(H)E2.fm02/8/28
SD-AT50H
ENGLISH
DX-AT50H
Preparation for Use
- System connections -
System connections
!Connecting the components
Connect the DVD player, AV control unit and subwoofer/amplifier unit as follows.
Caution:
"Make sure to connect the system after unplugging the DVD player and the sub-
woofer/amplifier unit.
"Put the 2 system connection cables (for sound and signal/power) together. If not,
noises may be heard.
To unplug the system connection cable:
AM loop aerial
DVD player
AV control unit
Subwoofer/amplifier unit
System
connection cable
(For DVD
player)
System
connection cable
(For sound, black)
Arrow upward
Closer
Closer
Arrow to the left
System
connection cable
(For signal/power,
blue)
FM aerial
Digital audio cable
Connect either a digital audio cable or commercially available RCA lead. Press the
DIGITAL/ANALOG button to switch between digital and analogue signals accord-
ing to the connection.
AV control unit
Connecting components Lead
AV control unit
AV control unit
AV control unit
AV control unit
DVD player
System connection cable
(For sound, black)
System connection cable
(For signal/power, blue)
Digital audio cable
(For digital signal)
Commercially available
RCA lead
(For analog signal)
System connection cable
(For DVD player)
DVD player
DVD player
Subwoofer/
amplifier unit
Subwoofer/
amplifier unit
1
2
Push
Unplug
Downloaded from: http://www.usersmanualguide.com/

E-12
SD-AT50H(H)E2.fm02/8/28
SD-AT50H
ENGLISH
8
DX-AT50H
Preparation for Use
- System connections -
!Connecting the satellite speakers
Insert the speaker plugs to the subwoofer/amplifier unit according to the colour cod-
ing.
Connect the speaker leads to the satellite speakers first and then to the sub-
woofer/amplifier unit.
Caution:
"Make sure to connect the speakers after unplugging the DVD player and the sub-
woofer/amplifier unit.
"Insert the speaker plug fully with the rising side facing to the left.
"Hold the speaker plug when removing it from the subwoofer/amplifier unit. Pulling
the lead may cause malfunction to the subwoofer/amplifier unit.
"Do not mistake the and , and right and left terminals of the speaker leads. (The
right speaker is placed on the right when you face the system. See page 16.)
"Only the supplied speakers should be used with this product.
"Do not stand or sit on the speakers. You may be injured.
Binding leads:
Tie the leads connected to the subwoofer/amplifier unit with a lead holder.
"All satellite speakers provide the same performance.
Their positions can be exchanged with one another.
Red Red Red
Red
Red Red
Red
Grey
Grey
Black Black
Black BlackBlack
Green
Green
Blue
Blue
White
White
Front speaker
(Right)
Surround speaker
(Right) Surround speaker (Left)
Centre speaker
Subwoofer/
amplifier unit
Front speaker
(Left)
"Never short-circuit the speaker leads. If the
speaker leads are short-circuited, the protec-
tion circuit is activated and the system enters
the stand-by mode. In such a case, check that
the leads are properly connected before turn-
ing the power on again.
Tube
Red
Black
Label
Speaker terminals
(Satellite speaker) (Subwoofer/amplifier unit)
Speaker plug
Plug in with the rising
side facing to the left.
Lead holder
Downloaded from: http://www.usersmanualguide.com/

E-13
SD-AT50H(H)E2.fm02/8/28
SD-AT50H
ENGLISH
DX-AT50H
Preparation for Use
- Aerial connection / TV connection -
Aerial connection
Notes:
"Placing the aerial on the system or near the AC power lead may cause noise
pickup. Place the aerial away from the system for better reception.
"When static is still heard even after adjusting the position of the AM loop aerial, try
reversing the wire connections.
Installing the AM loop aerial:
External FM or AM aerial:
Use an external FM or AM aerial if you require better reception. Consult your dealer.
Note:
When using an external AM aerial, be sure to keep the wire of the AM loop aerial
connected.
TV connection
Caution:
"Before connecting the TV, turn off all the equipment.
"The TV screen display may be scrambled if not PAL system.
Three types of sockets [VIDEO OUT (VIDEO), VIDEO OUT (S-VIDEO) and COMPO-
NENT VIDEO OUT] are available for TV and DVD player connection.
Connect according to your TV.
!Connecting to a TV with a video input
socket
You can enjoy DVD images by connecting your TV and the DVD player with a video
cable.
Notes:
"Change the TV input in accordance with the connected socket.
"Do not connect other equipment between the TV and the DVD player. If they are
connected via a VCR, pictures may be distorted.
Supplied FM aerial:
Connect the FM aerial wire to the FM 75 OHMS
socket and position the FM aerial wire in the di-
rection where the strongest signal can be re-
ceived.
Supplied AM loop aerial:
Connect the AM loop aerial wire to the AM and
GND terminals. Position the AM loop aerial for
optimum reception. Place the AM loop aerial on
a shelf, etc., or attach it to a stand or a wall with
screws (not supplied).
< Assembling > < Attaching to the wall >
Wall Screws (not supplied)
White Black
External
FM aerial External
AM aerial
15 m (49 feet )
7.5 m (25 feet )
Earth rod
Earth wire
AM loop aerial
Video cable
(supplied)
To video output socket
To video input
socket
TV
Downloaded from: http://www.usersmanualguide.com/
